JACKING AND TIRE CHANGING ... 230 VEHICLE MAINTENANCE ....252 INTERIORS ..... . . 287 Preparations For Jacking .
Page 8
FCA aims at a constant improvement of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer. When it comes to service, remember that authorized dealers know your Jeep® best, have factory-trained technicians, genuine Mopar® parts, and care about your satisfaction.
INTRODUCTION IMPORTANT NOTICE SYMBOLS KEY ALL MATERIAL CONTAINED IN THIS PUBLICATION IS BASED ON THE LATEST INFORMA- TION AVAILABLE AT THE TIME OF PUBLICATION APPROVAL. THE RIGHT IS RESERVED TO WARNING! These statements apply to operating pro- PUBLISH REVISIONS AT ANY TIME. cedures that could result in a collision, After you have read the Owner’s Manual, it should be stored in the vehicle for conve- bodily injury and/or death.
INTRODUCTION ROLLOVER WARNING VEHICLE MODIFICATIONS/ALTERATIONS Utility vehicles have a significantly higher rollover rate than other types of vehicles. This vehicle has a higher ground clearance and a higher center of gravity than many pas- WARNING! senger vehicles. It is capable of performing better in a wide variety of off-road applica- Any modifications or alterations to this vehicle could seriously affect its roadworthi- tions.
Page 11
INTRODUCTION Red Warning Lights Red Warning Lights Door Open Warning Light Oil Temperature Warning Light page 104 page 105 Electric Power Steering (EPS) Fault Warning Light Seat Belt Reminder Warning Light page 104 page 105 Electronic Throttle Control (ETC) Warning Light Speed Warning Light page 104 page 105...
GETTING TO KNOW YOUR VEHICLE NOTE: KEYS CAUTION! • In case the ignition switch does not change with the The electrical components inside of the key fob may push of a button, the key fob may have a low or fully KEY FOB be damaged if the key fob is subjected to strong elec- depleted battery.
Page 17
GETTING TO KNOW YOUR VEHICLE Replacing The Battery In The Key Fob 2. Remove the depleted battery by inserting a small WARNING! flat-blade screwdriver into the battery removal slot The recommended replacement battery is CR2450. and sliding the battery forward and up being careful •...
GETTING TO KNOW YOUR VEHICLE NOTE: If the Vehicle Security Light turns on during normal vehicle operation (vehicle running for longer than • When having the Sentry Key Immobilizer system 10 seconds), it indicates that there is a fault in the elec- serviced, bring all vehicle keys with you to an autho- tronics.
GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! In case the ignition switch does not change with the push of the START/STOP ignition button, the key fob An unlocked vehicle is an invitation for thieves. may have a low or depleted battery. In this situation, a Always remove key fob from the vehicle and lock all backup method can be used to operate the ignition doors when leaving the vehicle unattended.
GETTING TO KNOW YOUR VEHICLE NOTE: • For security, power window operation is disabled TO EXIT REMOTE START MODE when the vehicle is in the Remote Start mode. • The vehicle must be equipped with an automatic To drive the vehicle after starting the Remote Start sys- •...
GETTING TO KNOW YOUR VEHICLE • • ture. Once the timer expires, the system will automati- In ambient temperatures from 40°F (4.5°C) to Remote Start Canceled — Fuel Low cally adjust the settings depending on ambient condi- 78°F (26°C), the climate settings will be based on •...
GETTING TO KNOW YOUR VEHICLE 3. Perform one of the following methods to lock the you are in the vehicle or not. If you remain in the vehicle MANUAL DOOR LOCKS vehicle: and open a door, the alarm will sound. If this occurs, All doors are equipped with an interior rocker-type door ○...
GETTING TO KNOW YOUR VEHICLE • The key fob may not be detected by the vehicle Pas- WARNING! WARNING! sive Entry system if it is located next to a mobile • phone, laptop, or other electronic device; these Never leave children alone in a vehicle, or with •...
Page 24
GETTING TO KNOW YOUR VEHICLE When any of these situations occur, after all open doors are shut, the FOBIK-Safe search will be executed. If it detects a Passive Entry key fob inside the vehicle, the vehicle will unlock and alert the customer. If Passive Entry is disabled using Uconnect system, the key fob protection described in this section remains active/functional.
GETTING TO KNOW YOUR VEHICLE To Unlock/Enter The Swing Gate NOTE: • The Passive Entry system will not operate if the key fob battery is depleted. The swing gate Passive Entry unlock feature is built into • When the Child-Protection Door Lock system is the swing gate handle.
GETTING TO KNOW YOUR VEHICLE FRONT DOOR REMOVAL Outside rearview mirrors are mounted on the doors. If you choose to remove the doors, see an authorized dealer for a replacement cowl-mounted outside mirror. WARNING! Law requires outside mirrors on vehicles for on-road use.
Page 27
GETTING TO KNOW YOUR VEHICLE 4. Pull up on the red locking tab to unlock the wiring harness. Open Wiring Harness Door Check Arm 8. With the door open, lift the door with the help of Closed Wiring Harness 1 – Wiring Harness Lever (Open Position) another person, to clear the hinge pins from their 2 –...
Page 28
GETTING TO KNOW YOUR VEHICLE 4. Using your fingers, turn the screw clockwise at least 1. With light finger pressure, seat the wiring connector straight into the wiring harness until the wiring har- two full turns. Gently pull on the screw to ensure it is secure.
GETTING TO KNOW YOUR VEHICLE NOTE: REAR DOOR REMOVAL (FOUR-DOOR MODELS) • Doors are heavy; use caution when removing them. • Hinge pin can break if overtightened during door reinstall (Max Torque: 7.5 ft· lb / 10 N·m). For off- WARNING! road driving tips, see page 159.
GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! Keep the check arm in the extended position for • easier reinstallation. Careless handling and storage of the half-doors may damage the seals resulting in water leaks into the interior of the vehicle. •...
Page 31
GETTING TO KNOW YOUR VEHICLE Lower Half-Door Hinge Pins Cloth Strap Attachment Front Door Wiring Harness 3. Insert the upper and lower hinge pin screws into the 1 — Metal Hook 1 — Open Wiring Harness body hinges. Tighten the screws using a #T50 Torx 2 —...
Page 32
GETTING TO KNOW YOUR VEHICLE 9. Push down firmly on the inside of the upper half- door until it is fully seated in the lower half. Place Tool Into Service Hole Of Plug To Remove Check Door Latch And Striker Alignment NOTE: c.
Page 33
GETTING TO KNOW YOUR VEHICLE 2. With the bolts loose, hold the door in the almost 2. Open the affected door and hold a dollar-size piece closed position, and check that the latch and striker of paper along the top of the door opening against align.
Page 34
GETTING TO KNOW YOUR VEHICLE To adjust the seal compression, proceed as follows: 5. Close the door and repeat the “paper test”. Repeat the adjustment procedure if needed. 1. Open the door and lift the upper half-door up and away from the lower half. Lay the upper half-door on 6.
GETTING TO KNOW YOUR VEHICLE To unlock the steering column, push the control handle downward (toward the floor). To tilt the steering column, move the steering wheel upward or downward as desired. To lengthen or shorten the steering column, pull the steering wheel outward or push it inward as desired.
GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! The engine must be running for the heated steering • wheel to operate. Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat For information on use with the Remote Start system, belts.
GETTING TO KNOW YOUR VEHICLE Reclining The Seatback Forward Or Rearward The seatback can be reclined both forward and rear- ward. Push the power recline switch forward or rear- ward. The seatback will move in the direction of the switch. Release the switch when the desired position has been reached.
GETTING TO KNOW YOUR VEHICLE Front Easy Entry Seat — Two Door WARNING! Models Do not ride with the seatback reclined so that the Pull upward on the easy entry lever located on the out- shoulder belt is no longer resting against your chest. board side of the seatback, and slide the entire seat In a collision you could slide under the seat belt, forward.
GETTING TO KNOW YOUR VEHICLE TO RAISE THE REAR SEAT MANUAL ADJUSTMENT REAR WARNING! SEATS Raise the seatback and lock it into place. Then, raise • Be sure everyone in your vehicle is in a seat and the head restraint until it locks into place. If interfer- using a seat belt properly.
GETTING TO KNOW YOUR VEHICLE WARNING! being in the fully lowered position, otherwise the bottom may not lock during frontal impact. If the seat cushion is not fully lowered, serious injury could occur. FOLD AND TUMBLE REAR SEAT — TWO DOOR MODELS NOTE: Flip Seat Bottom Forward Fold Seatback Down...
GETTING TO KNOW YOUR VEHICLE Using The Retention Straps WARNING! 1. There are two retention straps located on the back • In a collision, you or others in your vehicle could be of the rear seat and two corresponding wire loops injured if seats are not properly latched to their located on the back of each B-pillar.
GETTING TO KNOW YOUR VEHICLE WARNING! WARNING! WARNING! • Head restraints should never be adjusted while the • Be certain that the seatback is securely locked into Persons who are unable to feel pain to the skin vehicle is in motion. Driving a vehicle with the head position.
GETTING TO KNOW YOUR VEHICLE Rear Head Restraints — Two Door To return the head restraint to its upward position, lift Models up on the head restraint until it locks into place. For information on child seat tether routing, see The rear seat is equipped with non-adjustable, but fold- page 201.
GETTING TO KNOW YOUR VEHICLE To raise the center head restraint, lift up on the head UCONNECT VOICE RECOGNITION restraint. To lower the center head restraint, push the adjustment button, located at the base of the head INTRODUCING VOICE restraint, and push down on the head restraint. To remove the center head restraint, push the release RECOGNITION button, located on the base of the head restraint, and...
GETTING TO KNOW YOUR VEHICLE • MIRRORS You can interrupt the help message or system ILLUMINATED VANITY MIRRORS prompts by pushing the VR button and saying a To access an illuminated vanity mirror, flip down one of Voice Command from the current category. the visors and lift the cover.
GETTING TO KNOW YOUR VEHICLE POWER MIRRORS — IF EQUIPPED EXTERIOR LIGHTS WARNING! The power mirror controls are located on the door panel Vehicles and other objects seen in the passenger next to the door handle. HEADLIGHT SWITCH side convex mirror will look smaller and farther away than they really are.
GETTING TO KNOW YOUR VEHICLE DAYTIME RUNNING LIGHTS (DRLS) AUTOMATIC HIGH BEAM AUTOMATIC HEADLIGHTS — — IF EQUIPPED HEADLAMP CONTROL — IF EQUIPPED IF EQUIPPED The Daytime Running Lights are active when the low This system automatically turns the headlights on or off beams are not on, and the engine is running.
