- Page 1 OWNER'S MANUAL 2024 790 ADVENTURE Art. no. 3214950en...
- Page 3 KTM accepts no liability for delivery options, deviations from fig- ures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not belong to the regular scope of supply.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Switches on the right side of the TABLE OF CONTENTS MEANS OF REPRESENTATION ...... 6 handlebar........19 Symbols used ........6 6.5.1 Start button/emergency OFF Formats used........6 switch......... 19 6.5.2 Hazard warning flasher switch..20 SAFETY ADVICE..........7 Ignition and steering lock.... - Page 5 TABLE OF CONTENTS 7.21 Front rider's seat heating (optional)..40 7.28.47 Consumption ....... 62 7.22 Passenger seat heating (optional) ..40 7.28.48 Language ........62 7.23 Favorites display ......40 7.28.49 DRL ........... 63 7.24 Quick Selector 1 display ....40 7.28.50 Heating (function optional) ...
- Page 6 TABLE OF CONTENTS 13 SERVICE WORK ON THE CHASSIS....87 14.9 Checking that the brake linings of the rear brake are secured....113 13.1 Raising the motorcycle with rear lifting gear ........87 15 WHEELS, TIRES ........115 13.2 Removing the rear of the motorcycle 15.1 Removing the front wheel ....
- Page 7 TABLE OF CONTENTS 20 CLEANING, CARE ........145 20.1 Cleaning the motorcycle ....145 20.2 Checks and maintenance steps for winter operation......146 21 STORAGE ..........147 21.1 Storage ......... 147 21.2 Preparing for use after storage..148 22 TROUBLESHOOTING ........ 149 23 TECHNICAL SPECIFICATIONS ....
-
Page 8: Means Of Representation
Indicates work that requires expert knowledge and technical understanding. In the interest of your own safety, have these jobs performed by an authorized KTM workshop! Your motorcycle will be cared for there to the highest degree by specially trained experts using the special tools required. -
Page 9: Safety Advice 2
SAFETY ADVICE 2 Use definition – intended use The vehicle is designed and constructed to withstand the usual demands of regular traffic and use on gentle ter- rain (unpaved roads). This vehicle is not suitable for use on race tracks. Info This vehicle is only authorized for operation on public roads in its homologated version. -
Page 10: Tampering Warning
The vehicle should only be used by trained persons. An appropriate driver's license is needed to ride the vehicle on public roads. Have malfunctions that impair safety promptly eliminated by an authorized KTM workshop. Adhere to the information and warning labels on the vehicle. -
Page 11: Protective Clothing
– Always wear protective clothing that is in good condition and meets the legal regulations. In the interest of your own safety, KTM recommends that you only operate the vehicle while wearing protective clothing. Work rules Unless specified otherwise, the ignition must be turned off during all work (models with ignition lock, models with transponder key) or the motor must be at a standstill (models without ignition lock or transponder key). - Page 12 2 SAFETY ADVICE The Owner's Manual is also available for download from your authorized KTM dealer and on the KTM website. A printed copy can also be ordered from your authorized KTM dealer. International KTM Website: KTM.COM...
-
Page 13: Important Notes 3
Manufacturer warranty, implied warranty The work prescribed in the service schedule must only be carried out in an authorized KTM workshop and con- firmed in the KTM Dealer.net, as otherwise all warranty claims will be void. Damage or secondary damage caused by tampering with and/or conversions on the vehicle are not covered by the manufacturer warranty. -
Page 14: View Of Vehicle
4 VIEW OF VEHICLE View of vehicle, front right (example) W00257-11 Luggage rack ( p. 27) Storage compartment under the passenger seat Vehicle identification number ( p. 14) Level viewer, engine oil Foot brake lever ( p. 28) -
Page 15: View Of Vehicle, Rear Left (Example)
VIEW OF VEHICLE 4 View of vehicle, rear left (example) W00256-11 Clutch lever ( p. 16) Light switch ( p. 17) Menu buttons ( p. 18) Turn signal switch ( p. 19) Horn button ( p. 19) Cruise control system tip switch ( p. -
Page 16: Serial Numbers
5 SERIAL NUMBERS Vehicle identification number The vehicle identification number is stamped on the right side of the steering head. 402324-10 Type label The type label is located on the frame on the left. The type label for Australia is located on the frame on the right. -
Page 17: Engine Number
SERIAL NUMBERS 5 Engine number The engine number is stamped onto the engine case at the top. H01047-10 Fork part number The fork part number is stamped on the inner side of the fork stub. 402295-10 Shock absorber article number Shock absorber article number is on the left side of the shock absorber. -
Page 18: Controls
6 CONTROLS Clutch lever Clutch lever is fitted on the handlebar on the left. I00286-10 Hand brake lever The hand brake lever is fitted on the right side of the handle- bar. The front brake is engaged using the hand brake lever. I00287-10 Throttle grip The throttle grip... -
Page 19: Light Switch
CONTROLS 6 6.4.2 Light switch The light switch is fitted on the combination switch on the left. Possible states Low beam on – Light switch in position . In this position, the low beam and the tail light are switched High beam on –... -
Page 20: Menu Buttons
