  • Page 1 RIGOL User’Guide DS6000 Series Digital Oscilloscope May 2011 RIGOL Technologies, Inc.

  • Page 3: Guaranty And Declaration

    Notices RIGOL products are protected by patent law in and outside of P.R.C.  RIGOL reserves the right to modify or change parts of or all the specifications  and pricing policies at company’s sole decision. Information in this publication replaces all previously corresponding materials.

  • Page 4: Safety Requirement

    Do not operate the instrument with covers or panels removed. Change The Power Fuse. If the power fuse needs to be changed, please return the instrument back to our factory and the RIGOL authorized operator will change it for you. DS6000 User’s Guide...
  • Page 5 If you suspect damage occurs to the instrument, have it inspected by qualified service personnel before further operations. Any maintenance, adjustment or replacement of components must be performed by RIGOL authorized personnel. Keep Proper Ventilation. Inadequate ventilation may cause temperature increase which would damage the instrument.

  • Page 6: Safety Terms And Symbols

    RIGOL Safety Terms and Symbols Terms in this Manual. The following terms may appear in this manual: WARNING Warning statements indicate the conditions or practices that could result in injuries or loss of life. CAUTION Caution statements indicate the conditions or practices that could result in damage to this product or loss of data.

  • Page 7: Measurement Category

    RIGOL Measurement Category Measurement Category DS6000 series digital oscilloscopes can make measurements in Measurement Category I. WARNING This oscilloscope can only be used for measurements within its specified measurement categories. Measurement Category Definitions Measurement category I is for measurements performed on circuits not directly connected to MAINS.

  • Page 8: Ventilation Requirement

    RIGOL Ventilation Requirement This oscilloscope uses fan to force cooling. Please make sure that the air intake and exhaust areas are free from obstructions and have free air. When using the oscilloscope in a bench-top setting, provide at least 10 cm clearance beside, above and behind the instrument for adequate ventilation.

  • Page 9: Working Environment

    RIGOL Working Environment Temperature Operating: 0℃ to +50℃ Non-operating: -20℃ to +70℃ Humidity Under +35℃: ≤90％ relative humidity +35℃ to +40℃: ≤60％ relative humidity WARNING To avoid short circuit inside the instrument or electric shock, please do not operate in humid environment.
  • Page 10 RIGOL Pollution Degree Degree 2 Pollution Degree Definitions Pollution degree 1: No pollution or only dry, non-conductive pollution occurs. The pollution has no influence. For example: a clean room or air-conditioned office environment. Pollution degree 2: Normally only dry, non-conductive pollution occurs. Occasionally a temporary conductivity caused by condensation may occur.

  • Page 11: General Care And Cleaning

    RIGOL General Care and Cleaning General Care Do not leave the instrument exposed to direct sunlight for long period of time. Cleaning Clean the instrument regularly according to its use condition. To clean the oscilloscope: 1. Disconnect the instrument from power.

  • Page 12: Environmental Considerations

    RIGOL Environmental Considerations The following symbol indicates that this product complies with the requirements of European Union according to Directives 2002/96/EC on waste electrical and electronic equipment (WEEE). Instrument Recycle Some substances contained in this product might be harmful to the environment or human health.

  • Page 13: Ds6000 Series Overview

    RIGOL DS6000 Series Overview Being a multifunctional and high performance digital oscilloscope, DS6000 delivers perfect combination of easy-to-use and powerful features to help users to fulfill their tasks more quickly. Main Features: 1 GHz or 600 MHz bandwidth.  2-channel or 4-channel model.
  • Page 14 RIGOL Provide more than 2-hour lithium battery power supply (optional) to facilitate  on-field test and use. Built-in 1 GBytes flash memory.  DS6000 User’s Guide...

  • Page 15: Document Overview

    RIGOL Document Overview 1 Quick Start Describes the preparations before using the instrument and generally introduce the instrument. 2 To Set the Vertical System Introduces the functions of the vertical system of the oscilloscope. 3 To Set the Horizontal System Introduces the functions of the horizontal system of the oscilloscope.
  • Page 16 RIGOL oscilloscope. 13 System Function Setting Introduces how to perform the remote interface, system-related and print operations. 14 Remote Control Introduces how to perform remote control of the oscilloscope. 15 Troubleshooting Introduces how to deal with common failures of the oscilloscope.

  • Page 17: Table Of Contents

    RIGOL Contents Guaranty and Declaration ................. I Safety Requirement ................II General Safety Summary ................II Safety Terms and Symbols ............... IV Measurement Category ................V Ventilation Requirement ................VI Working Environment ................VII General Care and Cleaning ............... IX Environmental Considerations ..............
  • Page 18 RIGOL Knob .................... 1-20 Navigation Knob ................1-21 Menu .................... 1-21 Record ..................1-22 MEAS ................... 1-22 Clear .................... 1-22 Print ..................... 1-22 User Interface ..................1-23 To Use the Security Lock ............... 1-28 To Use the Desk Mount Instrument Arm ..........1-29 To Use the Rack Mount Kit ..............
  • Page 19 RIGOL Acquisition Mode ................... 4-2 Normal ..................4-2 Average ..................4-2 Peak Detect ..................4-4 High Resolution ................4-4 Sample Mode ..................4-5 Real-time Sample ................4-5 Equivalent Sample ................4-5 Sample Rate ..................4-6 Memory Depth ..................4-8 Antialiasing ................... 4-9 5 To Trigger the Oscilloscope ..............
  • Page 20 RIGOL Logic Operation ................6-8 Advanced Operation ............... 6-10 Auto Measurement ................6-13 Quick Measurement after Auto............6-14 One-key Measurement of 22 Parameters .......... 6-15 Frequency Counter Measurement ............ 6-20 Measurement Setting ..............6-21 Clear the Measurement ..............6-23 All Measurement ................6-24 Statistic Function ................
  • Page 21 RIGOL 10 Waveform Recording ..............10-1 Waveform Recording................10-2 Waveform Playback ................10-4 Waveform Analysis ................10-6 Analysis Based on Trace ..............10-9 Analysis Based on Pass/Fail Mask........... 10-10 11 Display Control ................11-1 To Select the Display Type ..............11-2 To Set the Persistence Time ..............
  • Page 22 RIGOL System Time ................. 13-8 Self-calibration Information ............13-10 Screen ..................13-11 Error Information ................. 13-12 Self-calibration ................13-13 Power Status ................13-14 External Trigger Impedance ............13-14 Aux Output ................. 13-15 Reference Clock ................13-16 Option Management ..............13-17 To Print the Waveform ................

  • Page 23: Quick Start

    RIGOL 1 Quick Start This chapter introduces the preparations when using the oscilloscope for the first time, the front panel, rear panel and user interface of the oscilloscope as well as the using method of the built-in help system. The contents of this chapter: General Inspection ...

  • Page 24: General Inspection

    If your instrument has damaged during shipping, please contact your shipper and carrier for compensation. RIGOL will provide no free repair or replacement. 2. Inspect the instrument. If there is any mechanical damage or defect, or if the instrument does not pass electrical and mechanical tests, please contact your RIGOL sales representative.

  • Page 25: Appearance And Dimensions

    RIGOL Appearance and Dimensions Figure 1-1 Front View Unit: mm Figure 1-2 Side View Unit: mm DS6000 User’s Guide...

  • Page 26: To Prepare The Oscilloscope For Use

    RIGOL To Prepare the Oscilloscope for Use To Remove the Cover Before using the oscilloscope, remove the front panel cover by grasping the transverse grab on each side and pull them in the arrow directions as shown in the figure below.

  • Page 27: To Adjust The Supporting Legs

    RIGOL To Adjust the Supporting Legs Adjust the supporting legs properly to use them as stands to tilt the oscilloscope upwards, thus to place the oscilloscope stably and to operate and observe the display better. Figure 1-4 To Adjust the Supporting Legs...

  • Page 28: To Connect To Ac Power Supply

    Figure 1-5 To Connect to AC Power Supply CAUTION If the power fuse needs to be changed, please return the instrument back to our factory and the RIGOL authorized operator will change it for you. DS6000 User’s Guide...

  • Page 29: To Use The Battery

    RIGOL To Use the Battery This oscilloscope also provides rechargeable battery on your option. Please install the battery as shown in the figure below. When leaving the factory, the battery holds certain electric quantity. When use the battery only, a battery icon...

  • Page 30: Power-On Inspection

    RIGOL Power-on Inspection When the oscilloscope is energized, press the power key at the lower-left corner of the front panel to turn on the oscilloscope. During the start-up process, the oscilloscope performs a series of self-tests and you can hear the sound of relay switching.

  • Page 31: To Connect The Probe

    RIGOL To Connect the Probe RIGOL provides passive and active probes for the DS6000 series oscilloscopes. For detailed technical information of the probes, please refer to corresponding Probe User’s Guide. The following are the probes recommended for use with this oscilloscope.