GETTING TO KNOW YOUR VEHICLE TURN SIGNALS INTERIOR LIGHTS Move the multifunction lever up or down to activate the turn signals. The arrows on each side of the instrument INTERIOR COURTESY LIGHTS cluster flash to show proper operation. The courtesy lights will turn on when the front doors are NOTE: opened, by rotating the dimmer control on the headlight switch fully upward, or, if equipped, when the unlock...
GETTING TO KNOW YOUR VEHICLE DIMMER CONTROL WINDSHIELD WIPER OPERATION CAUTION! The dimmer control is part of the headlight switch and In cold weather, always turn off the wiper switch and is located on the left side of the instrument panel. allow the wipers to return to the park position before turning off the engine.
GETTING TO KNOW YOUR VEHICLE NOTE: REAR WINDOW WIPER/WASHER — CLIMATE CONTROLS As a protective measure, the washer will stop if the IF EQUIPPED switch is held for more than 20 seconds. Once the The Climate Control system allows you to regulate the switch is released the washer will resume normal A rotary switch on the center portion of the windshield temperature, air flow, and direction of air circulating...
GETTING TO KNOW YOUR VEHICLE Rear Defrost Button NOTE: this mode is not recommended. Recirculation mode may automatically adjust to optimize customer experi- The MAX A/C button is only available on the Press and release the Rear Defrost button ence for warming, cooling, dehumidification, etc. touchscreen.
GETTING TO KNOW YOUR VEHICLE Floor Mode • Touchscreen: Use the small blower icon to reduce Push the blue button on the faceplate or touchscreen or press and slide the tempera- the blower setting and the large blower icon to Air comes from the floor outlets.
GETTING TO KNOW YOUR VEHICLE Outside Air Intake Did You Know: Voice Command for Climate may only be 3. When the system is set up for your comfort level, it is not necessary to change the settings. You will used to adjust the interior temperature of your vehicle. Make sure the air intake, located directly in front of the experience the greatest efficiency by simply allowing Voice Command will not work to adjust the heated...
GETTING TO KNOW YOUR VEHICLE WEATHER CONTROL SETTINGS WARNING! Cool Sunny Operate in (Bi-Level Mode). Do not operate this vehicle with a glove compartment Set the mode control to in the open position. Driving with the glove compart- Cool & Humid (Floor Mode) and turn (A/C) ment open may result in injury in a collision.
GETTING TO KNOW YOUR VEHICLE USB/AUX CONTROL The Media Hub is located on the instrument panel, below the climate controls. Behind the media hub access door, the Media Hub contains one AUX port, a Type C USB port and one standard USB port. Both USB ports allow you to play music from MP3 players, smart- phones or USB devices through the vehicle’s sound system.
GETTING TO KNOW YOUR VEHICLE WARNING! Do not plug in or remove the external device while driving. Failure to follow this warning could result in a collision. POWER OUTLETS There are two 12 Volt (13 Amp) auxiliary power outlets that can provide power for accessories designed for use with the standard power outlet adapters.
GETTING TO KNOW YOUR VEHICLE The power inverter is designed with built-in overload CAUTION! CAUTION! protection. If the power rating of 150 W is exceeded, the power inverter automatically shuts down. Once the tery even more quickly. Only use these intermit- •...
Page 58
GETTING TO KNOW YOUR VEHICLE Auxiliary Switches Auxiliary Switch Connections – Under Instrument Panel NOTE: In addition to the four auxiliary switch wires, a fused battery wire and ignition wire are also located in the Holding last state conditions are met when switch type interior, in the passenger side under the instrument is set to latching and power source is set to ignition.
GETTING TO KNOW YOUR VEHICLE Wire Color Chart Circuit Function Fuse Wire Color Locations Interior (passenger side under instrument Aux Switch 1 F93 – 40 Amp Beige/Pink panel) & Underhood (right side near battery) Interior (passenger side under instrument Aux Switch 2 F92 –...
GETTING TO KNOW YOUR VEHICLE To open the window part way (manually), push the win- WINDOW LOCKOUT SWITCH WRANGLER TOPS dow switch down briefly and release. NOTE: PROVIDED TOOLS The power window switches will remain active for up to For your convenience, a tool kit is provided with your 10 minutes after ignition is placed in the OFF position.
GETTING TO KNOW YOUR VEHICLE If your vehicle is equipped with a Dual Top (four door If the temperature is below 72°F (24°C) and/or the top Failure to follow these cautions may cause interior models only), the soft top system will be provided in a has been folded down for a period of time, the top will water damage, stains or mildew on the top material: separate box located in the rear of the vehicle for ship-...
Page 62
GETTING TO KNOW YOUR VEHICLE Four Door Side View Components 1 — #1 Bow 6 — #6 Bow 2 — #2 Bow 7 — Front Window Retainer 3 — #3 Bow 8 — Lower Window Retainer 4 — #4 Bow 9 —...
Page 63
GETTING TO KNOW YOUR VEHICLE Two Door Side View Components 1 — #1 Bow 6 — #6 Bow 2 — #2 Bow 7 — Front Window Retainer 3 — #3 Bow 8 — Lower Window Retainer 4 — #4 Bow 9 —...
Page 64
GETTING TO KNOW YOUR VEHICLE Two And Four Door Rear Components 1 — Rear Window Retainer Attachment Points 2 — Quarter Window Pillars 3 — Swing Gate Bar Retainers NOTE: • All lowering and raising the soft top instructions are applicable to both two and four door model vehicles. •...
Page 65
GETTING TO KNOW YOUR VEHICLE NOTE: The following options are available to you when lower- 3. From both the left and right sides, lift up on the ing your vehicle’s soft top: #1 Bow of the soft top to start the operation. If leaving the soft top in the Sunrider®...
Page 66
GETTING TO KNOW YOUR VEHICLE Removing The Soft Top Windows 4. Remove the plastic retainers from both quarter win- dow pillars. NOTE: Before fully lowering the soft top, the rear window and rear quarter windows must be removed. Remove The Rear Window: 1.
Page 67
GETTING TO KNOW YOUR VEHICLE Remove The Right And Left Quarter Windows: 3. Starting at the rear of the vehicle, remove plastic 5. While keeping the window level, slide rearward until it is completely separate from its retainer. Do not retainer from along the bottom of the window mov- 1.
Page 68
GETTING TO KNOW YOUR VEHICLE Soft Top Window Storage Bag — 3. Lay the second quarter window on top of the first If Equipped divider all the way to the left side with the inside of the window facing downward and the window pillar To safely store the soft top rear window, and rear quar- to the outside.
Page 69
GETTING TO KNOW YOUR VEHICLE Lowering The Soft Top All The Way 5. Lay the rear window on top of the second divider. 1. Remove the rear window and quarter panel windows page 64. 2. From the Sunrider® position page 59, remove straps if previously secured and move to the rear of the vehicle.
GETTING TO KNOW YOUR VEHICLE 6. Once the lock lever is in the “lock” position, push RAISING THE SOFT TOP downward on each side of the folded soft top to Raising The Soft Top From The Fully Lowered Position ensure it is secure. An audible “click” may be heard. 1.
Page 71
GETTING TO KNOW YOUR VEHICLE 7. Pull the handle back upward while squeezing the 2. Place the top of the quarter window pillar into the hook, locking the latch into place. top cover, and insert the bottom tab into the clip. Step Five 6.
Page 72
GETTING TO KNOW YOUR VEHICLE 3. Engage the retainers on the front of the windows, ensuring they are fully engaged, followed by the retainers along the bottom of the windows. Step Four Step Two Install The Rear Window 3. Rotate the swing gate bar into the left and right side retainers.
GETTING TO KNOW YOUR VEHICLE REMOVING THE SOFT TOP 1. Fully lower the soft top page 67. CAUTION! Failure to follow the next steps could result in dam- age to the Soft Top or vehicle. 2. Make sure the lift assist mechanism on both the left and right sides are in the “lock”...
GETTING TO KNOW YOUR VEHICLE 7. Using the provided #50 Torx head driver and ratchet, unscrew the Torx screw on both rear cor- ners of the vehicle, removing the retainers. Step Four Step Three 5. Repeat on the opposite side. CAUTION! Step Seven 6.
Page 75
GETTING TO KNOW YOUR VEHICLE 4. Making sure the lift assist mechanism is in the the following table for recommended torque specifi- 6. While pulling the release lever on the top of the rail “lock” position, lift the soft top into the rear of the cations), being careful not to cross-thread the rearward, place the side link into the guide track on vehicle with the side links pointing toward the front.
GETTING TO KNOW YOUR VEHICLE HARD TOP FRONT PANEL(S) REMOVAL CAUTION! • The hard top is not designed to carry any addi- tional loads, such as after-market roof racks, spare tires, building materials, hunting or camping sup- plies, etc. For optional Mopar® accessory roof racks page 92.
Page 77
GETTING TO KNOW YOUR VEHICLE Four Door Hard Top Components 1 — Right Side Panel 2 — Left Side Panel 3 — Hard Top...
Page 78
GETTING TO KNOW YOUR VEHICLE Two Door Hard Top Components 1 — Right Side Panel 2 — Left Side Panel 3 — Hard Top NOTE: • All hard top removal and installation instructions are applicable to both two and four door model vehicles. •...
Page 79
GETTING TO KNOW YOUR VEHICLE To remove the hard top front panel(s), proceed as 2. Unfold the black panel divider (ensure the divider is follows: lying flat). 1. Fold down the sun visor against the windshield. 3. Insert the right side Freedom Top panel into the bag with the latches facing downward.
GETTING TO KNOW YOUR VEHICLE HARD TOP FRONT PANEL(S) 5. Open the swing gate all the way to ensure clearance of the rear window glass. Lift the rear window glass. INSTALLATION 1. Open the header latch inside the vehicle, and the three L-shaped locks on each panel.
Page 81
GETTING TO KNOW YOUR VEHICLE 7. Release the locking tab by pushing it downward. 10. Store the wire harness and washer hose in the compartment below the trim. To access the stor- age compartment, lift the trim cover as shown. Step Eight Step Seven 9.
GETTING TO KNOW YOUR VEHICLE 12. Secure the washer hose by snapping it in next to INSTALLING THE HARD TOP the receptacle, then replace the compartment If the door frames are installed from soft top usage, cover. they must be removed prior to installation of the hard top.
