- Page 1 5000-090A SINGLE ROW SERIES STALK DEVASTATOR OWNER’S MANUAL PART IDENTIFICATION 2565-972-Rev-A ● 02/2024 YETTER MANUFACTURING CO. Founded 1930 Colchester, IL 62326 Toll free: (800)447-5777. Fax: (309)776-3222 Website: yetterco.com E-mail: info@yetterco.com...
-
Page 2: Table Of Contents
WARRANTY Yetter Manufacturing warrants all products manufactured and sold by it against defects in material. This warranty being expressly limited to replacement at the factory of such parts or products as shall appear to be defective after inspection. -
Page 3: Safety Information
BE ALERT! YOUR SAFETY IS INVOLVED WATCH FOR THIS SYMBOL. IT POINTS OUT IMPORTANT SAFETY PRECAUTIONS. IT MEANS “ATTENTION – BE ALERT!” It is your responsibility as an owner, operator, or supervision to know and instruct everyone using this machine at the time of initial assignment and at least annually thereafter, of the proper operation, precautions, and work hazards which exist in the operation of the machine in accordance with OSHA regulations. - Page 4 PLEASE READ, VERY IMPORTANT SECURE CORN HEADER AGAINST UNWANTED LOWERING BY APPLYING THE LOCKING MECHANISM ON THE HYDRAULIC CYLINDERS! 1. Attach head to combine, lock head to combine 2. Raise the head off the ground and engage safety stop on the feeder house cylinder.
- Page 5 PLEASE READ, VERY IMPORTANT Subject to the size and weight of the corn header, one or two additional hydraulic cylinders may be required. The combine manufacturer generally keeps corresponding kits readily available for dealers. Subject to the design of the corn header and the carrying capacity of different combines, the steering axle may require the fitting of additional weights and the rear tires be filled with ballast.
-
Page 6: Torque & Tools Needed
BOLT TORQUE Important: Over-tightening hardware can cause just as much damage as under-tightening. Tightening hardware beyond the recommended range can reduce its shock load capacity. All hardware on the 5000 Devastator is either Grade 5 or Grade 8, unless otherwise noted. Grade 5 cap screws are marked with three radial lines on the head. -
Page 7: Bill Of Materials / Pictorial Index
BILL OF MATERIALS PER KIT 5000-090A – 1) 5000-147 LockingTorsion Pivot Assembly, 1) 5000-160A Roller Bearing Bolt Bag, 1) 5000-176 Single Row Torsion Mount Bolt Bag, 1) 5000-2001 1 Row Roller, 1) 5000-2002A 1 Row Roller Mount, 2) 5000-292 Torsion Arm Before beginning your installation, go through your kit to verify that you have the correct parts and quantities. - Page 8 ASSEMBLY INSTRUCTIONS Step 3: Install the 5000-2002 roller mount to the torsion arms using 2570-568 ½ X 2 ½ X 3 ½ U-bolts & 2520-357 ½ lock hex nuts. NOTE: MAKE SURE THE BEARING SUPPORT TAB ON THE ROLLER MOUNT IS ON THE BACK SIDE. Bearing Support Tab should be on back side of the roller Step 4:...
-
Page 9: Lock Up / Operation
LOCK UP To “lock up” the Devastator roller, install a rod through the hole in the bottom of the torsion mount bracket, in front of the pivot arms. A Lock Pin can be ordered to lock up the devastators, 3841-302. OPERATION CORN HEAD ANGLE NEEDS TO BE ADJUSTED BETWEEN 23 –... -
Page 10: Part Identification
5000-090 PART IDENTIFICATIONS ITEM PART # DESCRIPTION QUANTITY 2502-353 ½-13 X 2 ½ HHCS GR 8 ZP 2502-430 ¾ - 10 X 8 HHCS GR 8 ZP 2502-805 M16 X 2 X 120 HEX FLANGE BOLT W/ THRD LOCK ZP 2502-806 M16 X 2 X 110 HEX FLANGE BOLT W THRD LOCK ZP 2520-357... - Page 12 2565-972-Rev-A – 02/2024...
