- Page 1 VariTansanit - EN - Safety is our Concern! Part No.175_4121 2/08.08 LEMKEN GmbH & Co. KG Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220 E-Mail: lemken@lemken.com, Internet:...
- Page 3 Only use genuine LEMKEN spare-parts. Spurious parts negatively influence the function of the implement, show a shorter lifetime and increase in nearly all cases the maintenance effort. We trust that you will understand that LEMKEN is unable to guarantee poor op- eration and damage caused by using spurious parts!
-
Page 4: Definded Use
Therefore use this instruction book with the ’General Health- and Safety precau- tions’! • The LEMKEN-implements have been designed purely for the agricultural use! Any use beyond the one stipulated above is no longer considered as defined use! •... -
Page 5: Table Of Contents
Contents CONTENTS Definded Use........................2 Contents ........................... 3 Basic equipment and accessories ................7 Safety Instructions ....................8 Warning Stickers ..................... 12 General Instructions ....................12 Meaning of the Stickers ....................12 Preparation of the Tractor ..................14 Tyres..........................14 Lift Rods........................ - Page 6 Contents Attachment and Detachment ................. 24 Attachment........................24 Detachment........................26 Working- and Transport Position ................28 General Instructions ....................28 7.1.1 Locking and releasing the cross shaft ..............29 7.1.2 Locking and releasing the tail wheel ................ 29 Working Position......................31 Transport Position ......................
- Page 7 Contents 11.7 Manual turning as emergency function (in Setting menu) ........49 11.8 Sensors ........................51 12 Adjustments......................52 12.1 Optiquick setting centre ..................... 52 12.2 Front furrow width....................... 52 12.2.1 Hydraulic front furrow width adjustment device ............ 53 12.3 Adjustment of the Tractor/Plough Alignment ............54 12.4 Vertical Adjustment.....................
- Page 8 Contents 13.1 Shearbolt Device ......................65 13.2 Automatic non-stop overload protection Hydromatic ..........66 13.2.1 General information ....................66 13.2.2 Setting release force..................... 66 14 Maintenance......................67 14.1 Bolts ..........................69 14.2 Wheel bolts ........................69 14.3 Hydraulic hoses......................70 15 Advices for Driving on Public Raods ..............
-
Page 9: Basic Equipment And Accessories
Basic equipment and accessories BASIC EQUIPMENT AND ACCESSORIES These operating instructions do not distinguish between basic equipment and ac- cessories. The product package of the particular basic equipment depends on the price list which was valid at the time the sales contract was concluded. -
Page 10: Safety Instructions
Safety Instructions SAFETY INSTRUCTIONS General Safety Instructions • Before using the machine, always check both it and the tractor for roadworthi- ness and operational safety! • As well as the notes in these instructions the operator is advised to comply with the generally applicable safety at work regulations and those relating to use of the public highway! •... - Page 11 Safety Instructions • Fit and check transport gear, road lights and warning guards! • The release ropes for quick coupler latches should hang freely and in the low- ered position must not release the quick coupling by themselves. • Never leave the driver's seat whilst in motion! •...
- Page 12 • Regularly check the hydraulic pipes and replace them in the event of damage or signs of ageing. The replacement pipes must comply with the technical specification as laid down by Lemken! • When searching for leaks appropriate aids should be used because of the dan- ger of injury! •...
- Page 13 Safety Instructions Tyres • When working on the tyres make sure that the implement has been placed on the ground safely and that it is secured by chocks against unintentional rolling! • Fitting tyres requires knowledge and special tools! • Repair work on tyres may only be conducted by trained staff and with suitable tools! •...
-
Page 14: Warning Stickers
WARNING STICKERS General Instructions The LEMKEN implement is equipped with all features to ensure safe operation. Where potential danger areas of the implement can not be fully safeguarded, warning stickers are fitted which draw attention to these. Damaged, lost or un- readable warning stickers must be replaced immediately. - Page 15 Warning Stickers WARNING: Keep well clear of the working and swinging area of the implement! 390 0510 WARNING: Pinch point! 390 0506 WARNING: Keep well clear of the turning and swinging area of the implement! 390 0520 WARNING: Hydraulic accumulator contains gas and oil under pressure.