Page 83
GETTING TO KNOW YOUR VEHICLE 3. Swing the front frame bracket around the side of the 5. Repeat steps 3 and 4 on the other side of the rail, and insert the door rail attachment bolt (pro- vehicle. vided bolt without spacer) from underneath. Tighten NOTE: with a #40 Torx head driver until snug.
GETTING TO KNOW YOUR VEHICLE To Open The Sunrider® Top 4. Secure the top by using the two hook-and-loop fas- teners provided with the Sunrider® kit, and wrap To open the Sunrider® top, proceed as follows: one around the side rails on each side of the 1.
GETTING TO KNOW YOUR VEHICLE Power Top Maintenance Manual Open/Close WARNING! To open the power top manually, push and hold the Use only a non-abrasive cleaner and a soft cloth to • open switch to the full open position, then release. Never leave children unattended in a vehicle, or clean the quarter window glass panel.
GETTING TO KNOW YOUR VEHICLE Rear Quarter Window Removal NOTE: Quarter Window Storage Bag Do not pull down or apply any weight to the windows To use the storage bags for the rear quarter windows, On vehicles equipped with a Power Sliding Top, the rear after the latches are released.
GETTING TO KNOW YOUR VEHICLE DOOR FRAME REMOVAL WARNING! NOTE: In a collision, unsecured rear quarter windows in the vehicle could cause injury. They could fly around in a In four door models, the rear door frames must be sudden stop or rough terrain and strike someone in removed first, followed by the front door frames.
GETTING TO KNOW YOUR VEHICLE WARNING! • Do not drive your vehicle on public roads with the door frame(s) removed as you will lose the protec- tion that they can provide. This procedure is fur- nished for use during off-road operation only. •...
GETTING TO KNOW YOUR VEHICLE 6. Swing the frame bracket around the side of the rail, and insert the screws from underneath. Tighten with #40 Torx head driver until they are snug, being care- ful not to cross-thread the screws or overtighten. Refer to the previous table for the appropriate torque specifications for the door rail screws.
GETTING TO KNOW YOUR VEHICLE • FOLDING WINDSHIELD Door Frame page 85 WARNING! • Freedom Top Panels page 77 Carefully follow these warnings to help protect CAUTION! against personal injury: CAUTION! • Do not drive your vehicle on-road with the wind- Lowering of the windshield is NOT recommended in shield down.
Page 91
GETTING TO KNOW YOUR VEHICLE Adaptive Cruise Control (ACC)/Forward Collision Warning (FCW) Sensor Protective Cover — If Equipped Your vehicle may be equipped with a protective cover that is to be used whenever the windshield is folded down in order to protect the Adaptive Cruise Control (ACC)/Forward Collision Warning (FCW) sensor.
GETTING TO KNOW YOUR VEHICLE RAISING THE WINDSHIELD 5. Reinstall the protective caps over the wiper arm hex HOOD bolts and push gently until they snap into place. 1. Release the strap that secured the windshield in the OPENING THE HOOD lowered position.
GETTING TO KNOW YOUR VEHICLE • You may have to push down slightly on the hood CAUTION! before pushing the safety latch. • To prevent possible damage, do not slam the hood to While lifting the hood, use both hands. close it.
GETTING TO KNOW YOUR VEHICLE WARNING! WARNING! • To help protect against personal injury, passengers Driving with the flip-up window open can allow poi- should not be seated in the rear cargo area. The sonous exhaust gases into your vehicle. You and your rear cargo space is intended for load carrying pur- passengers could be injured by these fumes.
Page 95
GETTING TO KNOW YOUR VEHICLE Crossbars should always be used whenever cargo is CAUTION! placed on the roof rack. Check the straps frequently to be sure that the load remains securely attached. • Travel at reduced speeds and turn corners care- fully when carrying large or heavy loads on the roof NOTE: rack.
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER INSTRUMENT CLUSTER DISPLAY CAUTION! DESCRIPTIONS Driving with a hot engine cooling system could dam- Your vehicle will be equipped with an instrument cluster 1. Tachometer display, which offers useful information to the driver. age your vehicle.
GETTING TO KNOW YOUR INSTRUMENT PANEL Down Arrow Button • INSTRUMENT CLUSTER DISPLAY The system allows the driver to select information by pushing the following buttons mounted on the steering Push and release the down arrow button to LOCATION AND CONTROLS wheel: scroll downward through the Main Menu items.
GETTING TO KNOW YOUR INSTRUMENT PANEL Secondary Method For Oil Change Reset Procedure • Five Second Unstored Messages The instrument cluster display will normally display the main menu or the screens of a selected feature of the When the appropriate conditions occur, this type of 1.
GETTING TO KNOW YOUR INSTRUMENT PANEL Front Seat Belts Unbuckled Oil Change Due ACC Override Driver Seat Belt Unbuckled Fuel Low Cruise Set To XXX mph or km/h Passenger Seat Belt Unbuckled Service Anti-lock Brake System Service Shifter Traction Control Off Service Electronic Throttle Control Tire Pressure Screen With Low Tire(s) Washer Fluid Low...
GETTING TO KNOW YOUR INSTRUMENT PANEL Speedometer ○ Adaptive Cruise Control Ready Transfer Case Lock Status: displays “Lock” graphic only during 4WD High, 4WD High Part When ACC is activated but the vehicle speed setting Push and release the up or down arrow button Time, 4WD Low status.
Page 103
GETTING TO KNOW YOUR INSTRUMENT PANEL Audio change to a “LOW” message. Adding a significant Upper Left and Right amount of fuel to the vehicle will turn off the “LOW” Push and release the up or down arrow button None Current Econ Average Econ message and a new Range value will display.
GETTING TO KNOW YOUR INSTRUMENT PANEL Phone Call Status — If Equipped Gear Display — If Equipped In cases when the IBS detects charging system failure, or the vehicle battery conditions are deteriorating, elec- • Full A pop-up message for an incoming call will appear on trical load reduction actions will take place to extend •...
GETTING TO KNOW YOUR INSTRUMENT PANEL ○ Loss of the battery charge may indicate one or more of Check what may be plugged in to power outlets RED WARNING LIGHTS the following conditions: +12 Volt, 150W, USB ports ○ Air Bag Warning Light Check HVAC settings (blower, temperature) •...
GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Throttle Control (ETC) Warning NOTE: system is indicated by the Brake Warning Light, which will turn on when the brake fluid level in the master Light This light shows only that the parking brake is applied. cylinder has dropped below a specified level.
Page 107
GETTING TO KNOW YOUR INSTRUMENT PANEL Oil Temperature Warning Light Transmission Temperature Warning If the light turns on while driving, safely pull over and stop the vehicle. If the Air Conditioning (A/C) system is Light This warning light will illuminate to indicate on, turn it off.
GETTING TO KNOW YOUR INSTRUMENT PANEL Vehicle Security Warning Light — Loose Fuel Filler Cap Warning Light — running. If the ESC Indicator Light comes on continu- If Equipped ously with the engine running, a malfunction has been If Equipped detected in the ESC system.
Page 109
GETTING TO KNOW YOUR INSTRUMENT PANEL Service 4WD Warning Light — Cruise Control Fault Warning Light Certain conditions, such as a loose or missing gas cap, poor quality fuel, etc., may illuminate the light after If Equipped This warning light will illuminate to indicate engine start.
GETTING TO KNOW YOUR INSTRUMENT PANEL Each tire, including the spare (if provided), should be nated, the system may not be able to detect or signal YELLOW INDICATOR LIGHTS checked monthly when cold and inflated to the inflation low tire pressure as intended. TPMS malfunctions may 4WD Indicator Light —...
GETTING TO KNOW YOUR INSTRUMENT PANEL Forward Collision Warning (FCW) OFF Rear Axle Lock Indicator Light 4WD Auto Indicator Light — If Equipped Indicator Light — If Equipped This light indicates when the rear axle lock This light alerts the driver that the vehicle is has been activated page 120.
GETTING TO KNOW YOUR INSTRUMENT PANEL Plug Status Indicator Light — PHEV Only Gear Shift Indicator Light — If Equipped NOTE: with a Base Cluster When plugged in, the green plug indicator • A continuous chime will sound if the vehicle is light will illuminate if the Electric Vehicle driven more than 1 mile (1.6 km) with either turn When the automatic transmission is in...
GETTING TO KNOW YOUR INSTRUMENT PANEL Cruise Control SET Indicator Light — ONBOARD DIAGNOSTIC SYSTEM — OBD II ONBOARD DIAGNOSTIC SYSTEM If Equipped With Base Instrument (OBD II) CYBERSECURITY Cluster Your vehicle is equipped with a sophisticated Onboard Your vehicle is required to have OBD II and a connection Diagnostic system called OBD II.
STARTING AND OPERATING STARTING THE ENGINE NORMAL STARTING 4. If the gear selector is in NEUTRAL, and the vehicle speed is below 5 mph (8 km/h), pushing the START/ To Turn On The Engine Using The ENGINE START/STOP STOP button once will turn the engine off. The igni- Before starting your vehicle, adjust your seat, adjust Button tion will remain in the ACC position.
STARTING AND OPERATING If the driver shifts into PARK while moving, the vehicle • 4. Push the ENGINE START/STOP button a third time to Driver’s door is ajar or if the driver’s door is removed may AutoPark. return the ignition to the OFF position (instrument and the driver is not on the seat (seat pad sensor cluster will display “OFF”).
STARTING AND OPERATING EXTENDED PARK STARTING IF ENGINE FAILS TO START EXTREME COLD WEATHER (BELOW –22°F OR −30°C) If the engine fails to start after following the “Normal NOTE: Starting” procedure and the vehicle has not experi- Extended Park condition occurs when the vehicle has To ensure reliable starting at these temperatures, use enced an extended park condition, as previously not been started or driven for at least 30 days.
STARTING AND OPERATING NOTE: 300 to 500 miles (483 to 805 km): • A new engine may consume some oil during its first few Exercise the full engine RPM range, shifting manu- thousand miles (kilometers) of operation. This should ally (paddles or gear shift) at higher RPMs when be considered a normal part of the break-in and not possible.
STARTING AND OPERATING AUTOMATIC TRANSMISSION WARNING! WARNING! running. Before exiting a vehicle, always come to a • Never use the PARK position as a substitute for the You must press and hold the brake pedal while shifting complete stop, then apply the parking brake, shift parking brake.
