- Page 1 BAY/3 SIDED AND LEFT/RIGHT SIDE OPEN LPM BAY/3 SIDED AND LEFT/RIGHT SIDE OPEN LPM V2 44"-56"-68"-80"-96"-120" TRIM KIT 44"-56"-68"-80"-96"-120" TRIM KIT Owner/Installation Guide modernflames.com...
- Page 2 Assembly, Parts & Hardware List What's in the Box 5 PC TRIM KIT FOR LPM 44". P/N: 02-00291-01 o o 5 PC TRIM KIT FOR LPM 56". P/N: 02-00291-02 5 PC TRIM KIT FOR LPM 68". P/N: 02-00291-03 o o 5 PC TRIM KIT FOR LPM 80". P/N: 02-00291-04 5 PC TRIM KIT FOR LPM 96".
- Page 3 Installation and Assembly Trim Installation The 5 pieces can accommodate a bay/3-sided installation and a left/right installation finished with drywall or wood up to 3/4". "C" shape trim Bottom Example: Bay/3-sided uses: Top, bottom and two "C" shaped trims. "C" shape trim Side trim Bottom Example: Left/Right side open uses: Top, bottom, one "C"...
- Page 4 Installation and Assembly All are held on by magnents for easy installation and removal. Note: they do have hanging holes for powder coating which may be seen with thicker materials. Black paint or film can be placed underneath the trim to help hide the hole but is not included. Space for trim For a case as the one shown in the image, there needs to be a 3/4"...
- Page 5 DO NOT RETURN TO STORE! CALL US FIRST For immediate help with installation, product information or if your product arrives damaged, please call our toll-free number at: AUSTRALIA/NEW ZEALAND 07 5630 6840 (Monday - Friday, 9:00AM - 5:00PM, AEST) Or email us at: info@modernflames.com EUROPE +46 762 09 58 09 (Monday - Friday, 8:00AM - 4:00PM, CEST)
- Page 6 Thank you for choosing Modern Flames, we appreciate all our customers and hope you have many years of enjoyment of our products. Take a look at our other products from our RPG Brands family of companies GrandCanyonGasLogs.com For all your indoor, outdoor gas fireplaces & fire feature products.
