Page 1 Operating Instructions Front hopper Solitair 23+ - en - Item no. 17514977 03/06.22 LEMKEN GmbH & Co. KG Weseler Straße 5, 46519 Alpen / Germany Telephone +49 28 02 81 0, Fax +49 28 02 81 220 lemken@lemken.com, www.LEMKEN.com...
Page 3 However, this brief instruction is not a substitute for thorough study of the operating instructions. These operating instructions will help to familiarise you with the LEMKEN GmbH & Co. KG device and the options available for using it.
Page 4 Remember that you should only use genuine LEMKEN spare parts. Reproduction parts have a negative influence on the function of the device, have a shorter ser- vice life and present risks and hazards that cannot be estimated by LEMKEN GmbH & Co. KG. They also increase the maintenance costs.
Page 5: Table Of Contents
CONTENTS General information ....................10 Liability ......................... 10 Guarantee ........................10 Copyright ........................11 Optional accessories ....................11 Notes ..........................11 Type plate ........................12 Symbols used in the Operating Instructions ............14 Hazard classes ......................14 Information ........................14 Environmental protection ...................
Page 6 Residual risks ......................25 3.6.1 Hazard caused by mechanical systems ..............25 3.6.2 Hazards of hydraulic systems ..................25 3.6.3 Hazard during operation .................... 25 Applicable rules and regulations ................26 Operation on public highways ................... 27 3.8.1 Lighting system and identification ................27 3.8.2 Front mounted machines on public roads ..............
Page 7 Description ........................47 5.3.1 Headstock ........................47 5.3.2 Tyre packer roller ....................... 47 5.3.3 Additional weights ...................... 48 5.3.4 Ascent/platform ......................49 5.3.5 Blower ........................49 5.3.6 Hopper for seeds and fertiliser ................... 50 5.3.7 Metering ........................51 5.3.8 Metering wheels ......................52 5.3.9 Electronic level indicator ....................
Page 8 Preparing the implement ..................67 Converting pressure system to injector ..............67 Replacing metering wheels ..................72 Checking back pressure of the pressureless return ..........80 Attaching the implement ..................81 Connecting machine to the tractor ................82 8.1.1 Adjust attachment points ................... 82 8.1.2 Mounting connecting hoses ..................
Page 9 10.3 Working with the implement ..................94 10.3.1 Stopping the implement in an emergency .............. 94 10.3.2 Working lights with hopper light ................94 10.4 Turning at the headland ....................95 10.5 Calibration ........................96 10.6 Starting and stopping the metering device ............... 96 10.7 Section switch ......................
Page 10 14 Maintenance and servicing .................. 113 14.1 Specific safety information ..................113 14.1.1 General......................... 113 14.1.2 Personnel qualifications ..................113 14.1.3 Protective equipment .................... 113 14.1.4 Immobilise the implement for maintenance and repairs ........114 14.1.5 Working on the hydraulics ..................114 14.1.6 Working on the electrics ..................
Page 11 14.8 Checking connections to the tractor ............... 130 14.8.1 Couplings ......................130 14.8.2 Connectors and cables ..................130 14.9 Hydraulic lines ......................131 15 Troubleshooting ....................132 16 Decommissioning and disposal ................133 16.1 Disposal ........................133 17 Technical data ....................... 134 17.1 Dimensions ........................
Page 12: General Information
Co. KG, in particular Section IX, shall apply. Liability. In line with the dimensions cited in these conditions the LEMKEN GmbH & Co. KG shall not be held liable for any personal or material damage, when such damage is caused by one or more of the following reasons: ...
Page 13: Copyright
Infringements will result in a claim for damages. Optional accessories LEMKEN implements may be equipped with various accessories. The operating instructions below describe both series components and optional accessories. Please note: These accessories will vary depending on the type of equipment.
Page 14: Type Plate
General information Type plate The implement is marked with a type plate. The type plate is located at the front right of the implement. The operating instructions can apply to va- rious implement types implement equipment. In the operating instructions, contents are marked that are only valid for a certain im- plement type...
Page 15 General information 1 Series 2 Type designation 3 Model year 4 Serial number 5 Year of manufacture 6 Vehicle class, subclass, speed index 7 EU type approval number 8 Vehicle identification number. The vehicle identification number is also engraved in the frame near the type plate. 9 Permitted gross weight [kg]* 10 Permissible drawbar load [kg] (axle 0) 11 Permissible axle load [kg] (axle 1)
Page 16: Symbols Used In The Operating Instructions
Symbols used in the Operating Instructions SYMBOLS USED IN THE OPERATING INSTRUCTIONS Hazard classes The following symbols are used in the Operating Instructions for particularly im- portant information: DANGER Denotes an imminent hazard with high risk, which will result in death or severe physical injury, if not avoided.
Page 17: Indication Of Passages
Symbols used in the Operating Instructions Indication of passages The following symbols are used for particular passages in the operating instruc- tions:  Indicates work steps  Indicates enumerations Orientation and assignment Orientation on the machine is aligned in the direction of travel from left to right. 2.5.1 Metering units Implement with 2 metering units Metering unit 1: on left...