6 CONTROLS – Operating the hand brake lever – Operating the foot brake lever – Operating the clutch lever – Turning the throttle grip beyond the basic position – Control of the motorcycle traction control (MTC) – Slip at the rear wheel or lifting front wheel –... -
Page 21: Turn Signal Switch
CONTROLS 6 6.4.5 Turn signal switch Turn signal switch is fitted on the combination switch on the left. Possible states Turn signal off Left turn signal, on – Turn signal switch pressed to the left. The turn signal switch returns to the center position after activation. -
Page 22: Hazard Warning Flasher Switch
6 CONTROLS 6.5.2 Hazard warning flasher switch The hazard warning flasher switch is fitted on the right side of the switch. The hazard warning flasher is used to indicate emergency situa- tions. Info The hazard warning flasher can be activated or deactivated while the ignition is switched on or up to 60 seconds after the ignition is switched off. -
Page 23: Unlocking The Steering
CONTROLS 6 Unlocking the steering – Insert the ignition key into the ignition and steering lock, press in, and turn to the right. Remove the ignition key. The handlebar can now be moved again. 400731-01 Socket for electrical accessories Socket for electrical accessories is mounted on the left side of the mask support. -
Page 24: Closing The Fuel Tank Filler Cap
6 CONTROLS Warning Danger of poisoning Fuel is harmful to health. – Avoid skin, eye and clothing contact with fuel. – Immediately consult a doctor if you swallow fuel. – Do not inhale fuel vapors. – Rinse the affected area immediately with plenty of water in the event of contact with the skin. –... -
Page 25: Fuel Cocks
CONTROLS 6 6.13 Fuel cocks A fuel cock is located on each side of the fuel tank. Info The fuel cocks are located behind the fuel tank covers. The fuel cocks must always be open during operation. The fuel cocks are only closed to remove the fuel tank. Possible states Fuel cocks are closed –... -
Page 26: Closing The Storage Compartment Under The Passenger Seat (Optional)
6 CONTROLS 6.15 Closing the storage compartment under the passenger seat (optional) Main work – Close storage compartment. – Attach lock in area and press down in the direction of the arrow. F01893-10 Finishing work – Mount the passenger seat. ( p. -
Page 27: Closing The Storage Compartment On The Left (Optional)
CONTROLS 6 6.17 Closing the storage compartment on the left (optional) Main work – Close storage compartment. – Raise elastic fastener and hang up in area F01899-10 Finishing work – Install the left side cover. ( p. 95) – Mount the front rider's seat. ( p. -
Page 28: Closing The Storage Compartment On The Right (Optional)
6 CONTROLS Main work – Lift the elastic fastener and detach in area – Open storage compartment. F01900-10 6.19 Closing the storage compartment on the right (optional) Main work – Close storage compartment. – Raise elastic fastener and hang up in area F01901-10 Finishing work –... -
Page 29: Tool Set
CONTROLS 6 6.20 Tool set The tool set is located in the storage compartment under seat T04547-01 6.21 Grab handles The grab handles are used for moving the motorcycle around. If you carry a passenger, the passenger can hold onto the grab handles during the trip. -
Page 30: Passenger Foot Pegs
6 CONTROLS 6.24 Passenger foot pegs The passenger foot pegs can be folded up and down. Possible states Passenger foot pegs folded up – For operation without a pas- • senger. Passenger foot pegs folded down – For operation with a pas- •... -
Page 31: Side Stand
CONTROLS 6 6.27 Side stand The side stand is located on the left of the vehicle. The side stand is used for parking the motorcycle. Info The side stand must be folded up during motorcycle use. The side stand is coupled with the safety starting system; follow the riding instructions. -
Page 32: Combination Instrument
7 COMBINATION INSTRUMENT Combination instrument I00194-10 The combination instrument is attached in front of the handlebar. The combination instrument is divided into two function areas. indicator lamps ( p. 33) Display Caution Danger of burns Parts of the combination instrument become hot in certain situations. In particular, the display gets hot in ambient temperatures above 55 °C (131 °F), during extended sta- tionary periods, for example, at a traffic light, or in direct sunlight. -
Page 33: Demo Mode
You will regularly be shown messages indicating when demo mode will be ending. All optional software functions will be deactivated and no longer displayed when demo mode ends. The optional software functions are available from an authorized KTM dealer. Functions included in demo mode –... -
Page 34: Warnings
7 COMBINATION INSTRUMENT Warnings Warnings appear in the middle of the display; these are marked yellow or red depending on their relevance. Yellow warnings indicate a malfunction or information which requires prompt intervention or an adjustment to the riding style. Red warnings indicate a malfunction or information which requires immediate intervention. -
Page 35: Indicator Lamps
TC indicator lamp lights up/flashes yellow – MTC ( p. 139) is not enabled or is currently intervening. The TC indicator lamp also lights up if a malfunction is detected. Contact an authorized KTM workshop. The TC indicator lamp flashes, if MTC or MSR (optional) actively engage. -
Page 36: Display