-
Page 16: Preparation Of The Tractor
Preparation of the Tractor PREPARATION OF THE TRACTOR Tyres The pressure - especially in the rear tractor tyres - must be equal. In heavy condi- tions it may be necessary to add wheel weights and/or water ballast. (See manu- facturer’s instructions). Lift Rods Adjust lift rods to equal length. -
Page 17: Control
Preparation of the Tractor Control For operation and transport the tractor hydraulic is to be switched to “position con- trol”. See manufacturer's instructions! Tractor output A tractor with an output of more than 100 kW must be available for the VariTan- sanit with the Hybridcontrol electronic plough control system. -
Page 18: Power Supply
Preparation of the Tractor Power Supply For the electronic control and the lighting equipment a power supply of 12 V is re- quired. See section "Required Sockets". Excess voltage and undervoltage lead to a breakdown and can destroy electric components. For connecting the electronic control to the tractor battery use the delivered battery mounting set (1) with a fuse (2) of 40 A and a plug-in coupling (3) with lock clip (4). -
Page 19: Required Sockets
Preparation of the Tractor 4.10 Required Sockets For the electric use of the implement the following sources of electricity must be available at the tractor: Direct connection to Voltage Socket the tractor battery Electronic Control according to Lighting Equipment DIN-ISO 1724... -
Page 20: Axle Loads
Preparation of the Tractor 4.11 Axle Loads The attachment of implements to the front- and rear-three point linkage must not lead to exceeding the allowed total weight, the allowed axle load and the allowed tyre load of the tractor. The tractor front axle must always be loaded with 20 % of the tractor dead weight at minimum. -
Page 21: Changing Axle Loads
Preparation of the Tractor 4.12 Changing axle loads The hydraulic upper link is used to permanently transfer weight from the plough to the tractor. This not only improves traction, it also enhances the tractor's stability on an incline. The weight percentage for the turning operation is set ex-factory and can be altered at any given time if required. -
Page 22: Use
General Instructions Before the first use it is recommendable - with fully lowered implement - to carry out the following adjustments at the farm. Afterwards only few adjustment correc- tions have to be carried out in the field. Electronic plough control - Hybridcontrol Switch on electronic plough control system on the control terminal (see arrow)! Top Link Control... -
Page 23: Skimmers
Skimmers The skimmers should be set to a depth be- tween 5 and 10 cm. If the required working depth of the plough is 25 cm, the skimmers should be adjusted so that the distance A between the point of the skimmer and point of the plough body amounts to 15 to 20 cm. -
Page 24: Three Point Attachment
Three Point Attachment 5.5.1 General Instructions The category of the three point linkage must be the same with the implement as well as with the tractor. If there is no correspondence, either the three point linkage of the tractor must be adapted or the drawbar (1) and if required the top link pin must be replaced by a corresonding version. - Page 25 Read and adhere to the General Safety Instructions as well as to the Instructions ’Mounted implements’!
-
Page 26: Attachment And Detachment
Attachment and Detachment ATTACHMENT AND DETACHMENT Attachment Attach the plough parked in working posi- tion as follows to the tractor: − Set tractor hydraulics to position control! − Connect tractor lower links to the draw- bar (1) and secure! Swing upwards stand (2) and put it into the holder (3)! −... - Page 27 Attachment and Detachment − Close lock valve (6) at the hydraulic top link (7)! − Switch on the operation terminal (5) of the electronic plough control (see arrow)! − Press key A4 (8) once or twice to reach the attachment menu! −...