Page 18: Safety Measures And Precautions
Safety measures and precautions SAFETY MEASURES AND PRECAUTIONS General safety instructions for the operator are specified in the chapter entitled «Safety measures and precautions». At the start of some main chapters the safety instructions, which refer to all work to be carried out in this chapter, are listed to- gether.
Page 19: Possible Applications
Safety measures and precautions Clarify questions of comprehension concerning the contents of these operating instructions before starting work. To do this, contact the LEMKEN sales partner if required. Possible applications The front hopper Solitair 23+ can be combined for use with the following machi-...
Page 20: Safety And Warning Signs
Safety measures and precautions Coulter bar Solitair 25 Metering of seeds Required metering Coulter bar with 2 distributors  2 metering units  2 sections  2 fill level sensors Coulter bar with 4 distributors  4 metering units  4 sections ...
Page 21: Overview Of The Position Of Warning Symbols
Safety measures and precautions 3.4.2 Overview of the position of warning symbols 3.4.3 Meaning of warning signs  Please familiarise yourself with the meaning of the warning signs. The following explanations provide detailed information. Please read and observe the operating in- structions and safety instructions before starting up the implement for the first time.
Page 22 Safety measures and precautions Before carrying out maintenance or repair work, switch off the engine and remove key. Area between tractor and implement A running tractor may cause or initiate un- intentional movements. This will result in death or serious injuries. When the tractor is running: ...
Page 23: Meaning Of Other Symbols
Safety measures and precautions 3.4.4 Meaning of other symbols. Fan – note  Ensure connection to pressureless re- turn.  Maximum back pressure level is 3 bar  Spool valve for fan: On the tractor, set to priority if possible. Hydraulic equipment Hydraulic motor for fan P6: Supply line...
Page 24: Special Safety Instructions
Safety measures and precautions Special safety instructions Risk of injury due to non-observance of the currently valid occupational safety guidelines If the currently valid occupational safety guidelines are bypassed WARNING or safety equipment is rendered unusable when handling the de- vice, there is a risk of injury.
Page 25 Safety measures and precautions Risk of injury when freeing casualties When rescuing people trapped or injured by the device, there is a risk of additional serious injury to the casualty if the hydraulic con- nections were not connected according to their colour coding as described in the section entitled "Required hydraulic equipment".
Page 26: Hazardous Areas During Operation Of The Implement
Safety measures and precautions 3.5.1 Hazardous areas during operation of the implement Moving hazardous area The implement's hazardous area moves as the implement is ope- rated. WARNING  While driving on the field, observe the entire hazardous area. Stop if required. ...
Page 27: Residual Risks
Safety measures and precautions Residual risks Residual risks are particular hazards which occur when handling the device and which cannot be eliminated despite a design in accordance with safety require- ments. Residual risks are not usually obvious and may be the source of a potential injury or health hazard.
Page 28: Applicable Rules And Regulations
Safety measures and precautions Applicable rules and regulations The applicable rules which must be observed during operation of the device are listed below:  Observe the currently valid national highway code!  Observe the currently valid national laws and regulations for occupational safe- ...
Page 29: Operation On Public Highways
Safety measures and precautions Operation on public highways 3.8.1 Lighting system and identification A proper lighting system, identification and equipment must be on the device if it is to be transported on public roads. Further information can be requested from the appropriate authorities.
Page 30 Safety measures and precautions Lighting equipment If lighting equipment of the tractor is con- cealed by a front mounted machine:  Repeat lighting equipment on the front mounted machine.  Adjust any permitted maximum speed of the tractor. See operating instructions for the tractor.
Page 31: Checking Field Of View
Safety measures and precautions Orange side reflectors For lateral marking, orange lateral reflec- tors are attached to the left and right sides of the machine. Side warning boards (4) According to national regulations (e.g. France):  Attach side warning boards to left and right sides of the machine.
Page 32: Measures In Case Of Restricted Fields Of View
Safety measures and precautions Checking the field of view  Look from the reference point (1) to the bearing point (3). The unobstructed view from the reference point (1) to the bearing point (3) must not impair the front mounted implement. If required: ...
Page 33: Requirements Of The Tractor
Safety measures and precautions 3.8.5 Requirements of the tractor  Ensure that the tractor with mounted device always reaches the stipulated brak- ing deceleration. Observe the permitted axle loads, gross weights and transportation dimensions, see also section entitled "Axle loads"! Observe the permitted power limit of the tractor! Risk of accidents due to inadequate steerability A tractor which is too small or which has inadequate front ballast...
Page 34: Axle Loads
Safety measures and precautions 3.8.6 Axle loads Implements mounted to the front and rear three-point linkage must not result in the following being exceeded:  permissible gross weight of tractor,  permissible axle loads of tractor,  the tractor's tyre load-carrying capacities. The tractor's front axle must always be loaded with at least 20 % of the tractor's curb weight.
