SERVICE, INSTALLATION, AND INSTRUCTION MANUAL
MIM50 / MIM50P / MIM50P-ADA
MIM50P-O
MIM50V
MIM50-O
For AUTHORIZED PARTS or TECHNICAL SERVICE, please contact:
(877) 368-2797 or
TechnicalServices@thelegacycompanies.com
3355 Enterprise Avenue, Suite 160, Fort Lauderdale, FL 33331 USA
Phone: (954) 202-7419 • Website: Maxx-Ice.com
MIM50, MIM50P, MIM50P-ADA
MIM50P-O, MIM50V, MIM50-O
SELF CONTAINED ICE MAKER │ PLEASE READ CAREFULLY
Advertisement
Table of Contents
Related Manuals for Maxx Ice MIM50P-ADA
Summary of Contents for Maxx Ice MIM50P-ADA
- Page 1 SERVICE, INSTALLATION, AND INSTRUCTION MANUAL MIM50 / MIM50P / MIM50P-ADA MIM50P-O MIM50V MIM50-O For AUTHORIZED PARTS or TECHNICAL SERVICE, please contact: (877) 368-2797 or TechnicalServices@thelegacycompanies.com 3355 Enterprise Avenue, Suite 160, Fort Lauderdale, FL 33331 USA Phone: (954) 202-7419 • Website: Maxx-Ice.com...
-
Page 2: Table Of Contents
Table of Contents ICE MAKER SAFETY ................................... 1 IMPORTANT SAFEGUARDS ............................... 1 TECHNICAL INFORMATION ..............................3 INTRODUCTION ..................................3 COMPONENT LOCATIONS ................................ 4 ICE MAKER INSTALLATION ............................... 5 Remove Packaging Materials ............................5 Cleaning Before Use ............................... 5 Installation Clearances ..............................5 Electrical Requirements .............................. -
Page 3: Ice Maker Safety
Before the ice maker is used, it must be properly positioned and installed as described in this manual, read the manual carefully. Maxx Ice strongly recommends that you have a professional install your new ice maker. The warranty may be affected or voided by an incorrect installation. To reduce the risk of fire, electrical shock or injury when using the ice maker, follow basic precautions, including the following: •... - Page 4 WARNING • Use two or more people to move and install ice maker. Failure to do so can result in back or other injury. • Never install or operate the unit behind closed doors. To ensure proper ventilation for your ice maker, the front of the unit must be completely unobstructed.
-
Page 5: Technical Information
The technical data and performance index listed above is subject to change and should be used for reference only. INTRODUCTION Maxx Ice MIM50 ice maker series produce hard, gourmet cube ice and offers convenience for homeowners, restaurants and hotel guests. An insulated ice storage bin is built in. -
Page 6: Component Locations
COMPONENT LOCATIONS MIM50V / MIM50 / MIM50P/MIM50P-O MIM50-O Front Back Front Back MIM50V / MIM50 / MIM50P/MIM50P-O MIM50-O ITEM # ITEM # Door Door Water Control Panel Distribution (Behind access Tube panel) Evaporator Water Inlet (ice mold) Water Drain Outlet Trough Float Power Cord... -
Page 7: Ice Maker Installation
ICE MAKER INSTALLATION WARNING Excessive Weight Hazard Use two or more people to move and install ice maker. Failure to do so can result in back or other injury. Remove Packaging Materials IMPORTANT: Do not remove any permanent instruction labels or the data label on your ice maker. Remove tape and glue from your ice maker before using. -
Page 8: Electrical Requirements
WARNING Normal operating ambient temperature should be between 50°F (10°C) to 99°F (37°C). Normal operating water temperature should be between 40°F (4°C) and 90°F (32°C). Operation of the ice maker for extended periods outside of these normal temperature ranges may affect production capacity. •... -
Page 9: Reversing The Door Swing For Mim50-O And Mim50V
Reversing The Door Swing For MIM50-O and MIM50V Tools needed: Flathead screwdriver, Phillips screwdriver NOTE: Before you begin, unplug the ice maker or disconnect power. To Remove Door From Hinges 1. Remove the top hinge cover. 2. Using a Phillips screwdriver, remove the screws, remove the top hinge mat and top hinge. Keep the parts together and set them aside. -
