Configure the device using the web interface
Service
Secure Web Server, also
known as HyperText
Transfer Protocol over
Secure Socket Layer
(HTTPS)

IP filtering settings

Some Digi devices support built-in firewall functionality to limit TCP/IP traffic to and from certain
networks, TCP ports, and interfaces. The functionality implemented is based on the iptables tool.
You can restrict your Digi device on the network by only allowing certain devices or networks to
connect. This is better known as IP Filtering or Access Control Lists (ACL). By enabling IP filtering, you
are telling the Digi device to only accept connections from specific and known IP addresses or
networks. You can filter devices on a single IP address or restrict device to a group of devices using a
subnet mask that only allows specific networks to access to the device.
CAUTION! Plan and review your IP filtering settings before applying them. If the settings
are incorrect, the Digi device will be inaccessible from the network.
The settings for IP Filtering Settings include:
n
Only allow access from the following devices and networks: Enables IP filtering so that
only the specified devices or networks are allowed to connect to and access the device. Note
that if you enable this feature and the system from which you are connecting to the Digi device
is not included in the list of allowed devices or networks, then you will instantly no longer be
able to communicate or configure the device from this system.
Automatically allow access from all devices on the local subnet: Specifies that all
l
systems and devices on the same local subnet or network of the device are allowed to
connect to the device.
Allow access from the following devices: A list of IP addresses of systems or devices that
l
are allowed to connect to this device.
Allow access from the following networks: A list of networks based on an IP address
l
and matching subnet mask that are allowed to connect to this device. This option allows
grouping several devices that exist on a particular subnet or network to connect to the
device without having to manually specific each individual IP address.

IP forwarding settings

When a Digi device acts as a router and communicates on both a private and public network with
different interfaces, it is sometimes necessary to forward certain connections to other devices. This is
also known as Network Address Translation (NAT) or Port Forwarding.
When an incoming connection is made to the device on the private network, the IP port is searched
for in the table of port forwarding entries. If the IP port is found, that connection is forwarded to
Digi Connect Family and ConnectPort TSFamily
Services provided
You can secure access to configuration web
pages by requiring a user to sign in with
encryption for greater security.
Network configuration
Default network
port number
443
