Digital Displacement® DDP096 pump and DPC12 controller
Electrical installation
©
Danfoss | October 2023
Controller connectors
Controller connector descriptions
Label
Name
C1
Power connection
C2
System connection
C3
Sensor connection
C4
Coil harness "A"
connection
C5
Coil harness "B"
connection
C6
Comm connection
Connector type
DEUTSCH DT04-08PA (gray)
DEUTSCH DTM04-12PD (brown)
DEUTSCH DTM04-12PC (green)
DEUTSCH DTM04-12PA (gray)
DEUTSCH DTM04-12PB (black)
DEUTSCH DTM04-08PA (gray)
Mating receptacle (for pump-to-
connector harness)
DEUTSCH DT06-08SA (gray)
DEUTSCH DTM06-12SD (brown)
DEUTSCH DTM06-12SC (green)
DEUTSCH DTM06-12SA (gray)
DEUTSCH DTM06-12SB (black)
DEUTSCH DTM06-08SA (gray)
BC306384089197en-000202 | 57
