OPERATOR'S MANUAL
R28-1824 and R76-2436 Rollers
R28-1824
R76-2436
Spyker Spreaders
Contact us at 800.972.6130
www.spyker.com
IMPORTANT
!
!
This manual contains information for the safety of persons and property.
Read it carefully before assembly and operation of the equipment!
©2021 Spyker Spreaders/A Brinly-Hardy Co.
Page 1
1019528-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R28-1824 and is the answer not in the manual?

Questions and answers

Summary of Contents for SPYKER R28-1824

  • Page 1 OPERATOR'S MANUAL R28-1824 and R76-2436 Rollers R28-1824 R76-2436 Spyker Spreaders Contact us at 800.972.6130 www.spyker.com IMPORTANT This manual contains information for the safety of persons and property. Read it carefully before assembly and operation of the equipment! ©2021 Spyker Spreaders/A Brinly-Hardy Co.
  • Page 2: Table Of Contents

    • To avoid accidents and/or injuries, please make sure there is no person around or behind the roller when use. Tools Required for Assembly: TO PREVENT INJURY, USE WITH CAUTION ! Wrenches or Deep Sockets: LIFTING HAZARD: When the roller is • (x1) 1/4" fully loaded with water, it weighs: • (x1) 5/16" R28-1824 = 270 lbs R76-2436 = 680 lbs • (x1) 7/16" • (x2) 1/2" • (x2) 9/16" WARNING: PINCH POINTS Use caution between the scraper bar and roller, as well as the handle. English Manual Page 2 1019528-A...
  • Page 3: Parts

    PLEASE CALL: 1 (800) 972-6130 Ref. Description Qty. Part No. Bag, Hardware 1019535 Spring Clip 1019526 Bolt; Hex, #6-32 x 5/8" 1019567 Ref. Description Qty. Part No. Bolt; Carriage, 5/16" x 2 11M1032P models > R28-1824 R76-2436 Bolt; Hex Head, 5/16" x 3 2M1048P Handle Weldment 1019542-10 Bolt; Hex, 3/8-16 x 2-1/4" 1019565 Bolt; Hex, 3/8-16 x 1-1/2" 1019566 Frame Tubes 1019540-10 1019541-10 U-Bolt; 1/4"-20, 1-1/8" 1019569 Plug, Tube End 1019551 Washer; Flat, 1/4"...
  • Page 4 ILLUSTRATIONS ON THIS PAGE ARE TO SCALE FOR FASTER Hardware Identifier IDENTIFICATION OF HARDWARE DURING ASSEMBLY. DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. PLEASE CALL: 1 (800) 972-6130 Bolt; Hex #6-32 x 5/8” (x1) ........1019567 Nut, Nylon Lock, #6-32 (x1)
  • Page 5: Assembly

    Assembly 1. On the end of the top hitch plate (5), align the spring 3. Align the hitch Fig. 3 plates (5 and 6) clip (4) as illustrated below. at the end of the Run the #6 Hex Bolt (14) through the spring clip and frame tubes. secure beneath the hitch plate with the #6 Nylon Lock Nut (23). NOTE: Bolts to be added will straddle the first bolt Fig. 1 at the end of the tubes. (Noted here as Bolt "A") Run two 5/16 x 2"...
  • Page 6 Assembly 5. Align the scraper bar (8) parallel with the roller NOTE: Leave a small gap between the bar (8) and roller (7) drum (but not touching), and across the frame ensuring the scraper bar does not touch the roller at any point tubes (2) as illustrated. The logo panel faces in one full revolution. away from the roller drum. Slide the two U-Bolts (19) in place, straddling the frame tubes (2), running through the NOTE:...
  • Page 7 Assembly 7. Securing the Hardware Fully secure all of the nuts and bolts that were added on Steps 3, 5 and 6. Fig. 7 8. Insert the handle (1) through D-ring (9) and then 9. Attach the roller plug (11) by squeezing slide the handle through the upper hitch plate (5) tabs. tether spring and insert into roller, rotating the plug in place. Slide a 3/8" washer (22) between the handle and hitch tabs. Run the 3/8" x 2-1/4" hex head bolt (17) through and secure in place with a 3/8" nylon lock nut (26). Fig. 9 NOTE: Tighten firmly to reduce play but do not overtighten as handle needs to rotate. NOTE: Resting the handle in the spring clip may help.
  • Page 8: Use And Care

    (5). NOTE: The bottom hitch plate can be used to store the clevis pin upside down. CAUTION! Avoid Damage. WARNING: Pinch Points Do not overload your tractor / rider. Use caution between Roller fully loaded with water weighs: the scraper bar and roller, R28-1824 = 270 lbs as well as the handle. R76-2436 = 680 lbs English Manual Page 8 1019528-A...
  • Page 9: Maintenance

    If possible, hang the roller when not department: in use to prevent possibility of developing a flat spot. In North America and Canada call Toll-Free: 800-972-6130 If a flat spot develops on the roller during Chat online: www.spyker.com storage, ensure that the roller is empty then leave out in the sun to warm and roll around to reduce flat area. English Manual...
  • Page 10: Warranty

    WARRANTY 1 YEAR LIMITED WARRANTY This is warranted to the original purchaser only. Spyker will replace parts with defects in materials and workmanship, for a period of one year from the date of purchase. Spyker Spreaders will not be liable for any loss, damage or expense including, but not limited to, consequential or incidental damages, arising from the operation, condition or use of the item. The sole and exclusive remedy against Spyker Spreaders being the replacement of the defective parts. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. This express warranty, which is applicable only to the original purchase, is in lieu...
