- Page 1 USER MANUAL ENGLISH Stellar S-1200 Snow Machine Product code: 61115 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Stellar S-1200 Snow Machine Preface Thank you for purchasing this Showtec product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
Stellar S-1200 Snow Machine Table of contents Introduction ................................4 Before Using the Product ..........................4 Intended Use ............................... 4 Product Lifespan ..............................4 Text Conventions ..............................4 Symbols and Signal Words ..........................5 Symbols on the Information Label ........................5 Safety .................................. - Page 4 Stellar S-1200 Snow Machine DMX Channels ..............................31 1 Channel ..............................31 3 Channels ...............................31 5 Channels ...............................31 Troubleshooting ..............................32 Maintenance ..............................33 Safety Instructions for Maintenance ......................33 Preventive Maintenance ..........................33 Basic Cleaning Instructions ........................33 Cleaning the Fluid Pipes ........................34 Corrective Maintenance ..........................34 Replacing the Fuse ..........................34...
-
Page 5: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Showtec Stellar S-1200 Snow Machine ● Schuko to Power Pro cable (1,5 m) ● User manual Fig. -
Page 6: Symbols And Signal Words
Stellar S-1200 Snow Machine Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury. -
Page 7: Safety
Stellar S-1200 Snow Machine Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions... - Page 8 Stellar S-1200 Snow Machine ● Do not point the snow output directly at persons or animals. ● Make sure that persons cannot come closer than 50 cm to the snow output nozzle. WARNING Risk of explosion caused by incorrect handling ●...
- Page 9 Stellar S-1200 Snow Machine Attention Power supply ● Before connecting the device to the power supply, make sure that the current, voltage and frequency match the input voltage, current and frequency specified on the information label on the device. ●...
-
Page 10: Requirements For The User
Stellar S-1200 Snow Machine Attention Do not expose the device to conditions that exceed the rated IP class conditions. This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater than 12 mm, such as fingers, and no protection against harmful ingress of water. -
Page 11: Description Of The Device
Description of the Device The Stellar S-1200 is a snow machine. It can be controlled manually with the help of a clear LCD display, via DMX or with an optional remote control. For best results, we recommend using Showgear snow liquid or concentrate. -
Page 12: Back View
Stellar S-1200 Snow Machine Back View Fig. 03 06) LCD display + control buttons 07) 5-pin DMX connector OUT 08) ON/OFF switch 09) Fuse F8A / 250 V 10) 220–240 V Power Pro connector IN (Blue) 11) 3-pin DMX connector OUT... -
Page 13: Product Specifications
Stellar S-1200 Snow Machine Product Specifications Model: Stellar S-1200 Snow Machine Electrical: Input voltage: 220–240 V AC, 50 Hz Power consumption: 1200 W Fuse: 8A /250 V Physical: Dimensions: 503 x 302 x 440 mm (LxWxH) Weight: 9,4 kg Snowmachine capacity:... -
Page 14: Dimensions
Stellar S-1200 Snow Machine Dimensions Fig. 04 Product code: 61115... -
Page 15: Installation And Setup
Stellar S-1200 Snow Machine Installation and Setup Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing. - Page 16 Stellar S-1200 Snow Machine To mount the device, follow the steps below: Use a clamp to attach the device to the supporting structure, as shown in Fig. 05. Make sure that the device cannot move freely. 02) Secure the device with a secondary suspension, for example a safety cable. Make sure that the secondary suspension can hold 10 times the weight of the device.
-
Page 17: Connecting To Power Supply
Stellar S-1200 Snow Machine Connecting to Power Supply DANGER Electric shock caused by short-circuit The device accepts AC mains power at 220–240 V and 50 Hz. Do not supply power at any other voltage or frequency to the device. This device falls under IEC protection class I. Make sure that the device is always electrically connected to the ground (earth). -
Page 18: Setup
Disconnect power supply before connecting or disconnecting data cables. Stand-alone Setup When the Stellar S-1200 Snow Machine is not connected to a controller or to other devices, it functions as a stand-alone device. It can be operated manually. For more information about the control mode, refer to 6.7.4.1. DMX Address on page 29. -
Page 19: Dmx Cables
Stellar S-1200 Snow Machine DMX Cables Shielded twisted-pair cables with 3-pin/5-pin XLR connectors must be used for reliable DMX connection. You can purchase DMX cables directly from your Highlite International dealer or make your own cables. If you use 3-pin XLR audio cables for DMX data transmission, this may lead to signal degradation and unreliable operation of the DMX network. -
Page 20: Dmx Addressing
04) Continue assigning the starting addresses of the remaining devices by adding each time 5 to the previous number. Make sure that you do not have any overlapping channels in order to control each Stellar S-1200 Snow Machine correctly. If two or more devices are addressed similarly, they will work similarly. -
Page 21: Operation
Stellar S-1200 Snow Machine Operation Safety Instructions for Operation Attention This device must be used only for the purposes it is designed for. This device is designed to be used as a professional snow effect. Any incorrect use may lead to hazardous situations and result in injuries and material damage. -
Page 22: Filling The Tank
Stellar S-1200 Snow Machine Filling the Tank WARNING Risk of explosion caused by incorrect handling ● Do not add flammable liquids such as perfume and alcohol to the snow fluid. ● Operate the device only with the fluids recommended in this user manual. - Page 23 Stellar S-1200 Snow Machine Place the fluid tank on a flat surface near the device, as shown in Fig. 10. Use a funnel to pour the snow fluid into the tank, as shown in Fig. 11. Fig. 10 Fig. 11 Fill the fluid container with the recommended snow fluid ( Max.