Page 35 Safety measures and precautions Data from tractor operating instructions  Take the following data from your tractor's operating instructions: Abbreviation Data Tractor kerb weight (kg) _______ kg Front axle load (kg) of empty tractor _______ kg Rear axle load (kg) of empty tractor _______ kg Data from implement operating instructions ...
Page 36 Safety measures and precautions Data to be determined through remeasuring are  Determine the following data through remeasuring: Abbreviation Data Distance (m) between centre of gravity for front _______ m mounting implement or front weight and centre of front axle Tractor wheelbase (m) _______ m Distance (m) between centre of rear axle and centre...
Page 37 Safety measures and precautions Calculation of actual front axle load T V tat x b – G x (a + b) + T x (c + d) V tat  Enter the value for the calculated actual front axle load and the permissible front axle load as given in the tractor's operating instructions into the table.
Page 38: Obligation Of The Operator
Safety measures and precautions Obligation of the operator  Before switching on the device, read the operating instructions.  Follow the safety instructions!  Wear appropriate protective clothing when carrying out any work on the device. Protective clothing must be tight-fitting! ...
Page 39 Safety measures and precautions  Always attach the implement correctly and only attach it to the equipment provi- ded for that purpose.  Always take great care when attaching the implement to and detaching it from the tractor. There is a risk of injury due to crush and shear points in the area around the three-point linkage.
Page 40: Personnel Selection And Qualifications
Safety measures and precautions 3.10.2 Personnel selection and qualifications  The tractor driver must have the appropriate driving licence.  All work on the implement must be carried out by properly trained and instructed personnel. The personnel must not be under the influence of drugs, alcohol or medication.
Page 41: When The Implement Is Parked
Safety measures and precautions 3.10.4 When the implement is parked Climbing on the implement The implement is not a play area. Climbing on the parked implement may cause serious injuries, e.g. as a result of slipping or tripping.  Never climb onto the parked implement without permission. 3.10.5 Stopping the implement in an emergency ...
Page 42: Handing Over The Implement
Handing over the Implement HANDING OVER THE IMPLEMENT  As soon as the implement is delivered, ensure that it corresponds with the order package.  Also check the type and completeness of any supplied accessories. When the device is handed over, your dealer will explain how it works. ...
Page 43: Layout And Description
Layout and description LAYOUT AND DESCRIPTION Overview Tyre packer roller Hopper Cover Step, platform Lighting equipment Working lights Headstock Metering Stands Additional weights...
Page 44: Safety Features Of The Device
Layout and description Safety features of the device To protect the operator and the device, the device is equipped with special safety features in accordance with country specific requirements.  Always keep all safety devices in working order. 5.2.1 Lighting equipment The lighting equipment consists of: ...
Page 45: Stabilisation
Layout and description 5.2.2 Stabilisation Implement with tyre packer roller Separate stands are required to deposit the implement. The stands are equipped with transport rollers so that the implement can be moved manually. Required stands:  2 stands with steerable transport rollers, braked...
Page 46 Layout and description Implement without tyre packer roller The implement can be deposited on the frame. Separate transport supports with rollers are available for the implement, allowing the implement to be manually moved and deposited. Required stands for manual movement: ...
Page 47: Sensors
Layout and description 5.2.3 Sensors The following sensors are provided for monitoring and controlling the machine: Metering RPM monitoring of metering shaft (1) RPM monitoring (2)
Page 48 Layout and description Headstock Mechanical lifting sensor (3) Alternatively: Hydraulic lifting sensor Hopper Machine with 2 metering units and 2 sections Level indicator (4), on right and left sides of hopper Each metering unit is monitored with a separate sensor. Machine with 4 metering units and 4 sections Level indicator (5)+(6), on right and left...
Page 49: Metering Push Button
Layout and description 5.2.4 Metering push button Metering can be started and stopped via the push button (1) for individual control functions. See the operating instructions for the control. Description 5.3.1 Headstock The headstock consists of the following coupling points for the front linkage: ...
Page 50: Additional Weights
Layout and description Steering assembly The steering assembly of the tyre packer roller allows easy cornering. (20° steering angle, 10° any direction) If required, the steering assembly can be locked. Scrapers The tyre packer roller is equipped with scrapers. The scrapers remove soil sticking to the individual tyres.
Page 51: Ascent/Platform
Layout and description 5.3.4 Ascent/platform The platform can be accessed via the ascent. The cover of the seed hopper can be opened and closed from the platform. Do not ride on the platform. 5.3.5 Blower The compressed air generated by the fan conveys seeds or fertiliser from the mete- ring into the hose system and transports them further to the shares of the combina-...
Page 52: Hopper For Seeds And Fertiliser
Layout and description 5.3.6 Hopper for seeds and fertiliser The hopper holds a total of 1900 l seeds or fertiliser. The cover and the optional screen protect the distribution from exter- nal influences and foreign objects. Cover Machine without pressure system The machine is fitted with a roller tarpaulin cover.
Page 53: Metering
