REFERENCE ADJUSTMENT
Astig Adjustment
This feature allows you to adjust the beam shape.
Proceed as follows:
1 Press and hold the CTL button then press the ADJUST button to
display the "REF. ADJUST" menu.
• The projector may ask you to enter your passcode.
• See page 59 for the explanation of the PASSCODE.
2 Use the CURSOR
or
item. Press the ENTER or INPUT "1" button to display the
"ASTIG" menu.
Items to select
• CENTER ......... Adjusts the whole screen
• EDGE ............. Adjusts the top, bottom, left, and right sides on
the screen
• CORNER ........ Adjusts the four corners on the creen
3 Use the CURSOR
or
"EDGE", or "CORNER" item. Press the ENTER button to
display the "ASTIG" adjustment screen.
• The "DOT COARSE" test pattern is automatically displayed.
• Pressing The CTL and FOCUS buttons rotates three items as
follows:
CENTER→EDGE→CORNER
4 Select the CRT you wish to adjust with R, G, or B button.
5 Press the R, G, or B button to project the only CRT beam to be
adjusted.
• You can turn on or off each CRT beam (R, G, or B).
button to highlight the "1/ASTIG"
button to select the "CENTER",
– R E F . A D J U S T –
1 / A S T I G
2 / B R I G H T U N I F O R M .
3 / W H I T E U N I F O R M .
4 / R A S T E R C E N T E R I N G
5 / F O C U S B A L .
6 / R E F . W H I T E B A L
A S T I G
- C E N T E R -
C R T - G -
H
V
120
– A S T I G –
1 / C E N T E R
2 / E D G E
3 / C O R N E R
5 0 %
5 0 %