  • Page 32: Function Inspection

    RIGOL Function Inspection 1. Press SAVE  Factory to restore the oscilloscope to its default configuration. 2. Use the probe to connect the input terminal of channel 1 (CH1) of the oscilloscope and the “Compensation Signal Output Terminal” of the probe.
  • Page 33 RIGOL WARNING To avoid electric shock during the use of probe, please make sure that the insulated wire of the probe is in good condition and do not touch the metallic part of the probe when the probe is connected to high voltage source.

  • Page 34: Probe Compensation

    RIGOL Probe Compensation When the probes are used for the first time, you should compensate the probes to match the input channels of the oscilloscope. Non-compensated or poorly compensated probes may cause measurement inaccuracy and error. The probe compensation procedure is as follows: 1.

  • Page 35: Front Panel Overview

    RIGOL Front Panel Overview ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲⑳ Figure 1-11 Front Panel Overview Table 1-1 Front Panel Description Description Description Menu HORIZONTAL Area ① ⑪...

  • Page 36: Rear Panel Overview

    RIGOL Rear Panel Overview 1. Trig Out/Calibration 3.Video Output 5.USB DEVICE 7. AC Input/Switch 2. Reference Clock 4. LAN 6.USB HOST 8. Lock Hole Figure 1-12 Rear Panel Overview 1. Trig Out/Calibration This connector can output various signals (press UTIL  Aux Output to select the desired output type.):...
  • Page 37 USB flash device to store waveform files. GPIB interface communication can be realized by using the USB-GPIB module (optional) provided by RIGOL. Note that the front panel also provides this interface. 7. AC Input/Switch When using AC power supply, please insert the power cord plug into the socket vertically and use the switch under the socket to power the oscilloscope on or off.

  • Page 38: Front Panel Function Overview

    RIGOL Front Panel Function Overview VERTICAL CH1, CH2, CH3, CH4: analog input channels. The four channels are marked by different colors which are also used to mark both the waveforms on the screen and the channel input connectors. Press any key to turn on the corresponding channel menu and press again to turn off the channel.
  • Page 39 RIGOL position quickly. VERTICAL SCALE: modify the vertical scale of the current channel. Turn clockwise to decrease the scale and turn counterclockwise to increase. During the modification, the amplitude of the waveform would enlarge or reduce and the scale information (e.g.

  • Page 40: Horizontal

    RIGOL HORIZONTAL MENU: press this key to turn on the horizontal control menu under which to turn on or off the delayed sweep function, switch between different time base modes, switch between “Coarse” and “Fine” of scale as well as modify the horizontal reference setting.

  • Page 41: Trigger

    RIGOL TRIGGER MODE: press this key to switch the trigger mode to Auto, Normal or Single and the corresponding state backlight of the current trigger mode would be illuminated. TRIGGER LEVEL: modify the trigger level. Turn clockwise to increase the level and turn counterclockwise to reduce the level.

  • Page 42: Single

    RIGOL Single Press this key to set the trigger mode to “Single”. In single trigger mode, press the FORCE key to generate a trigger signal immediately. Auto Press this key to turn on the waveform auto setting function. The oscilloscope will automatically adjust the...

  • Page 43: Navigation Knob

    RIGOL Navigation Knob This knob provides quick Adjust/Locate function for numerical parameters with relatively large settable range. Turn clockwise (counter-clockwise) to increase (reduce) the value. Note that the inner knob is used for fine adjustment and the outer knob for coarse adjustment.

  • Page 44: Record

    RIGOL refer to the introduction in “To Use the Built-in Help System”. Record Play/Pause: press this key to play the recorded or paused waveform and press again to pause the play. The backlight is illuminated in yellow. Stop: press this key to stop the waveform in record or play back mode.

  • Page 45: User Interface

    RIGOL User Interface DS6000 oscilloscope provides 10.1 inches, WVGA (800*480) 160,000 color TFT LCD. What is worth mentioning is that the 14-grid ultra-wide screen makes you view “longer” waveform. Figure 1-13 User Interface DS6000 User’s Guide 1-23...
  • Page 46 RIGOL 1. Measurement Menu Provide 12 horizontal (HORIZONTAL) and 10 vertical (VERTICAL) measurement parameters. Press the softkey at the left of the screen to activate corresponding measurement item. 2. Channel Label/Waveform Different channels are marked by different colors and the color of the waveform complies with the color of the channel.
  • Page 47 RIGOL 9. Trigger Type Display the currently selected trigger type and trigger condition setting. Different labels are displayed when different trigger types are selected. For example: represents triggering on the rising edge in “Edge” trigger. 10. Trigger Source Display the trigger source currently selected (CH1-CH4, EXT, EXT/5 or AC Line).
  • Page 48 RIGOL Use VIRTICAL SCALE to modify this parameter.  The following labels will be provided according to the current channel  setting: channel coupling, bandwidth limit and input impedance. 15. CH4 Vertical Scale Display the voltage value per grid of CH4 waveform vertically.
  • Page 49 RIGOL Denote that you can use the Navigation Knob to quickly adjust/locate parameters. Denote that can be used to adjust parameters and then press to select the parameter. Denote that the current menu has several options. Denote that the current menu has a lower level menu.

  • Page 50: To Use The Security Lock

    RIGOL To Use the Security Lock If needed, you can use the security lock (please buy it yourself) to lock the oscilloscope to a fixed location. The method is as follows, align the lock with the lock hole and plug it into the lock hole vertically, turn the key clockwise to lock the oscilloscope and then pull the key out.

  • Page 51: To Use The Desk Mount Instrument Arm

    RIGOL To Use the Desk Mount Instrument Arm Using an arm, the oscilloscope could be mounted on the work desk to save your operation space. The height and angle of the instrument could be adjusted freely to acquire supreme comfort and efficiency and to convenient your measurement and view.

  • Page 52: To Use The Rack Mount Kit

    RIGOL To Use the Rack Mount Kit This oscilloscope can be mounted in a standard 19-inch rack cabinet that conforms to the Electric Industrial Association (EIA) standard. If needed, please buy and install the corresponding option. Kit Parts List Name Part No.

  • Page 53: Installation Tool

    RIGOL Installation Tool PH2 Phillips Screwdriver (recommended). DS6000 User’s Guide 1-31...

  • Page 54: Installation Space

    RIGOL Installation Space The following requirements must be fulfilled by the machine cabinet in which the instrument is mounted. The machine cabinet must be a standard 19-inch one.  At least 6U (266.7 mm) space should be provided by the machine cabinet.

  • Page 55: Installation Procedures

    RIGOL Installation Procedures Only authorized operators can execute the installation operation. Improper installation might result in damage of the instrument or incorrect installation of the instrument on the rack. 1. Install the right and left plates: align the detents of the right and left plates with the openings on the support board and insert them into the support board respectively, then fix them with six M4 screws.
  • Page 56 RIGOL 3. Fix the instrument: fix the instrument on the support board with two back battens and twelve M4 screws. 4. Install the front panel: align the screw holes on the right and left plates with the screw holes on the front panel of the rack and let the front panel of the oscilloscope protrude from the opening.
  • Page 57 RIGOL 5. Load into the machine cabinet: mount the rack with the instrument fixed to it into a standard 19-inch machine cabinet with four M6 screws and four M6 square nuts. 6. Post-installation notice: the rack occupies a height of 6U. The holes pointed out by the arrows are installation holes.

  • Page 58: To Use The Built-In Help System

    RIGOL To Use the Built-in Help System The help system of this oscilloscope provides instructions for all the function keys (including menu keys) at the front panel. Press HELP to open the help interface and press again to close the interface. The help interface mainly consists of two parts.

  • Page 59: To Set The Vertical System

    RIGOL 2 To Set the Vertical System The contents of this chapter: To Enable the Channel  Channel Coupling  Bandwidth Limit  Probe  Input Impedance  Waveform Invert  Vertical Scale  Vertical Expansion  Amplitude Unit ...

  • Page 60: To Enable The Channel

    RIGOL To Enable the Channel DS6000 provides four analog input channels (CH1-CH4) and each channel can be controlled independently. Connect a signal to the channel connector of any channel for example CH1 and then press CH1 in the vertical control area (VERTICAL) at the front panel to enable CH1.

  • Page 61: Channel Coupling

    RIGOL Channel Coupling Set the coupling mode to filter out the signals that is not needed. For example: the signal under test is a square waveform signal with DC offset. When the coupling mode is “DC”: the DC and AC components of the signal under ...

  • Page 62: Bandwidth Limit

    Read the type of the probe currently connected as “Nor-Probe” or “DiffProbe”. Note that when using a 50 Ω “DiffProbe”, the Input Impedance of the channel is set to “50Ω” automatically. Normal Probe: such as RP5600, RP3500 and RP6150 of RIGOL.  Differential Probe: such as RP7150 of RIGOL.
  • Page 63 RIGOL Table 2-1 Probe Attenuation Coefficient Menu Attenuation coefficient 0.001X 1:1000 0.01X 1:100 0.1X 1:10 10:1 100X 100:1 1000X 1000:1 For “DiffProbe”, this menu blanks off. DS6000 User’s Guide...