7 COMBINATION INSTRUMENT The oil pressure warning lamp lights up red – The oil pressure is too low. Stop immediately, taking care not to endanger yourself or other road users in the process, and switch off the engine. The alarm system indicator lamp lights up or flashes red – Status or error message of the alarm system. -
Page 37: Rally Display (Optional)
COMBINATION INSTRUMENT 7 Heated grip (optional) ( p. 39) Unit for the speedometer MTC display ( p. 38) ABS display ( p. 38) Favorites display ( p. 40) Fuel range display Fuel level display ( p. 39) Ambient air temperature indicator ( p. -
Page 38: Speed
7 COMBINATION INSTRUMENT Favorites display ( p. 40) Front rider's seat heating (optional) ( p. 40) Heated grip (optional) ( p. 39) Throttle Response (optional) ( p. 140) ABS display ( p. 38) Fuel range display Gear display Unit for the engine speed display Ambient air temperature indicator ( p. -
Page 39: Speedometer
COMBINATION INSTRUMENT 7 7.11 Speedometer The speed is shown in area of the display. Speed is shown in kilometers per hour km/h or in miles per hour mph. The unit of speed can be configured in the Distance submenu. I00204-10 7.12 Cruise control indicator (optional) The operating state of the active cruise control is shown in the... -
Page 40: Ride-Mode Display
7 COMBINATION INSTRUMENT 7.15 Ride‑Mode display The Ride Mode ( p. 139) setting is shown in area of the dis- play. The drive mode can be configured in the Ride Mode submenu. I00204-13 7.16 ABS display The ABS mode setting is shown in the area of the display. -
Page 41: Fuel Level Display
COMBINATION INSTRUMENT 7 Info If the coolant temperature indicator shows HOT, the indica- tor also starts to flash. If the cooling system overheats, the maximum engine speed is limited. Possible states The engine is cold – The coolant temperature indicator •... -
Page 42: Front Rider's Seat Heating (Optional)
7 COMBINATION INSTRUMENT 7.21 Front rider's seat heating (optional) The status of the front rider's seat heating is shown in area the display. The front rider's seat heating can be configured in the Seat Heat- ing Rider submenu. I00208-11 7.22 Passenger seat heating (optional) The status of the passenger seat heating is shown in area the display. -
Page 43: Quick Selector 2 Display
COMBINATION INSTRUMENT 7 7.25 Quick Selector 2 display When the menu is closed, the Quick Selector 2 display is opened by pressing the DOWN button. Press the BACK button to close the Quick Selector 2 display. Info The Quick Selector 2 display can be configured in the Settings menu under Quick Selector 2. -
Page 44: Menu
7 COMBINATION INSTRUMENT 7.28 Menu Info Press SET button in the start screen to open the menu. Navigate through the menu using the UP button the DOWN button By pressing the BACK button , the menu structure jumps one step back, or the menu is closed. F01784-10 7.28.1 Motorcycle... -
Page 45: Abs
COMBINATION INSTRUMENT 7 Rain - Reduced homologated performance with soft response for improved rideability on surfaces with low road grip; the motorcycle traction control allows very little slip on the rear wheel. ABS regulates both wheels. Offroad- Reduced homologated performance for better rideability on unpaved roads;... -
Page 46: Mtc
7 COMBINATION INSTRUMENT 7.28.4 Condition • Cruise control system function (optional) deactivated. – Press the SET button when the menu is closed. – Press the UP or DOWN button until Motorcycle is highlighted. Press the SET button to open the menu. –... -
Page 47: Quickshift+ (Optional)
COMBINATION INSTRUMENT 7 7.28.6 Quickshift+ (optional) Condition • Model with QUICKSHIFTER+. – Press the SET button when the menu is closed. – Press the UP or DOWN button until Motorcycle is highlighted. Press the SET button to open the menu. –... -
Page 48: Throttle Response (Optional)
7 COMBINATION INSTRUMENT 7.28.9 Throttle Response (optional) Condition • Model with RALLY PACK. • Riding mode Rally (optional) is activated. – Press the SET button when the menu is closed. Warning Danger of accidents An incorrectly selected riding mode makes control of the vehicle considerably more difficult. -
Page 49: Bike Info
COMBINATION INSTRUMENT 7 – Press the SET button to set the maximum permitted slip for the motorcycle traction control. Info Do not open the throttle during the selection. The spin adjuster is a motorcycle traction control function. The slip adjustment allows the motorcycle traction control to be tuned through nine levels to the desired characteristic map. -
Page 50: Warning
7 COMBINATION INSTRUMENT 7.28.13 Warning Condition • Message or warning is present. – Press the SET button when the menu is closed. – Press the UP or DOWN button until Bike Info is highlighted. Press the SET button to open the menu. –... -
Page 51: Trip 2
COMBINATION INSTRUMENT 7 7.28.16 Trip 2 – Press the SET button when the menu is closed. – Press the UP or DOWN button until Trip is highlighted. Press SET button to open the menu. – Press the UP or DOWN button until Trip 2 is highlighted. Press the SET button to open the submenu. -
Page 52: Last Search (Optional)
7 COMBINATION INSTRUMENT 7.28.18 Last search (optional) Condition • Bluetooth ® function is activated. • The KTMconnect app (optional) is installed and opened on a suitable cellphone (Android devices Version 7.0 and higher, iOS devices Version 13 and higher). • The combination instrument is connected to a suitable phone. -
Page 53: Skip Waypoint (Optional)
