Migrating From Esp-Idf Gnu Make System - Espressif ESP32-S2 Programming Manual

Chapter 4. API Guides
Enumeration
This phase builds a final list of components to be processed in the build, and is performed in the first
half of idf_build_process().
• Retrieve each component's public and private requirements.
ated which executes each component's CMakeLists.txt in script mode.
of idf_component_register REQUIRES and PRIV_REQUIRES argument is re-
turned to the parent build process.
CMAKE_BUILD_EARLY_EXPANSION is defined during this step.
• Recursively include components based on public and private requirements.
Processing
This phase processes the components in the build, and is the second half of idf_build_process().
• Load project configuration from sdkconfig file and generate an sdkconfig.cmake and sdkconfig.h
header. These define configuration variables/macros that are accessible from the build scripts and
C/C++ source/header files, respectively.
• Include each component's project_include.cmake.
• Add each component as a subdirectory, processing its CMakeLists.txt. The component CMake-
Lists.txt calls the registration command, idf_component_register which adds source files,
include directories, creates component library, links dependencies, etc.
Finalization
This phase is everything after idf_build_process().
• Create executable and link the component libraries to it.
• Generate project metadata files such as project_description.json and display relevant information
about the project built.
Browse /tools/cmake/project.cmake

4.4.25 Migrating from ESP-IDF GNU Make System

Some aspects of the CMake-based ESP-IDF build system are very similar to the older GNU Make-based system. The
developer needs to provide values the include directories, source files etc. There is a syntactical difference, however,
as the developer needs to pass these as arguments to the registration command, idf_component_register.
Automatic Conversion Tool
An automatic project conversion tool is available in /tools/cmake/convert_to_cmake.py. Run this command line tool
with the path to a project like this:
$IDF_PATH/tools/cmake/convert_to_cmake.py /path/to/project_dir
The project directory must contain a Makefile, and GNU Make (make) must be installed and available on the PATH.
The tool will convert the project Makefile and any component component.mk files to their equivalent CMake-
Lists.txt files.
It does so by running make to expand the ESP-IDF build system variables which are set by the build, and then
producing equivalent CMakelists files to set the same variables.
Important: When the conversion tool converts a component.mk file, it doesn't determine what other com-
ponents that component depends on. This information needs to be added manually by editing the new component
Espressif Systems
This is called early expansion.
for more details.
1297
Submit Document Feedback
A child process is cre-
The values
The variable
Release v4.4