  • Page 64: Input Impedance

    RIGOL Input Impedance To reduce the circuit load caused by the interaction of the oscilloscope and the circuit under test, this oscilloscope provides two input impedance modes: 1 MΩ (default) and 50 Ω. 1 MΩ: at this point, the input impedance of the oscilloscope is very high and the ...

  • Page 65: Waveform Invert

    RIGOL Waveform Invert When waveform invert is turned on, the waveform display rotates 180 degree relative to the ground potential. When the waveform invert is turned off, the waveform display is normal. Press CH1  Invert to turn waveform invert on or off.

  • Page 66: Vertical Expansion

    RIGOL Vertical Expansion When using VERTICAL SCALE to change the vertical scale of the analog channel, you can choose to expand or compress the vertical signal around the center of the screen or around the ground point of the signal.

  • Page 67: Channel Label

    RIGOL Channel Label You can modify the labels used to mark the analog channels (CH1 to CH4) at the left side of the screen. The label is the number of the channel (e.g. ) by default and the length of the modified label can not exceed 4 characters.

  • Page 69: To Set The Horizontal System

    RIGOL 3 To Set the Horizontal System The contents of this chapter: Delayed Sweep  Time Base Mode  Horizontal Scale  Horizontal Reference  DS6000 User’s Guide...

  • Page 70: Delayed Sweep

    RIGOL Delayed Sweep Delayed sweep can be used to enlarge a length of waveform horizontally to view the details of the image. MENU Press the MENU key in the horizontal control area (HORIZONTAL) and then press the Delayed softkey to turn the delayed sweep on or off. Note that to turn on the delayed sweep, the current time base mode must be “Y-T”...
  • Page 71 RIGOL The waveform before enlargement Main time base Delayed Sweep 延迟扫描时基 The waveform after enlargement The waveform before enlargement: The waveform in the area that has not been covered by the subtransparent blue in the upper part of the screen is the waveform before enlargement. You can turn...

  • Page 72: Time Base Mode

    RIGOL Time Base Mode Press the MENU key in the horizontal control area at the front panel and then press the Time Base softkey to select the time base mode of the oscilloscope and the default is Y-T mode. Y-T Mode This mode is the main time base mode and is applicable to CH1-CH4 input channels.

  • Page 73: X-Y Mode

    RIGOL X-Y Mode In this mode, the oscilloscope automatically turns on all the four channels (CH1-CH4) and the screen is divided into two coordinate areas, where, X1 and Y1 track the voltages of CH1 and CH2 and X2 and Y2 track the voltages of CH3 and CH4.
  • Page 74 RIGOL X-Y function can be used to measure the phase deviation occurred when the test signal passes through a circuit network. Connect the oscilloscope to the circuit to monitor the input and output signals of the circuit. Application example: Measure the phase deviation of the input signals of two channels.
  • Page 75 RIGOL When X-Y mode is turned on, “Delayed” will be turned off automatically.  The following functions are not available in X-Y mode:  Auto measure, cursor measure, math operation, delayed sweep, vector display type, HORIZONTAL POSITION, trigger control, screen grid, memory depth, acquisition mode, Pass/Fail test and waveform recording.

  • Page 76: Roll Mode

    RIGOL Roll Mode In this mode, the waveform scrolls from the right to the left to update the display and the waveform horizontal position and trigger control are not available. Note that when Roll mode is turned on, “Delayed”, “Protocol Decoding”, “Pass/Fail”...

  • Page 77: Horizontal Scale

    RIGOL Horizontal Scale Being similar to “Vertical Scale”, the horizontal scale adjustment has two modes : “Coarse” and “Fine”. Press MENU  ScaleAdjust in the horizontal control area (HORIZONTAL) at the front panel to select the desired mode. Turn HORIZONTAL SCALE to adjust the horizontal scale.

  • Page 78: Horizontal Reference

    RIGOL Horizontal Reference Horizontal reference is the reference position according to which the screen waveform expands and compresses horizontally when adjusting HORIZONTAL SCALE. In Y-T mode, press MENU  HorRef in the horizontal control area (HORIZONTAL) to select the desired reference mode and the default is “Center”.
  • Page 79 RIGOL direction, the screen can display a maximum of 700 points with the leftmost as 350 and the rightmost as -350. For example: set the reference position to 150: DS6000 User’s Guide 3-11...

  • Page 81: To Set The Sample System

    RIGOL 4 To Set the Sample System The contents of this chapter: Acquisition Mode  Sample Mode  Sample Rate  Memory Depth  Antialiasing  DS6000 User’s Guide...

  • Page 82: Acquisition Mode

    RIGOL Acquisition Mode The acquisition mode is used to control how to generate waveform points from the sample points. Press ACQ  Acquisition in the function menu at the front panel and use select the desired acquisition mode (the default is normal), then press the knob to select this mode.
  • Page 83 RIGOL The available range of the number of averages is from 2 to 8192 and the default is 2. When “Average” mode is selected, press the Averages menu and use to set the desired number of averages as the power function of 2.

  • Page 84: Peak Detect

    RIGOL Peak Detect In this mode, the oscilloscope acquires the maximum and minimum values of the sample interval signal to get the envelope or the narrow pulse of the signal that might be lost. Use this mode to avoid signal confusion at the expense of exaggerating any noise.

  • Page 85: Sample Mode

    RIGOL Sample Mode Press ACQ  Sampling and press this softkey continuously to switch the sample mode (the default is real-time sample). Note that all the “Acquisition Mode” support real-time sample and equivalent sample. Real-time Sample In this mode, the oscilloscope samples and displays waveform within a trigger event.

  • Page 86: Sample Rate

    RIGOL Sample Rate Sample rate refers to the process that the oscilloscope converts the analog signals to discrete data at a certain time interval and stores the data in order. Sample rate is the reciprocal of the time interval. ...
  • Page 87 RIGOL 3. Waveform Leakage: when the sample rate is too low, the waveform rebuilt by the sample data does not reflect all the actual signal information. Pulse disappeared DS6000 User’s Guide...

  • Page 88: Memory Depth

    RIGOL Memory Depth Memory depth refers to the number of waveform points that the oscilloscope can store in a single trigger sample and it reflects the storage ability of the acquisition memory. DS6000 provides a memory depth up to 140 M points.

  • Page 89: Antialiasing

    RIGOL Antialiasing At slower sweep speeds, the sample rate is reduced and a proprietary display algorithm is used to minimize the likelihood of aliasing. Press ACQ  Anti_aliasing to turn on or off the antialiasing function. By default, Antialiasing is disabled. The displayed waveforms will be more susceptible to aliasing when this function is disabled.

  • Page 91: To Trigger The Oscilloscope

    RIGOL 5 To Trigger the Oscilloscope When working, the oscilloscope continuously acquires waveform data even if a valid trigger does not occur. However, only when valid triggers occur, can the display become stable. The trigger circuit guarantees that each sweep or sample starts from the position of the trigger event in the input signal, namely each sweep and sample are synchronous and the waveforms acquired overlap to display stable waveform.

  • Page 92: Trigger Source

    RIGOL Trigger Source Press MENU  Source in the trigger control area (TRIGGER) at the front panel to select the desired trigger source. Signals input from the analog channels CH1-CH4 and the [EXT TRIG] connector as well as the AC Line can all be used as the trigger source.

  • Page 93: Trigger Mode

    RIGOL Trigger Mode Trigger mode would influence the mode in which the oscilloscope searches for trigger event. The following is the schematic diagram of the acquisition memory from which you can see that the position of the trigger event is determined by the reference time point and the delay setting.
  • Page 94 RIGOL Auto: No matter whether the trigger condition is met, there is always waveform display. A horizontal line is displayed when no signal is input. When this mode is selected, the oscilloscope fills the pre-trigger buffer first and then search for a trigger while at the same time continues filling data. When the oscilloscope is searching for trigger, the data firstly filled into the pre-trigger buffer will overflow and be pushed out of the FIFO queue.

  • Page 95: Trigger Coupling

    RIGOL Trigger Coupling Trigger coupling decides which kind of components will be transmitted to the trigger circuit. Note to distinguish it with “Channel Coupling”. DC: allow the DC and AC components to pass the trigger path.  AC: block all the DC components and attenuate signals lower than 8 Hz.

  • Page 96: Trigger Holdoff

    RIGOL Trigger Holdoff Trigger holdoff could trigger complicated waveforms (e.g. pulse sequence) stably. Holdoff time is the time the oscilloscope waits to re-enable the trigger circuit. During the holdoff time, the oscilloscope will not trigger before the end of the holdoff time.

  • Page 97: Noise Rejection

    RIGOL Noise Rejection Noise Rejection reduces noise on the diplayed waveform and stablizes the displayed waveform. Press MENU  Set Up  Noise Reject in the trigger control area (TRIGGER) at the front panel and enable or disable Noise Rejection.

