5.
Remove the bo om pickup roller from the
right side of the machine.
6.
Take out the new bo om pickup roller and install it into the machine according to
the removal method (insert the right end first, and then flip the bo om pickup roller
removal lock block to the right side, insert the bo om pickup roller and rotate it 90°
to lock it ghtly), then cover the bo om pickup roller cover.
Remark: The rubber of the bo om pickup roller can be replaced separately; remove the
old rubber by following the figure below and then install the new rubber.
Please use the product correctly on the basis of fully understanding the contents.
3-7
