  • Page 1 English User manual IVP 5311 MW Pet...
  • Page 2 IVP 5311 MW Pet Passive infrared sensor Congratulations, you have just purchased a product with Intelbras quality and safety. The IVP 5311 MW Pet passive infrared sensor has passive infrared and microwave detection technology, adopting advanced signal analysis technology, which can prevent false triggering in dangerous environments. This sensor is intended for indoor...
  • Page 3 Care and safety » LGPD – Data processing by Intelbras: Intelbras does not access, transfer, capture or perform any type of processing of personal data from this product. » Follow all instructions in the manual for assembling and installing the product;...
  • Page 4 » The Pet function is intended for crawling animals weighing up to 20 kg. If the animal is on top of a bench, for example, the Pet function can be canceled. Note: before starting the installation, it is necessary to define the height at which the sensor will be positioned, which can vary from 1.8 to 2.2 m.

  • Page 5: Table Of Contents

    Summary 1. Technical specifications 2. Features 3. Product 4. Installation 4.1. Microwave sensitivity adjustment ............. . .9 4.2.

  • Page 6: Technical Specifications

    1. Technical specifications Operating voltage 9 ~16 Vdc Operating current 38 mA Detection angle 90° Detection range (PIR and MW) 12 meters Detection method Microwave and PIR (AND) Animal immunity Up to 20 kg Microwave frequency 10.525 GHz 1- High sensitivity 2- Sensitivity (factory default) Sensitivity (J.

  • Page 7: Product

    3. Product MODO TAMPER ALARME 17 18 13. MODE jumper (AND and anti-stealth 1. Top front cover 14. Jumper Relay (NO / NC) 2. Fresnel lens 15. Tamper switch 3. Lower front cover 16. Jumper WRIST 4. Hole for fixing the bottom cover 17.
  • Page 8 To install the sensor, follow the procedure below: 1. Remove the lower front cover; 1P 2P 3P 4P TAMPER ALARME 2. Route the wiring through the cable knockouts located on the back cover of the sensor. Note: use a tool to drill the hole in the indicated location and to facilitate the installation, use the recesses in the rear cover to pass the cables.

  • Page 9: Microwave Sensitivity Adjustment

    3. Connect the connecting cables to the sensor terminals and install them in the place to be protected. For installation directly on the wall or on the edge of the wall, break the sealing waxes indicated for the furos on the rear fixing cover. Note: for installation directly on the wall, use the oblong located on the back of the product.

  • Page 10: Operating Mode Settings

    To facilitate the adjustment of the microwave coverage, adjust the trimpot in an anti-clockwise direction (less sensitive) and walk in the environment that you want to protect. Observe the motion detection of the sensor. If necessary, increase the sensitivity (clockwise). Repeat this process until the sensor protects only the environment where it is installed. The figure below shows a reference range of detection of the microwave channel.

  • Page 11: Jumper J. Led

    4.3. Jumper J. LED Position Condition Open LEDs off Closed LEDs on (factory default) The J.LEDs jumper is used to control the LED indication without interfering with the detector. With the jumper in the Closed position, the LEDs are able to function normally. With the jumper in the Open position, the LEDs are disabled, that is, they do not light up.

  • Page 12: Jumper Mode

    4.7. Jumper Mode Position Condition AND (factory default) Anti camouflage With the Mode jumper in position 1, the sensor will operate in AND mode, that is, the sensor will activate when both technologies (PIR and microwave) detect the presence of an intruder at the same time. This function is indicated when the sensor is installed in semi-open environments or when there are domestic animals in the environment.

  • Page 13: Operation

    5. Operation When turning on the sensor, the LEDs flash for approximately 80 seconds. This time is necessary for the stabilization of the circuits that make up the sensor. After this period, if enabled, the LEDs light up at every motion detection. »...

  • Page 14: Homologation

    7. Homologation This equipment is not entitled to protection against harmful interference and may not cause interference in duly authorized systems. This is a product approved by Anatel, the approval number can be found on the product label, for inquiries visit the website: https://www.gov.br/anatel/pt-br.

  • Page 15: Warranty Term

    7. Intelbras is not responsible for the installation of this product and also for any attempts of fraud and/or sabotage on its products. Keep software and application updates, if any, up to date, as well as network protections necessary to pro¬tect against hackers.
  • Page 16 Customer Service: 0800 7042767 Where to buy? Who installs it? 0800 7245115 Produced by: Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Rodovia BR 459, km 124, nº 1325 – Distrito Industrial – Santa Rita do Sapucaí/MG – 37540-000 03.23 CNPJ 82.901.000/0016-03 –...