  • Page 98: Trigger Type

    RIGOL Trigger Type DS6000 has abundant trigger functions including multiple serial bus triggers. Edge Trigger  Pulse Trigger  Slope Trigger  Video Trigger  Pattern Trigger  RS232 Trigger  I2C Trigger  SPI Trigger  CAN Trigger ...

  • Page 99: Edge Trigger

    RIGOL Edge Trigger Trigger on the trigger threshold of the specified edge of the input signal. Trigger Type: Press Type to select “Edge”. At this point, the trigger setting information as shown in the figure below is displayed at the upper right corner of the screen.

  • Page 100: Pulse Trigger

    RIGOL Pulse Trigger Trigger on positive or negative pulse with specified width. Trigger Type: Press Type to select “Pulse”. At this point, the trigger setting information as shown in the figure below is displayed at the upper right corner of the screen.
  • Page 101 RIGOL Trigger level Positive pulse width When the Pulse Condition is set to , press  Set Up and use to input the desired value. The range available is from 4 ns to 4 s. When the Pulse Condition is set to , press Upper Limit and ...

  • Page 102: Slope Trigger

    RIGOL Slope Trigger Trigger on the positive or negative slope with specified time. Trigger Type: Press Type to select “Slope”. At this point, the trigger setting information as shown in the figure below is displayed at the upper right corner of the screen.
  • Page 103 RIGOL The upper limit of trigger level (Up Lvl) The lower limit of trigger level (Low Lvl) Positive Slope time When the Slope Condition is set to  press Time and use to input the desired value. The range available is from 10 ns to 1 s.
  • Page 104 RIGOL unchanged. : adjust the upper and lower limits of the trigger level at the same time.  During the adjustment, the “UP Lvl” and the “Low Lvl” change accordingly but the “Slew Rate” remains unchanged. Trigger Mode: Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto, normal or single.

  • Page 105: Video Trigger

    RIGOL Video Trigger Trigger on the standard video signal fields and lines of NTSC (National Television Standards Committee), PAL (Phase Alternating Line) or SECAM (Systeme Electronique Pour Couleur Avec Memoire). Trigger Type: Press Type to select “Video”. At this point, the trigger setting information as shown in the figure below is displayed at the upper right corner of the screen.
  • Page 106 RIGOL SECAM: the frame frequency is 25 frames per second. The sweep line is 625  with interlacing sweep. Trigger Mode: Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto, normal or single. The corresponding status light of the current trigger mode turns on.

  • Page 107: Pattern Trigger

    RIGOL Pattern Trigger Identify the trigger condition through searching for the specified pattern. Pattern is the logic “AND” combination of each channel and the value of each channel can be H (High), L (Low) or X (Don’t Care). One channel in the pattern can be specified with rising edge or falling edge and if the pattern settings of all the other channels are “True”...
  • Page 108 RIGOL define another edge item, thus the former edge item defined will be replaced by X. Trigger Mode: Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto, normal or single. The corresponding status light of the current trigger mode turns on.

  • Page 109: Rs232 Trigger

    RIGOL RS232 Trigger Trigger according to the start frame, error frame, check error and data. Trigger Type: Press Type to select “RS232”. At this point, the trigger setting information as shown in the figure below is displayed at the upper right corner of the screen.
  • Page 110 RIGOL 19200 bps, 38400 bps, 57600 bps, 115200 bps and user-defined. After “User” is selected, press the Setup softkey and use to set more specific value from 1 to 900000 with the adjustment step as 1 bps. Trigger Mode: Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto, normal or single.

  • Page 111: I2C Trigger

    RIGOL I2C Trigger Trigger on the start condition, restart, stop and missing acknowledgement or on the read/write frame with specific device address and data value. When using I2C trigger, you need to specify the SCL and SDA data sources. Trigger Type: Press Type to select “I2C”.
  • Page 112 RIGOL --Press the ByteLength softkey to set the length of data and the range is from 1 to 5; --Press the CurrentBit softkey to select the desired data bit and the range is from 0 to (ByteLength× 8-1); -- Press the Data softkey to set the data pattern of the current data bit to X, H or L.

  • Page 113: Spi Trigger

    RIGOL SPI Trigger Trigger on the data pattern with specified edge. When using SPI trigger, you need to specify the SCL, SDA and CS data sources. Trigger Type: Press Type to select “SPI”. At this point, the trigger setting information as shown in the figure below is displayed at the upper right corner of the screen.
  • Page 114 RIGOL Press ClockEdge to select the desired clock edge. : trigger on the rising edge of the data pattern when the voltage level meets  the preset Trigger Level. : trigger on the falling edge of the data pattern when the voltage level meets ...

  • Page 115: Can Trigger

    RIGOL CAN Trigger Trigger on the specified frame type of the data frame. When using CAN trigger, you need to specify the signal source, signal rate and trigger signal type of the CAN signal. Trigger Type: Press Type to select “CAN”. At this point, the trigger setting information as shown in the figure below is displayed at the upper right corner of the screen.
  • Page 116 RIGOL format). -- Press the Bits softkey and use to set the desired value. The range is from 1 to 8. -- Press the CurrentBit softkey to select the desired data bit and the range is from 0 to (Bits× 8-1).
  • Page 117 RIGOL Press SamplePoint and use to modify the parameter with the step as 1% and the range is from 5% to 95%. Trigger Mode: Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto, normal or single. The corresponding status light of the current trigger mode turns on.

  • Page 118: Usb Trigger

    RIGOL USB Trigger Trigger on the SOP, EOP, RC, Suspended and Exit Suspended of the data packet on the differential USB data cable (D+ and D-). This trigger supports USB Low Speed and Full Speed. Trigger Type: Press Type to select “USB”. At this point, the trigger setting information as shown in the figure below is displayed at the upper right corner of the screen.
  • Page 119 RIGOL Trigger Level: Use TRIGGER LEVEL to modify the level. For details, please refer to the description of “Trigger Level” on page 5-9. DS6000 User’s Guide 5-29...

  • Page 120: Trigger Ouput Connector

    RIGOL Trigger Ouput Connector The trigger output connector at the rear panel can output trigger signals decided by the current setting. Trigger Output Connector Press UTIL  AuxOutput to select “TrigOut”. When the oscilloscope is triggered, it will output a trigger signal decided by the current setting through the [Trig Out/Calibration] interface.

  • Page 121: To Make Measurements

    RIGOL 6 To Make Measurements After data is sampled and displayed, the DS6000 can make math operation, cursor measurement and auto measurement. The contents of this chapter: Math Operation  Auto Measure  Cursor Measurement  DS6000 User’s Guide...

  • Page 122: Math Operation

    RIGOL Math Operation DS6000 can realize various math operations of waveforms between channels including: addition (A+B), subtraction (A-B), multiplication (AxB), division (A÷ B), FFT, logic operation and advanced operation. The results of math operation also allows further measurement (for details, please refer to “Cursor Measurement”).

  • Page 123: Subtraction

    RIGOL Subtraction Subtract the waveform voltage values of signal source B from A point by point and display the results. Press MATH  Operate to select “A-B”: Press Source A and Source B to select the desired channels. The channels ...

  • Page 124: Division

    RIGOL Division Divide the waveform voltage values of signal source A by B point by point and display the results. It can be used to analyze the multiple relationships of waveforms in two channels. Note that when the voltage value of channel B is 0, the result of the division is treated as 0.

  • Page 125: Fft

    RIGOL FFT is used to quickly perform Fourier transform on specified signals and transform time domain signals to frequency domain signals. Use FFT to facilitate the following works: Measure harmonic components and distortion in the system  Measure the characteristics of the noise in the DC power ...
  • Page 126 RIGOL 2. Select Window Function Spectrum leakage can be considerably decreased when a window function is used. DS6000 provides four kinds of FFT window functions with different characteristics and are applicable to measure different waveforms. You need to select the window function according to different waveforms and characteristics.
  • Page 127 RIGOL Full Screen: the source channel and the FFT operation results are displayed in the same window to view the frequency spectrum more clearly and to perform more precise measurement. Note that in FFT mode and when MATH is the active channel, you can also press HORIZONTAL SCALE to switch to “Split”...

  • Page 128: Logic Operation

    RIGOL Logic Operation Perform logic operation on the waveform voltage values of the specified source point by point and display the results. In operation, when the voltage value of the source channel is greater than 0, it is regarded as logic “1”, otherwise logic “0”. Following...
  • Page 129 RIGOL Press MATH  Operate to select “Logic”: Press Expression to select the desired operation expression and the default is  AND. Press Source A and Source B to select the desired channels. The channels  available are CH1, CH2, CH3 and CH4.

