Electrical installation
Wedge, strips and seals
Description
Wedge
Solid strip length
Stamped strip length
Rear seal maximum OD
Sealing plugs
56 | © Danfoss | October 2023
12 pin DTM
WM-12S
3.96 to 5.54 mm
[0.156 to 0.218 in]
3.81 to 5.08 mm
[0.150 to 0.200 in]
3.05 mm [0.120 in]
0413-204-2005
Contact Danfoss for further information on compatible DEUTSCH products and tools.

Pump connectors

Pump connector descriptions
Label Connector
C3 Sensor connector
C4 Coil harness "A" connector DEUTSCH DTM04-12PA (gray)
C5 Coil harness "B" connector DEUTSCH DTM04-12PB (black)
8 pin DTM
WM-8S
3.96 to 5.54 mm
[0.156 to 0.218 in]
3.81 to 5.08 mm
[0.150 to 0.200 in]
3.05 mm [0.120 in]
0413-204-2005
Description
DEUTSCH DTM04-12PC (green)
8 pin DT
W8S
6.35 to 7.92 mm
[.250 to .312 in]
3.81 to 5.08 mm
[0.150 to 0.200 in]
3.68mm [0.145 in]
Sealing pin:
114017-zz
Locking sealing pin:
0413-217-1605
Mating receptacle (for pump-to-
controller harness)
DEUTSCH DTM06-12SC (green)
DEUTSCH DTM06-12SA (gray)
DEUTSCH DTM06-12SB (black)
