Chapter 4. API Guides
For more information, see ESP32-S2 Technical Reference Manual > IO MUX and GPIO Matrix (GPIO, IO_MUX)
[PDF].
Being in the same blink.c project as before, set two breakpoints right after gpio_set_level instruction. Enter
two times c to get to the break point followed by x /1wx 0x3FF44004 to display contents of GPIO_OUT_REG
memory location:
(gdb) c
Continuing.
Target halted. PRO_CPU: PC=0x400DB75E (active)
Target halted. PRO_CPU: PC=0x400DB74E (active)
Breakpoint 2, blink_task (pvParameter=0x0) at /home/user-name/esp/blink/main/./
blink.c:34
→
34 vTaskDelay(1000 / portTICK_PERIOD_MS);
(gdb) x /1wx 0x3FF44004
0x3ff44004: 0x00000000
(gdb) c
Continuing.
Target halted. PRO_CPU: PC=0x400DB751 (active)
Target halted. PRO_CPU: PC=0x400DB75B (active)
Breakpoint 3, blink_task (pvParameter=0x0) at /home/user-name/esp/blink/main/./
blink.c:37
→
37 vTaskDelay(1000 / portTICK_PERIOD_MS);
(gdb) x /1wx 0x3FF44004
0x3ff44004: 0x00000010
(gdb)
If your are blinking LED connected to GPIO4, then you should see fourth bit being flipped each time the LED
changes the state:
0x3ff44004: 0x00000000
...
0x3ff44004: 0x00000010
Now, when the LED is off, that corresponds to 0x3ff44004:
command to set this bit by writting 0x00000010 to the same memory location:
(gdb) x /1wx 0x3FF44004
0x3ff44004: 0x00000000
(gdb) set {unsigned int}0x3FF44004=0x000010
You should see the
int}0x3FF44004=0x000010 command.
Watching and setting program variables
as the program runs. To be able to demonstrate this functionality, update file blink.c by adding a declaration of
a global variable int i above definition of function blink_task. Then add i++ inside while(1) of this
function to get i incremented on each blink.
Exit debugger, so it is not confused with new code, build and flash the code to the ESP and restart debugger. There
is no need to restart OpenOCD.
Once application is halted, enter the command watch i:
(gdb) watch i
Hardware watchpoint 2: i
(gdb)
This will insert so called "watchpoint"in each place of code where variable i is being modified. Now enter
continue to resume the application and observe it being halted:
Espressif Systems
LED to turn on immediately
A common debugging tasks is checking the value of a program variable
1409
Submit Document Feedback
APP_CPU: PC=0x400D1128
APP_CPU: PC=0x400D1128
APP_CPU: PC=0x400D1128
APP_CPU: PC=0x400D1128
0x00000000 being displayed, try using set
after entering set {unsigned