  • Page 130: Advanced Operation

    RIGOL Advanced Operation DS6000 provides advanced operation function that allows user-defined operation functions. Press MATH  Operate  Advance  Expression  On, and the editing window as shown in the figure below pops up on the screen. Turn to select any item ( if they are currently available for selection) in “Channel”, “Function”, “Variable”, “Operator”...
  • Page 131 RIGOL 1. Expression Here, it refers to the formulas formed by channel, function, variable, operator and figure. The length of the expression is limited to 64 bytes. 2. Channel You can select one or more channels from CH1, CH2, CH3 and CH4.
  • Page 132 RIGOL variable. After setting the “Step” or pressing this softkey, turn the knob to modify this parameter. The range available is from -9.9999 to 9.9999. Exponent: press this softkey to set the numeric values of the exponents  with 10 as the mantissa in the variables. The range is from -9 to 9.

  • Page 133: Auto Measurement

    RIGOL Auto Measurement DS6000 provide auto measurements of 22 waveform parameters and the statistic and analytical functions of the measurement results. What’s more, you can also use the frequency counter to realize more precise frequency measurement. MENU MEAS DS6000 User’s Guide...

  • Page 134: Quick Measurement After Auto

    RIGOL Quick Measurement after Auto When the oscilloscope is correctly connected and has detected input signal, press Auto to display the waveform automatically and open the following function menu: Single-period: measure the “Period” and “Frequency “of the current signal within a single period and display the measurement results at the bottom of the screen.

  • Page 135: One-Key Measurement Of 22 Parameters

    RIGOL One-key Measurement of 22 Parameters Press the MENU key at the left of the screen to turn on the measurement menu of the 22 parameters and then press the corresponding menu softkey to quickly realize “One-key” measurement. The measurement result will be displayed at the bottom of the screen.
  • Page 136 RIGOL Time Parameters RiseTime FallTime -Width +Width 1. Period: defined as the time between the two crossing points of the middle threshold values of two continuous edges with the same polarity. 2. Frequency: defined as the reciprocal of period. 3. Rise Time: the time that the signal amplitude rises from 10% to 90%.
  • Page 137 RIGOL Delay and Phase Period Source A Delay Source B 1. Delay A→B : the time deviation between the rising edges of source A and source B. Negative delay means that the rising edge of source A appears later than that of source B.
  • Page 138 RIGOL Voltage Parameters Overshoot Vmax Vtop Vamp Vbase Vmin Preshoot 1. Vmax: the voltage value from the highest point of the waveform to the GND. 2. Vmin: the voltage value from the lowest point of the waveform to the GND.
  • Page 139 RIGOL 9. Overshoot: the ratio of the difference of the maximum value and top value of the waveform to the amplitude value. 10. Preshoot: the ratio of the difference of the minimum value and base value of the waveform to the amplitude value.

  • Page 140: Frequency Counter Measurement

    RIGOL Frequency Counter Measurement The hardware frequency counter supplied with this oscilloscope can make more precise measurement of the signal frequency. Press MEAS  Counter to select anyone of CH1-CH4 as the source. The measurement result is displayed at the upper right corner of the screen and you can identify the current measurement source according to the color of the icon.

  • Page 141: Measurement Setting

    RIGOL Measurement Setting 1. Source Selection Press MEAS  Source to select the desired channel for measurement (CH1-CH4). The color of the parameter icon under the MENU at the left of the screen will change with the source selected. 2. Measurement Range Press MEAS ...
  • Page 142 RIGOL Press MEAS  Meas Setting  Type  “Phase” and then press Source A and Source B to set the two channel sources (CH1-CH4) of the phase measurement respectively. 5. Threshold Measurement Setting Specify the vertical level (in percentage) being measured in the analog channel.

  • Page 143: Clear The Measurement

    RIGOL Clear the Measurement If you have currently turned on one or more items in the 22 measurement parameters, you can “Delete” or “Recover” the 5 parameters ahead or “Delete” or “Recover” all the measurement items that have been turned on. Note that the 5 parameters ahead is determined according to the order in which you turned them on and they will not change as you delete one or more measurement items.

  • Page 144: All Measurement

    RIGOL All Measurement All measurement could measure all the time and voltage parameters (totally 18) of the current measurement source and display the results at the bottom of the screen. Press MEAS  Display All to turn the function on or off.

  • Page 145: Statistic Function

    RIGOL Statistic Function Make statistic and display the current, average, minimum (or standard deviation) and maximum (or count) values of at most 5 measurement items that are turned on last. Press MEAS  Statistic to turn the statistic function on or off.

  • Page 146: Measurement History

    RIGOL Measurement History To view the history measurement data, press MEAS MeasHistory  MeasHistory  “On”. The history data can be displayed in two modes: Graph: display the results of the last 10 measurements of at most 5  measurement items that are turned on last in graph mode. The measurement points are connected using linear interpolation.

  • Page 147: Cursor Measurement

    RIGOL Cursor Measurement Cursors are the horizontal and vertical marks that can be used to measure the X axis values (usually Time) and Y axis values (usually Voltage) on a selected waveform. Please connect the signal to the oscilloscope and obtain stable display before using cursor measurement.

  • Page 148: Manual Mode

    RIGOL Manual Mode In this mode, a pair of cursors will appear. You can adjust the cursors to measurement the X (or Y), X increment (or Y increment), and reciprocal of the X increment on the selected source (CH1-CH4 or MATH).
  • Page 149 RIGOL 3. Select X (Y) Axis Unit When the cursor type is “Time”, press Time Unit to select “s”, “Hz”, “°” or “%”. S: when this unit is selected, in the measurement results, the CurA, CurB  and △X are in “s” and 1/△X is in “Hz”.
  • Page 150 RIGOL 5. Measurement Example Use manual cursor measurement to measure the period (△X) of a square waveform and the result is 1 ms equal to the result from auto measurement. Cursor Measurement Auto Measurement DS6000 User’s Guide 6-30...

  • Page 151: Track Mode

    RIGOL Track Mode In this mode, one or two pairs of cursors will appear. You can adjust the two pairs of cursors to measure the X and Y values on two different sources respectively. The points being measured on cursor A and B are marked by an orange rectangle and rhombus respectively.
  • Page 152 RIGOL operation results (MATH) as the measurement source of cursor B (only channels that are turned on are available). You can also select “None”, namely do not use cursor B. 2. Adjust Cursor Position Adjust cursor A: press CursorA and use to adjust the position of cursor ...
  • Page 153 RIGOL Cursor Track (Before Horizontal Expansion): Cursor Track (After Horizontal Expansion): DS6000 User’s Guide 6-33...

  • Page 154: Auto Mode

    RIGOL Auto Mode In this mode, one or more cursors will appear. You can use auto cursor measurement to measure anyone of the 22 waveform parameters. Before using this mode, you need to at least turn on one auto measurement parameter and the number of cursors will change with the measurement parameters.

  • Page 155: Protocol Decoding

    RIGOL 7 Protocol Decoding Protocol analysis can be used by users to discover errors, debug hardware and accelerate development easily, so as to guarantees quick and high-quality accomplishment of projects. Protocol decoding is the basis of protocol analysis. Only protocol analyses with correct protocol decoding are acceptable and only correct protocol decoding can provide more error information.

  • Page 156: Parallel Decoding

    RIGOL Parallel Decoding Parallel bus consists of clock line and data line. As shown in the figure below, CLK is the clock line, while Bit0 and Bit1 are the 0 bit and 1 bit on the data line respectively. Bit0...
  • Page 157 RIGOL Next, press Channel to specify a channel source for the bit currently selected in ChanBits. 3. Analog Channel Threshold Setting To judge logic “1” and logic “0” of the buses, you need to set a threshold for each analog channel (CH1, CH2, CH3 and CH4). When the signal amplitude is greater than the preset value, it is considered as “1”, otherwise “0”.

  • Page 158: Rs232 Decoding (Option)

    RIGOL RS232 Decoding (Option) RS232 serial bus consists of the transmitting data line (TX) and the receiving data line (RX). DeviceA DeviceB The industry standard of RS232 uses “Negative Logic”, namely high level is logic “0” and low level is logic “1”.
  • Page 159 RIGOL Data Bits Start Bit: represent when the data starts outputting. Setting the Polarity is equivalent to having specified the “Start Bit”. Data Bits: represent the number of data bits actually contained in each frame of data. Even-OddCheck: be used to check the correctness of the data transmission.
  • Page 160 RIGOL 5. Data Packet Setting As mentioned before, in RS232, you need to set the start bit, the data bits, the check bit (optional) and the stop bit of each frame of data. “Start Bit” has been specified by the “Polarity Setting”. The setting methods of other parameters are introduced below: Press Data Bits to set the data width of each frame.
  • Page 161 RIGOL Check Error: When check errors are detected during the decoding, the data will be filled with red batches. For example: when the transmitting terminal is set to none check and the decoder is set to odd check, the following errors appear:...

  • Page 162: Spi Decoding (Option)

    RIGOL SPI Decoding (Option) SPI serial bus consists of chip select line (SS), clock line (SCLK), MISO and MOSI. SCLK MISO MISO Host Device MOSI MOSI MISO SCLK SCLK MOSI SS: select positive or negative polarity. When positive polarity is selected, low level is valid.
  • Page 163 RIGOL Press SCLK to turn on the clock line setting interface. Press Channel to select any channel (CH1-CH4) as the clock channel.  Press Slope to set to sample MISO and MOSI on the rising edge or falling  edge of SCLK.
  • Page 164 RIGOL with red patches. For example, when Data Bits is set to 8, and SCLK slope is set to rising edge, deording error will be generated. 8 bits no enough DS6000 User’s Guide 7-10...