STARTING AND OPERATING IGNITION PARK INTERLOCK must also press the brake pedal to shift from NEUTRAL into DRIVE or REVERSE when the vehicle is stopped or This vehicle is equipped with an Ignition Park Interlock moving at low speeds. Select the DRIVE range for nor- which requires the transmission to be in PARK before mal driving.
Page 120
STARTING AND OPERATING PARK (P) The following indicators should be used to ensure that CAUTION! you have properly engaged the transmission into the This range supplements the parking brake by locking PARK position: the transmission. The engine can be started in this •...
STARTING AND OPERATING MANUAL (M) • Even if the transmission can be reset, we recom- mend that you visit an authorized dealer at your The MANUAL (M, +/-) position (beside the DRIVE posi- earliest possible convenience. An authorized dealer tion) enables full manual control of transmission shift- has diagnostic equipment to assess the condition of ing also known as AutoStick mode.
STARTING AND OPERATING • The transmission will automatically downshift to WARNING! FIRST gear when coming to a stop. After a stop, the driver should manually upshift (+) the transmission Do not downshift for additional engine braking on a as the vehicle is accelerated. slippery surface.
STARTING AND OPERATING N (Neutral) In the event that additional traction is required, the erator pedal after completing the shift. Do not acceler- transfer case 4H and 4L positions can be used to lock ate while shifting the transfer case. Apply a constant the front and rear driveshafts together, forcing the front force when shifting the transfer case lever.
STARTING AND OPERATING 4H PART TIME/4H AUTO TO 4L OR 4L TO 4H Trac-Lok is especially helpful during slippery driving This feature will only activate when the following condi- conditions. With both rear wheels on a slippery surface, tions are met: PART TIME/4H AUTO a slight application of the accelerator will supply maxi- •...
STARTING AND OPERATING • AXLE LOCK (TRU-LOK) REAR ONLY Vehicle must not be actively in a high wheel slip or tight cornering condition. — IF EQUIPPED To activate the system, push the AXLE LOCK switch The rear axle may be locked in 4H if the proper condi- down to lock the rear axle only (“REAR ONLY”...
STARTING AND OPERATING OFF ROAD+ — IF EQUIPPED Once in Off Road+, the vehicle will begin to behave in WARNING! different ways depending on the 4WD mode in use. The When activated, Off Road+ is designed to improve the following enhancements will occur when using Off vehicle speed is reduced below 14 mph (22 km/h), user experience when using specific Off Road driving Road+.
STARTING AND OPERATING DUAL MODE EXHAUST — 6.4L WINCH USAGE — RUBICON If the ESC OFF button is pushed while in Off Road+, the following will occur on the vehicle: (IF EQUIPPED) (IF EQUIPPED) • Push of the ESC OFF Button: Traction Control will turn off, but Stability Control will remain active.
STARTING AND OPERATING 3. Remote Socket: The remote socket (underneath Snatch/Block Pulley: Used properly, the CAUTION! this cap) allows the remote control to be attached to multi-purpose snatch block allows you to (1) the control pack to allow the winch to function. increase the winch's pulling power;...
STARTING AND OPERATING General Information WARNING! CAUTION! Practice using your winch before you get stuck. Some • • Always wear heavy leather gloves when handling Inspect for cracks, pinches, frayed rope, or loose key points to remember when using your winch are: the synthetic rope.
Page 130
STARTING AND OPERATING WARNING! CAUTION! • Never touch winch rope or hook while someone Always be certain the anchor you select will withstand else is at the control switch or during winching the load. operation. • Never touch winch rope or hook while under ten- NOTE: sion or under load.
Page 131
STARTING AND OPERATING Tree Trunk Protector Winch Box Remote Control Connector Heavy Blanket Over Rope 10. Put synthetic rope under tension. Using the remote In certain situations you may decide to throw a 1 — Clevis/D-Shackles control switch, slowly wind the rope until no slack heavy blanket or similar object over the rope.
Page 132
STARTING AND OPERATING NOTE: ○ Avoid overheating the winch motor. For extended winching, stop at reasonable intervals to allow the winch motor to cool down. What to look for under load: The synthetic rope ○ must always spool onto the drum as indicated by the drum rotation decal on the winch.
STARTING AND OPERATING How To Change The Pulling Direction Double Line on the synthetic rope. Walk the synthetic rope towards the fairlead, carefully spooling in the Because pulling power decreases with the number of remaining rope by pulsing the remote control switch. layers of synthetic rope on the winch drum, you can use 18.
STARTING AND OPERATING NOTE: If the “SERVICE POWER STEERING” message and a flashing icon are displayed on the instrument cluster This system may take some time to return to full func- screen, it indicates that the vehicle needs to be taken tionality after a battery disconnect.
STARTING AND OPERATING To Activate The Autostop Mode, The Following Must • • The transmission is not in a forward gear. Battery voltage drops too low. Occur: • • Hood is open. Stop/Start OFF switch is pushed. • The system must be in STOP/START READY state. A •...
STARTING AND OPERATING • TO MANUALLY TURN ON THE Only one Cruise Control feature can operate at a WARNING! time. For example, if Fixed Speed Cruise Control is STOP/START SYSTEM enabled, Adaptive Cruise Control will be unavailable, Cruise Control can be dangerous where the system and vice versa.
STARTING AND OPERATING USING CRUISE CONTROL ON HILLS When the vehicle has reached the desired speed, push Pushing the on/off button or placing the ignition in the the SET (+) or SET (-) button and release. Release the OFF position erases the set speed from memory. The transmission may downshift on hills to maintain the accelerator and the vehicle will operate at the selected vehicle set speed.
STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation Adaptive Cruise Control Ready WARNING! When ACC is activated, but the vehicle speed setting The buttons on the right side of the steering wheel while driving to maintain safe control of your has not been selected, the display will read “Adaptive operate the ACC system.
STARTING AND OPERATING To Set A Desired Speed NOTE: • When the automatic transmission is in PARK, REVERSE or NEUTRAL When the vehicle reaches the speed desired, push the • Keeping your foot on the accelerator pedal can • SET (+) button or the SET (-) button and release. The When the vehicle speed is below the minimum cause the vehicle to continue to accelerate beyond speed range...
STARTING AND OPERATING To Turn Off NOTE: WARNING! When you override and push the SET (+) button or SET The system will turn off and erase the set speed in (-) buttons, the new set speed will be the current speed The Resume function should only be used if traffic memory if: of the vehicle.
STARTING AND OPERATING NOTE: • The vehicle ahead moves out of your lane or view of the sensor When the vehicle transitions from a location with left • hand drive traffic to a location with right hand drive traf- The distance setting is changed fic or vice versa, the ACC system will automatically •...
STARTING AND OPERATING Display Warnings And Maintenance • Do not remove any screws from the sensor. Doing so The “ACC/FCW Limited Functionality Clean Front Wind- could cause an ACC system malfunction or failure shield” message can sometimes be displayed while “WIPE FRONT RADAR SENSOR IN FRONT OF and require a sensor realignment.
Page 143
STARTING AND OPERATING Precautions While Driving With ACC TURNS AND BENDS LANE CHANGING In certain driving situations, ACC may have detection When driving on a curve with ACC engaged, the system ACC may not detect a vehicle until it is completely in the issues.
STARTING AND OPERATING NARROW VEHICLES ParkSense will retain the last system state (enabled or disabled) from the last ignition cycle when the ignition Some narrow vehicles traveling near the outer edges of is placed in the ON/RUN position. the lane or edging into the lane are not detected until ParkSense can be active only when the gear selector is they have moved fully into the lane.
STARTING AND OPERATING PARKSENSE DISPLAY The warning display will turn on indicating the system status when the vehicle is in REVERSE or when the vehicle is in DRIVE and an obstacle has been detected. The system will indicate a detected obstacle by showing a single arc in one or more regions based on the obsta- cle’s distance and location relative to the vehicle.
Page 146
STARTING AND OPERATING ParkSense Arcs 1 — No Tone/Solid Arc 6 — Fast Tone/Flashing Arc 2 — No Tone/Flashing Arc 7 — Fast Tone/Flashing Arc 3 — Fast Tone/Flashing Arc 8 — Slow Tone/Solid Arc 4 — Continuous Tone/Flashing Arc 9 —...
Page 147
STARTING AND OPERATING The vehicle is close to the obstacle when the display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the sys- tem is detecting an obstacle: WARNING ALERTS FOR REAR Greater than Rear Distance 79-59 inches...
STARTING AND OPERATING NOTE: When the gear selector is moved to REVERSE and the If the “ParkSense Unavailable Service Required” mes- system is disabled, the instrument cluster display will sage appears in the instrument cluster display, see an ParkSense will reduce the volume of the radio, if on, show the “PARKSENSE OFF”...
STARTING AND OPERATING NOTE: PARKVIEW REAR BACK UP CAMERA — WARNING! The “ParkSense Off” message will not display while IF EQUIPPED the vehicle is in 4WD Low position. You are responsible for safety and must continue to pay attention to your surroundings. Failure to do •...
STARTING AND OPERATING NOTE: NOTE: WARNING! If snow, ice, mud, or any foreign substance builds up on • If the vehicle speed remains below 8 mph the camera lens, clean the lens, rinse with water, and Drivers must be careful when backing up even when (13 km/h), the Rear View Camera image will be dis- dry with a soft cloth.
STARTING AND OPERATING Manual Activation Of The TrailCam NOTE: TrailCam view can be activated via these methods: • If the vehicle speed remains below 8 mph • Press the FWD Camera button on the controls (13 km/h) while in 2WD or 4WD High, the TrailCam screen.
STARTING AND OPERATING NOTE: NOTE: cation Number (VIN). A Month-Day-Hour (MDH) number ○ is included on this label and indicates the Month, Day When the fuel nozzle “clicks” or shuts off, the • When the fuel nozzle “clicks” or shuts off, the fuel and Hour of manufacture.
STARTING AND OPERATING Curb Weight Gross Trailer Weight (GTW) WARNING! The curb weight of a vehicle is defined as the total The GTW is the weight of the trailer plus the weight of Do not load your vehicle any heavier than the GVWR weight of the vehicle with all fluids, including vehicle all cargo, consumables and equipment (permanent or or the maximum front and rear GAWR.
STARTING AND OPERATING Frontal Area Weight-Distributing Hitch WARNING! The frontal area is the maximum height multiplied by A Weight-Distributing Hitch works by applying leverage • An improperly adjusted Weight Distributing Hitch the maximum width of the front of a trailer. through spring (load) bars.