Layout and description 5.3.7 Metering Metering consists of several metering units (1). The metering units are used to preset and control the distribution rate. The speed of the metering devices depends on the driving speed. The metered distribution is conveyed via the airflow of the fan to the seeding coulters.
Page 54: Metering Wheels
Layout and description 5.3.8 Metering wheels The following metering wheel sets can be used for the metering units depending on the application:  Universal  MegaPlus The metering wheels are attached to a me- tering shaft and are separated from each other by separating discs which allow the individual metering wheels to work inde- pendently of each other.
Page 55: Electronic Level Indicator
Layout and description MegaPlus metering wheel set Application: highly encrusted fertiliser The metering wheel set consists of 4 mete- ring wheels per metering unit:  4 wide metering wheels 5.3.9 Electronic level indicator The level of the hopper is electronically monitored via sensors (1).
Page 56: Work Lighting
Layout and description 5.3.10 Work lighting Working lights 2 working lights LED (1) illuminate the area in front of the machine at night. This lighting equipment is not intended for road travel. Hopper light The hopper light is attached inside the hopper.
Page 57: Camera Monitoring
Layout and description 5.3.12 Camera monitoring If the field of view is restricted, an instructor is required in addition to the camera system. The camera system consists of two cam- eras. The cameras capture the lower field of view in front of the machine. Holders (1) are provided on brackets on both sides of the hopper for mounting the cameras (2).
Page 58: Injector Equipment
Layout and description Radar (1) at machine without tyre packer roller Radar (2) at machine with tyre packer roll- 5.3.14 Injector equipment The machine differs from the pressure sys- tem by the following components:  Roller tarpaulin cover  Metering units with exhaust air hose (for use with fertiliser)
Page 59 Layout and description  Screen grid (1) (for use with seeds, NEVER use with fer- tiliser) Corrosion damage at the machine and tractor due to escaping fer- WARNING tiliser dust NEVER use the screen grid with fertiliser. Always attach the exhaust air hose to the metering unit before use with fertiliser.
Page 60: Pressure System Equipment
Layout and description 5.3.15 Pressure system equipment The pressure system is used to increase the flow rate. The implement is fitted with special com- ponents:  Steel cover with 3 locking latches (2)  Sealed metering units No hopper ventilation: Air distributor to the hopper closed with a protecting cap (1).
Page 61: Preparations On The Tractor
Preparations on the tractor PREPARATIONS ON THE TRACTOR DANGER Lowering or raising the three-point linkage Incorrect setting or operation of the three-point linkage may cause uncontrolled movements. This may result in serious injury to the operator. Overview The following preparations must be made before attaching the implement to the tractor: ...
Page 62: Checking The Three-Point Connection
Preparations on the tractor 6.1.3 Checking the three-point connection Only lower link and top link pins with the same category as the tractor’s three- point linkage are approved for use with this implement, see «...
Page 63: Power Supply Electronic Control
Preparations on the tractor Three-point connection, page 136». If they do not correspond, either the tractor's three-point linkage must be adapted or the lower link and top link pins on the im- plement must be replaced with a suitable, approved version. Loss of the implement The category of the three-point linkage on the tractor and the ca- tegory of the lower link and top link pins must correspond.
Page 64: Connection To Tractor Battery
Preparations on the tractor The entire electronic control is supplied with power via the power supply cable. The power supply cable is connected di- rectly to the tractor's battery. Tractors without ISOBUS implement con- trol must be equipped with an ISOBUS mounting set.
Page 65: Connecting Electronic Control
Preparations on the tractor 6.2.2 Connecting electronic control The following electronic equipment is at- tached to the hopper under the fan:  (1) LEMKEN Powerbox  (2) Job computer with ISOBUS  Connect the ISOBUS connection cable to the ISOBUS socket.
Page 66: Required Hydraulic Spool Valves
Preparations on the tractor Required hydraulic spool valves For operation of the specific hydraulic equipment, the tractor must be equipped with the following spool valves: 6.4.1 Machine without flow control valve Double ac- Pressurel- Single acting Equipment ting spool ess return Colour Code spool valve...
Page 67 Preparations on the tractor Operation with precision seed drill Connection fan drive (1)
Page 68: Machine With Flow Control Valve
Preparations on the tractor 6.4.2 Machine with flow control valve Double ac- Single acting Pressureless Equipment ting spool Colour Code spool valve return line valve Pre- emergen Yellow Fan drive Return: White Return: White Operation with coulter bar or precision seed drill Connection fan drive (1) Connection coulter bar (2)
Page 69: Installing The Holder For Connections
Preparations on the tractor Preventing damage to the fan After switching off the fan:  Switch spool valve to float position. Installing the holder for connections The connecting hoses and lines between the front mounted im- plement and the rear implement must be guided securely and fas- tened to the tractor.
Page 70: Preparing The Implement
Preparing the implement PREPARING THE IMPLEMENT Converting pressure system to injector Purpose  If the pressure-resistant cover is leaky or damaged. Required components (example: Machine with 4 metering units)  4x nozzle (7) for metering unit  4x panel (8) for metering unit ...
Page 71 Preparing the implement Adapting lid of metering units For seeds:  Remove the lid (11).  Mount the screen grid (13). CAUTION Material damage due to fertiliser dust Metering units with screen grid are NOT suitable for fertiliser.
