Digital Displacement® DDP096 pump and DPC12 controller
Model code

DDP part options

© Danfoss | October 2023
Below is a list of the available configuration options for the DDP. Note that not all combinations are
possible.
The tandem section of the model code is not presented below.
The stand-alone letter in the title corresponds with model code location. Please refer to
on page 26 for entire model code breakdown.
C; Displacement
Code Description
3
096 96 cm /rev [5.86 in
D; Product type
SHNN Single pump for high-power applications
E; Rotation
R Clockwise rotation [CW]
L Counterclockwise rotation [CCW]
F; Mounting flange
C SAE C 4-bolt
G; Input shaft spline and auxiliary shaft spline
ANN 23T input; no auxiliary shaft
A09* 23T input; 9T auxiliary coupling
A11* 23T input; 11T auxiliary coupling
A13* 23T input; 13T auxiliary coupling
A15* 23T input; 15T auxiliary coupling
A14* 23T input; 14T auxiliary coupling
A17* 23T input; 17T auxiliary coupling
H; Auxiliary mounting flange (through-drive shaft)
CP Cover plate (no auxiliary flange)
AA* 2-bolt SAE A auxiliary mounting flange
BA* 2-bolt SAE B auxiliary mounting flange
CA* 4-bolt SAE C auxiliary mounting flange
* On request.
I; Endcap (inlet and outlet ports)
1AAA
Single-outlet endcap:
Inlet port S: DN 51 ISO 6162-1; M12 x 1.75
Outlet port P: DN 25 ISO 6162-2; M12 x 1.75
3BAA
Multi-outlet endcap:
Inlet port S: DN 51 ISO 6162-1; M12 x 1.75
Outlet port P1: DN 19 ISO 6162-2; M10 x 1.5
Outlet port P2: DN 13 ISO 6162-2; M8 x 1.25
Outlet port P4: DN 13 ISO 6162-2; M8 x 1.25
3
/rev] maximum displacement
DDP model code
