M_BX(label_num)
Macro: unconditional branch to label
This macro generates two ulp_insn_t values separated by a comma, and should be used when defining
contents of ulp_insn_t arrays. First value is not a real instruction; it is a token which is removed by
ulp_process_macros_and_load function.
M_BXZ(label_num)
Macro: branch to label if ALU result is zero
This macro generates two ulp_insn_t values separated by a comma, and should be used when defining
contents of ulp_insn_t arrays. First value is not a real instruction; it is a token which is removed by
ulp_process_macros_and_load function.
M_BXF(label_num)
Macro: branch to label if ALU overflow
This macro generates two ulp_insn_t values separated by a comma, and should be used when defining
contents of ulp_insn_t arrays. First value is not a real instruction; it is a token which is removed by
ulp_process_macros_and_load function.
Defines
RTC_SLOW_MEM
RTC slow memory, 8k size
The ULP (Ultra Low Power) coprocessor is a simple FSM (Finite State Machine) which is designed to perform
measurements using the ADC, temperature sensor, and external I2C sensors, while the main processors are in deep
sleep mode. The ULP coprocessor can access the RTC_SLOW_MEM memory region, and registers in RTC_CNTL,
RTC_IO, and SARADC peripherals. The ULP coprocessor uses fixed-width 32-bit instructions, 32-bit memory
addressing, and has 4 general-purpose 16-bit registers.

4.28.3 Installing the Toolchain

The ULP coprocessor code is written in assembly and compiled using the
If you have already set up ESP-IDF with CMake build system according to the
toolchain will already be installed.

4.28.4 Compiling the ULP Code

To compile the ULP code as part of the component, the following steps must be taken:
1. The ULP code, written in assembly, must be added to one or more files with .S extension. These files must be
placed into a separate directory inside the component directory, for instance ulp/.
2. Call ulp_embed_binary from the component CMakeLists.txt after registration. For example:
...
idf_component_register()
set(ulp_app_name ulp_${COMPONENT_NAME})
set(ulp_s_sources ulp/ulp_assembly_source_file.S)
set(ulp_exp_dep_srcs "ulp_c_source_file.c")
ulp_embed_binary(${ulp_app_name} "${ulp_s_sources}" "${ulp_exp_dep_srcs}")
The first argument to ulp_embed_binary specifies the ULP binary name. The name specified here
will also be used by other generated artifacts such as the ELF file, map file, header file and linker export
file. The second argument specifies the ULP assembly source files. Finally, the third argument specifies
the list of component source files which include the header file to be generated. This list is needed to build
the dependencies correctly and ensure that the generated header file will be created before any of these
files are compiled. See section below for the concept of generated header files for ULP applications.