-
Page 28: Detachment
Attachment and Detachment − Secure top link pin. − For ploughing do not set tractor hydraulics to power control but to positon con- trol. See operating manual of the tractors’ manufacturer! − Fit warning boards respectively lighting equipment when driving on public roads! For ploughing work the lock valve (6) on the hydraulic top link must always be closed. - Page 29 Attachment and Detachment − The following shown, − Using the J2 joystick (switch positions R or L) enables the upper link to be ad- justed so that it is no longer under ten- sile stress or compressive stress. − Remove hydraulic top link (7) from the tractor! −...
-
Page 30: Working- And Transport Position
Working- and Transport Position WORKING- AND TRANSPORT POSITION General Instructions The VariTansanit must be adjusted for plough work and transport correspondingly. Therefore the cross shaft (1) and the tail axle (2) should be alternately locked and unlocked in the following sequence. -
Page 31: Locking And Releasing The Cross Shaft
Working- and Transport Position 7.1.1 Locking and releasing the cross shaft − Open shutoff valve (5)! − Set control unit to pressure position = lock cross shaft! − Set control unit to discharge position = release cross shaft! − Close shutoff valve (5), to prevent any unintended locking or releasing of the cross shaft! 7.1.2 Locking and releasing the tail wheel... - Page 32 Working- and Transport Position − If the button and joystick functions are locked, they can be released by pressing the A3 and A4 buttons on the control terminal at the same time! − Move joystick J1 to T thereby raising the plough frame at the rear slightly! The tail axle is locked.
-
Page 33: Working Position
Working- and Transport Position Working Position For plough work − lock the hydraulic locking device of the drawbar and − than unlock the tail axle! Drawbar locked Tail axle unlocked Locking valve at wheel − Close lock valve (5) and if existing lock valve (6)! −... -
Page 34: Transport Position
Working- and Transport Position Transport Position Turn plough frame to half-turned transport position by means of pressing key A3! • In transport position all key - and Joystick - functions will be locked now. • The key - and Joystick - functions will be re-activated when press- ing the keys A3 and A4 simultanously. - Page 35 Working- and Transport Position After that close the lock valve (5) and if existing also the lock valve (6) at the wheel!
-
Page 36: Lifting And Lowering The Plough Frame
Lifting and lowering the plough frame LIFTING AND LOWERING THE PLOUGH FRAME The plough frame is lifted and lowered at the front using the tractor's lifting hydrau- lics. The plough frame at the rear is lifted and lowered using the supporting wheel hy- draulics. -
Page 37: Turning The Plough Frame
Turning the Plough Frame TURNING THE PLOUGH FRAME Before any turning process, always use the tractor's hydraulics to raise the plough frame at the front first, and then the support wheel hydraulics to raise it at the rear. To do so move the joystick J1 to the T switch position. In a fully-automated turn of the plough frame, the plough frame is automatically raised at the rear using the support wheel hydraulics before the turning process. -
Page 38: Fully Automatic Turning (Light-Emitting Diode For The Turning Menu Button B3 Lights Up In Green)
Turning the Plough Frame Fully Automatic Turning (Light-Emitting Diode for the turning menu button B3 lights up in green) Turn the plough to right-turning plough position: Shift joystick J1 shortly to the right to position R. Now the plough frame will be turned completely. Turn plough to the left-turning plough position: Shift joystick J1 shortly to the left to position L. -
Page 39: Turning On The Headland
Turning on the headland TURNING ON THE HEADLAND 10.1 Hybridcontrol for semi-automated turn Upon reaching the headland − Lift plough frame at front using tractor hydraulic system! − Lift plough frame at rear using support- ing wheel hydraulics! Set joystick J1 to The oil pressure in the hydraulic upper link is automatically switched to the preset oil pressure for the turning procedure. -
Page 40: Hybridcontrol For Fully-Automated Turn