COMBINATION INSTRUMENT 7 7.28.20 Skip Waypoint (optional) Condition • Bluetooth ® function is activated. • The KTMconnect app (optional) is installed and opened on a suitable cellphone. • The combination instrument is connected to a suitable phone. • The GPS function is activated on the connected phone. •... -
Page 54: Stop Navigation (Optional)
7 COMBINATION INSTRUMENT 7.28.22 Stop Navigation (optional) Condition • Bluetooth ® function is activated. • The KTMconnect app (optional) is installed and opened on a suitable cellphone (Android devices Version 7.0 and higher, iOS devices Version 13 and higher). • The combination instrument is connected to a suitable phone. -
Page 55: Call
COMBINATION INSTRUMENT 7 7.28.24 Call Condition • Bluetooth ® function is activated. • The Bluetooth ® function should also be activated in the device to be paired. • The combination instrument is connected to a suitable phone. • The combination instrument is connected to a suitable com- munication system. -
Page 56: Settings
7 COMBINATION INSTRUMENT Info It is not possible to change the audio volume using the combination switch with every cellphone. The call duration and contact are displayed. Depend- ing on the cellphone settings, the contact is shown by name. Accessing contacts must be enabled on the cellphone. An incoming call is shown in a small window at the top of the combination instrument display when the naviga- tion function is active. -
Page 57: Quick Selector 1
COMBINATION INSTRUMENT 7 7.28.29 Quick Selector 1 Condition • The motorcycle is stationary. – Press the SET button when the menu is closed. – Press the UP or DOWN button until Settings is highlighted. – Press the SET button to open the menu. –... -
Page 58: Bluetooth
7 COMBINATION INSTRUMENT 7.28.32 Bluetooth Condition • The motorcycle is stationary. – Press the SET button when the menu is closed. – Press the UP or DOWN button until Settings is highlighted. – Press the SET button to open the menu. –... -
Page 59: Riders Headset (Optional)
COMBINATION INSTRUMENT 7 – Press the UP or DOWN button until Delete Pairing is highlighted. The paired device can be deleted by pressing the SET button. – Move the previously paired device into the range of the vehicle while the Bluetooth ®... -
Page 60: Headset Type (Optional)
7 COMBINATION INSTRUMENT If the device is not automatically connected with the vehi- cle after approx. 30 seconds: – Switch on the vehicle again or repeat the New Pair- ing procedure. In the Riders Headset menu, a suitable rider communication sys- tem can be paired with the vehicle. -
Page 61: Rpm1
COMBINATION INSTRUMENT 7 7.28.38 RPM1 Condition • The motorcycle is stationary. • ODO > 1,000 km (621 mi). – Press the SET button when the menu is closed. – Press the UP or DOWN button until Settings is highlighted. Press SET button to open the menu. –... - Page 62 7 COMBINATION INSTRUMENT – Press the SET button when the menu is closed. – Press UP or DOWN button until Settings appears. Press the SET button to open the menu. – Press the UP or DOWN button until Clock & Date is highlighted. Press the SET button to open the submenu.
-
Page 63: Clock Format
COMBINATION INSTRUMENT 7 7.28.41 Clock Format Condition • The motorcycle is stationary. – Press the SET button when the menu is closed. – Press the UP or DOWN button until Settings is highlighted. Press SET button to open the menu. –... -
Page 64: Temperature
7 COMBINATION INSTRUMENT 7.28.45 Temperature Condition • The motorcycle is stationary. – Press the SET button when the menu is closed. – Press the UP or DOWN button until Settings is highlighted. Press SET button to open the menu. – Press the UP or DOWN button until Units is highlighted. -
Page 65: Drl
Make sure that the daytime running light is deac- tivated with the diagnostics tool when the menu item is not available, but the low beam is required. (Your authorized KTM workshop will be glad to help.) – Note the legal regulations regarding the daytime running light. -
Page 66: Heated Grips (Function Optional)
7 COMBINATION INSTRUMENT Info In the Settings menu, the Heating submenu solely controls the visibility of Heated Grips and Seat Heating in the Motor- cycle menu. 7.28.51 Heated Grips (function optional) Condition • Model with heated grip. • The motorcycle is stationary. –... -
Page 67: Extra Functions
Use the UP or DOWN button to navigate through the extra func- I00260-01 tions. Info The optional extra functions are listed. The current KTM PowerParts and available software are listed on the KTM website. 7.28.55 Demo Mode Condition • The motorcycle is stationary. -
Page 68: Ergonomics
8 ERGONOMICS Setting the front rider's seat Preparatory work – Remove the passenger seat. ( p. 88) – Remove the front rider's seat. ( p. 89) Alternative 1 – Attach the front rider's seat to the fuel tank at the recesses , and push the front rider's seat down and forward at the same time. -
Page 69: Adjusting The Basic Position Of The Clutch Lever
ERGONOMICS 8 – Remove screws . Take off the handlebar clamps . Posi- tion the handlebar so that screws are accessible. Info Cover the components to protect them against damage. Do not kink the cables and lines. – Remove screws . -
Page 70: Adjusting The Basic Position Of The Hand Brake Lever
If there is no free travel on the foot brake lever, pressure builds up in the brake system on the rear brake. – Set the free travel on the foot brake lever in accordance with the specification. – Ensure that the adjustment steps are performed properly. (Your authorized KTM workshop will be glad to help.) -