STARTING AND OPERATING BREAKAWAY CABLE ATTACHMENT European braking regulations for braked trailers up to 7,700 lb (3,500 kg), require trailers to be fitted with either a secondary coupling or breakaway cable. The recommended location for attaching the normal trailer's breakaway cable is in the stamped slot located on the sidewall of the hitch receiver.
STARTING AND OPERATING TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) Model Frontal Area Maximum GTW Maximum Trailer TW Two-Door 20 ft (1.86 m 3,300 lb (1,497 kg) 165 lb (75 kg) Four-Door 30 ft (2.79 m 5,500 lb (2,495 kg) 275 lb (125 kg) Four-Door 6.4L 30 ft...
STARTING AND OPERATING Towing Requirements — Trailer Brakes Towing Requirements — Trailer Lights CAUTION! And Wiring Do not interconnect the hydraulic brake system or • • Do not tow a trailer at all during the first 500 miles vacuum system of your vehicle with that of the Whenever you pull a trailer, regardless of the trailer (805 km) the new vehicle is driven.
Page 158
STARTING AND OPERATING Seven-Pin Connector 13–Pin Connector — If Equipped 1 — Backup Lamps 2 — Running Lamps 3 — Left Stop/Turn 4 — Ground 5 — Battery 6 — Right Stop/Turn 7 — Electric Brakes Pin Number Function Wire Color Left Turn Signal Black/White Rear Fog Light...
STARTING AND OPERATING Pin Number Function Wire Color Reverse Lights Blue/Red Permanent Power Supply (+12 Volt) Power Supply Controlled by Ignition Switch (+12 Volt) Yellow Return for Contact (Pin) 10 Yellow/Brown Reserve for Future Allocation – Return for Contact (Pin) 9 Red/Brown NOTE: The allocation pin 12 has been changed from “Coding for Coupled Trailer”...
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE Towing Condition Wheels OFF the Ground Four-Wheel Drive Models Flat Tow NONE NOT ALLOWED Front NOT ALLOWED Dolly Tow Rear NOT ALLOWED On Trailer NOTE: When towing your vehicle, always follow applicable laws. Contact local authorities for additional details. OFF-ROAD DRIVING TIPS DRIVING TIPS Side Step Removal —...
STARTING AND OPERATING Bumper End Cap Removal trail, you should always be looking ahead for surface obstacles and changes in terrain. The key is to plan The end caps on your vehicle’s front fascia/bumper can your future driving route while remembering what you be removed by following the steps listed: are currently driving over.
STARTING AND OPERATING CAUTION! CAUTION! Deep mud creates a great deal of suction around the Do not use 4L when operating the vehicle on dry Reduced tire pressures may cause tire unseating and tires and is very difficult to get through. You should use pavement.
Page 164
STARTING AND OPERATING Hill Climbing Have the person stand a safe distance in front of you WARNING! where they can see the obstacle, watch your tires and Hill climbing requires good judgment and a good under- undercarriage, and guide you through. There is an increased risk of rollover when crossing standing of your abilities and your vehicle's limitations.
STARTING AND OPERATING Driving Through Water DRIVING ACROSS AN INCLINE surface and will usually provide enough traction to com- plete the climb. If you do not make it to the top, place If at all possible, avoid driving across an incline. If it is Extreme care should be taken crossing any type of the vehicle in REVERSE and back straight down the necessary, know your vehicle's abilities.
STARTING AND OPERATING BEFORE YOU CROSS ANY TYPE OF WATER CROSSING DITCHES, STREAMS, SHALLOW • Completely inspect the underbody of your vehicle. Check tires, body structure, steering, suspension, RIVERS OR OTHER FLOWING WATER As you approach any type of water, you need to deter- and exhaust system for damage.
MULTIMEDIA UCONNECT SYSTEMS Press the Back Arrow button to exit out of a Menu or WARNING! certain option on the Uconnect system. • For detailed information about your Uconnect 5 NAV ONLY insert trusted devices/components into your CUSTOMER PROGRAMMABLE With 12.3-inch Display, refer to your Uconnect Radio vehicle.
Page 168
MULTIMEDIA NOTE: When making a selection, press the button on the ting is complete, press the Vehicle button to exit to the touchscreen to enter the desired menu. Once in the screen. Pressing the Up or Down Arrow button on the •...
Page 169
MULTIMEDIA Setting Name Description Navigation Turn-by-Turn Displayed in This setting will display Navigation prompts in the Instrument Cluster Display. Cluster Phone Pop-ups Displayed In Cluster This setting will display smartphone notifications and messages in the Instrument Cluster Display. Auto Launch with Off-Road+ This setting will determine how the Off-Road feature is launched through the radio when turning the vehicle on.
Page 170
This setting will allow you to change the voice options for the radio to “Male” or “Female”. Wake Up Word This setting will allow you to set the system “Wake Up” word. The available options are “Off”, “Hey, Uconnect”, and “Hey, Jeep”. Voice Barge-in This setting will allow Voice Barge-in to be turned on or off.
MULTIMEDIA Setting Name Description Navigation Turn-by-Turn Displayed in This setting will display Navigation prompts in the Instrument Cluster Display. Cluster Phone Pop-ups Displayed In Cluster This setting will display smartphone notifications and messages in the Instrument Cluster Display. Safety/Driving Assistance When the Safety/Driving Assistance button is pressed on the touchscreen, the system displays the options related to the vehicle’s safety settings.
MULTIMEDIA Setting Name Description Traffic Sign Recognition This setting will turn Traffic Sign Recognition on or off. Traffic Sign Assist This setting will turn Traffic Sign Assist on or off. Traffic Sign Assist Warning This setting will allow you to set the warning type related to the traffic sign. The available options are “Off”, “Visual”, and “Visual + Chime”.
MULTIMEDIA Clock & Date When the Clock & Date button is pressed on the touchscreen, the system displays the different options related to the vehicle’s internal clock. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Sync Time With GPS This setting will sync the time to the GPS receiver in the system.
Page 174
This setting will allow you to change the system’s voice to either “Male” or “Female”. Wake Up Word This setting will allow you to set the system’s “Wake Up” word. The available options are “Off”, “Hey, Uconnect”, and “Hey, Jeep”. Voice Barge-In This setting allows you to respond to a Voice Response before the statement is completed by the system.
Page 175
MULTIMEDIA Camera When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description ParkView Backup Camera Delay This setting will add a timed delay to the ParkView Backup Camera when shifting out of REVERSE. ParkView Backup Camera Active This setting will turn the ParkView Backup Camera Active Guidelines on or off.
MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE: • When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchase.
Page 177
MULTIMEDIA Setting Name Description Sound Horn With Lock This setting will sound the horn when the Lock button is pushed on the key fob. The “Off” setting will not sound the horn when the Lock button is pushed. The “1st Press” setting will sound the horn when the Lock button is pushed once. The “2nd Press” setting will sound the horn when the Lock button is pushed twice.
MULTIMEDIA AUX Switches When the AUX Switches button is pressed on the touchscreen, the system displays the option related to the four vehicle AUX switches. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will adjust the type and power source for the four vehicle AUX switches. There are two types: “Latching” and “Momen- tary”.
Page 179
MULTIMEDIA Audio When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone. NOTE: Depending on the vehicle’s options, feature settings may vary.
MULTIMEDIA Radio Setup When the Radio Setup button is pressed on the touchscreen, the system will provide selectable options related to the regional setup of the radio. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Regional This setting will automatically switch between network stations depending on the region.
MULTIMEDIA STEERING WHEEL AUDIO CONTROLS — OFF-ROAD PAGES — IF EQUIPPED The following describes the left-hand control operation in each mode: IF EQUIPPED If your vehicle is equipped with Off-Road Pages, it will RADIO OPERATION provide you vehicle status information while operating on off-road conditions.
MULTIMEDIA ACCESSORY GAUGE The Accessory Gauge page displays the current status of the vehicle’s Coolant Temperature, Oil Temperature, Oil Pressure (Gas Vehicles Only), Transmission Tem- perature (Automatic Transmissions Only), and Battery Voltage. Vehicle Dynamics Menu 2WD/4WD Pitch & Roll Menu 2WD/4WD 1 —...
MULTIMEDIA • TRAIL RECORDING — IF EQUIPPED Places Places Obstacles Guidance • Obstacle Staging Area Sand Dead End Overview • Guidance Trailhead Steep Ascent Hard Left The Trail Recording feature can be accessed from a NOTE: Water Steep Descent Hard Right variety of different ways: Within the Vehicle Dashboard A Waypoint can be placed whether or not the vehicle is Water...
MULTIMEDIA Saved Trails ○ ADVENTURE GUIDES — IF EQUIPPED If there are no search results within the area in which you added the address or keyword, the To view previously saved trails, click the Saved Record- message “No Results Found” will display on your ings button on the Trail Recording home page.
Page 185
MULTIMEDIA Preloaded Trails Press “Preloaded Trails” to see a list of trails that are preloaded onto your Uconnect system. Expanded Trail Difficulty View Navigate To Trail NOTE: 5. If the trail does not exist within your Uconnect sys- tem’s local memory, press the Download button. If Each trail detail screen will provide you information Preloaded Trails the trail already exists, meaning it has already been...
Page 186
MULTIMEDIA Press the Remove icon to remove a trail from the list. You will be presented with a confirmation, “Are you sure you want to delete this trail?”. Press “Yes” to show the selected trail was deleted successfully, or press “No” or the X button which will bring you back to the Down- loaded Trails list.
SAFETY Anti-Lock Brake System (ABS) Warning SAFETY FEATURES WARNING! Light • The ABS contains sophisticated electronic equip- ANTI-LOCK BRAKE SYSTEM (ABS) The yellow ABS Warning Light will turn on when the igni- ment that may be susceptible to interference tion is placed in the ON/RUN mode and may stay on for caused by improperly installed or high output radio The ABS provides increased vehicle stability and brake as long as four seconds.
SAFETY Brake System Warning Light WARNING! WARNING! The red Brake System Warning Light will turn on when never be exploited in a reckless or dangerous man- • Before exiting a vehicle, always come to a com- the ignition is placed in the ON/RUN mode and may ner, which could jeopardize the user's safety or the plete stop, then shift the automatic transmission stay on for as long as four seconds.
