Diode Dynamics Stage Series Manual

Aiming Instructions

12. Park your vehicle 25 feet away from a wall or garage door on a level surface.
13. Loosen the 5/32" allen bolts on each side of your SS3 pod, just enough to allow you
to adjust the pod.
14. On your vehicle, measure the distance between the ground and the center of your
SS3 pod. This is your mounting height.
15. Mark the mounting height on the wall or garage door using tape.
16. Add another piece of tape four inches below the mounting height. This is your fog
light cutoff line.
17. Aim your SS3 pods on each side, so that the top of the beam pattern is on the
cutoff line mark.
18. Tighten the 5/32" allen bolts back down. Do not overtighten or use power tools to
torque them down.
19. Use the included rubber grommets to cover the adjustment screws.
20. Replace the shroud, upper bumper piece, fender flare, and fender liner using the
original hardware to complete the installation.
Measure lamp height to center
Please contact Diode Dynamics should you have any questions about the installation
or wiring process, at 314-205-3033 (10a-5p CST) or contact@diodedynamics.com.
NEED MORE HELP?
Scan the QR code to link to our installation video online!
We've taken the time to test our products on your vehicle.
We can guarantee compatibility and fitment the first time
– no guessing game!
This installation guide is for the following SKUs:
SS3 Sport Type F2 Kit White SAE Driving (DD6237 W/O BL, DD7011 ABL)
3 YEAR
SS3 Sport Type F2 Kit White SAE Fog (DD6238 W/O BL, DD7012 ABL)
SS3 Sport Type F2 Kit Yellow SAE Fog (DD6240 W/O BL, DD7013 ABL)

WARRANTY

SS3 Pro Type F2 Kit White SAE Driving (DD6241 W/O BL, DD7014 ABL)
PAGE 4
PP0110F
Level
Four (4) inches
Top of
Beam
25 feet
SS3 Pro Type F2 Kit White SAE Fog (DD6242 W/O BL, DD7015ABL)
SS3 Pro Type F2 Kit Yellow SAE Fog (DD6244 W/O BL, DD7016 ABL)
SS3 Max Type F2 Kit White SAE Fog (DD6694 W/O BL, DD7017 ABL)
SS3 Max Type F2 Kit Yellow SAE Fog (DD6695 W/O BL, DD7018 ABL)
Thank you for your purchase of our new SS3 Type F2 Foglight
Kit. CAD-designed to use existing mounting points, this kit
is compatible with the 2015+ F-150 and 2017+ F-250/F-350
models. Basic installation instructions are included below.
Please contact us if you have any questions.
Rubber
Grommet
Passenger/Right Side (opposite for driver/left side)
1. Install the supplied nuts into the pod housing with the nylon facing inward. Attach the
bracket to the pod using the supplied screws and washers. Make sure the bracket is in the
correct orientation. There will be a small gap between the pod and bracket to allow for
aiming. See diagrams above. Ensure that the screws are tightened such that the pod retains
its position, but can pivot with force for aiming.
(314) 205-3033
SS
3" LED Pod
3
Type F2 Foglight Kit