Page 71: Checking The Basic Position Of The Shift Lever
ERGONOMICS 8 – Detach spring – Loosen nut Press the foot brake lever downwards to make this eas- ier. – Turn the push rod to set the basic position of the foot brake lever. F02003-10 Info The range of adjustment is limited. The screw must be screwed in by at least five full turns. -
Page 72: Adjusting The Basic Position Of The Shift Lever
8 ERGONOMICS – Sit on the vehicle in the riding position and determine distance between the upper edge of your boot and the shift lever. Distance between shift lever 10 … 20 mm (0.39 … and upper edge of boot 0.79 in) »... -
Page 73: Preparing For Use 9
When using your vehicle, remember that others may feel disturbed by excessive noise. – Make sure that the pre-sales inspection work has been carried out by an authorized KTM workshop. You will receive a delivery certificate when the vehicle is handed over. -
Page 74: Running In The Engine
9 PREPARING FOR USE – Run the engine in. ( p. 72) Running in the engine – During the running-in time, do not exceed the specified engine speed. Guideline Maximum engine speed During the first: 1,000 km (620 mi) 6,500 rpm After the first: 1,000 km (620 mi) 9,800 rpm –... - Page 75 PREPARING FOR USE 9 Warning Danger of accidents A high payload alters the handling characteristic and increases the stopping distance. – Adapt your speed to your payload. Warning Fire hazard The hot exhaust system may burn luggage. – Fasten your luggage in such a way that it cannot be burned or singed by the hot exhaust system. –...
-
Page 76: Riding Instructions
10 RIDING INSTRUCTIONS 10.1 Checks and maintenance measures when preparing for use Info Before every trip, check the condition of the vehicle and ensure that it is roadworthy. The vehicle must be in perfect technical condition when it is being operated. –... -
Page 77: Starting Off
RIDING INSTRUCTIONS 10 The ABS warning lamp lights up and goes back out after starting off. – Shift the transmission into neutral The green idle indicator lamp N lights up. – Briefly press the start button/emergency OFF switch into the lower position Info Only press the start button/emergency OFF switch into... -
Page 78: Shifting, Riding
10 RIDING INSTRUCTIONS 10.5 Shifting, riding Warning Danger of accidents Abrupt load alterations can cause the vehicle to get out of control. – Avoid abrupt load alterations and sudden braking actions. – Adapt your speed to the road conditions. Warning Danger of accidents If you change down at high engine speed, the rear wheel blocks and the engine races. - Page 79 Info If unusual noises occur while riding, stop immediately (taking care not to endanger yourself or other road users in the process), switch off the engine and contact an authorized KTM workshop. – Shift into a higher gear when conditions allow (incline, road situation, etc.).
- Page 80 Contact an authorized KTM workshop. – If the malfunction indicator lamp lights up during a trip, please contact an authorized KTM workshop as soon as possi- ble. – If the general warning lamp lights up during a trip, the dis- play shows a message.
-
Page 81: Msr (Optional)
Danger of accidents A spongy pressure point on the front or rear brake reduces braking efficiency. – Check the brake system and do not continue riding until the problem is eliminated. (Your authorized KTM workshop will be glad to help.) Warning Danger of accidents The brake system fails in the event of overheating. -
Page 82: Stopping, Parking
10 RIDING INSTRUCTIONS Warning Danger of accidents Driving aids can reduce the probability of a fall only within physical limits. It is not always possible to compensate for certain riding situations, for example with luggage loaded with a high center of gravity, varying road surfaces, steep descents or full braking without disengaging the gear. -
Page 83: Transporting
RIDING INSTRUCTIONS 10 – Switch off the ignition by turning the ignition key to the position Info If the engine is switched off with the emergency OFF switch and the ignition remains switched on at the ignition lock, power continues to flow to most electrical power consumers. This discharges the 12- V battery. -
Page 84: Refueling
In some countries and regions, the available fuel quality and cleanliness may not be sufficient. This will result in problems with the fuel system. – Refuel only with clean fuel that meets the specified standards. (Your authorized KTM workshop will be glad to help.) Note Environmental hazard Improper handling of fuel is a danger to the environment. - Page 85 RIDING INSTRUCTIONS 10 – Switch off the engine. – Open the fuel tank filler cap. ( p. 21) – Fill the fuel tank with fuel up to the lower edge of the filler neck. Total fuel tank 20 l Super unleaded capacity, approx.
-
Page 86: Service Schedule
Different service intervals may apply in your country, depending on the local operating conditions. Individual service intervals and scopes may change in the course of technical developments. The most up-to-date service schedule can always be found on KTM Dealer.net. Your authorized KTM dealer will be happy to advise you. - Page 87 Final check: Check the vehicle is roadworthy and take a test ride. ○ ● ● ● ● ● Read out the error memory after the test ride using the KTM diagnostics tool. ○ ● ● ● ● ● Adjust service display with KTM diagnostics tool.