SAFETY ESC Operating Modes begins to flash during acceleration, ease up on the WARNING! accelerator and apply as little throttle as possible. Be Depending upon model and mode of operation, the ESC sure to adapt your speed and driving to the prevailing Many factors, such as vehicle loading, road condi- system may have multiple operating modes.
SAFETY Indicator Light also flashes when TCS is active. If the WARNING! WARNING! ESC Activation/Malfunction Indicator Light begins to flash during acceleration, ease up on the accelerator • • When in “Partial Off” mode, the TCS functionality In the ESC “Full Off” mode, the engine torque and apply as little throttle as possible.
SAFETY NOTE: • 3. Active (feature is enabled and actively controlling HDC detects excessive brake temperature. vehicle speed). Feedback To The Driver During HDC the +/- shifter input is used for HDC target Enabling HDC speed selection, but will not affect the gear chosen by The instrument cluster has an HDC icon and the HDC the transmission.
Page 192
SAFETY Rain Brake Support (RBS) the driver does not apply the throttle before this time WARNING! expires, the system will release brake pressure and the RBS may improve braking performance in wet condi- vehicle will roll down the hill as normal. safe control of your vehicle.
Page 193
SAFETY Deactivating SSC • • The parking brake is released. 9th = 5.6 mph (9 km/h) — if equipped • • The driver door is closed (If doors are attached, the REVERSE = 0.6 mph (1 km/h) SSC will be deactivated but remain available if any of door must be closed.
SAFETY Trailer Sway Control (TSC) • The cluster icon and switch light will flash for several seconds then extinguish when SSC disables due to TSC uses sensors in the vehicle to recognize an exces- excess speed. sively swaying trailer and will take the appropriate •...
Page 195
SAFETY Entering From The Side • The BSM system detection zone DOES NOT change if your vehicle is towing a trailer. Therefore, visually Vehicles that move into your adjacent lanes from either verify the adjacent lane is clear for both your vehicle side of the vehicle.
SAFETY Rear Cross Path (RCP) Overtaking Traffic The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foli- If you pass another vehicle slowly with a relative speed RCP is intended to aid the driver when backing out of age, berms, etc.
SAFETY NOTE: chime will also be sounded. Whenever a turn signal and Upon re-installation of both doors, the system will detected object are present on the same side at the resume functionality based on the personalized mode In a parking lot situation, oncoming vehicles can be same time, both the visual and audible alerts will be selected.
SAFETY • • collision. If the Forward Collision Warning with Mitiga- The FCW system is intended for on-road use only. If Select “OFF” in the FCW menu to turn the FCW sys- tion event stops the vehicle completely, the system will the vehicle is taken off-road, the FCW system should tem off.
SAFETY Service FCW Warning NOTE: The TPMS will warn the driver of a low tire pressure if the tire pressure falls below the low-pressure warning The “Far” setting may result in a greater number of If the system turns off, and the instrument cluster limit for any reason, including low temperature effects FCW possible collision warnings experienced.
SAFETY NOTE: NOTE: When filling warm tires, the tire pressure may need to • The TPMS is not intended to replace normal tire be increased up to an additional 4 psi (28 kPa) above care and maintenance, or to provide warning of a the recommended cold placard pressure in order to tire failure or condition.
Page 201
SAFETY SERVICE TPMS WARNING Light to be on, a chime to sound, an Inflate to XX message to appear in the instrument cluster, and When a system fault is detected, the TPMS Warning the graphic display will still show the low tire pres- Light will flash on and off for 75 seconds and then sure value in a different color.
Page 202
SAFETY display pressure values in place of the dashes. On the When Tire Fill Alert mode is entered, the tire pressure In the Selectable Tire Fill Alert application, which is next ignition cycle the "SERVICE TIRE PRESSURE SYS- display screen will be displayed in the instrument located in the apps menu of the Uconnect system, you TEM"...
SAFETY Horn chirps will indicate STFA status as tires are Here are some simple steps you can take to minimize 3. If a child from 2 to 12 years old (not in a rear-facing inflated/deflated. The horn will chirp under the follow- the risk of harm from a deploying air bag: child restraint) must ride in the front passenger ing STFA states:...
SAFETY Enhanced Seat Belt Use Reminder repeat based on vehicle speed until the driver and WARNING! System (BeltAlert) occupied outboard front seat passenger seat belts are • buckled. The driver should instruct all occupants to Should it be necessary to carry a child on the pas- Driver And Passenger BeltAlert —...
Page 205
SAFETY under normal conditions. However, in a collision the WARNING! WARNING! seat belt will lock and reduce your risk of striking the inside of the vehicle or being thrown out of the vehicle. • Two people should never be belted into a single seat internal injuries.
SAFETY 3. Slide the latch plate upward over the folded web- bing. The folded webbing must enter the slot at the top of the latch plate. 4. Continue to slide the latch plate up until it clears the folded webbing and the seat belt is no longer twisted.
SAFETY Seat Belts And Pregnant Women NOTE: NOTE: The adjustable upper shoulder belt anchorage is These devices are not a substitute for proper seat belt equipped with an Easy Up feature. This feature allows placement by the occupant. The seat belt still must be the shoulder belt anchorage to be adjusted in the worn snugly and positioned properly.
SAFETY • Knee Impact Bolsters function. While the air bag system is designed to be instrument panel. The Redundant Air Bag Warning Light maintenance free, if any of the following occurs, have will stay on until the fault is cleared. In addition, a •...
SAFETY Driver And Passenger Front Air Bag WARNING! WARNING! Features because the air bags may no longer be functional. • Being too close to the steering wheel or instrument The front air bag system is designed to inflate based on The protective covers for the air bag cushions are panel during front air bag deployment could cause the severity and type of collision as determined by the...
Page 210
SAFETY When the Occupant Restraint Controller (ORC) detects a WARNING! collision requiring the front air bags, it signals the infla- tor units. A large quantity of non-toxic gas is generated • Do not install a child restraint in the front seat to inflate the front air bags.
Page 211
SAFETY Once the self-check is complete, only one Passenger Air WARNING! Bag Indicator Light should be illuminated at a time. • NEVER use a rearward facing child restraint on a WARNING! seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
Page 212
SAFETY DISABLING (OFF) The Passenger Advanced Front Air Bag To DISABLE (OFF) the Passenger Advanced Front Air Bag, access the instrument cluster display main menu located in the instrument cluster by pushing the Up or Down arrow but- ton located on the steering wheel, then complete the following actions: Action Information Scroll Up or Down to “Vehicle Set-Up”...
Page 213
SAFETY ENABLING (ON) The Passenger Advanced Front Air Bag Access the instrument cluster display main menu located in the instrument cluster by pushing the Up or Down arrow button located on the steering wheel, then complete the fol- lowing actions: Action Information Scroll Up or Down to “Vehicle Set-Up”...
SAFETY Supplemental Side Air Bags could injure occupants if they are not seated properly, WARNING! or if items are positioned in the area where the SAB Supplemental Seat-Mounted Side Air Bags (SABs) — • inflates. Children are at an even greater risk of injury Should it be necessary to carry a child on the pas- If Equipped from a deploying air bag.
Page 215
SAFETY Side Impacts SABICs (if equipped with SABICs) may help reduce the WARNING! risk of head and other injuries to front and rear seat The Side Air Bags are designed to activate in certain outboard occupants in certain side impacts, in addition •...
SAFETY Air Bag System Components Enhanced Accident Response System ing along a carpet or gymnasium floor. They are not caused by contact with chemicals. They are not per- In the event of an impact, if the communication net- NOTE: manent and normally heal quickly. However, if you work remains intact, and the power remains intact, haven’t healed significantly within a few days, or if The Occupant Restraint Controller (ORC) monitors the...
SAFETY Maintaining Your Air Bag System Event Data Recorder (EDR) NOTE: After an accident, remember to cycle the ignition to the This vehicle is equipped with an event data recorder STOP (OFF/LOCK) position and remove the key from the WARNING! (EDR).
SAFETY CHILD RESTRAINTS — CARRYING sure you have the correct seat for your child. Carefully WARNING! read and follow all the instructions and warnings in the CHILDREN SAFELY child restraint Owner’s Manual and on all the labels • NEVER use a rearward facing child restraint on a attached to the child restraint.
Page 219
The rear-facing child restraint is restrained by the vehi- a seating position is suitable for the type of child Jeep® vehicles. cle’s seat belts, as shown in fig. A. The child seat restraint you are using page 222.
Page 220
SAFETY Group 3 Children who weigh between 9 kg and 18 kg may be WARNING! carried in a Group 1, forward facing seat like the one in fig. B. This type of child restraint is for older children ments. Remove the child restraint before adjusting who are too big for a Group 0 or 0+ child restraint.
SAFETY belt buckle is latched. A child’s squirming or slouching Your vehicle is equipped with the child restraint anchor- can move the belt out of position. If the shoulder belt age system called ISOFIX. This system allows ISOFIX- contacts the face or neck, move the child closer to the equipped child seats to be installed without using the center of the vehicle, or use a booster seat to position vehicle’s seat belts.
SAFETY Center Seat ISOFIX Four-Door Models the vehicle, you may wish to move it to its rear-most position to make room for the child seat. You may There are tether strap anchorages behind each rear Two-Door Model also move the front seat forward to allow more room outboard seating position located on the back of the for the child seat.
SAFETY Installing Child Restraints Using The Top Suitability Of Passenger Seats For i-Size Tether Anchorage: Child Restraint System Use The rear outboard seats of the vehicle are type- 1. Look behind the seating position where you plan to approved to house the state-of-the-art i-Size child install the child restraint to find the tether anchor- restraint systems.
Page 224
SAFETY Child Restraint Usage By Seating Position This table gives technical information specifically intended for the child restraint system manufacturer and, as such, translation into national language is not required: Seating Positions Four-Door Seat Position Number Seating Posi- tion Suitable For Universal Belted (Yes / No)
Page 225
SAFETY SEATING POSITIONS: 1. Front Left 2. Front Center 3. Front Right 4. 2nd Row Left 5. 2nd Row Center 6. 2nd Row Right 7. 3rd Row Left 8. 3rd Row Center 9. 3rd Row Right Always follow the directions of the child restraint manufacturer when installing your child restraint.
SAFETY SAFETY TIPS CONNECTED VEHICLES the system inspected at an authorized dealer as soon as possible. This light will illuminate with a single chime Privacy of any wireless and wired communications can- when a fault with the Air Bag Warning Light has been not be assured.
