4.3.13 Serial Breakout Header Connector (J17)

The serial breakout header connector J17 of the Portenta Mid Carrier can be used to debug the SERIAL1 interface.
Pin Number Silkscreen
1
2
3
4
5
21 / 30
Power Net
N/A
N/A
N/A
N/A
N/A
Portenta HD Standard Pin
SERIAL1_RX
SERIAL1_TX
SERIAL1_RTS
SERIAL1_CTS
GPIO_6
Arduino® Portenta Mid Carrier
Arduino® Portenta Mid Carrier
High-Density Pin
J1-35
J1-33
J1-37
J1-39
J2-58
Interface
UART 1 RX
UART 1 TX
UART 1 RTS
UART 1 CTS
