Summary of Contents for Intelbras IVP 4101 PET
- Page 1 User manual IVP 4101 PET smart...
- Page 2 Passive infrared sensor Congratulations, you have just purchased a product with Intelbras quality and safety. The passive infrared sensor IVP 4101 PET smart was developed by Intelbras with 100% digital technology. The sensor has an integrated Temperature Sensor to offer the same detection sensitivity in different environments (from -10 °C to + 50 °C)
- Page 3 Care and safety » This product is intended for Indoor environments. » It is important to note that the Pet function is designed for crawling animals, so if the animal is not on the ground, but on top of a bench, for example, it can be detected thus canceling the Pet function, as can be seen in the image below: »...
- Page 4 » We recommend that the sensor configuration is done according to item 5. Configuring the sensor IVP 4101 PET smart (for cards in version 4410350/5 and firmware 3.0.0) and item 8. Configuring the sensor IVP 4101 PET smart (for cards version 4410350/4 and firmware 2.2.1 o earlier).
-
Page 5: Table Of Contents
8.2. Setting the operating mode of the smart IVP 4101 PET sensor ...... -
Page 6: Technical Specifications
- 10 °C to + 50 °C Transmission frequency 433,92 MHz Sensitivity Levels Immunity to animals 20 kg Check item 4. Installing the smart IVP 4101 PET sensor in this manual Installation height Detection method Battery LITHIUM CR123A 3 V Supervision... -
Page 7: Detection Range
1,8 to 2,2 m Note: to install the IVP 4101 PET smart sensor, make sure that the battery is not connected to the board. The sensor IVP 4101 PET smart does not have an articulator. So for your installation, follow the procedure below:... - Page 8 Important: the IVP 4101 PET smart was designed for INDOOR AND CLOSED AREAS and with the presence of animals of up to 20 kg, so do not use it for protection of outdoor or open areas and with the presence of animals of more than 20 kg.
-
Page 9: Configuring The Ivp 4101 Pet Smart Sensor (For Cards In Version 4410350/5 And Firmware 3.0.0)
With jumper JP1 closed the sensor provides minimum sensitivity. Closed factory default. 5.2. Setting the operating mode of the smart IVP 4101 PET sensor Via the ECO/CONT jumper (JP2), select between intelligent continuous mode and economy mode. With jumper JP2 open the sensor is in intelligent continuous mode. -
Page 10: Ivp 4101 Pet Smart Sensor Supervision Adjustment
5.3. IVP 4101 PET smart sensor supervision adjustment The SUPERV (JP3) jumper is used to select between supervised (FSK) or unsupervised (OOK) modes. With jumper JP3 open the sensor is in supervised mode (FSK). With jumper JP3 closed the selected mode is unsupervised (OOK). The type of supervision to be used will depend on the receiver’s compatibility with the Control Panel. -
Page 11: Low Battery Sensor
6. Low battery sensor The IVP 4101 PET smart sensor controls the battery level. If it is critical (equal to or below 2.5V), it will send the information to the control panel. If the sensor is configured in unsupervised mode (OOK) and the low battery signal is enabled in the control unit, the information is sent during the trip. -
Page 12: Test
Adjust its sensitivity if necessary or reposition the sensor installation. If the alarm control panel used is Intelbras, put it in test mode, this way it will not be necessary to observe the LED, as the control panel will indicate the sensor’s operation through siren beeps. -
Page 13: Ivp 4101 Pet Smart Sensor Supervision Adjustment
50 sec 30 min 8.3. IVP 4101 PET smart sensor supervision adjustment The OOK/FSK jumper (JP3) is used to select the modulation. With jumper JP3 open the sensor is in supervised mode (FSK). With jumper JP3 closed the selected mode is unsupervised (OOK). The type of supervision to be used will depend on the receiver’s compatibility with the Control Panel. -
Page 14: Homologation
9. Homologation 3685-15-0160 This equipment operates on a secondary basis, that is, it is not entitled to protection against harmful interference, even from stations of the same type, and may not cause interference to systems operating on a primary basis. This is a product approved by Anatel, the approval number can be found on the product label, for queries go to the website: sistemas.anatel.gov.br/sch. -
Page 15: Warranty Term
8. After its useful life, the product must be delivered to an authorized Intelbras service center or directly disposed of in an environmentally appropriate manner to avoid environmental and health impacts. If you prefer, the battery, as well as other unused Intelbras brand electronics, can be disposed of at any Green Eletron collection point (waste management facility to which we are associated). - Page 16 Support via e-mail: suporte@intelbras.com.br Customer Service: 0800 7042767 Where to buy? Who installs it? 0800 7245115 Produced by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira 01.22 Rodovia BR 459, km 124, 1325 – Distrito Industrial – Santa Rita do Sapucaí/MG – 37540-000 CNPJ 82.901.000/0016-03 –...
