Belmont PHOT-X IIS 505 LCD Operator Instructions Manual

Dental x-ray
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DENTAL X-RAY
WARNING
This X-ray equipment may be dangerous to patient and operator unless safe
exposure factors, operating instructions and maintenance schedules are
observed.
OPERATOR'S
INSTRUCTIONS
· Wall Mount Type ................. WK
· Floor Mount Type ................ FK1/FK2
· Mobile Type ........................ FM
· Room Mount Type .............. RK
· Ceiling Mount Type ............. CK
LCD
505
0197
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHOT-X IIS 505 LCD and is the answer not in the manual?

Questions and answers

Related Manuals for Belmont PHOT-X IIS 505 LCD

Summary of Contents for Belmont PHOT-X IIS 505 LCD

  • Page 1 DENTAL X-RAY OPERATOR’S INSTRUCTIONS · Wall Mount Type ....WK · Floor Mount Type ....FK1/FK2 · Mobile Type ......FM · Room Mount Type ....RK · Ceiling Mount Type ..... CK 0197 WARNING This X-ray equipment may be dangerous to patient and operator unless safe exposure factors, operating instructions and maintenance schedules are observed.
  • Page 2 INDEX [1] INTRODUCTION ..............................1 [2] MAJOR COMPONENTS ............................ 3 [3] LAYOUT OF CONTROLS ........................... 5 [4] FUNCTION OF CONTROLS ..........................6 [5] OPERATING PROCEDURES ........................... 10 [6] SETTING MODE .............................. 11 [7] OPTIONAL HAND EXPOSURE SWITCH ......................12 [8] DIGITAL IMAGING SYSTEM ..........................13 [9] INFECTION CONTROL AND CLEANING ......................

  • Page 3: Intended Purpose

    [1] INTRODUCTION 1. GENERAL This manual provides information for the operation and maintenance procedures and technical specifications for PHOT-X IIs 505 dental x-ray. The instructions contained in this book should be thoroughy read and understood before operetion. PHOT-X IIs 505 has no user serviceable items. Repair should be performed by qualified dealer service personnel. Any part of this x-ray unit shall not be maintenanced or serviced while in use with a patient.
  • Page 4 7. SYMBOLS In this book , on the labels or on the control panel of PHOT-X IIs 505 LCD, following symbols are used. Confirm the meanings of each symbol by the table below. Manufacturer Date of manufacture ON (POWER) OFF (POWER)

  • Page 5: Major Components

    [2] MAJOR COMPONENTS 1. MOBILE TYPE (FM) Main Power Switch X-Ray Head Cone Yoke Arm Collar Balance Arm Pole Bush Pole Pole Base Leg Bar (long) Leg Bar (Short) Lock Caster Standard Caster Main Controller Sub Controller fi Hand Exposure Switch fi...
  • Page 6 3. FLOOR MOUNT TYPE (FK) Main Power Switch X-Ray Head Cone Yoke Arm Collar Balance Arm Horizontal Arm (300mm) Pole Bush Back Supporter Pole Base Cover Mounting Plate Main Controller Sub Controller Hand Exposure Switch Typ FK1 Typ FK2 Fig.2-3 Major Components for FK1/FK2 4.

  • Page 7: Layout Of Controls

    5. WALL MOUNT TYPE (WK) Main Power Switch X-Ray Head Cone Yoke Arm Collar Balance Arm Horizontal Arm Main Controller Sub Controller Hand Exposure Switch (Option) Fig.2-5 Major Components for WK [3] LAYOUT OF CONTROLS Main Power Switch is intentionally omitted Ready Indication kV Selection Switch Exposure Time Adjustment Switch (Down)

  • Page 8: Function Of Controls

    [4] FUNCTION OF CONTROLS Main Power Switch Pushing the upper side of this switch to the ON position energizes the x-ray unit. Ready Indication This indication becomes green when the exposure time is set and the line voltage is within operable range (207 ~ 253Vac). When this indication is white, exposure cannot be made.
  • Page 9 Image Receptor Selection Switch To get optimal images the exposure timer adjustment according to the sensitivity of image receptor is important. The PHOT-X IIs 505 has 16 density settings for each three kinds of image receptors, i.e. film, digital sensor and Image Receptor selection window phosphor plate.
  • Page 10 TABLE 1. Speed Setting and Exposure Time (Short Cone) [ unit : sec.] Child Adult Large Adult Speed Setting 0.20 0.25 0.28 0.32 0.50 0.32 0.40 0.50 0.56 0.80 0.40 0.50 0.63 0.71 1.00 0.10 0.11 0.14 0.16 0.25 0.16 0.20 0.25 0.28 0.40 0.20 0.25 0.28 0.36 0.50 F.09 0.14 0.16 0.20 0.22 0.36 0.25 0.28 0.36 0.40 0.56 0.28 0.36 0.45 0.50 0.71 0.07 0.08 0.10 0.11 0.18 0.11 0.14 0.18 0.20 0.28 0.14 0.18 0.22 0.25 0.36...
  • Page 11 Exposure Warning Indication This indication appears while the unit is producing x-radiation. Exposure Switch This switch initiates radiographic exposure. When making an exposure, depress and hold this switch until the Exposure Warning Indication and the audible warning shut off. Failure to keep this switch depressed will result in the premature termination of the exposure and an error code E.00 will be displayed.