Turning on the headland 10.2 Hybridcontrol for fully-automated turn Upon reaching the headland − Lift plough frame at front using tractor hydraulic system! − Rotate plough frame! Set joystick J1 briefly to R or L! The plough frame is automatically raised at the rear and the oil pressure in the hydraulic upper link switched to the oil pressure preset for the turning process first and then the plough frame is turned. -
Page 41: Hybrid Control
Hybrid Control HYBRID CONTROL 11.1 General Information The operation terminal inclusive the joysticks is equipped with all buttons and functions being required for the plough with maximum equipment and future func- tions. Therefore not all buttons are taken respectively not all joystick positions are active. -
Page 42: Operation Terminal
Hybrid Control 11.2 Operation Terminal For switching on and off the terminal the switch (1) must be pressed for approxi- mately one second. Via the top joystick J1 the plough will be lifted or lowered at the rear and the plough frame turned. -
Page 43: Button Functions
Hybrid Control 11.2.1 Button functions Setting button for inclination, front furrow width, control sensitivity, upper link pressure; for turning process, upper link pressure; for quick pull-in, language Display of operating states for sensors, solenoid Information button valves, battery, fuses and display of calibration va- Transport button Turn plough frame into transport position (all joy- stick and button functions are simultaneously blok-... -
Page 44: Line Breaker
Hybrid Control 11.2.3 Line Breaker When the line breaker (4) is pushed, all keys will be locked. By means of pressing the rotary switch (2) the alarm can be confirmed: than the light-emitting diodes light; no electro-hydraulic function can be carried out. Only when the line breaker (4) is in its starting position the electro-hydraulic function can be carried out. -
Page 45: Setting Menu
Hybrid Control 11.4 Setting menu Press Setting button A1, to enter the Setting menu and press the Setting button repeatedly or turn the rotary encoder to call up the submenus. The following table shows the corresponding displays with the relevant setting information. Display Information The frame swing-in cylinder can be extended and retracted using the J2 joystick. - Page 46 Hybrid Control Display Information Upper link Set the upper link pressure for quick pull-in to ON, to speed up the plough being pressure pulled-in at the rear, using a temporary lower oil pressure in the hydraulic upper Quick penetrat.: link. Select OFF to switch off the function. Upper link pressure The lower oil pressure for the quick pull-in can be preset, e.g.
- Page 47 Using joystick J2, fully retract the frame swing-in cylinder and save this set- Ram min: ting by pressing the Save button B2. The measuring system is now cali- 1000 mV brated. Language: Select desired language! Service menu Only Authorised for LEMKEN Service employees only! Service...
-
Page 48: Information Menu
Hybrid Control 11.5 Information menu Press Information button A2, to enter the Information menu press Information button repeatedly or turn the rotary encoder to call up the submenus. following table shows corresponding displays with the relevant information. Display Information Press. sensor S1: Measured values of sensor S1. - Page 49 Hybrid Control Display Information Failure A1 = Line Breaker pressed A2 = Sensor S3 front furrow not reached A3 = Wrong value press. sensor S1 A4 = Wrong value angle sensor S2 turning 0 = No fault present. A5 = Wrong value angle sensor S5 working width 1 = Fault present.
-
Page 50: Valve Overview
Hybrid Control 11.5.1 Valve overview... -
Page 51: Couple Menu
Hybrid Control 11.6 Couple Menu Press key A4 to reach the couple menu. By means of repeated pressing of the cou- ple key you reach alternately the attaching or detaching menu. Display Informations Attach Joystick J2 in position B = Close top link Top Link closing: J2 - B Detach... - Page 52 Hybrid Control − Press entry button again! The following display is shown The plough frame can now be turned using the J2 joystick. The plough frame is, e.g. in a left-hand turn ploughing position. − Move joystick from J2 to R : Both hydraulic cylinders are retracted and the plough frame comes to a standstill at the centre position.
