Summary of Contents for Belmont IO 5000TA
- Page 1 DENTAL LIGHT IO 5000TA TYPE AL-820S INSTALLATION OPERATION INSTRUCTIONS IMPORTANT After installation is completed, check all the bolts, screws and fasteners to confirm that they are securely fastened.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Page [1] MAJOR PARTS IDENTIFICATION --------------------------------------------- 1 [2] SPECIFICATIONS ------------------------------------------------------------------- 1 [3] CLASSIFICATION ------------------------------------------------------------------- 1 [4] WIRING DIAGRAM ---------------------------------------------------------------- 2 [5] DIMENSIONS ------------------------------------------------------------------------- 2 [6] INSTALLATION 6-1. Attach the light assembly to the light pole ------------------------------------ 3 6-2. - Page 4 Pressure : 600 ~ 1060 hpa Important Notes In case of the troubles, please contat Takara Belmont offices or your dealers. Do not disassemble or attempt to repair. Disassembly, repair or modifications shoud only be done by a qualified repair technician.
- Page 5 WARNING Operation of a dental light under Electro Magnetic Interferences. This equipment may malfunction by electromagnetic interferences. Do not install dental light close to the equipment that generates electromagnetic interference (i.e. communication equipment, elevator) Do not use the device that creates interference (i.e. cellular phone) near this equipment. Do not use electric surgical knife or laser knife with dental light.
- Page 6 CAUTION Before use • Check connection of switches and make sure that the device functions properly. • Make sure that grounding wire is connected. • Make sure that cables are properly and perfectly connected. During use • Do not use the light longer than required for examination or treatment. •...
-
Page 7: Major Parts Identification
[1] MAJOR PARTS IDENTIFICATION Light Pole Joint Balance Arm Joint Arm Joint Cover Balance Arm Arm Joint Cover Yoke Joint First Yoke Second Yoke Intensity Switch Handle (Left) Touchless Sensor Switch Reflector Cover Light Bulb Cover Handle (Right) Yoke Rear Cover Bracket Frame Reflector [2] SPECIFICATIONS... -
Page 8: Wiring Diagram
[4] WIRING DIAGRAM Remark Connector Symbol Black dot NMF ・ ・ ・ New Mini Fit Connector VL・ ・ ・ VL Connector Black dot indicates YL・ ・ ・ YL Connector male pin side Mode Selection Switch SV・ ・ ・ SV Connector VH・... -
Page 9: Installation
[6] INSTALLATION 6-1. Attach the light assembly to the light pole (Fig.6-1) Pass the light cable through the light pole and insert the light pole joint into the light pole. Fasten with two button screws (M6x8 ) . Light Pole Joint Button Screw (M6x8) Light Pole Light Cable... -
Page 10: Operation
[7] OPERATION 7-1. Touchless Switch (Fig.7-1) Approach a hand to the touchless switch within the reaction zone to turn on/off for the light. Intensity Switch Touchless Sensor Reaction Zone : 65mm Fig. 7-1 7-2. Intensity Switch (Fig.7-2) Light Intensity Push intensity switch. Green High 28,000Lux... -
Page 11: Adjustment Of The Tension Of The Balance Arm
[8] ADJUSTMENT 8-1. Adjustment of the tension of the balance arm Position the angle of the balance arm so the tension adjustment nut becomes visible just under slot A. Turn the nut and adjust the tension with the adjustment bar supplied with the light. Balance Arm Joint Adjustment Bar Light Pole Joint... -
Page 12: Adjusting The Tension Of The Light Head
8-3. Adjusting the tension of the light head 1. With a No.2 Phillips head screwdriver, unscrew the M3x5 screws, and remove the left and right yoke caps. 2. Adjust the tension by equally tightening or loosening the two socket head screws using the supplied 1.5mm Allen key. -
Page 13: Converting The Balance Arm For Left Handed
8-5. Converting the balance arm for left handed use When converting the balance arm from right to left handed use, follow the procedures below. 1. Loosen the four M5 socket head screws (E) of the balance arm joint with the supplied 2.5mm Allen key. 2. -
Page 14: Replacement Of The Bulb
[9] REPLACEMENT OF THE BULB CAUTION Make sure the power supply is turned off. Halogen bulb and surrounding parts be hot immediately after the lamp goes off. Wait until they get cool down. Do not touch glass with bare hand. Halogen bulb surface must be clean. Oil or body moisture will affect bulb span of life. -
Page 15: Inserting A New Bulb
9-3. Inserting a new bulb IMPORTANT Replace halogen lamp only with type JA-24V 60W cbtaainable through your local dealer. (1) At inserting the bulb, make sure that the projection of the bulb holder and the cut-out of the bulb are aligned. -
Page 16: Cleaning
[10] CLEANING CAUTION Allow light to cool prior to cleaning. CAUTION All surfaces can be cleaned with DURR FD333 cleaner. Spray the cleaner (DURR FD333) on cloth and wipe the surfaces with the cloth. Wipe all surfaces dry after cleaning. REFLECTOR : Extreme care should be taken to prevent scratching reflector surfaces, as this will degrade the performance of the light. -
Page 17: Maintenance And Inspection
[11] MAINTENANCE AND INSPECTION 11-1.Guide for daily maintenance and inspection (Maintenance and inspection by user) Management of maintenance and inspection of medical equipment should be implemented by the user (medical inspection). In case the user does not implement such management, it is permitted that such management is outsourced to a qualified entity such as a medical equipment repair company. -
Page 18: Before Asking For Repairs
11-2. Guide for Periodical Check-up Some parts and components of the products are degraded or deteriorated depending on the frequency of use. Annual check-up and maintenance, as well as replacement of consumable parts, are required. The required parts (including consumable parts) are listed below. It may be different from the following list depending on the option of the light. -
Page 19: Electromagnetic Compatibility(Emc)
[13] ELECTROMAGNETIC COMPATIBILITY(EMC) Medical electrical equipment needs special precautions regarding EMC and needs to be installed and put into service according to the EMC information provided in this manual. Portable and mobile RF communications equipment can affect medical electrical equipment. The equipment or system should not be used adjacent to or stacked with other equipment. - Page 20 Guidance and manufacture’s declaration – electromagnetic immunity The IO5000TA is intended for use in the electromagnetic environment specified below. The customer or the user of the IO5000TA should assure that it is used in such an environment. Compliance Immunity test IEC 60601 test level Electromagnetic environment －...
- Page 21 Recommended separation distances between Portable and mobile RF communications equipment and the IO5000TA The IO5000TA is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the IO5000TA can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the IO5000TA as recommended below, according to the maximum output power of the communications equipment.
- Page 24 NOTE Takara Belmont (U.K.) Ltd. Belmont House TAKARA BELMONT CORPORATION One St.Andrews Way,Bow, 2-1-1, Higashishinsaibashi,Chuo-ku, Osaka, 542-0083, Japan London E3 3PA U.K. TEL : 81-6-6213-5945 FAX : 81-6-6212-3680 Tel: (44)20 7515 0333 Book No. 1E014RC0 Fax:(44)20 7987 3596 Printed in Japan 2012.04...