  • Page 12: Operating Procedures

    [5] OPERATING PROCEDURES 1. Turn ON the Main Power Switch NOTE: Do not turn on the main power switch while touching the LCD screen, as the touch sensor initializes the sensitivity when the power is turned on. 2. Select the appropriate tooth type ( ), and confirm the pre-selected conditions (cone type, film or digital, kV, mA and patient size) are suitable for exposure.

  • Page 13: Setting Mode

    [6] SETTING MODE By touching the setting mode switch at bottom left corner, the normal operation mode can be changed to the setting mode or service mode. There are 13 setting modes and each purposes of those settings are as follows. 1.
  • Page 14 11. Screen saver setting If the unit is left without being operated and the main power switch is kept on, display will go into screen saver mode. You can select one of following four kinds of screen saver modes. a. Energy saving mode: Backlight of LCD becomes minimum in this mode. b.
  • Page 15 [8] DIGITAL IMAGING SYSTEM No x-ray image receptor is integrated into the PHOT-X IIs 505 x-ray system. If a receptor for digital imaging is used with PHOT-X IIs 505, the type and performance of the image receptor should be as follows. 1.

  • Page 16: Error Codes

    [10] ERROR CODES If an abnormal condition exists in the unit, or a malfunction occurs, an error code, code condition, and the possible solution will be displayed on the LCD screen. Please refer to the table below. Error Code Condition Step to be Taken Possible Solution All the tooth selection lights...

  • Page 17: Maintenance

    Maintenance personnel: Qualified dealer service personnel who has the experience with Belmont’s x-ray or has been trained by Belmont. But item 7 - 14 of the maintenance check list on Page 16 should be verified routinely by treatment room personnel.
  • Page 18 Parameter Acceptance limit Frequency Procedures when failed OK/NG 4. Mounting plate for wall Confirm the plate is firmly Yearly If bolts are loose, find the (WK), ceiling (CK) or floor fixed to the wall (WK), ceiling reason why bolts became (FK1/FK2) (CK) or floor (FK1/FK2).

  • Page 19: Technical Data

    [12] TECHNICAL DATA 1. X-ray tube ------------------------------------------------------------ D-046 (Stationary Anode) a. Nominal focal spot value ----------------------------------------- 0.4 b. Target Material ---------------------------------------------------- Tungsten c. Target angle ------------------------------------------------------- 12.5 deg d. Maximum anode heat content ---------------------------------- 4.3 kJ (6.1 kHU) 2. Maximum x-ray tube assembly heat content --------------------- 293 kJ (413 kHU) 3.
  • Page 20 Nominal Radiation Output Table Nominal Radiation Output without Rectangular Collimator with Rectangular Collimator Exp. Time 60 kV 70 kV 60 kV 70 kV [sec.] Regular Cone Long Cone Regular Cone Long Cone Regular Cone Long Cone Regular Cone Long Cone 0.00 0.00 0.00...

  • Page 21: Physical Dimensions

    [13] PHYSICAL DIMENSIONS [unit : mm] 1. Wall mount type (WK) Maximum Reach 2122 mm with 1000 mm arm 1922 mm with 800 mm arm 1622 mm with 500 mm arm Max.1190 Stroke 1100 1422 mm with 300 mm arm Location for Power Cable PHOT-X IIs Sub Controller (See Max.
  • Page 22 4. Ceiling mount type (CK) except for Germany for Germany 220˚ 220˚ 300˚ 300˚ 600˚ 600˚ Max.1190 Max.1190 Stroke 1100 Stroke 1100 ø600 ø600 75.5 75.5 90˚ 90˚ 90˚ 300˚ 300˚ 5. Room mount type (RK) Focal Spot Marking Reference Axis SSD + 158 mm SSD (Source to Skin Distance) : a.

  • Page 23: Electromagnetic Compatibility (Emc)

    [14] ELECTROMAGNETIC COMPATIBILITY (EMC) This product conforms to EMC standard EN60601-1-2:2015. 1. Caution to EMC and Compliance with information in attached document Medical electrical equipment requires special attention to EMC and it must be installed and used according to the EMC information provided in this instruction manual.
  • Page 24 Electromagnetic environment - Immunity test EN 60601 test level Compliance level guidance dips dips Mains power quality should be 0 %Ut: 0.5 cycle 0 %Ut: 0.5 cycle that of a typical commercial or (0, 45, 90, 135, 180, 225, (0, 45, 90, 135, 180, 225, hospital environment.

  • Page 25: Other Information

    4. Essential performance Unless the exposure switch is pressed, x-ray is not exposed. If the Essential performance is lost or deteriorated, the device may operate inadvertently and may harm the patient, the operator, and the surrounding people. [15] OTHER INFORMATION 1.

  • Page 26: Label Location

    [17] LABEL LOCATION COMP COMP COMP (WK Type) (RK Type) (FM Type) F6.3AH, 250V COMP (FM, FK, RK Type) (Type FK) (FM, FK, RK Type) COMP (CK Type) (FM Type) COMP COMP COMP COMP COMP...
  • Page 27 COMP (WK, FM, FK and CK Type) COMP (WK and FK Type) COMP (RK Type) (FM Type)
  • Page 28 NOTE TAKARA COMPANY EUROPE GmbH TAKARA BELMONT CORPORATION Berner Strasse 18, 60437 2-1-1, Higashishinsaibashi, Chuo-ku, Osaka, 542-0083, Japan Frankfurt am Main, Germany TEL: +81 6 6213 5945 Tel:+49 69 506878 0 TELEFAX: +81 6 6212 3680 Fax:+49 69 506878 20 BOOK NO.
