Step 2: Connect the slide rails to the main frame
1. Place the main frame (1) upright.
2. Mount the slide rail (3L/R) to the frame (1) with four screws
(99) on the top/seat side, two screws (77) on the outside and
six screws (65) on the bottom.
3. Tighten the screws.
99
65
Step 3: Assembly of the console Part 1
1. Loosen and remove the bolt (66), washers (74), spring washer
(86) and nut (78) pre-mounted on the console holder (9).
2. Connect the cables of the console (54) to their corresponding
counterparts of the console holder (9).
3. Insert the excess cable into the console holder (9).
ATTENTION
Be careful not to pinch the cables during the following step.
4. Secure the console (54) to the console holder (9) with the
previously loosened bolt (66), washers (74), spring washer
(86) and lock nut (78).
14
71
71
99
65
65
