ADJUSTMENT.
1 2 3 4 5 6
1 2 3 4 5 6
1 2 3 4 5 6
1 2 3 4 5 6
1 2 3 4 5 6
Set-Up Procedure
Before adjusting
1 Installation of the projector.
• This projector is pre-adjusted at the factory for 100 inch screen front projection at 12.4˚ for XG75A and 12.2˚ for
XG135LC/XG110LC, and ceiling mounting. If your application is the same as the factory setting, you will not have to
reconfigure the projector for your application. However, if you want to do some fine or further adjustments, carry out
the following adjustments.
2 Connect the external equipment to the projector.
3 Turn on power to the external equipment and the projector.
• If you want to institute the use of a passcode, register the passcode. See page 59.
• Carry out the adjustments after displaying an image for 20 minutes or more.
4 Select the input signal.
• If your input signal has not been recorded, it is necessary to perform the signal entry beforehand. See page 19.
If you want to use the projector in any other configuration than the factory setting, perform the following after installation.
1) Electrical Focus Adjustment
2) Alignment Adjustment
3) Static Convergence Adjustment
4) Dynamic Convergence Adjustment
5) Color temperature & White Balance Adjustment
6) R, G, B Gain Adjustment
(only when used with the ISS-6020/ISS-6020G)
*If a wrong button is pressed accidently, an error message will appear.
*Pressing the HELP button will display a brief description of the
selected function and button operation instructions.
See page 37
See page 41
See page 47
See page 48
See page 57
See page 58
36
Check and adjust again
if necessary