  • Page 165: I2C Decoding (Option)

    RIGOL I2C Decoding (Option) I2C serial bus consists of the clock line (SCLK) and the data line (SDA). SCLK Device Host SCLK SCLK: sample the SDA on the clock rising edge or falling edge. SDA: denote the data channel. Press MATH  BUS1  Decode to select “I2C” and turn the I2C decoding function menu on.
  • Page 166 RIGOL Press Offset and use to adjust the vertical display position of the bus. Press BusStatus to turn the bus display on or off. 4. Error Expressions during Decoding In I2C bus, the front part of each frame of data contains the address information and blue patches are used to represent address ID.

  • Page 167: Can Decoding (Option)

    RIGOL CAN Decoding (Option) Press MATH  BUS1  Decode and select “CAN” to open the CAN decoding function menu. 1. Source Press the Source softkey and select any channel (CH1-CH4) as the source channel. 2. Signal Type Press the Signal Type softkey to select the desired signal type.
  • Page 168 RIGOL 5. Threshold Refer to the introduction in Parallel Decoding. 6. Display-related Setting Press the Ary softkey and set the bus display format to Hex, Decimal, Binary or ASCII. Press the Offset softkey and use to adjust the vertical display position of the bus.

  • Page 169: Reference Waveform

    RIGOL 8 Reference Waveform In actual testing process, the waveform being tested can be compared with the reference waveform module to judge the reasons for failures. The contents of the chapter: To Enable REF Function  To Select REF Source ...

  • Page 170: To Enable Ref Function

    RIGOL To Enable REF Function Press the REF function key in the vertical control area (VERTICAL) at the front panel to enable REF function. Note that when the time base is in X-Y mode, REF function can not be enabled.

  • Page 171: To Select Ref Source

    RIGOL To Select REF Source Press Current and use to select any reference channel (Ref1-Ref10) that has been turned on and then press Source to specify a reference source (CH1-CH4, MATH) for this channel. To Save to Internal Memory Press Save to save the waveform (screen region) in the specified source to internal memory as reference waveform and display it on the screen.

  • Page 172: To Export To Internal Or External Memory

    RIGOL To Export to Internal or External Memory Users can also save the reference waveform to the Flash memory inside the instrument or to the external USB flash device. The file format of the reference waveform is “*.ref”. At most 10 reference files (LocalREF1.ref to LocalREF10.ref) can be saved inside the instrument.

  • Page 173: Pass/Fail Test

    RIGOL 9 Pass/Fail Test Monitor the change of the signal by judging whether the input signal is within the creation mask. The monitor information can be displayed on the screen as well as be prompted by the system sound or the pulse signal output from the [Trig Out/Calibration] connector at the rear panel.

  • Page 174: To Enable Pass/Fail Test Function

    RIGOL To Enable Pass/Fail Test Function Press UTIL  Pass/Fail to turn on the Pass/Fail test menu. Note that when the time base is in X-Y mode, the Pass/Fail test function can not be enabled. UTIL To start testing, press Operate. Select “ ” to start testing and select “■” to stop testing.

  • Page 175: To Select Source

    RIGOL To Select Source Press Source to select the channel (CH1-CH4) to be tested. During the test, the oscilloscope will judge whether each frame of waveform in the source complies with the current test mask and those waveforms pass through the mask area is considered as failed.

  • Page 176: To Save The Test Mask

    RIGOL are detected. The test results on the screen will update continuously and the [Trig Out/Calibration] connector at the rear panel will output a pulse each time a failed waveform is detected. Press Output to select “Fail” or “Fail+ ”.

  • Page 177: 10 Waveform Recording

    RIGOL 10 Waveform Recording Waveform recording can record the waveforms in the input channels (CH1-CH4). Waveform backplay and waveform analysis can provide better waveform analysis effect. The contents of this chapter: Waveform Recording  Waveform Playback  Waveform Analysis ...
  • Page 178 RIGOL Waveform Recording Waveforms from all the channels currently turned on will be recorded during waveform recording. WaveFinder (Playback) UTIL Play/Pause (Playback) Stop Recording/Playback Record (Record) Press UTIL  Record  Mode and use to select “Record” to turn the waveform recording operation menu on.
  • Page 179 RIGOL 4. Maximum End Frame The menu shows the maximum end frame that can be recorded currently. As the capacity of the waveform memory is fixed, the more the number of points of each frame of waveform has, the less the number of waveform frames can be recorded.

  • Page 180: Waveform Playback

    RIGOL Waveform Playback Waveform playback can play back the waveforms currently recorded. Press UTIL  Record  Mode and use to select “Play Back”. At this point, the information as shown in the figure below is displayed at the upper left corner of the screen, indicating the specific frame currently displayed on the screen.
  • Page 181 RIGOL 5. End Frame Press this softkey and use to set the end frame of the playback. The default is the number of frames of the waveform to be played back. 6. Playback Operation Waveform playback can be realized through the shortcut buttons in the menu or at the front panel.

  • Page 182: Waveform Analysis

    RIGOL Waveform Analysis This function is used to analyze the recorded waveform. Press UTIL  Record  Mode and use to select “Analyze” to open the waveform analysis menu. At this point, the screen is divided into two display areas as shown in the figure below.
  • Page 183 RIGOL 3. Start Press the Satrt softkey or press the Run/Stop key to enable waveform analysis. Note that during the analysis process, the progress bar is displayed and the parameters can not be modified. After the analysis finishes, the analysis results of “Error Frames”, “Current Error”...
  • Page 184 RIGOL 5. Previous After the waveform analysis finishes, press the Previous softkey can locate the error frame before the current error frame. Pressing the Run/Stop button can also perform the operation. 6. Next After the waveform analysis finishes, press the Next softkey can locate the error frame following the current error frame.

  • Page 185: Analysis Based On Trace

    RIGOL Analysis Based on Trace Press the Analyze softkey and select “Trace”. Then, set the templet used in analysis based on trace through the method below. 1. Trace Press the Trace softkey to select the creation method of analysis templet.

  • Page 186: Analysis Based On Pass/Fail Mask

    RIGOL Analysis Based on Pass/Fail Mask Press the Analyze softkey and select “Pass/Fail”. Then, set the templet used in analysis based on Pass/Fail mask through the method below. 1. X Mask Press this softkey and use to adjust the horizontal threshold and the range is from 0.02 div to 4.00div.

  • Page 187: 11 Display Control

    RIGOL 11 Display Control You can set the type, the persistence time and the brightness of waveform display as well as the grid type, grid brightness of the screen display and the menu display time. The contents of this chapter: To Select the Display Type ...

  • Page 188: To Select The Display Type

    RIGOL To Select the Display Type DISP Press DISP  Type to set the waveform display mode to “Vectors” or “Dots”. Vectors: the sample points are displayed in connecting line mode. Normally, this  mode can provide the most vivid waveform to view the steep edge of the waveform (e.g.

  • Page 189: To Set The Persistence Time

    RIGOL To Set the Persistence Time Press DISP  Persis. Time to set the persistence time of the oscilloscope to Vmin, specific values (From 50 ms to 20 s) or Infinite. In the following part, a frequency sweep signal of the sine waveform is used to demonstrate the waveform effects in different persistence times.
  • Page 190 RIGOL 3. Infinite In this mode, the oscilloscope displays the waveform newly acquired without clearing the waveforms acquired formerly. The waveforms acquired formerly will be displayed in relatively low-brightness color and the waveform newly acquired will be displayed in normal brightness and color. Infinite persistence can be used to measure noise and jitter and to capture incidental events.

  • Page 191: To Set The Waveform Brightness

    RIGOL To set the Waveform Brightness Press DISP  WaveIntensity or turn in normal operation mode to adjust the waveform brightness of the analog channel. The default is 50% and the range available is from 0% to 100%. To Set the Screen Grid Press DISP ...

  • Page 193: 12 Store And Recall

    RIGOL 12 Store and Recall Users can save the current settings, waveforms, and screen image in internal memory or external USB mass storage device (e.g. USB flash device) in various formats and recall the stored settings or waveforms when needed.

  • Page 194: Storage System

    RIGOL Storage System Press SAVE to enter the store and recall setting interface. SAVE Insert the USB flash device This oscilloscope provides two USB Host interfaces at the front and rear panel to connect USB flash storage device for external storage. The USB flash storage device connected is marked with “Disk E”...

  • Page 195: Storage Type

    RIGOL Storage Type Press SAVE  Storage to select the desired storage type. The default is “Traces”. The store and recall descriptions of each type are as follows: 1. Traces Save the data in internal or external memory in “*.trc” format.
  • Page 196 RIGOL One-key Bitmap Saving After a USB flash device is connected, press the print key at the front panel to quickly save the current screen image under the root directory of the USB flash device in bitmap mode (*.bmp). 5. CSV Save the waveform data displayed on the screen or of the specified channels in external memory in a single “*.csv”...

