Returnstar Interactive Tech IQTouch HA1100 Pro User Manual page 100

7F 08 99 A2 B3 C4 02 FF 01
Speaker volume
33 CF
7F 08 99 A2 B3 C4 02 FF 01
D.Mode
35 CF
Backlight 7F 08 99 A2 B3 C4 02 FF 01
brightness 49 CF
7F 08 99 A2 B3 C4 02 FF 01
Backlight status
81 CF
Screen lock 7F 08 99 A2 B3 C4 02 FF 01
status 84 CF
7F 09 99 A2 B3 C4 02 FF 01 33 XX
CF
Notes:
XX indicates current volume value
(XX is a hexadecimal value, range:
00~64).
For example, XX = 20 indicates
current volume value is 32 (decimal
value), XX = 00 indicates mute state.
7F 09 99 A2 B3 C4 02 FF 01 35 XX
CF
Notes:
XX indicates the mode.
XX = 00-standard;
XX = 01-ECO mode;
XX = 02-custom.
XX = 03-auto.
7F 09 99 A2 B3 C4 02 FF 01 49 XX
CF
Notes:
XX indicates the value of backlight
brightness (0 - 100), corresponding to
the hexadecimal number system (00 -
64).
7F 09 99 A2 B3 C4 02 FF 01 81 XX
CF
Notes:
XX = 00 indicates the backlight is
on.
XX = 01 indicates the backlight is
off.
7F 09 99 A2 B3 C4 02 FF 01 84 XX
CF
98