SAFETY Door Latches WARNING! WARNING! Check for proper closing, latching, and locking. • • ALWAYS REMOVE THE EXISTING FLOOR If the vehicle carpet has been removed and Fluid Leaks MAT FROM THE VEHICLE before installing re-installed, always properly attach carpet to the any other floor mat.
SAFETY Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the vehicle, or when the underside or rear of the vehicle is damaged, have an authorized dealer inspect the complete exhaust system and adjacent body areas for broken, damaged, deteriorated, or mispositioned parts.
IN CASE OF EMERGENCY NOTE: HAZARD WARNING FLASHERS ing. Pressing the SOS button on the overhead console will illuminate the light within the button. When the con- With extended use the Hazard Warning Flashers may nection between the vehicle and a public safety opera- wear down your battery.
Page 231
IN CASE OF EMERGENCY You will then be able to speak with the emergency ser- Even if the SOS-Emergency Call system is fully func- WARNING! vice operator to determine if additional help is needed. tional, external or uncontrolled factors may prevent or stop SOS-Emergency Call operation.
IN CASE OF EMERGENCY JACKING AND TIRE CHANGING 2. Turn on the Hazard Warning Flashers. WARNING! 3. Apply the parking brake. emergency service operator. All occupants should 4. Shift the automatic transmission into PARK (P), or a exit the vehicle immediately and move to a safe WARNING! manual transmission into REVERSE (R).
IN CASE OF EMERGENCY 3. Turn the plastic wing nut counterclockwise to loosen the jack from the storage bin. Load Floor Handle Unlock Rear Camera Cover NOTE: 3. Remove the lug nuts with the lug wrench turning Plastic Wing Nut Location them counterclockwise.
IN CASE OF EMERGENCY NOTE: JACKING INSTRUCTIONS If your vehicle comes with factory equipped 35 inch (88.9 cm) tires, a jack lift block is provided in the WARNING! rear cargo area. The jack lift block is used to provide higher ground clearance when changing a flat or Carefully follow these tire changing warnings to help spare tire.
Page 235
IN CASE OF EMERGENCY Front Lifting Point Front Jacking Location Rear Jacking Location NOTE: 5. Raise the vehicle by turning the jack screw clock- wise. Raise the vehicle only until the tire just clears Keep the jack and tools aligned while raising the the surface and enough clearance is obtained to vehicle to prevent tool damage.
IN CASE OF EMERGENCY WARNING! CAUTION! To avoid the risk of forcing the vehicle off the jack, do Do not use a portable battery booster pack or any not tighten the wheel nuts fully until the vehicle has other booster source with a system voltage greater been lowered.
IN CASE OF EMERGENCY NOTE: The battery in your vehicle is located in the right rear of If your vehicle is equipped with a Stop/Start system, it the engine compartment. will be equipped with two batteries page 132. The positive (+) battery post is covered with a protective cap.
IN CASE OF EMERGENCY frame or chassis, such as an accessory bracket or 5. Start the engine in the vehicle that has the booster CAUTION! large bolt. The ground must be away from the bat- battery, let the engine idle a few minutes, and then tery and the fuel injection system.
IN CASE OF EMERGENCY If the temperature gauge is moving towards or close to 3. Fish the tether strap up through the opening in the WARNING! the HOT (H) position, you can reduce the potential for console base. overheating by taking the appropriate action. Always secure your vehicle by fully applying the park- •...
IN CASE OF EMERGENCY To Reset The Manual Park Release: FREEING A STUCK VEHICLE WARNING! 1. Pull upward on the tether strap, releasing it from the when you are stuck and do not let anyone near a If your vehicle becomes stuck in mud, sand or snow, it “locked”...
IN CASE OF EMERGENCY Towing Condition Wheels OFF The Ground 4WD MODELS NOT ALLOWED Flat Tow NONE NOT ALLOWED Front Wheel Lift Or Dolly Tow NOT ALLOWED Rear BEST METHOD Flatbed NOTE: When towing your vehicle, always follow applicable state and provincial laws. Contact state and provincial Highway Safety offices for additional details. Proper towing or lifting equipment is required to prevent CAUTION! damage to your vehicle.
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM CAUTION! (EARS) • The tow eye must only be used for roadside emer- gencies. Use with an appropriate device in accor- dance with highway code (a rigid bar or rope) to This vehicle is equipped with an Enhanced Accident maneuver the vehicle in preparation for transport Response System.
SERVICING AND MAINTENANCE Once A Month Or Before A Long Trip: SCHEDULED SERVICING On non-instrument cluster display equipped vehicles, “Change Oil” will flash in the instrument cluster odom- • Check the engine oil level. eter and a single chime will sound, indicating that an oil Your vehicle is equipped with an automatic oil change •...
Page 244
SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First): Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, rear suspension, and replace if necessary. Inspect the front and rear axle fluid. Inspect the brake linings, replace as necessary.
Page 245
SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First): Or Years: Or Kilometers: Flush and replace the engine, intercooler (if equipped), power electronics (if equipped), and battery (if equipped) cool- ant at 10 years or 150,000 miles (240,000 km) whichever comes first. Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading,...
SERVICING AND MAINTENANCE NOTE: • Check the fluid levels of the coolant reservoir, WARNING! engine oil, brake master cylinder, and add as • The oil change indicator message will not monitor needed. • You can be badly injured working on or around a the time since the last oil change.
SERVICING AND MAINTENANCE MAINTENANCE PLAN Miles: Or Months: 96 102 108 114 120 126 132 138 144 150 Or Kilometers: Change the engine oil and engine oil filter. Rotate the tires. Rotate at the first sign of irregular wear, even if it occurs before scheduled maintenance.
Page 248
SERVICING AND MAINTENANCE Miles: Or Months: 96 102 108 114 120 126 132 138 144 150 Or Kilometers: Inspect the front and rear axle fluid. Change if using your vehicle for any of the following: police, taxi, fleet, sus- tained high speed driving, off-road or frequent trailer towing.
SERVICING AND MAINTENANCE WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
SERVICING AND MAINTENANCE 3.6L ENGINE 1 — Power Distribution Center (Fuses) 7 — Power Pack Unit Pressure Cap — If Equipped 2 — Battery 8 — Washer Fluid Reservoir Cap 3 — Engine Oil Dipstick 9 — Engine Air Cleaner, Filter 4 —...
SERVICING AND MAINTENANCE CHECKING OIL LEVEL CAUTION! WARNING! To ensure proper engine lubrication, the engine oil must Overfilling or underfilling the crankcase will cause Commercial windshield washer solvents are flam- be maintained at the correct level. Check the oil level at aeration or loss of oil pressure.
SERVICING AND MAINTENANCE PRESSURE WASHING ENGINE OIL WARNING! Cleaning the engine compartment with a high pressure Engine Oil Selection • Serious injury or death could result if you do not washer is not recommended. disconnect both batteries. To learn how to properly For engine oil selection page 296.
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection and ENGINE OIL FILTER CAUTION! Replacement The engine oil filter should be replaced with a new filter Do not use chemical flushes in your engine oil as the at every engine oil change. Follow the recommended maintenance intervals as chemicals can damage your engine.
Page 256
SERVICING AND MAINTENANCE First Water Separation Chamber Removal — 6.4L Engine Removal 1. Loosen the six captured fasteners from the first water separation chamber using a suitable tool. Engine Air Cleaner Filter Cover First Water Chamber Removal Engine Air Cleaner Filter Installation Installation NOTE: NOTE:...
SERVICING AND MAINTENANCE CAUTION! Do not overtighten the engine air cleaner filter cover lid screws or damage may result. ACCESSORY DRIVE BELT INSPECTION WARNING! • Do not attempt to inspect an accessory drive belt First Water Separation Chamber Engine Air Cleaner Cover with vehicle running.
SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling — AIR CONDITIONER MAINTENANCE R–1234yf For best possible performance, your air conditioner should be checked and serviced by an authorized R–1234yf Air Conditioning Refrigerant is a Hydrofluo- dealer at the start of each warm season. This service roolefin (HFO) that is endorsed by the Environmental should include cleaning of the condenser fins and a Protection Agency and is an ozone-friendly substance...
SERVICING AND MAINTENANCE 5. Remove the air filter from the HVAC air inlet housing. Pull the filter elements out pinching them to the right for clearance. Glove Compartment Travel Stop Travel Dampener 3. Pivot the glove compartment downward. 1 — Travel Dampener Housing Air Filter 2 —...
SERVICING AND MAINTENANCE The external lock cylinders should be lubricated twice a If a wiper blade or wiper arm is damaged, replace the year, preferably in the Autumn and Spring. Apply a small affected wiper arm or blade with a new unit. Do not amount of a high quality lubricant, such as Mopar®...
SERVICING AND MAINTENANCE Rear Wiper Blade Removal/Installation Installing The Rear Wiper 1. Lift the wiper arm off of the glass. 1. Open swing gate to access the wiper arm. 2. Insert the wiper blade pivot pin into the opening on the end of the wiper arm and rotate the wiper in to place.
SERVICING AND MAINTENANCE Coolant Checks the vehicle, turn off the engine and allow it to cool. Ser- WARNING! vice, including a tune-up to manufacturer’s specifica- Check the engine and intercooler (if equipped) coolant tions, should be obtained immediately. exhaust system. Do not park or operate your (antifreeze) protection every 12 months (before the vehicle in areas where your exhaust system can To minimize the possibility of catalytic converter...
SERVICING AND MAINTENANCE NOTE: • prevent reducing this extended maintenance period, it Use care when filling under hood fluids such as is important to use the same engine coolant (OAT cool- engine oil, washer fluid, antifreeze, etc., to minimize • Mixing of engine coolant (antifreeze) other than ant conforming to MS.90032) throughout the life of spillage onto the top of the engine.
SERVICING AND MAINTENANCE Engine Coolant Level When additional engine coolant is needed to maintain WARNING! the proper level, only OAT coolant that meets the • requirements of the manufacturer Material Standard Do not use a pressure cap other than the one WARNING! MS.90032 should be added to the coolant bottle.
SERVICING AND MAINTENANCE • Keep the front of the radiator clean. If your vehicle is expected to fall as the brake pads wear. Brake fluid FRONT/REAR AXLE FLUID equipped with air conditioning, keep the front of the level should be checked when pads are replaced. If the For normal service, periodic fluid level checks are not condenser clean.
