Components and Func ons

This chapter introduces the names of components and the func ons of the high-speed
scanner
Front
No. Name
1 Guide arm (le /right)
2 Paper feed mode toggle switch
3 Paper output tray
4 Paper output tray extension
board A
5 Paper output tray extension
board B
6 Paper stop board
7 Power bu on
8 Release bu on
9 Paper feed tray
Paper feed tray extension
10
board A
Paper feed tray extension
11
board B
Descrip on
Adjust the posi on of documents to suitable
posi ons
Slide the switch to toggle between "split" and "non-
split" mode.
- Slide it to the le (white) to set the mode to
manual/single paper feed mode.
- Slide it to the right (black) to set the mode to
mul ple feed mode.
Stack the output documents
Pull it out to extend the length of the output tray
Pull it out to extend the length of the output tray
Stop a stack of the output documents from sliding off
Control the scanner's on/off and sleep mode
Li it up to open the scanner cover for removing
paper jams or for cleaning.
Place the documents to be scanned
Pull it out to extend the length of the feed tray.
Pull it out to extend the length of the feed tray
2-1
