- Page 1 English User manual IVP 7000 EX...
- Page 2 Congratulations, you have just purchased a product with Intelbras quality and safety. The IVP 7000 EX motion sensor features passive infrared ray detection technology, adopting advanced sig- nal analysis technology to prevent accidental triggering in high-risk intrusion environments. The IVP 7000 EX sensor has dust protection, water and white light immunity, which makes it perfect for the harshest en- vironments, and can be installed in semi-open and outdoor environments.
- Page 3 Care and safety » LGPD – Data processing by Intelbras: Intelbras does not access, transfer, capture or perform any type of proces- sing of personal data from this product. » Do not touch the surface of the infrared (PIR) sensor. If necessary, use a soft, dry cloth for cleaning.
- Page 4 » The sensor must be installed where an intruder can be easily detected, that is, where it moves transversely to the detection beams. » The sensor must be installed on a flat, fixed, flicker-free surface, with a height between 2.0 and 2.2 meters. It is recommended to install the sensor parallel to the wall for the greatest detection range.
-
Page 5: Table Of Contents
Summary 1. Technical specifications 2. Features 3. Product 4. Installation 4.1. Installation without using the articulator ..........8 4.2. Installation with or use of the articulator . -
Page 6: Technical Specifications
1. Technical specifications Operating voltage 9 ~16 Vdc Operating current 30 mA Consumption 480 mW Detection angle 110° Detection range (PIR and MW) 12 metros Detection method Number of pyroelectric sensors Pyroelectric sensor type Dual Animal immunity Up to 30 kg 1P - Maximum Sensitivity 2P –... -
Page 7: Product
3. Product Pyro sensor Tamper key LED light conductor LED jumper Fresnel lens Sensitivity key Product basis Connection terminal 10. Cable passage 4. Installation » Before starting the installation, it is necessary to define the height at which the sensor will be positioned, which can vary from 2 to 2.2 m;... -
Page 8: Installation Without Using The Articulator
4.2. Installation with or use of the articulator » The IVP 7000 EX sensor is accompanied by the XSA 1000 support. Follow the steps below for its correct use. This support was designed to adapt perfectly to most presence sensors available on the market. It offers a wide tar- geting angle, support for routing wiring and UV protection, making it suitable for indoor or outdoor installations. - Page 9 Technical specifications General characteristics Material Plastic with UV protection Weight Load capacity 1.5kg Installation environment Internal / External Dimensions (L × W × D) 99 × 58 × 64 Horizontal movement angle 160° Vertical movement angle 160° » Model 1: separate shaft and connector: ...
- Page 10 Installation » Insert the shaft into the ring (piece 1 and piece 2); » Pass the fixing nut through the assembly formed by parts 1 and 2 (using part 3); » Insert the nut into the connector (combining part 5 and part 6); ...
- Page 11 » Fix the base (part 4) in the location to be installed and tighten the fixing nut (part 3) clockwise. Model 2 Mounted stand Components Axle Fastening nut Ring Base Screw 3.5 x 9.5 mm Installation » Fix the axis (part 1) to the product, using the screws; ...
- Page 12 » Position the ring (piece 3) in the assembly above with the opening at the beginning of the shaft (piece 1). Rotate the ring to fit the shaft; » Position the product so that the markings are aligned; Marcações Markings ...
-
Page 13: Operating Mode Settings
Cable routing The XSA 1000 support has an opening for cable passage, if necessary. Follow the steps below for correct use. 1. Guide the cable through the designated passage; 2. Secure the cable using the two internal locks; 3. Route the cable through the hole located in the center of the base, towards the inside of the sensor that will be fixed. -
Page 14: Process Completion
» J.SENS switch – SENSITIVITY: controls the sensor detection sensitivity to trigger the alarm. This adjustment has three selectable levels, according to the following table. Properly choose the configuration according to the environment in which the sensor will be installed. Factory default: 2P medium sensitivity. -
Page 15: Test
6. Test Once installed and running, walk across the area to be protected, simulating a possible intrusion into the environment. See if the sensor is able to detect your movements during the journey, through the LEDs. Adjust the microwave’s sensitivity to the size of the room or reposition the sensor. Be sure to take all precautions and follow the installation recommendations to obtain the best operating performance from the product. -
Page 16: Warranty Term
7. Intelbras is not responsible for the installation of this product, or for possible attempts at fraud and/or sabotage in its products. Maintain the updates of the software and applications used up-to-date, if it is the case, as well as the network protection required for defense against hackers. - Page 17 Support via e-mail: suporte@intelbras.com.br Customer Service / Where to buy? / Who installs it? : 0800 7042767 Produced by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia BR 459, km 124, 1325 – Distrito Industrial – Santa Rita do Sapucaí/MG – 37540-000 CNPJ 82.901.000/0016-03 –...