-
Page 88: Tuning The Chassis
12 TUNING THE CHASSIS 12.1 Adjusting the spring preload of the shock absorber Warning Danger of accidents Modifications to the suspension setting may seriously alter the handling characteris- tic. – Ride slowly to start with after making adjustments to get the feel of the new handling characteristic. Info The spring preload defines the initial status of the spring operation on the shock absorber. -
Page 89: Service Work On The Chassis 13
SERVICE WORK ON THE CHASSIS 13 13.1 Raising the motorcycle with rear lifting gear Note Danger of damage The parked vehicle can roll away or fall over. – Park the vehicle on a firm and level surface. – Mount retaining adapter on the link fork. –... -
Page 90: Taking The Motorcycle Off The Front Lifting Gear
13 SERVICE WORK ON THE CHASSIS – Move the handlebar to the straight-ahead position. – Use suitable lifting gear when attaching the steering stem. – Align the front lifting gear with the fork legs. Info Always raise the motorcycle at the rear first. –... -
Page 91: Mounting The Passenger Seat
SERVICE WORK ON THE CHASSIS 13 13.6 Mounting the passenger seat – Hook holding lugs of the passenger seat into the bushings on the subframe, lower the front, and simultaneously push back- ward. – Insert locking pin into the lock housing and push down the front of the passenger seat until the locking pin engages with an audible click. -
Page 92: Checking For Chain Dirt
13 SERVICE WORK ON THE CHASSIS 13.9 Checking for chain dirt – Check the chain for coarse dirt accumulation. » If the chain is very dirty: – Clean the chain. ( p. 90) 400678-01 13.10 Cleaning the chain Warning Danger of accidents Lubricants on the tires reduces the road grip. –... -
Page 93: Checking The Chain Tension
SERVICE WORK ON THE CHASSIS 13 13.11 Checking the chain tension Warning Danger of accidents Incorrect chain tension damages components and results in accidents. If the chain is tensioned too much, the chain, engine sprocket, rear sprocket, transmission and rear wheel bearings wear more quickly. Some components may break if overloaded. If the chain is too loose, the chain may fall off the engine sprocket or the rear sprocket. -
Page 94: Checking The Chain, Rear Sprocket, Engine Sprocket, And Chain Guide
13 SERVICE WORK ON THE CHASSIS Main work – Loosen nut – Loosen nuts – Adjust the chain tension by turning adjusting screws left and right. Guideline Chain tension 2 … 5 mm (0.08 … 0.2 in) Turn the adjusting screws on the left and right so that the markings on the left and right chain adjusters are in... - Page 95 SERVICE WORK ON THE CHASSIS 13 – Shift the transmission into neutral – Pull on the lower chain section with the specified weight Guideline Weight, chain wear measure- 15 kg (33 lb.) ment – Measure distance of 18 chain rollers in the lower chain section.
-
Page 96: Removing The Left Side Cover
13 SERVICE WORK ON THE CHASSIS – Check the chain sliding guard for wear. » If continuous signs of wear to the chain are visible on the chain sliding guard in the area marked: – Change the chain sliding guard. »... -
Page 97: Installing The Left Side Cover
SERVICE WORK ON THE CHASSIS 13 13.15 Installing the left side cover Main work – Position the left side cover with holding lug on bushing and push backward. The left side cover engages under the tail part. – Press the left side cover in area into rubber bushing and press into rubber bushing in area... -
Page 98: Installing The Right Side Cover
13 SERVICE WORK ON THE CHASSIS 13.17 Installing the right side cover Main work – Position the right side cover with holding lug on bush- and push backward. The right side cover engages under the tail part. – Press the right side cover in the area into rubber bush- and press into rubber bushing in area... -
Page 99: Installing The Battery Cover
SERVICE WORK ON THE CHASSIS 13 13.19 Installing the battery cover Main work – Position the battery cover with holding lugs bushings and push downward. The battery cover engages on the left and right under the fuel tank spoiler. – Mount screws with the bushings and tighten. -
Page 100: Installing The Left Fuel Tank Spoiler
13 SERVICE WORK ON THE CHASSIS Main work – Remove screw – Remove screws Z03260-10 – Remove the left fuel tank spoiler from the rubber bushing in area – Pull the left fuel tank spoiler in area out of the bracket. –... -
Page 101: Removing The Right Fuel Tank Spoiler
SERVICE WORK ON THE CHASSIS 13 – Mount screws , but do not tighten yet. Guideline Screw, trim 3 Nm (2.2 lbf ft) – Mount screw , but do not tighten it yet. Guideline Screw, fuel tank 5 Nm (3.7 lbf ft) spoiler The front edge of the left fuel tank spoiler is evenly aligned. -
Page 102: Installing The Right Fuel Tank Spoiler
13 SERVICE WORK ON THE CHASSIS Main work – Remove screw – Remove screws Z03255-10 – Remove the fuel tank spoiler from the rubber bushing in area – Pull the right fuel tank guard in area out of the bracket. –... -
Page 103: Removing The Front Fender
SERVICE WORK ON THE CHASSIS 13 – Mount screws , but do not tighten yet. Guideline Screw, trim 3 Nm (2.2 lbf ft) – Mount screw , but do not tighten it yet. Guideline Screw, fuel tank 5 Nm (3.7 lbf ft) spoiler The front edge of the right fuel tank spoiler is evenly aligned. -
Page 104: Cleaning The Dust Boots Of The Fork Legs
