SPEC SERIES FRONT BUMPER
19-21 CHEVY 1500
FBCS1-07
TOOLS
REQUIRED
- 10, 21, 22mm Wrench
- #4 L shaped Tool
- #4 Allen Bit
- 21mm Socket
- Swivel Joint
WARNINGS/CAUTIONS BEFORE STARTING INSTALLATION
Before you install this kit —
instructions, warnings, cautions, and notes contained in
this installation instruction guide. Consult your vehicle
owner's manual for proper disconnection of electrical and
lifting of vehicle if required for installation of this product.
This install may require some technical skills and
knowledge of basic mechanical work. If you do not feel that
you are capable of performing this install please take this
product to a trained professional.
After reading this guide please contact us with any
questions or concerns before installing product.
Customer Service: 855-680-9595
DV8 Offroad is not responsible for any bodily injury or harm to you
or your vehicle as a result of an improper install.
6400 SYCAMORE CANYON BLVD.
RIVERSIDE, CALIFORNIA 92507
855-680-9595
WWW.DV8OFFROAD.COM
SKILL
LEVEL
- Intermediate
- 2 persons
Little skill level required, however,
additional help is required for
removal and installation of
bumpers.
Read and understand all
PRODUCT
INSTALLATION
TIME
- 4 Hours
Time to install this should only
take about four hours.
Proper installation of this kit required knowledge of the factory
recommended procedures for removal and installation of original
equipment components. We recommend that the factory shop manual
and any special tools needed to service your vehicle be on hand during
the installation. Installation of this kit without proper knowledge of the
factory recommended procedures may affect the performance of these
components and the safety of the vehicle
• Always wear eye protection when operating power tools
Inspect all contents of this package to make sure product is not damaged
and all installation hardware has been included. If parts are missing from
kit, please be prepared to provide the following information
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
NEED HELP?
MANUAL
REQUIRED
855-680-9595
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DV8 OFFROAD SPEC FBCS1-07
Summary of Contents for DV8 OFFROAD SPEC FBCS1-07
- Page 1 1. Name of purchase location Customer Service: 855-680-9595 2. Bar Code on side of box DV8 Offroad is not responsible for any bodily injury or harm to you 3. Date above bar code or your vehicle as a result of an improper install.
- Page 2 INSTALLATION MANUAL TOOLS REQUIRED - Trim Clip Tool - T15 Torx Bit - 10, 18mm Socket - 18mm Wrench - Swivel Joint - 10” Extension - Pick STEP 1 | Use a trim clip tool to remove the fasteners securing the upper valance to the grille.
- Page 3 INSTALLATION MANUAL STEP 2 | Use a T15 torx bit to remove the hardware secruing the valance tie downs. NEED HELP? 855-680-9595...
- Page 4 INSTALLATION MANUAL STEP 3 | Use a trim clip tool to unclip the various fasteners located along the edges of each headlight and the top of the grille. NEED HELP? 855-680-9595...
- Page 5 INSTALLATION MANUAL STEP 4 | Once all fasteners are unclipped, pull the grille straight away from the vehicle, being careful to avoid breaking any clips. STEP 5 | Use an 18mm socket to remove the top two bolts on the bumper support bracket, for each side of the bumper.
- Page 6 INSTALLATION MANUAL STEP 7 | Remove the bumper wiring harness connector located near the bottom passenger corner of the air shroud. Use a trim clip tool to pull back the red safety before attempting to remove. STEP 6 | Use a 10mm socket with a 10”...
- Page 7 INSTALLATION MANUAL STEP 8 | Use an 18mm socket to remove the hardware securing the bumper mounting plate to the frame horns, and set it off to the side. STEP 9 | Use an 18mm socket/wrench to remove the hardware securing the tow hook and set it off to the side.
- Page 8 INSTALLATION MANUAL STEP 10 | Use an 18mm socket to remove the hardware securing the STEP 11 | Use an 18mm socket to remove the hardware securing the plastic/metal bracket assembly. Use a trim clip tool to remove the fasteners securing the wiring harness as the assembly is removed.
- Page 9 INSTALLATION MANUAL STEP 12 | Remove any remaining clips securing the wiring harness using a trim clip tool. STEP 13 | Remove the sensors from the bezels by gently spreading the locking tabs to release the sensor from the bezel. STEP 14 | Use a pick or similar to carefully press the retaining tabs around...
- Page 10 INSTALLATION MANUAL Begin by unpacking all items and inspecting for missing pieces or damage. If you have any concerns, please contact the company the product was purchased from. Extra hardware may be included with the product. HARDWARE INCLUDED (4) M12x35 Hex (2) M6x25 Tapered Allen (4) M12 Nylon Lock Nuts (10) M6x20 Allen...
- Page 11 INSTALLATION MANUAL STEP 17 | If you are installing pod lights, do so at this time using the hardware provided with the light. STEP 18 | Install the provided M12 nut clips by pressing them into place. STEP 19 | Install the sensor bezels in the locations and orientation they were removed from the factory bumper.
- Page 12 INSTALLATION MANUAL STEP 20 | Secure any wiring using the provided zip tie tabs. STEP 21 | If you are installed a winch, install and secure the winch to the winch place prior to mounting the plate on the vehicle. Use the provided M12 hardware with a 21mm scoket, swivel joint, and a 22mm wrench to secure the winch plate.
- Page 13 INSTALLATION MANUAL STEP 22 | Install the bumper onto the vehicle using the provided M12 hardware with a 21mm socket. STEP 23 | Congrats! You are finished with the install of the DV8 Front Bumper! NEED HELP? 855-680-9595...