SERVICING AND MAINTENANCE Selection Of Lubricant CAUTION! It is important to use the proper transmission fluid to Do not use chemical flushes in your transmission as ensure optimum transmission performance and life. the chemicals can damage your transmission compo- Use only the manufacturer specified transmission fluid nents.
SERVICING AND MAINTENANCE WARNING! CAUTION! Never replace a blown fuse with metal wires or any When installing the power distribution center cover, it other material. Failure to use proper fuses may is important to ensure the cover is properly posi- result in serious personal injury, fire and/or prop- tioned and fully latched.
Page 268
SERVICING AND MAINTENANCE Power Distribution Center Location...
Page 269
SERVICING AND MAINTENANCE Power Distribution Center Location (6.4 Engine)
Page 271
SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 30 Amp Pink – Pass Pwr Seat – 10 Amp Red MOD_SBW 40 Amp Green – Central Body Controller (CBC) 2-EXTERIOR LIGHTS #1 30 Amp Pink – Front Wipers 40 Amp Green –...
Page 272
SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 10 Amp Red Occupant Restraint Controller (ORC) – 10 Amp Red HD ACC * – 10 Amp Red Digital TV Inline / USB / ISRVM / Compass Mod –...
Page 273
SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 20 Amp Blue – PWR TOP RT – – Spare * – 20 Amp Yellow – 10 Amp Red Heated Mirrors – 10 Amp Red Intrusion Mod / SIREN / Intrusion Snsrs –...
SERVICING AND MAINTENANCE BULB REPLACEMENT Replacement Bulbs, Names, And Part Numbers In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers. NOTE: See an authorized dealer for LED bulb replacement. Interior Bulbs Bulb Name Bulb Number Automatic Transmission Indicator Lamp...
Page 276
SERVICING AND MAINTENANCE Exterior Bulbs Bulb Name Bulb Number Rear Base Tail Lamp Stop/Tail Bulb P27/7W Rear Base Tail Lamp Turn Signal Bulb WY21W Rear Base Tail Lamp Backup Bulb W16W Rear Base Tail Lamp Side Marker Center High Mounted Stop Lamp License Lamp Rear Fog W21W...
Page 277
SERVICING AND MAINTENANCE HALOGEN FRONT FOG LAMP REAR TAIL, STOP, TURN SIGNAL, AND BACKUP LAMP See the following steps to replace: See the following steps to replace: 1. Reach under the vehicle to access the back of the front fog lamp. 1.
SERVICING AND MAINTENANCE LICENSE PLATE LAMPS CAUTION! See the following steps to replace: Do not touch the new bulb with your fingers. Oil con- 1. Firmly grab the two latch features on either side of tamination will severely shorten bulb life. If the bulb the lamp and squeeze them together.
SERVICING AND MAINTENANCE Tire Markings Tire And Loading Information Placard Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle. Tire And Loading Information Placard Tire Markings This placard tells you important information about the: Example Tire Placard Location (Door)
SERVICING AND MAINTENANCE Tire Inflation Pressures NOTE: WARNING! Under a maximum loaded vehicle condition, Gross Axle The proper cold tire inflation pressure is listed on the • Weight Rating (GAWR) for the front and rear axles must Unequal tire pressures can cause steering prob- driver's side B-pillar or rear edge of the driver's side not be exceeded.
SERVICING AND MAINTENANCE Radial Ply Tires Example: If garage temperature = 68°F (20°C) and the has limited driving capabilities and needs to be outside temperature = 32°F (0°C) then the cold tire replaced immediately. A Run Flat tire is not repairable. inflation pressure should be increased by 3 psi When a Run Flat tire is changed after being driven in a WARNING!
SERVICING AND MAINTENANCE Tread Wear Indicators • Tire pressure - Improper cold tire inflation pressures on “Tread Wear Indicators” in this section. Refer to the can cause uneven wear patterns to develop across Tire And Loading Information Placard or the Vehicle Tread wear indicators are in the original equipment the tire tread.
SERVICING AND MAINTENANCE Summer tires do not contain the all season designation SPARE TIRES — IF EQUIPPED WARNING! or mountain/snowflake symbol on the tire sidewall. Use • Summer tires only in sets of four; failure to do so may NOTE: Failure to equip your vehicle with tires having adversely affect the safety and handling of your vehicle.
SERVICING AND MAINTENANCE Limited Use Spare — If Equipped T, S = Temporary Spare Tire Your wheels are susceptible to deterioration caused by salt, sodium chloride, magnesium chloride, calcium Since this tire has limited tread life, the original equip- The limited use spare tire is for temporary emergency chloride, etc., and other road chemicals used to melt ment tire should be repaired (or replaced) and rein- use only.
SERVICING AND MAINTENANCE NOTE: DEPARTMENT OF TRANSPORTATION Refer to the “Service and Warranty Handbook (Auto Biography)” for the proper maintenance intervals. The If you intend parking or storing your vehicle for an reasons for any rapid or unusual wear should be cor- UNIFORM TIRE QUALITY GRADES extended period after cleaning the wheels with wheel rected prior to rotation being performed.
SERVICING AND MAINTENANCE cantly from the norm due to variations TEMPERATURE GRADES STORING THE VEHICLE in driving habits, service practices, and The Temperature grades are A (the differences in road characteristics and WARNING! highest), B, and C, representing the climate. tire's resistance to the generation of •...
SERVICING AND MAINTENANCE What Causes Corrosion? NOTE: If you are storing your vehicle for more than three weeks, we recommend that you take the following steps • Corrosion is the result of deterioration or removal of You must isolate the supplemental battery connec- to minimize the drain on your vehicle's battery: paint and protective coatings from your vehicle.
SERVICING AND MAINTENANCE • Washing – Use Mopar® Car Wash or equivalent, or PRESERVING THE BODYWORK If you detect any stone chips or scratches in the paint, touch them up immediately. The cost of such mild soap suds, lukewarm water, and a brush with soft Washing repairs is considered the responsibility of the owner.
SERVICING AND MAINTENANCE CARPET REMOVAL 3. Remove the grommets under the front seat. First for 5. Finally open the carpet split around seat bracket the rear carpet and then the front carpet. and then remove the last two grommets. Front Carpets (Two And Four Door Models): 1.
Page 291
SERVICING AND MAINTENANCE Rear Carpet (Two Door Models): 1. Remove the rear seats. 2. Remove the sides grommets (one left and one right). First the grommet from the side carpet and then the rear carpet. Pull Toward The Rear Of Vehicle Under Rear Seat 1 —...
Page 292
SERVICING AND MAINTENANCE Cargo Carpet (Four Door Models): 1. Remove the grommets under the rear seat (one left and one right). 2. Pull the carpet out to the rear and open the carpet split around the seat belt attachment. Pull Carpet To The Rear Rear Load Floor 1 —...
SERVICING AND MAINTENANCE Cargo Carpet (Four Door Models) With Gap Hider: SEATS AND FABRIC PARTS 1. Remove the grommets under the rear seat (one left Use Mopar® Total Clean to clean fabric upholstery and and one right). carpeting. 2. Pull the carpet out to the front and open the carpet split around the seat belt attachment and under the WARNING! center seat bracket.
SERVICING AND MAINTENANCE PLASTIC AND COATED PARTS liquid. Please do not use polishes, oils, cleaning fluids, solvents, detergents, or ammonia-based cleaners to Use Mopar® Total Clean to clean vinyl upholstery. clean your leather upholstery. NOTE: CAUTION! If equipped with light colored leather, it tends to show •...
TECHNICAL SPECIFICATIONS Spare Tire Torque Specifications VEHICLE IDENTIFICATION NUMBER (VIN) In the event power assist is lost for any reason (i.e., repeated brake applications with the engine off) the brakes will still function. However, the effort required to Lug Nut/Bolt **Lug Nut/Bolt Lug Nut/Bolt The VIN is found on the left front corner of the A-pillar,...
TECHNICAL SPECIFICATIONS Besides using unleaded gasoline with the proper METHANOL octane rating, gasolines that contain detergents, corro- (Methyl) is used in a variety of concentrations when sion and stability additives are recommended. Using blended with unleaded gasoline. You may find fuels gasolines that have these additives may help improve containing 3% or more methanol along with other alco- fuel economy, reduce emissions, and maintain vehicle...
TECHNICAL SPECIFICATIONS DO NOT USE E-85 IN NON-FLEX CNG AND LP FUEL SYSTEM CAUTION! FUEL VEHICLES MODIFICATIONS Use of fuel with Ethanol content higher than 15% may Non-Flex Fuel Vehicles (FFV) are compatible with gaso- Modifications that allow the engine to run on Com- result in engine malfunction, starting and operating line containing up to 15% ethanol (E-15).
TECHNICAL SPECIFICATIONS Metric 3.6L Engine 5 qt 4.73 L 6.4L Engine 7.5 qt 7.1 L Cooling System * 2.0L Engine 11.8 qt 11.2 L 2.0L Engine Intercooler 3.7 qt 3.5 L 3.6L Engine 13.4 qt 12.7 L 6.4L Engine 15.6 qt 14.8 L * Includes coolant recovery bottle filled to MAX level.
Page 299
TECHNICAL SPECIFICATIONS Component Fluid, Lubricant, or Genuine Part Fuel Selection — 3.6L Engine Minimum 91 Research Octane Number (RON). Fuel Selection — 6.4L Engine Research Octane Number (RON) of 95 or higher – 98 Research Octane Number (RON) preferred. 0-15% ethanol. CAUTION! CAUTION! •...
TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid or equivalent. Fail- Automatic Transmission ure to use the correct fluid may affect the function or performance of your transmission.
CUSTOMER ASSISTANCE CUSTOMER ASSISTANCE FCA INTERNATIONAL OPERATIONS SERVICE CONTRACT Mopar® Vehicle Protection Plans offer valuable protec- FCA International Operations LLC and its authorized tion against repair costs when these warranties no lon- Here are the contact details of the FCA Middle East dealers are vitally interested in your satisfaction.
Page 302
INDEX INDEX Rearm The System ....20 Security Alarm ....19, 106 About Your Brakes....293 Battery .
Page 303
INDEX Car Washes ....286 Electronic Stability Control (ESC) ..187 Cellular Phone....179 Electronic Throttle Control Warning Light .
Page 304
INDEX Front And Rear ParkSense System ..142 Passing ....45 Front Axle (Differential) ....263 Replacing .
Need help?
Do you have a question about the Wrangler 2024 and is the answer not in the manual?
Questions and answers