13 SERVICE WORK ON THE CHASSIS Guideline Screw, fender M5x17 5 Nm (3.7 lbf ft) The fender is directed evenly toward the front. – Tighten all the screws of the fender. Guideline Screw, fender M5x12 3 Nm (2.2 lbf ft) Screw, fender M5x17 5 Nm (3.7 lbf ft) -
Page 105: Removing The Windshield
SERVICE WORK ON THE CHASSIS 13 13.27 Removing the windshield – Remove screws – Remove screws and detach windshield in area Z03266-10 13.28 Installing the windshield – Hook windshield into area – Mount and tighten screws Guideline Remaining screws, 5 Nm (3.7 lbf ft) chassis –... -
Page 106: Installing The Engine Guard
13 SERVICE WORK ON THE CHASSIS – Remove screws Z03269-10 – Remove engine guard Guideline Pull the damping rubbers out of the cut-outs on both sides. Z03270-10 13.30 Installing the engine guard – Position the engine guard. Damping rubbers engage in cut-outs on both sides. -
Page 107: Removing The Main Silencer
SERVICE WORK ON THE CHASSIS 13 – Attach tube to the angle piece. Z03267-11 13.31 Removing the main silencer – Remove screw – Remove the clamp. R06157-10 – Remove screw with the washer. – Take off the main silencer. T04574-02 13.32 Installing the main silencer –... - Page 108 13 SERVICE WORK ON THE CHASSIS – Position the clamp. Guideline 1 mm (0.04 in) Distance Info The clamp must not touch the brake line when the rear wheel suspension compresses. – Mount and tighten screw Guideline Screw, presi- 8 Nm (5.9 lbf ft) lencer exhaust Copper paste clamp...
-
Page 109: Brake System 14
Do not make any changes to the suspension travel. – Only use spare parts on the brake system which have been approved and recommended by KTM. – Only use tires/wheels approved by KTM with the corre- sponding speed index. – Maintain the specified tire pressure. –... -
Page 110: Checking Brake Discs
Warning Danger of accidents Worn-out brake discs reduce the braking effect. – Make sure that worn-out brake discs are replaced immediately. (Your authorized KTM workshop will be glad to help.) – Check front and rear brake disc thickness at multiple points... -
Page 111: Checking The Front Brake Fluid Level
– Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized KTM workshop will be glad to help.) – Make sure that only clean, approved brake fluid from a tightly sealed container is used. (Your autho- rized KTM workshop will be glad to help.) -
Page 112: Checking That The Brake Linings Of The Front Brake Are Secured
14.5 Checking that the brake linings of the front brake are secured Warning Danger of accidents Worn-out brake linings reduce the braking effect. – Ensure that worn-out brake linings are replaced immediately. (Your authorized KTM workshop will be glad to help.) -
Page 113: Checking The Free Travel Of The Foot Brake Lever
If there is no free travel on the foot brake lever, pressure builds up in the brake system on the rear brake. – Set the free travel on the foot brake lever in accordance with the specification. – Ensure that the adjustment steps are performed properly. (Your authorized KTM workshop will be glad to help.) – Detach spring –... -
Page 114: Checking The Rear Brake Fluid Level
– Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized KTM workshop will be glad to help.) – Make sure that only clean, approved brake fluid from a tightly sealed container is used. (Your autho- rized KTM workshop will be glad to help.) -
Page 115: Checking That The Brake Linings Of The Rear Brake Are Secured
Checking that the brake linings of the rear brake are secured Warning Danger of accidents Worn-out brake linings reduce the braking effect. – Ensure that worn-out brake linings are replaced immediately. (Your authorized KTM workshop will be glad to help.) Warning Danger of accidents Damaged brake discs reduce the braking effect. - Page 116 14 BRAKE SYSTEM – Check the brake linings for minimum thickness ≥ 1 mm (≥ 0.04 in) Minimum thickness » If the minimum thickness is less than specified: – Change the rear brake linings. – Check the brake linings for damage and cracking. »...
-
Page 117: Wheels, Tires 15
WHEELS, TIRES 15 15.1 Removing the front wheel Preparatory work – Raise motorcycle with rear lifting gear. ( p. 87) – Lift the motorcycle with the front lifting gear. ( p. 87) Main work – Remove screw and pull wheel speed sensor out of the hole. -
Page 118: Installing The Front Wheel
15 WHEELS, TIRES 15.2 Installing the front wheel Warning Danger of accidents Oil or grease on the brake discs reduces the braking effect. – Always keep the brake discs free of oil and grease. – Clean the brake discs with brake cleaner when necessary. –... -
Page 119: Removing The Rear Wheel
WHEELS, TIRES 15 Temporarily tighten one of the axle clamp screws so that the axle does not rotate with it. Loosen the axle clamp screw again before compression to allow the fork legs to align. – Position both brake calipers. The brake linings are correctly positioned. -
Page 120: Installing The Rear Wheel
15 WHEELS, TIRES Main work – Manually press the brake caliper toward the brake disc to push back the brake piston. – Remove screw and pull wheel speed sensor out of the hole. – Remove nut . Take off chain adjuster –... - Page 121 WHEELS, TIRES 15 Warning Danger of accidents There is no braking effect to start with at the rear brake after installing the rear wheel. – Actuate the foot brake several times before going on a ride until you can feel a firm pressure point. Main work –...