Page 10: Reversing The Door Swing For Mim50, Mim50P And Mim50P-O
Reversing The Door Swing For MIM50, MIM50P and MIM50P-O To remove door from hinges: Using a flathead screwdriver, separate the axis from Hinge 1. Set aside. Open the door about 20°around the axis of Bottom Hinge 2, then lift the door off Bottom Hinge 2 and set door aside. To replace door on hinges: 1. -
Page 11: Drain
Turn on the main water supply and tap. Check for water supply connection leaks. Tighten every connection (including connection at the water inlet). NOTE: When you connect the water supply hose and the drain hose, pay attention to the indications of “Water inlet” and “Drain outlet” on the ice maker. Drain You must connect the drain line before using the ice maker. -
Page 12: Installation Types
A stand pipe with a trap below it would be acceptable for the drain/waste receptacle. A floor drain is also acceptable. If this is not possible, Maxx Ice recommends the use of the MIM50P a condensate pump. -
Page 13: Operation
OPERATION Final Check List Prior To Operation Have all packing materials and tape been removed from the interior and exterior of the ice maker? Did you clean the ice storage bin? Have the installation instructions been followed, including connecting the ice maker to water, drain and electricity? Has the ice maker been leveled? Is the ice maker in a site where the ambient temperature is between 50°F (10°C) and 99°F (37°C) and the water temperature between 40°F (4°C) and 90°F (32°C) all year-round? -
Page 14: How The Ice Maker Makes Ice
How The Ice Maker Makes Ice Set the ON/OFF button to the ON position. The ice maker will automatically go to the ice making stage. There are two distinct cycles: ice freeze and harvest. 1. The freeze cycle happens when water flows to the evaporator surface. 2. - Page 15 Water Level Switch 2 PC Board Water Level Switch 1 • The PC board activates the water drain pump for 20 seconds, pumping out most of the water contained in the water reservoir. • The water can be pumped out up a rise of 1.5m (59”) or NOTE: The outlet of the drain hose must be raised higher than...
-
Page 16: Normal Sounds
Normal Sounds Your new ice maker may make sounds that are not familiar to you. Most of the new sounds are normal. Hard surfaces like the floor and walls can make the sounds louder than they actually are. The following list describes the sounds that might be new to you and what may be causing them. -
Page 17: Cleaning And Maintenance
CLEANING AND MAINTENANCE CAUTION If the ice maker is left unused for a long time, before the next use it must be thoroughly cleaned. Follow carefully any instructions provided for cleaning or use of sanitizing solutions. Do not leave any solution inside the ice maker after cleaning. Periodic cleaning and proper maintenance will ensure efficiency, top performance, and long life. -
Page 18: Condenser Cleaning
Condenser Cleaning A dirty or clogged condenser prevents proper airflow, reduces ice making capacity, and causes higher than recommended operating temperatures that may lead to component failure. Have the condenser cleaned at least once every six months. Unplug the ice maker or disconnect power. Condenser Gently pull off the lower front louver. -
Page 19: Control Panel
Allow 30 minutes for proper cleaning. After cleaning, press the ON/OFF switch again. Use a drain hose on the front of the water trough to drain off the waste water to a convenient container. Don’t drain off the waste water to the inside of the cabinet. Repeat steps 3 and 4 (without Ice Machine Cleaning Solution) three times to rinse the ice making system thoroughly. -
Page 20: Major Functions
MAJOR FUNCTIONS The operating procedure is completely automatic. When the ice storage bin is full of ice cubes, the ice maker stops making ice automatically. It starts making ice again after ice cubes are removed. The different colors of the LED display indicate various work modes. A sensitive probe and accurate timer enhance the performance of the ice maker. - Page 21 NOTES:...