-
Page 24: Emptying The Tank After Operation
Stellar S-1200 Snow Machine Emptying the Tank after Operation To empty the tank, follow the steps below: Do not disconnect the safety cable. Unscrew the lid on the fluid tank, as shown in Fig. 14. Take out the fluid tank, as shown in Fig. 15. -
Page 25: Restarting The Device After Running The Tank Empty
Make sure you fill the entire tank and then manually start blowing snow. This will take a few seconds until the completely emptied lines are filled with snow fluid. Control Modes The Stellar S-1200 Snow Machine supports the following control modes: ● Manual (snow intensity/volume, duration, interval/timer) ●... -
Page 26: Manual Operation
Stellar S-1200 Snow Machine Manual Operation To set up the device, follow the steps below: Fill the tank (Fluid Tank Capacity 5 L). See 6.3. Filling the Tank on page 22 for more information. Connect the power cable before supplying power to the device. See 4.5. Connecting to Power Supply on page 17 for more information. -
Page 27: Start-Up
Stellar S-1200 Snow Machine Start-up Upon start-up, the display will show the current software version. When the device is ready, the display will show: Menu Overview Notes: ● Manual operation with the control panel on the device always has priority over the remote control. -
Page 28: Main Menu Options
Stellar S-1200 Snow Machine Main Menu Options The main menu has the following options: Press the MENU button to navigate through the main menu. DMX Address In this menu you can set the DMX address. Press the UP/DOWN buttons to set the desired DMX address. The adjustment range is 001–512. -
Page 29: Dmx Mode
Stellar S-1200 Snow Machine DMX Mode In this menu you can manually set the DMX mode. Press the UP/DOWN buttons to set the desired DMX mode. Interval In this menu you can set the snow interval. Press the UP/DOWN buttons to set the desired interval time. The adjustment range is 0 or between 20–2000 sec. -
Page 30: Timer Mode
Stellar S-1200 Snow Machine Timer Mode Set the snow output volume. See 6.7.4.2. Snow Volume on page 27 for more information. Set the wind speed. See 6.7.4.3. Wind Speed on page 27 for more information. Set the interval time between separate snow outputs. See 6.7.4.5. Interval on page 28 for more information. -
Page 31: Manual Mode
Stellar S-1200 Snow Machine Manual Mode Set the snow output volume. See 6.7.4.2. Output Volume on page 27 for more information. Set the wind speed. See 6.7.4.3. Wind Speed on page 27 for more information. Press the MENU button, until the display shows: MSG RUN F100. -
Page 32: Dmx Channels
Stellar S-1200 Snow Machine DMX Channels 1 Channel 1 CH Function Value Setting Snow Output 000–255 Snow output from 0–100% 3 Channels 3 CH Function Value Setting Snow Output 000–255 Snow output from 0–100% Wind 000–255 Wind speed from 0–100% 000–128... -
Page 33: Troubleshooting
Stellar S-1200 Snow Machine Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage. -
Page 34: Maintenance
Stellar S-1200 Snow Machine Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. WARNING Risk of burns due to hot surface Allow the device to cool down for at least 15 minutes before servicing or cleaning. -
Page 35: Cleaning The Fluid Pipes
Stellar S-1200 Snow Machine Cleaning the Fluid Pipes The device must be cleaned periodically from the snow fluid residues. After every 40 hours of continuous operation, it is recommended to run a cleaning solution composed of 80 % distilled water and 20 % white vinegar through the system. -
Page 36: Deinstallation, Transportation And Storage
Stellar S-1200 Snow Machine Deinstallation, Transportation and Storage Instructions for Deinstallation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and derigging of the device. - Page 37 Stellar S-1200 Snow Machine Product code: 61115...
- Page 38 Stellar S-1200 Snow Machine Product code: 61115...
- Page 39 Stellar S-1200 Snow Machine Product code: 61115...
- Page 40 ©2023 Showtec...