  • Page 197: Internal Store And Recall

    RIGOL Internal Store and Recall Internal store and recall support “Traces”, “Waveforms” and “Setups” in Storage. In the following part, “Traces” are taken as an example for illustration. 1. Save the specified type of file in internal memory. 1) Connect the signal to the oscilloscope and obtain stable display.
  • Page 198 RIGOL Figure b Note that in internal storage, New menu is not available. 2. Load the specified type of file in the internal memory. 1) Press SAVE  Storage to select “Traces” and then press Load to turn on the interface as shown in Figure c. Use to select “Local Disk”...
  • Page 199 RIGOL Figure d DS6000 User’s Guide 12-7...

  • Page 200: External Store And Recall

    RIGOL External Store and Recall Before using external store and recall, make sure that a USB flash device is connected correctly. External storage supports all the types of files in Storage but in recall, “Picture” and “CSV” are not supported.
  • Page 201 RIGOL Figure f 4) After the storage position is selected, press New to turn on the interface as shown in Figure g. Refer to the descriptions in “To Create a New File or Folder” to create a new file name.
  • Page 202 RIGOL Figure h 2) As shown in Figure i, use to select the desired file to load and then press Load to load the selected file. Figure i DS6000 User’s Guide 12-10...

  • Page 203: Disk Management

    RIGOL Disk Management Press SAVE  Disk.Manage to turn on the disk management interface as shown in the figure below and use to select the desired disk. The disk currently selected is displayed in green and press to turn on the selecte diskd.

  • Page 204: To Create A New File Or Folder

    RIGOL To Create a New File or Folder This operation is only valid in external storage. Before using external store and recall, make sure that a USB flash device is connected correctly. First, press SAVE  Disk Manage and use to select and turn on the external disk (“Disk D”...
  • Page 205 RIGOL English Input Method For example: create a file or folder using the name “Filename”. 1. Press Keyboard. 1) Use to select English input method “En” and uppercase input state “ A”. 2) Use to input the letter “F”. If the input is wrong, press Delete to delete the character input.
  • Page 206 RIGOL Chinese Input Method For example: create a file or folder using the name “文件名”. 1. Press Keyboard. 1) Use to select Chinese input method “中” and lowercase input state “ Aa”. Note that the “Chinese” menu is added in the menu items at the right of the screen.

  • Page 207: To Delete A File Or Folder

    RIGOL To Delete a File or Folder Folder operation is valid only in external storage. Before using the external disk, make sure that a USB flash device is connected correctly. 1. Delete a file in internal memory. 1) Press SAVE  Disk Manage and use to select and turn on the local disk (“local Disk”).

  • Page 208: To Copy And Paste A File

    RIGOL To Copy and Paste a File You can copy a file in the local disk to the external disk or copy a file in one external disk to another external disk. Before using the external disk, make sure that a USB flash device is connected correctly.

  • Page 209: Factory

    RIGOL Factory Press SAVE  Factory to return the oscilloscope to its factory state. Refer to the table below. Table 12-2 Factory Parameter Factory Horizontal Setting (HORIZONTAL Channel Setting (VERTICAL Acquisition Setting (ACQ Trigger Setting (TRIGGER Display Setting (DISP Cursor Setting (CURS...
  • Page 210 RIGOL Bandwidth Input Impedance 1 MΩ Channel Invert Vertical Scale Coarse Channel Unit Acquisition Setting (ACQ) Acquisition Mode Normal Sampling Mode Real Time Memory Depth Auto Trigger Setting (TRIGGER) Trigger Type Edge Source Slope Rising Edge Trigger Mode Auto Trigger Coupling...
  • Page 211 RIGOL Track Cursor A Cursor B CurA -4*1 us CurB 4*1 us Storage Setting (SAVE) Storage Type Traces Utility Function Setting (UTIL) I/O Setting Network DHCP, Auto IP Configuration Mode USB Device Computer Sound Sound Pass/Fail Test Enable Test Source...
  • Page 212 RIGOL Power On Recall Last Vertical Expansion Ground Screen Saver Default Screen Saver Time OFF External Trigger 1 MΩ Impedance TrigOut Reference Clock ClockOutput Math Operation Setting (MATH->Operation) Operate Source A Source B Invert Scale Source A Source B Invert...
  • Page 213 RIGOL Vertical Scale 10 dB Vrms/div Vertical Scale 1.25 MHz Sample Rate 50 MSa/s Logic Operation Expression Source A Source B Invert Scale Advanced Operation Expression Expression CH1+CH2 Vertical Scale Protocol Decoding (MATH->BUS1/BUS2) Decoding Type Parallel BUS Status Offset Threshold...
  • Page 214 RIGOL Packet End NULL SS Channel SS Polarity Positive SCLK Channel SCLK Slope Rising Edge MISO Channel MISO Channel Positive MOSI Channel MOSI Polarity Positive MOSI Data Bits MOSI Endian SCLK Reference Waveform Setting (REF) Channel Setting REF1 Current Channel...

  • Page 215: 13 System Function Setting

    RIGOL 13 System Function Setting The contents of this chapter: Remote Interface Configuration  System-related  To Print the Waveform  13-1 DS6000 User’s Guide...

  • Page 216: Remote Interface Configuration

    Remote Interface Configuration DS6000 can communicate with PC via LAN, USB and GPIB (together with the USB to GPIB module of RIGOL) buses. Please refer to the introduction below to configure the corresponding interface before using the remote interfaces. LAN Setting Press UTIL ...
  • Page 217 RIGOL IP Configuration Type (DHCP) The configuration type of the IP address can be DHCP, auto IP or static IP. In different IP configuration type, the configuration mode of the network parameters such as the IP address is different. Press Config Mode and use to select “DHCP”.
  • Page 218 RIGOL nnn is from 0 to 223 (except 127) and the ranges of the other three nnn are from 0 to 255. You are recommended to ask your network administrator for an IP address available. Press IP Address and use to input the desired IP address.
  • Page 219 RIGOL range of the first nnn is from 0 to 223 (except 127) and the ranges of the other three nnn are from 0 to 255. You are recommended to ask your network administrator for an address available. press DNS and use to input the desired address.

  • Page 220: Usb Device

    RIGOL USB Device This oscilloscope can communicate with a PC or PictBridge printer via the USB Device interface at the rear panel. You need to set the oscilloscope to make it match with different device types. Press UTIL  IO Setting  USB and use to select the desired device type.

  • Page 221: System-Related

    RIGOL System-related Sound When the sound is enabled, you can hear the sound of the beeper when you press a function key or a menu softkey or when the prompt message pops up. Press UTIL  Sound to select (on) or (off).

  • Page 222: Power-Off Recall

    RIGOL Power-off Recall You can set the system configuration to be recalled when the oscilloscope is powered on again after power-off. Press UTIL  System  Power On to select “Last” (default) or “Default”. Last: return to the setting of the system at last power-off.
  • Page 223 RIGOL Year: 2000 to 2099  Month: 01-12  Date: 01-31 (28, 29 or 30)  Hour: 00 to 23  Minute: 00 to 59  Second: 00 to 59  Press Apply to put the current setting into effect. The time at the lower right corner of the screen will be updated.

  • Page 224: Self-Calibration Information

    RIGOL Self-calibration Information Press UTIL  System  SelfCalInfo to view the result of the last self-calibration of the oscilloscope. The self-calibration result usually contains the contents as shown in the figure below. Note: If the oscilloscope is installed with battery, the self-calibration information will also display the electric quantity, voltage and current of the battery.

  • Page 225: Screen

    Press UTIL  System  Screen to turn on the screen saver setting menu. “Default” means using the icon RIGOL as the screen saver icon. Press Time to select the time of the screen saver. When “OFF” is selected, the screen saver program is disabled.

  • Page 226: Error Information

    RIGOL Error Information If this menu is shown in gray, it means that the circuit board of the oscilloscope is working normally. Otherwise, an exclamation mark will be displayed in the status bar at the lower right corner of the screen, indicating that there is error information currently and at this point, press this key (press UTIL ...

  • Page 227: Self-Calibration

    RIGOL Self-calibration Self-calibration program can quickly help the oscilloscope to reach the best working state and get the most precise measurement values. You can perform self-calibration at any time especially when the change range of the environment temperature is up to or more than 5 ℃.

  • Page 228: Power Status

    RIGOL Power Status Users can set the power status of the oscilloscope after power-on. Connect the oscilloscope to the AC source using the power cord and turn on the power switch at the rear panel, the oscilloscope is powered on.

  • Page 229: Aux Output

    RIGOL Aux Output Users can set the signal type output from the [Trig Out/Calibration] connector at the rear panel. Press UTIL  AuxOutput to select the desired output type. 1. TrigOut After this type is selected, the oscilloscope output a signal that can reflect the current capture rate of the oscilloscope at each trigger.

