Technical Information
Digital Displacement® DDP096 pump and DPC12 controller
Electrical installation

Connectors

Crimp tool
Tool 12 pin DTM
Solid HDT-48-00 (12 to 24 AWG)
Stamped DTT-16-00 (16 AWG)
Contacts
Description 12 pin DTM
Solid size 20 0462-201-20141 (20 AWG Nickel)
contacts 0462-201-2031 (20 AWG Gold)
0462-005-20141 (16 to 18 AWG Nickel)
0462-005-2031 (16 to 18 AWG Gold)
Solid size 16
contacts
Stamped size 16 to 22 AWG (.75-.125 insulation dia)
20 contacts
1062-20-0122 (Nickel)
1062-20-0144 (Gold)
16 to 22 AWG (.051-.085 insulation dia)
1062-20-0222 (Nickel)
1062-20-0244 (Gold)
14 to 16 AWG (.075 - .125 insulation dia)
1062-20-0622 (Nickel)
1062-20-0631 (Gold)
Stamped size
16 contacts
Connector plug
Type 12 pin DTM
Gray A-key DTM06-12SA
Black B-key DTM06-12SB
Green C-key DTM06-12SC
Brown D-key DTM06-12SD
© Danfoss | October 2023
The DDP096 and DPC12 use DEUTSCH connectors.
DEUTSCH mating connector part information
8 pin DTM
HDT-48-00 (12 to 24 AWG)
DTT-20-00 (16 AWG)
8 pin DTM
0462-201-20141 (20 AWG Nickel)
0462-201-2031 (20 AWG Gold)
0462-005-20141(16 to 18 AWG Nickel)
0462-005-2031 (16 to 18 AWG Gold)
16 to 22 AWG (.75-.125 insulation dia)
1062-20-0122 (Nickel)
1062-20-0144 (Gold)
16 to 22 AWG (.051-.085 insulation dia)
1062-20-0222 (Nickel)
1062-20-0244 (Gold)
14 to 16 AWG (.075 - .125 insulation dia)
1062-20-0622 (Nickel)
1062-20-0631 (Gold)
The DDP096 pump connectors terminate with Nickel coated pins, whereas the DPC12 controller
connectors use Gold plated pins. Appropriate mating pins must be selected to avoid galvanic cells and
especially Gold-Tin reactions which can compromise the connection.
8 pin DTM
DTM06-08SA
8 pin DT
HDT-48-00 (12 to 24 AWG)
DTT-16-00 (16 AWG)
8 pin DT
0462-209-16141 (14 AWG Nickel)
0462-209-1631 (14 AWG Gold)
0462-201-16141 (16 to 20 AWG Nickel)
0462-201-1631 (16 to 20 AWG Gold)
12 to 16 AWG (.075 - .140 insulation dia)
1062-16-1222 (Nickel)
1062-16-1244 (Gold)
14 to 18 AWG (.075 - .140 insulation dia)
1062-16-0122 (Nickel)
1062-16-0144 (Gold)
14 to 18 AWG (.095 - .150 insulation dia)
1062-14-0122 (Nickel)
1062-14-0144 (Gold)
16 to 20 AWG (.055 - .100 insulation dia)
1062-16-0622 (Nickel)
1062-16-0644 (Gold)
8 pin DT
DT06-08SA
