Summary of Contents for Intelbras IVP 5000 MW LD

  • Page 1 English User manual IVP 5000 MW LD...
  • Page 2 Passive infrared motion sensor with triple technology Congratulations, you have just purchased a product with Intelbras quality and safety. The IVP 5000 MW LD motion sensor combines microwave detection with passive infrared detection, adopting advanced signal analysis technology to prevent accidental triggering. Developed with a PIR QUAD sensor and semi-spherical Fresnel lens, it increases the efficiency of motion detection and reduces undetected areas below the sensor.

  • Page 3: Care And Safety

    » Follow all instructions in the manual for assembly and installation of the product. » LGPD – Data processing by Intelbras: Intelbras does not access, transfer, capture or carry out any type of processing of personal data using this product.
  • Page 4 » The sensor must be installed where the intruder can be easily detected, that is, where it makes movements transverse to the detection beams. » The sensor must be installed on a flat, fixed and vibration-free surface, with a height between 2.0 and 2.80 meters.

  • Page 5: Table Of Contents

    Summary 1. Technical specifications 2. Characteristics 3. Product 3.1. Support................4.

  • Page 6: Technical Specifications

    1. Technical specifications Operating voltage 9 ~16 Vdc Operating current 45 mA Detection angle 110° Detection range (PIR and MW) 15 meters Detection method Microwaves and PIR (AND) Quantity of pyroelectric sensors Pyroelectric model QUAD Microwave frequency 10,525 GHz Animal immunity Up to 15 kg Automatic (factory default) Sensitivity...

  • Page 7: Product

    3. Product 9 10 ALARME TAMPER 1. Front cover 2. LED driver 3. Semi-spherical lens 4. Seals for corner installation 5. Seals for wall installation 6. Seals for installation in 4×2 box 7. Closing screw 8. Wire passage seals or wall installation 9.

  • Page 8: Support

    3.1. Support Parede 1. Support base 2. Adapter for wall installation 3. Adapter for ceiling installation 4. M3 hex nut 5. M3×20 mm screw (fine thread) 6. Fixing screw 3.5×25 mm 7. 6 mm fixing bushing 4. Installation » Before starting installation, it is necessary to define the height at which the sensor will be positio- ned, which can vary from 2 to 2.80 m;...
  • Page 9 To install the sensor, follow the procedure below: 1. Remove the front cover of the sensor using a Philips screwdriver. It is not necessary to remove the entire screw, as shown in the image. ALARME TAMPER 2. Use the markings on the sensor base for cable routing and necessary connections. Note item 3 that there are other options for routing the cable.

  • Page 10: Installation Using The Articulator

    3. For installation directly on the wall, 4×2 box or in a wall corner, remove the seals indicated for the holes in the rear fixing cover. Wall mounted 4×2 box installation Mounted in the corner of the wall 4.1. Installation using the articulator Attention: installing the sensor at an angle to the ground may compromise the performance of the PET function.

  • Page 11: Installation Using Xsa 1000

    Use the fixing holes located on the base to fix the XSA 1000 articulator. For more information about the XSA 1000 articulator, consult the user manual on the website: www.intelbras.com.br The recommended screw for fixing articulators to the product is 3.5 × 9.5 mm.
  • Page 12 Microwave sensitivity adjustment The trimpot allows you to adjust the microwave sensitivity. Turning the trimpot clockwise increases the sensitivity and consequently the distance at which the microwave is capable of detecting movements. Turning it counterclockwise makes the microwave less sensitive. Note:it is highly recommended to adjust the microwave sensitivity so that detection only occurs in the environment where the sensor is installed.
  • Page 13 The figure below shows a reference microwave channel detection range. Factory default: 50% Microwave range ALARME TAMPER Trimpot position Maximum distance (meters) 0% - up to 1 meter 25% - up to 5 meters 50% - up to 12 meters 75% - up to 15 meters 100% - up to 18 meters 100%...
  • Page 14 Key 2 – SENSITIVITY: controls the sensitivity of the PIR to trigger the alarm. With the key in the ON position, the sensitivity is configured to avoid shots with little movement, that is, minimum sensitivity. This configuration is recommended for semi-open environments, places where ani mals circulate or environments with any interference that could cause unwanted shots.
  • Page 15 » Key 4 – ANTI-CAMOUFLAGE: monitors camouflage attempts. With the key in the ON position, anti-camouflage is enabled.With the key in the OFF position, anti-camouflage remains disabled. Anti-camouflage Position Condition Enabled Disabled Factory default: Disabled. Completion of the process Close the case, first fitting the top part of the front cover and going down perpendicularly towards the bottom of the sensor.

  • Page 16: Operation

    » Red LED: microwave Anti-camouflage The IVP 5000 MW LD is capable of detecting movements even if the individual uses some material to camouflage their body temperature. When carrying out this analysis and detecting movement, the sensor indicates the trigger through...

  • Page 17: Test

    6. Test Once installed and in operation, walk around the entire area to be protected, simulating a possible intrusion into the environment. Observe whether the sensor is capable of detecting your movements during the journey, using the LEDs. Adjust the microwave sensitivity according to the size of the room or reposition the sensor.

  • Page 18: Warranty Term

    7. Intelbras is not responsible for the installation of this product, and also for any attempted fraud and/or sabotage of its products. Keep software and applications updates up to date, if applicable, as well as the required network protections to protect against intrusions (hackers).
  • Page 19 Support via e-mail: suporte@intelbras.com.br Customer Service / Where to buy? / Who installs it?: 0800 7042767 Produced by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia BR 459, km 126, nº 1325 – Distrito Industrial – Santa Rita do Sapucaí/MG – 37538-400 CNPJ 82.901.000/0016-03 –...