  • Page 230: Reference Clock

    RIGOL Reference Clock This oscilloscope can output the internal 10 MHz sample clock from the [10MHz In/Out] connector at the rear panel and accept an external 10 MHz clock to synchronize multiple oscilloscopes. 10MHz In/Out Press UTIL  RefClock to select the desired clock type.

  • Page 231: Option Management

    Option Management This oscilloscope provides multiple options to fulfill your measurement requirements. Please contact your RIGOL sales representative or RIGOL technical support to order the corresponding options. You can view the options currently installed on the oscilloscope or activate the newly bought option serial number through the menu.

  • Page 232: To Print The Waveform

    RIGOL To Print the Waveform To Connect the Print Device DS6000 oscilloscope supports normal and PictBridge printers and you can set the print parameters to print the current screen image. The connection modes of different print devices are different. Use the USB Host interface to connect normal printer and use the USB Device interface to connect the PictBridge printer.

  • Page 233: Normal Print

    RIGOL Normal Print After “Normal” is selected, please refer to the following steps to set the print parameters to execute print. 1. Print Range Press this softkey to select “Screen” (default) or “Wave”. Screen: print the whole screen image. ...

  • Page 234: Pictbridge Print

    RIGOL PictBridge Print PictBridge is a new print standard. If your oscilloscope and the printer both comply with the PictBridge standard, you can connect the oscilloscope to the printer using a USB cable to print the screen image directly. Devices complies with the PictBridge standard always have the icon as shown in the figure on the right.
  • Page 235 RIGOL function. 7. Quality Press this softkey to select the print quality. You can select: Default, Normal, Draft or Fine. Note that the selection is unavailable when the printer does not support this function. 8. Date Press this softkey to turn the date print on or off. Note that this attribute is the built-in attribute of the PictBridge printer.

  • Page 237: 14 Remote Control

    This oscilloscope can communicate with PC through USB, LAN and GPIB (together with the USB to GPIB module of RIGOL) instrument buses. This chapter will give a detailed introduction of how to use Ultra Sigma to control DS6000 remotely through various interfaces.

  • Page 238: Remote Control Via Usb

    RIGOL Remote Control via USB 1. Connect the device Connect the oscilloscope (USB DEVICE) with your PC using a USB cable. 2. Install the USB driver This oscilloscope is a USBTMC device. Assuming that your PC has already been installed with Ultra Sigma, after you connect the oscilloscope to the PC and turn both on for the first time, the PC will display a New Hardware Wizard as shown in the figure below.
  • Page 239 RIGOL DS6000 User’s Guide 14-3...
  • Page 240 4. View the device resource The resources found will appear under the “RIGOL Online Resource” directory and the model number and USB interface information of the instrument will also be displayed as shown in the figure below.
  • Page 241 RIGOL DS6000 User’s Guide 14-5...

  • Page 242: Remote Control Via Lan

    LAN. During the search, the status bar of the software is as shown in the figure below: 4. View device resource The resources found will appear under the “RIGOL Online Resource” directory as shown in the figure below: DS6000 User’s Guide...
  • Page 243 RIGOL 5. Communication test Right click the resource name “DS6104 (TCPIP::172.16.3.88::INSTR)” to select “SCPI Panel Control” to turn on the remote control command control panel, namely you can use this panel to send commands and read data. As shown in the figure below: 6.
  • Page 244 RIGOL DS6000 User’s Guide 14-8...

  • Page 245: Remote Control Via Gpib

    RIGOL Remote Control via GPIB 1. Connect the device Use the USB to GPIB module to extend a GPIB interface for the oscilloscope. Then connect the oscilloscope to your PC using a GPIB cable. 2. Install the driver of GPIB card Install the driver of the GPIB card which has been connected to the PC correctly.
  • Page 246 RIGOL 5. View device resource Click “OK” to return back to the main interface of Ultra Sigma. The resources found will appear under the “RIGOL Online Resource” directory. 6. Communication Test Right-click the resource name “DS6104 (GPIB0::18::INSTR)” to select “SCPI Panel Control”...

  • Page 247: 15 Troubleshooting

    The commonly encountered failures and their solutions are listed below. When you encounter those problems, please solve them following the corresponding steps. If the problem remains still, please contact RIGOL and provide your device information (acquisition method: Utility  System  Sys Info).
  • Page 248 RIGOL (2) Check the trigger type: general signals should use “Edge” trigger and video signal should use “Video” trigger. Only when the proper trigger type is used, can the waveform be displayed stably. (3) Try to change the Coupling to “HF Reject”or “LF Reject” to filter out the high-frequency or low-frequency noise that disturbs the trigger.

  • Page 249: 16 Specifications

    RIGOL 16 Specifications All the specifications are guaranteed except the parameters marked with “Typical” and the oscilloscope needs to operate for more than 30 minutes under the specified operation temperature. Sample Sample Mode Real-time Sample, Equivalent Sample Real Time Sample...
  • Page 250 RIGOL Probe Attenuation 0.001X, 0.01X, 0.1X, 1X, 10X, 100X, 1000X Coefficient Maximum Input Maximum Input Voltage of the Analog Channel Voltage (1MΩ) CAT I 300 Vrms, CAT II 100 Vrms, Transient Overvoltage 1000V pk with RP2200 10:1 probe: CAT II 300 Vrms...
  • Page 251 RIGOL 230 mV/div to 5 V/div: ± 40V (1MΩ) Bandwidth Limit 20 MHz or 250 MHz Low Frequency Response ≤5 Hz (on BNC) (AC Coupling -3dB) Calculated Rise DS606X: 600 ps Time DS610X: 400 ps DC Gain Accuracy ± 2% full scale 200 mV/div to 5 V/div: 0.1 div ±...
  • Page 252 RIGOL Negative Slope (greater than, lower than, within specific interval) Time Setting 10 ns to 1 s Video Trigger Signal Standard Support standard NTSC, PAL and SECAM broadcasting Line Frequency standards, the range of the number of lines is from 1 to 525...
  • Page 253 RIGOL Trigger condition SOP, EOP, RC, Suspended, Exit Suspended Measure Cursor Voltage Deviation between Cursors (△ V) Manual Mode Time Deviation between Cursors (△ T) Reciprocal of △ T (Hz) (1/△ T) Track Mode Voltage and Time Values of the Waveform...
  • Page 254 RIGOL FFT Vertical Linear RMS, dBV RMS Scale Logic AND, OR, NOT, XOR Operation Math Function Intg, Diff, Log, Exp, Sqrt, Sine, Cosine, Tangent Number of Buses for Decoding Decoding Type Parallel (standard), RS232/UART (option), I2C (option) , SPI (DS6XX4 option), CAN (option)
  • Page 255 RIGOL Power Power Voltage 100-120 V/50Hz/60Hz/400Hz 100-240 V/50 Hz/60Hz Power Maximum 150W Fuse 3 A, T Degree, 250 V Environment Operating: 0 ℃ to +50 ℃ Temperature Range Non-operating: -20 ℃ to +70 ℃ Cooling Method fan cooling Under +35 ℃: ≤90％ Relative Humidity Humidity Range +35 ℃...

  • Page 257: 17 Appendix

    RS232/UART Decoding Kit SD-RS232-DS6 I2C Decoding Kit SD-I2C -DS6 Decoding SD-SPI-DS6 (for Options SPI Decoding Kit DS6XX4 only) CAN Decoding Kit SD-CAN-DS6 NOTE: All the options or accessories can be ordered from you local RIGOL Office. 17-1 DS6000 User’s Guide...

  • Page 258: Appendix B: Warranty

    To get repair service and a complete copy of the warranty description, please contact with your nearest RIGOL sales and service office. RIGOL does not provide any other warranty items except the one being provided by this summary and the warranty statement. The warranty items include but not being subjected to the hint guarantee items related to tradable characteristic and any particular purpose.

  • Page 259: Appendix C: Any Comment Or Question

    RIGOL Appendix C: Any Comment or Question? If you have any comment or question on our document, please send email to: service@rigol.com DS6000 User’s Guide 17-3...

  • Page 261: Index

    RIGOL Index Acquisition Mode ......4-2 Manual Mode ......6-28 Addition ........6-2 Memory Depth ......4-8 AND .......... 6-8 Multiplication ......6-3 13-3 Network Status ......13-2 Auto IP ........Auto Mode ....... 6-34 Normal ........4-2 Aux Output ......13-15 NOT ..........
  • Page 262 RIGOL Track Mode ......6-31 Vertical Expansion ....... 2-8 Trigger Coupling ......5-5 Vertical Scale ......2-7 Trigger Holdoff ......5-6 Video Trigger ......5-15 Trigger Level ......5-9 Waveform Analysis ....10-6 Trigger Mode ......5-3 Waveform Invert ......2-7 Trigger Position ......

This manual is also suitable for:

Ds6062Ds6000 seriesDs6104Ds6064

Table of Contents