Page 72 Preparing the implement For fertiliser:  Starting from the centre of the machine, remove the outer plug (12).  Mount the hose connection (3) using the nut (4).  Mount the lid (11).
Page 73 Preparing the implement Inserting panel and nozzle Observe installation direction:  Panel (8): Discharge  Nozzle (7): Supply line Metering unit, front  Release the hose clip (14).  Remove the flexible hose (13) from the metering unit.  Mount the panel (8) to the pipe of the metering unit.
Page 74 Preparing the implement  Mount the nozzle (7) to the pipe of the metering unit.  Mount the flexible hose (15) on the me- tering unit using the hose clip (16).  Tighten the hose clip (16). Mounting exhaust air hose ...
Page 75: Replacing Metering Wheels
Preparing the implement Check the hopper ventilation Make sure the protecting cap (5) is fitted on the air distributor to the hopper. Replacing metering wheels When ballasting with five sets of weights or more, accessibility to the middle metering units may be limited. ...
Page 76 Preparing the implement Switch on all the metering wheels:  Screw in the stop screws (2) until they no longer protrude beyond the metering wheels/washers. See «Adjusting mete- ring wheels, page 99». If it is not possible to screw in the screw with a constant amount of force, the screw is probably not seated over the drive slot of the CAUTION metering shaft.
Page 77 Preparing the implement Metering unit without coupling piece:  Remove the linch pin (3) of the gear wheel. Metering unit with coupling piece:  Remove the M5 screw (4).
Page 78 Preparing the implement  Remove the gear wheel and the washer (5) from behind the gear wheel.  Pull out the metering shaft (6). For Mega Plus: A combined pull/twist motion is required as the paddles protrude.
Page 79 Preparing the implement  Remove the complete metering wheel set (7).  Maintain the order of the washers and metering wheels for subsequent use, as the order may be individual.  To simplify future metering wheel re- placement, permanently thread the me- tering wheel set onto another metering shaft (optional) and mark it with the number of the respective metering unit.
Page 80 Preparing the implement  For universal metering wheel set: Make sure that the correct order of the various metering wheels shown is ob- served.  Insert the metering shaft and note the following points:  Make sure that washers do not beco- me wedged in the metering housing.
Page 81 Preparing the implement  Re-attach the washer and the gear wheel and secure with the linch pin. It must be possible to insert the linch pin without force. If the holes (11) are not in line, check the metering shaft for wedged intermediate washers.
Page 82 Preparing the implement  Mount the lid (1).  For an idle mode test, make sure that seeds or fertiliser do not come into contact with the metering units.  Lower the machine.  Switch on the fan.  Enter a simulated speed of 6 km/h in the control.
Page 83: Checking Back Pressure Of The Pressureless Return
Preparing the implement Checking back pressure of the pressureless return For every tractor-implement combination:  Ensure the maximum back pressure at the fan is 3 bar.  If necessary, measure the back pressure or have it measured. Note on measurement ...
Page 84: Attaching The Implement
Attaching the implement ATTACHING THE IMPLEMENT Risk of accident from spurting hydraulic fluid Hydraulic fluid which escapes under high pressure may penetrate your skin and cause severe injuries. If injuries occur, call a doctor immediately  Before connecting the hydraulic hoses to the tractor hydraulics, WARNING check that the hydraulics are depressurised on the tractor and device.
Page 85: Connecting Machine To The Tractor
Attaching the implement Connecting machine to the tractor The machine may be mounted only on solid and level ground. After initially mounting the machine on the tractor, make sure there is enough space between the tractor and the machine. The- re must be at least 10 cm of clearance to the machine at each lift height of the front hydraulics.
Page 86 Attaching the implement  Release the clamping screws at both ad- justing pieces (1).  Remove the cross shaft (2).  Remove pined connections (3).  Undo the screws (4).  Turn the bar plates (5) by 180°.  Ensure that the holes for the bolted connections are in line with each other.
Page 87 Attaching the implement Top link If necessary, adjust the attachment point of the top link:  Couple and secure lower links and top link to the machine.  Lift machine with the three point linkage of the tractor to the designated height. ...
Page 88: Mounting Connecting Hoses
Attaching the implement 8.1.2 Mounting connecting hoses Observe the connection direction The connecting hoses are electrically conductive. A printed arrow indicates the direction of flow. If the connection directions are reversed, the machine will not function. The coupling parts of the connecting hoses are attached to the bracket of the hopper using a holder.
Page 89: Coupling Hydraulics And Electrics
Attaching the implement 8.1.3 Coupling hydraulics and electrics  Connect electrical lines.  Remove hydraulic connections (1) from the holder (2).  Remove protecting caps (3).  Connect pressure side coupling to the pressure side connection on the tractor. (Identification Yellow, P) ...
Page 90: Connecting Operation Terminal
Attaching the implement 8.1.4 Connecting operation terminal The LEMKEN job computer is equipped with ISOBUS.  Connect the ISOBUS secondary machi- ne to the tractor via ISOBUS.  Connect Solitair 23 + to the tractor via ISOBUS. 8.1.5 Removing stands ...
Page 91: Driving On Public Roads
Driving on public roads DRIVING ON PUBLIC ROADS General If the implement is transported on public roads: The correct lighting, signs and equipment must be installed on the implement. Ob- serve the standard laws and regulations which apply in your country when travelling on public roads.
Page 92: Lighting Equipment