-
Page 53: Sensors
Hybrid Control 11.8 Sensors Sensor S1 (1) Pressure sensor for top link cylinder on the hydraulic accumulator Sensor S2 (2) Front angle sensor on the pivot Sensor S3 (3) Switching sensor for enabling the rotating process Sensor S4 (4) Switching sensor for enabling the rotating process Sensor S5 (5) Angle sensor for working width indicator on... -
Page 54: Adjustments
Adjustments ADJUSTMENTS • Read and adhere to the General Safety Instructions! • The implement may only be operated, maintained and repaired by such persons who have been made acquainted with it and who have been advised about the dangers! • Adjustment- maintenance operations... -
Page 55: Hydraulic Front Furrow Width Adjustment Device
Adjustments − Then tighten the clamping screw (2) again! − Retract hydraulic cylinder (2) again! To do so, set joystick J2 to R! − Press the Escape button B1 to return to the operating menu! 12.2.1 Hydraulic front furrow width adjustment device The hydraulic front furrow width adjustment device sets the front furrow width via the operation terminal as follows: −... -
Page 56: Adjustment Of The Tractor/Plough Alignment
Adjustments 12.3 Adjustment of the Tractor/Plough Alignment Adjust the tractor/plough alignment by means of the inner spindle (1) so that there is no lateral draw. Tractor pulls to the ploughed land => turn inner spindle (1) longer! Tractor pulls to the unploughed land =>... -
Page 57: Vertical Adjustment
Adjustments 12.4 Vertical Adjustment During ploughing the plough legs should be positioned nearly vertical to the ground seen forwards. If not, the vertical adjustment must be set. − Press B3 button to switch-off the auto- matic plough turning! The LED (2) goes off. -
Page 58: Working Width
Adjustments 12.5 Working width The working width is set in the operating menu using the joystick J2 in switch posi- tions R and L. Switch position R (right) lower working width Switch position L (left) larger working width 12.6 Working Depth The working depth can be adjusted as de- sired by means of a socket pin (1) at the depth control wheel (2). -
Page 59: Plough Body Adjustments
Adjustments 12.7 Plough Body Adjustments 12.7.1 Pitch The distance A between point and plough frame should be the same with all plough bodies. The measurement D should be 1,5 Required settings will be done by means of the set screws (1). Therefore slacken bolts (2) and clamp screws (3). -
Page 60: Skimmers
Adjustments 12.8 Skimmers 12.8.1 General Instructions The skimmers (1) should be set to a depth between 5 and 10 cm. In plan view the skimmers should be positioned 2 to 3 cm to the side of the share line. In combination with an angle adjustment the pivot bracket (2) can be fitted to the bracket (3) in three different positions. -
Page 61: Projection Angle Adjustment
Adjustments 12.8.2 Projection angle adjustment The projection angle of the mulcher, which can be screwed with its flat blades (4) straight onto the blade brackets (5) or onto the T-plough beam on ploughs with Hy- dromatic overload protection, cannot be altered. -
Page 62: Conversion To The Front Or Rear
Adjustments 12.8.4 Conversion to the front or rear By means of re-positioning the skim stalk (4) or the bracket of the angle adjustment to the front or rear, the position of the skimmer (1) can be optimised. To the rear = more clearance between skimmer and the plough body fitted in front. -
Page 63: Trashboard
Adjustments 12.9 Trashboard Fit trashboard (1) with holder (2) to the mouldboard (3). The holder is provided with slotted holes (6) which allow an uni- versal adjustment. Adjust support-bolt (4) so that it touches the leg. Secure support-bolt (4) by means of the counter nut (5). -
Page 64: Disc Coulters
Adjustments 12.11 Disc Coulters 12.11.1 General Instructions When fitted, disc coulters should be set to a working depth of 7 - 9 cm and 2 - 3 cm to the landslide of the body. With the X- ploughs the disc coulter will be fitted to the beam by means of the holder and bolts (1). -
Page 65: Swivelling Limitation
Adjustments 12.11.4 Swivelling limitation By means of the adjustable stop (9) the lateral swivelling range of the disc coulter will be adjusted. IMPORTANT: All slackened bolts and nuts must be tightened carefully after adjustment. Never drive backwards with the plough when the disc coul- ters are still in the ground. -
