Pickup Roller Replacement

When the roller shows signs of wear. The paper feed ability will decrease, and the chance
of paper feed errors (such as paper jams) will increase.
Roller replacement cycle
The feed roller is a consumable, and needs to be replaced approximately every 150,000
pages fed.
When the pages fed by the roller exceed 150,000 pages, a er switching on the high-speed
scanner and scanning is performed using scanning so ware, a replace roller prompt will
appear on the computer screen.
Important
A er the replace roller prompt appears, please purchase a replacement roller kit and
・
replace the roller by following the related steps in the removal and reinstalla on
steps.
When the roller shows signs of wear, the chance of paper jam and paper feed errors
・
occurring will increase. If this type of situa on occurs, please replace the roller
regardless of the page count.
Make sure to reset the roller count a er replacing the roller.
・
Replacement pickup roller kit
The replacement pickup roller kit includes the replacement of the top pickup roller (paper
separa on roller) and the bo om pickup roller (feed roller). Please contact your local
authorized dealer or the customer service center for details.
Top pickup roller (paper separa on roller) replacement
1. Open the scanner cover as shown in the figure.
Open the cover of the top pickup roller by pressing
2.
the places indicated by the arrows inwards
3-4