Driving on public roads 9.4.2 Lighting equipment  Test that complete lighting equipment functions.  At front (1) 9.4.3 Closed hopper According to the variant of the machine:  Check that the roller tarpaulin cover is correctly fixed.  Make sure the latches are locked on the pressure-resistant steel cover.
Page 93: Front Linkage Of The Tractor
Driving on public roads 9.4.5 Front linkage of the tractor Lock spool valve to prevent unintentional operation. 9.4.6 Hydraulic spool valves Switch off Unobstructed view Lift front mounted machine so that the field of view is not impaired. See «Checking field of view, page 29».
Page 94: Operation
Operation OPERATION 10.1 Walking on the step and platform The platform is intended only for filling the tank. The transportation of persons or objects is not permitted. Machine with folding platform DANGER Suspended machine will overturn when walked on The machine may overturn due to a weight load on one side. ...
Page 95 Operation Folding in the step and platform  Remove the pin (2) and linch pin.  Push up the platform.  Swing the platform vertically into the sto- rage position. Lock step:  Insert the pin (2) and linch pin. Machine with permanently mounted platform Step and platform with handrail are secure- ly attached above the tyre packer roller.
Page 96: Filling The Hopper
Operation 10.2 Filling the hopper 10.2.1 Before filling Prerequisite  Bottom gates closed  Flaps closed  Fill level sensors set 10.2.2 Opening the tank To fill the hopper, open the cover accord- ing to the equipment of the machine: Steel cover ...
Page 97: Closing The Hopper
Operation 10.2.3 Closing the hopper When the hopper has been filled, close the cover according to the equipment of the machine: Pressure-resistant cover  Close cover.  Secure the cover with three locking lat- ches. 10.3 Working with the implement 10.3.1 Stopping the implement in an emergency ...
Page 98: Turning At The Headland
Operation 10.4 Turning at the headland DANGER Risk of damage to components If the implement is not fully raised, there is a danger that compo- nents may be damaged during an improper turn at the headland. Before turning at the headland the implement must be completely raised before turning-in to avoid any damage to the implement.
Page 99: Calibration
Operation 10.5 Calibration The complete calibration process is described in the operating in- structions for the electronic control system. Calibration must be carried out after the following operations:  After changing the product to be distribu-  After emptying any residual product ...
Page 100: Settings
Settings SETTINGS Risk of accidents during adjustment work During all adjustment work on the implement there is a risk of crushing, cutting, trapping or knocking the hands, feet or body on heavy parts which may be under spring pressure and/or have sharp edges.
Page 101 Settings Machine with 2 metering units Do not remove guard plate from the mete- ring. Machine with 4 metering units  Remove guard plate (5).  Remove linch pin (3) from the gear wheel (2) of the agitator shaft (1). ...
Page 102: Adjusting Metering Wheels
Settings 11.2 Adjusting metering wheels Risk of injury from rotating metering shaft WARNING The metering shaft is controlled via the operation terminal. Before working on the metering wheels:  Make sure no actions are performed with the operation terminal. Observe the operating instructions for the control. Required tool Universal metering wheel set: ...
Page 103: Switching On Metering Wheels
Settings Adjustment The metering shaft rotates automatically to the setting position. When the setting for the metering wheels appears in the operation terminal:  Remove the covers.  Screw in or unscrew the stop screws (3) with the corresponding tool. 11.2.1 Switching on metering wheels ...
Page 104: Switching Off Metering Wheels
Settings 11.2.2 Switching off metering wheels  Unscrew stop screw (3) as far as the stop plate (5). Pay attention to the note. Check correct position:  The stop plate supports the stop screw.  The stop screw cannot fall out of the tooth base (4).
Page 105: Adjusting The Bottom Gates
Settings 11.3 Adjusting the bottom gates The adjustment of the bottom gates is dis- played on the operation terminal at the start of the calibration test. The position of the bottom gates is determined on the ba- sis of the selected seeds or fertiliser. ...
Page 106: Replacing And Setting Sensors
Settings 11.4 Replacing and setting sensors Setting distance from the sensor to the pulse generator: 2 mm (tolerance +/- 1 mm) The following sensors are identical and are interchangeable:  Blower  Metering shaft  Mechanical lifting sensor 11.5 Adjusting the level sensor Carry out a safety check before entering the hopper: ...
Page 107: Start Metering
Settings 11.6 Start metering 11.6.1 Testing and adjusting sensor switching Mechanical lifting sensor The sensor is switched with a tension spring via a chain (1). Attach shackles (2) to the tractor in the ar- ea of the top link:  Chain longer: Start metering later ...
Page 108: Fan
Settings 11.7 Seeds and fertiliser are conveyed to the shares by an airflow from the fan. The speed of the fan is adjusted with the oil quantity via the spool valve of the trac- tor. The operation terminal of the control shows the current speed.
Page 109: Adjusting The Fan Speed
Settings 11.8 Adjusting the fan speed When attaching the machine, the user ad- justs the fan speed to the desired speed via the flow control valve. If the fan speed fluctuates during sowing and this causes the overpressure to fall, the user must readjust the fan speed.
Page 110: Adjustment Using Add-On Spool Valve With Volumetric Flow Control
Settings 11.8.2 Adjustment using add-on spool valve with volumetric flow control Precondition: The oil of the hydraulic sys- tem is at operating temperature.  On the implement: Completely open the flow control valve (1).  In the tractor cab: Set the desired speed or the mbar range via the volumetric flow control adjustment of the add-on spool valve.