Page 66: Soil Looseners
Adjustments 12.13 Soil Looseners 12.13.1 Subsoilers The subsoiler UD6 will be fitted as shown in the sketch. By means of displacing the stalk (1) the working depth of the subsoiler can be adjusted. Maximum working depth = 20 cm Minimum working depth = 14 cm For changing the working depth unsecure pin (2) and remove. -
Page 67: Overload Safety Devices
Art. no. Dimension VariTansanit 301 3424 M 12x75 LS 57x15 -10.9 VariTansanit with Hydromatic 301 3425 M 14x70 LS 51x15 -10.9 • There are crushing and shearing points in the area of the shear- ing protection! • Never stand in the plug base release area while ploughing! •... -
Page 68: Automatic Non-Stop Overload Protection Hydromatic
Overload Safety Devices 13.2 Automatic non-stop overload protection Hydromatic 13.2.1 General information This overload protection is maintenance free. When an obstacle is encountered the base avoids it by moving upwards and to the side. 13.2.2 Setting release force The system pressure of the overload protection and therefore the release force can be set as follows: −... -
Page 69: Maintenance
Maintenance MAINTENANCE All lubrication points must be greased regularly with environmentally friendly grease according to the following table. For a long operation break the piston rods of the hydraulic rams must be greased with non-acid grease. The polished areas of wearing parts and the pins as well as adjusting devices must be treated with grease regularly. - Page 70 Maintenance...
-
Page 71: Bolts
Maintenance 14.1 Bolts All nuts and bolts must be tightened after the first few hours of use, at least within the first 8 hours and checked, and tightened if necessary. At least every 50 hours all bolts and nuts must be checked for tight fit and tightened if necessary and se- cured with Loctite. -
Page 72: Hydraulic Hoses
Maintenance 14.3 Hydraulic hoses Check hydraulic hoses regularly. At least 6 years after the date stated on the hy- draulic hoses they must be changed. Porouse or defective hydraulic hoses must be changed immediately. Use hydraulic hoses only, which are accepted by Lem- ken! −... -
Page 73: Advices For Driving On Public Raods
Advices for Driving on Public Raods ADVICES FOR DRIVING ON PUBLIC RAODS 15.1 Laws and regulations All laws and regulations with regard to transport on public roads must be adhered 15.2 Warning Boards and Lighting The implement has to be equipped with warning boards and lighting when it is transported on public roads attached to a tractor. -
Page 74: Tail Wheel
Advices for Driving on Public Raods 15.4 Tail wheel For transport first the joint of the tail wheel must be locked and then the locking device of the drawbar at the front must be loosened. • Never lock or unlock the tail wheel joint and the drawbar at the same time. -
Page 75: Noise, Airborne Sound
Noise, Airborne Sound NOISE, AIRBORNE SOUND The noise level of the implement does not exceed 70 dB (A) during work. DISPOSAL After useful life of the implement, it must be disposed of environment-friendly by a specialist. NOTES As the version of equipment is depending from the order, the equipment of your implement and its description concerned may deviate in some cases. -
Page 76: Index
INDEX Attachment......................24 Automatic non-stop overload protection .............. 66 Axle Loads ......................18 Check Chains...................... 14 Control ........................ 15 Couple Menu....................... 49 Detachment......................26 Disc Coulters....................... 62 Front ballast ......................15 Front furrow width ....................52 Hydraulic Equipment ................... 15 Hydromatic...................... - Page 77 Index Subsoiler ......................64 Subsoiler Shares....................64 Sway Blocks......................14 Sword Coulter ..................... 61 Tail Pieces ....................57, 60 Tail wheel......................72 Tractor output...................... 15 Transport......................71 Transport Position ....................32 Trashboard......................61 Use ........................20 Vertical Adjustment ..................... 55 Warning Boards ....................