Page 111 Settings  To determine the speed fluctuation, ac- tuate the auxiliary consumer (e.g. track marker or lifting device). To ensure that the required quantity of oil is available, pay attention to the in- creased engine speed of the tractor.  If the pressure continues to drop by mo- re than 10 mbar or the speed by more than 750 rpm: Repeat the process.
Page 112: Cleaning And Care
Cleaning and care CLEANING AND CARE 12.1 Cleaning the implement Contact with seed dust and fertiliser dust DANGER  Wear appropriate personal protective equipment when cleaning: Face mask, gloves Cleaning should ideally take place on the area last treated. Cleaning water must not get into the surface water or the sewage system.
Page 113: Empty Tank
Cleaning and care Dry the implement:  Open all flaps and covers.  Switch on the fan. (Speed 2500 rpm)  Run the fan for 10 minutes.  Preserve cleaned components with pro- tective wax. Store the implement in a dry location after use. 12.2 Empty tank Empty hopper according to property of the...
Page 114 Cleaning and care Discharge Open the discharge flaps:  Swivel the lever (2) upwards. Open the bottom gates:  Swivel the lever (1) for adjustment of the bottom gates. The distribution is collected in the hopper. Using remaining quantity discharge program For a quick discharge: ...
Page 115: Detaching The Implement
Detaching the implement DETACHING THE IMPLEMENT CAUTION Tipping hazard The parked implement may tip over, causing crushing or fatal inju- ries.  Always park the implement on a stable, level surface. Danger from rolling tractor and implement DANGER There is a risk of serious injury or death if the tractor or implement rolls away while you are standing between them.
Page 116: Maintenance And Servicing
Maintenance and servicing MAINTENANCE AND SERVICING 14.1 Specific safety information 14.1.1 General Risk of injury There is a risk of injury during maintenance and repair work.  Always use suitable tools, suitable access aids, platforms and WARNING supports.  Always wear personal protective equipment. ...
Page 117: Immobilise The Implement For Maintenance And Repairs
Maintenance and servicing 14.1.4 Immobilise the implement for maintenance and repairs Risk of accidents when tractor starts up Injuries may occur if the tractor starts moving during maintenance and repair work.  Switch off the tractor engine before carrying out any work on the WARNING implement.
Page 118: Working Under The Raised Device
Maintenance and servicing 14.1.7 Working under the raised device Risk of accident due to lowering and extending of compo- nents and devices It is extremely dangerous to work under raised or next to retracted components and devices. WARNING  Always secure the tractor to prevent it from rolling away. ...
Page 119: Environmental Protection
Maintenance and servicing Risk of accident due to tool slipping off If applying a large force, e.g. when loosening bolts, the tool may WARNING slip off. This may result in hand injuries on sharp-edged parts.  Avoid applying a large force by using suitable auxiliary equip- ment (e.g.
Page 120: Maintenance Schedule
Maintenance and servicing 14.3 Maintenance schedule Tyre packer roller ● ● ● Tyres ●** ● Axle bearing ● ● Packer frame joints ● ● Control rod joints Axle ● ● Protecting caps ● ● ● ● Axle bearing Headstock ● ●...
Page 121 Maintenance and servicing ● ● Bolted connections ● ● ● ● Hydraulic supply pipes ● ● ● ● Safety equipment ● ● Connectors and cables ● ● Hopper seal ** Annually...
Page 122 Maintenance and servicing 14.4 Lubrication Eye injuries due to grease WARNING When lubricating the lubrication points, grease can escape be- tween components at high pressure and cause injury to the eyes. In case of injury, seek medical attention immediately.  Wear protective clothing during lubrication, particularly goggles. ...
Page 123 Maintenance and servicing 14.4.1 Tyre packer roller  Lubricate grease nipples (1) on the axle bearings:  Before the season (annually)  Lubricate grease nipples (3) on the pa- cker frame joints:  Every 8…10 operating hours  Lubricate grease nipples (2) on the con- trol rod joints: ...
Page 124: Testing And Servicing
Maintenance and servicing 14.5 Testing and servicing 14.5.1 Tyres Risk of accidents due to incorrect tyre pressure Tyres may burst if they are inflated beyond the recommended tyre WARNING pressure. Tyres will be overloaded if they are not inflated suffi- ciently.
Page 125: Threaded Connections
Maintenance and servicing 14.5.3 Threaded connections Check the threaded connections:  After the first 8 operating hours  Every 50 operating hours Tighten the bolts and nuts to the correct torque, see «  Tightening torques, page 139». 14.5.4 Checking the axle Protecting caps ...
Page 126: Testing Lower Link Attachment
Maintenance and servicing 14.5.5 Testing lower link attachment  Visually check cross shaft (1) for wear and damage:  Before wintering 14.6 Dosing units Check and clean metering units, depen- ding on use. Preparation  Empty hopper.
Page 127: Checking Exhaust Air Hose For Contamination
Maintenance and servicing 14.6.1 Checking exhaust air hose for contamination The exhaust air hoses (1) must be free of contaminants. Contaminated exhaust air hoses (1) impact the delivery rate.  Clean contaminated exhaust air hoses (1). See «Cleaning and care, page 109». 14.6.2 Checking metering units for damage ...
Page 128: Checking The Metering Wheels
Maintenance and servicing 14.6.3 Checking the metering wheels To ensure trouble-free metering:  Replace damaged metering wheels. Check metering wheels for damage:  Every 50 operating hours Required tools  Wrench 17 mm Depending on metering wheel:  Allen key 3 mm ...
Page 129: Checking Bottom Gates
Maintenance and servicing 14.6.4 Checking bottom gates Check the lever position:  Check every 50 operating hours  Move the lever (3) over the locking plate (2) in detent position 1 until a slight re- sistance is felt. Correct adjustment: The screw (1) points centrally to the hole of the locking plate.
Page 130: Fan
Maintenance and servicing 14.7 If the intake grille is soiled, the fan will lose power. This will result in uneven distributi- Visual inspection  Check the intake grille (1) for soiling.  Remove heavy soiling from the intake grille (1). 14.7.1 Cleaning the fan Fitting the covers ...
Page 131: Viewing Hose On The Fan
Maintenance and servicing Cleaning  Remove soiling from the ventilation gril-  Clean the housing with compressed air. Fit the covers.  Lift cover with the strut onto the holders of the hopper and engage.  Attach screws (2). 14.7.2 Viewing hose on the fan Inspection interval: ...
Page 132 Maintenance and servicing Precondition: The fan is switched off.  Disassemble the filter (if present).  Disassemble the hood (if present).  Inspect the viewing hose (1).  If oil can be seen in the viewing hose: If applicable, measure the back pressure or have it measured.
Page 133: Checking Connections To The Tractor
Maintenance and servicing 14.8 Checking connections to the tractor 14.8.1 Couplings Risk of accident due to spraying hydraulic fluid Fluid (hydraulic oil) escaping under high pressure can penetrate WARNING the skin and cause severe injuries. In case of injury, seek medical attention immediately.
Page 134: Hydraulic Lines
Maintenance and servicing 14.9 Hydraulic lines Hydraulic lines must be checked regularly for damage and leaks. Damaged or leaking lines must be replaced immediately. Hydraulic hoses must be replaced at the latest 6 years after the date of manufacture printed on the hydraulic hoses. Only hydraulic hoses approved by the im- plement manufacturer may be used.
Page 135: Troubleshooting
Troubleshooting TROUBLESHOOTING Risk of accidents DANGER If the implement is not shut down, components may move unex- pectedly or the implement may start to move. This may cause se- rious injuries or death.  Shut the implement down before carrying out any work.
Page 136: Decommissioning And Disposal
Decommissioning and disposal DECOMMISSIONING AND DISPOSAL Damage caused by improper storage of the implement If incorrectly or improperly stored, the implement may be dam- CAUTION aged, e.g. by humidity and dirt. The implement should be deposited on a flat and adequately sta- ble base only.
Page 137: Technical Data
Technical data TECHNICAL DATA 17.1 Dimensions Designation Value Unit Transport length  Maximum 2100 mm  Minimum 1600 mm Transport width  Maximum 2450 mm  Minimum 2450 mm Transport height  Maximum 1900 mm  Minimum 1700 mm Ground clearance ...
Page 138: Permitted Implement Weights
Technical data 17.2.2 Permitted implement weights Designation Value Unit Gross weight, filled  Maximum 3000 kg  Load on step, platform 200 kg  Load on handles 80 kg 17.2.3 Transport rollers Implement with tyre packer roller Designation Value Unit Total number 2 Quantity Function...
Page 139: Three-Point Connection
Technical data 17.3 Three-point connection Designation Value Unit Connection top link L2Z2 Category Connection lower link L2Z3 Category Spreading distance of the lower links Cat 2 Category Coupling points  Top link: 2 Quantity  Lower link 2 Quantity 17.4 Connection information Designation Value Unit...
Page 140: Oil Supply
Technical data 17.5.1 Oil supply Designation Value Unit Oil quality used at the factory HLP 46 / VG 46; DIN 51 524 T.2 Required oil quality HLP 46 / VG 46; DIN 51 524 T.2 Size of the hydraulic connections 3 BG Minimum required oil flow rate of the tractor (consider 35 l/min...
Page 141: Tyres
Technical data 17.8 Tyres For reasons of safety do not exceed or fall below the permitted tyre pressure. Designation Value Unit Tyre size 340/55-16 Profile AW-305 Load + speed index 140 A8 Air pressure 2 bar Rolling circumference 700 mm Specification 161/205 B2 6hole ET40...
Page 142: Tightening Torques
Technical data 17.9 Tightening torques 17.9.1 General  Secure self-locking nuts that have been loosened against working themselves loose again by:  Replacing them against new self-locking nuts  Using lock washers  Using locking compounds such as Loctite The tightening torques set out below refer to screw connections that are not specifically mentioned in these operating instructions.
Page 143: Screws And Nuts Made Of Stainless Steel
Technical data 17.9.3 Screws and nuts made of stainless steel Diameter [Nm] 1.37 11.0 M 10 M 12 M 14 M 16 M 18 M 20 M 22 M 24 M 27 17.9.4 Wheel bolts and wheel nuts Diameter / thread [Nm] M18 x 1,5 M20 x 1,5...
Page 144: Index
Index INDEX Agitator ......................... 97 Axle ........................122 Axle loads ......................32 Blower ........................49 Bottom gates ...................... 102 Braking system ..................... 88 Calibration ......................96 Camera ......................... 55 Cleaning ......................109 Connection information ..................136 Control ........................54 DECOMMISSIONING ..................133 Detaching ......................
Page 145 Index Metering wheels ....................52 Performance data ....................136 Power supply ......................61 Preparations on the tractor ................... 59 Roaddriving ......................88 Scrapers ......................48 Side shield metering ..................... 47 Speed detection ....................55 Spool valves ......................63 Stabilisation ......................43 Steering assembly ....................

LEMKEN Solitair 23+ Operating Instructions Manual

1 General Information

2 Symbols Used in the Operating Instructions

3 Safety Measures and Precautions

4 Handing over the Implement

5 Layout and Description

6 Preparations on the Tractor

7 Preparing the Implement

8 Attaching the Implement

9 Driving on Public Roads

10 Operation

11 Settings

12 Cleaning and Care

13 Detaching the Implement

14 Maintenance and Servicing

15 Troubleshooting

16 Decommissioning and Disposal

17 Technical Data

Index

Quick Links

Related Manuals for LEMKEN Solitair 23+

Summary of Contents for LEMKEN Solitair 23+

Table of Contents