-
Page 122: Checking The Rear Hub Damping Rubber Pieces
15 WHEELS, TIRES – Operate the foot brake lever repeatedly until the brake lin- ings are in contact with the brake disc and there is a pressure point. Finishing work – Check the chain tension. ( p. 91) – Remove the rear of the motorcycle from the lifting gear. p. -
Page 123: Checking The Tire Condition
Warning Danger of accidents If a tire bursts while riding, the vehicle becomes uncontrollable. – Ensure that damaged or worn tires are replaced immediately. (Your authorized KTM workshop will be glad to help.) Warning Danger of crashing Different tire tread patterns on the front and rear wheel impair the handling charac- teristic. -
Page 124: Checking Tire Pressure
Other spokes will become looser as a result. – Check spoke tension regularly, and in particular on a new vehicle. (Your authorized KTM workshop will be glad to help.) -
Page 125: Tubeless Tire System
The rigid rim design results in a spoke wheel that is almost entirely maintenance-free. KTM recommends that the rim seal band be changed after 5 years at the latest, regardless of the actual state of wear. F01999-10 15.10... - Page 126 15 WHEELS, TIRES Note Material damage Tire repair spray damages the tire pressure sen- sor. – Note that after using tire repair spray, the tire pressure sensor may need to be replaced.
-
Page 127: Electrical System 16
Make sure that the daytime running light is deacti- vated with the diagnostics tool when the menu item is not available, but the low beam is required. (Your authorized KTM workshop will be glad to help.) – Note the legal regulations regarding the daytime run- ning light. - Page 128 16 ELECTRICAL SYSTEM Caution Danger of accidents Electronic components and safety devices will be damaged if the 12-V battery is dis- charged or missing. If the 12-V battery is discharged or defective, malfunctions in the vehicle electronics can occur, espe- cially when starting. –...
-
Page 129: Installing The 12-V Battery
ELECTRICAL SYSTEM 16 16.3 Installing the 12-V battery Warning Risk of injury Battery acid and battery gases cause serious chemical burns. – Keep 12 V batteries out of the reach of children. – Wear suitable protective clothing and safety glasses. – Avoid contact with battery acid and battery gases. -
Page 130: Charging The 12-V Battery
16 ELECTRICAL SYSTEM – Hang battery mounting bracket to the left and right in the holding lugs and push downward at the back. – Mount and tighten screw Guideline Screw, battery sup- 4.5 Nm port bracket (3.32 lbf ft) – Position the diagnostics connector in the holder. - Page 131 ELECTRICAL SYSTEM 16 Info Even when there is no load on the 12-V battery, it discharges steadily each day. The charging level and the method of charging are very important for the service life of the 12-V battery. Rapid recharging with a high charging current shortens the service life of the battery. If the charging current, charging voltage, or charging time is exceeded, electrolyte escapes through the safety valves.
-
Page 132: Changing The Main Fuse
16 ELECTRICAL SYSTEM – Mount positive terminal cover – Connect negative cable to the 12 V battery. Guideline Screw, battery termi- 4.5 Nm (3.32 lbf ft) F03300-10 Finishing work – Install the battery cover. ( p. 97) – Mount the front rider's seat. ( p. -
Page 133: Changing The Abs Fuses
ELECTRICAL SYSTEM 16 Insert a new spare fuse into the starter relay to have it available when needed. – Mount protection cap F01989-10 Finishing work – Mount the front rider's seat. ( p. 89) – Mount the passenger seat. ( p. -
Page 134: Changing The Fuses Of Individual Electrical Power Consumers
16 ELECTRICAL SYSTEM To change the fuse of the ABS return pump: – Remove the protection cap and fuse Info A faulty fuse has a burned-out fuse wire – Insert the spare fuse with the correct rating. Fuse (75011088025) ( p. -
Page 135: Checking The Headlight Setting
ELECTRICAL SYSTEM 16 – Remove the faulty fuse. Guideline Fuse 1 - 10 A - ignition, alarm system (optional) Fuse 2 - 10 A - ignition, engine control unit, electronic fuel injection, fuel vapor retention system, lambda sensor, immo- bilizer Fuse 3 - 10 A - fuel pump Fuse 4 - 15 A - radiator fan Fuse 5 - 10 A - horn, combination instrument, brake light... -
Page 136: Adjusting The Headlight Range
16 ELECTRICAL SYSTEM – The rider now mounts the motorcycle with luggage and passen- ger if applicable. – Check the headlight setting. The light-dark boundary must be exactly on the lower mark- ing when the motorcycle is ready to be operated with the rider mounted along with any luggage and a passenger if applicable. -
Page 137: Front Acc1 And Acc2
ELECTRICAL SYSTEM 16 16.11 Front ACC1 and ACC2 Installation location – The front power supplies ACC1 and ACC2 are located in the right mask support. Info The front power supplies ACC1 and ACC2 can be accessed behind the cover of the right mask support. I00285-10 16.12 ACC1 and ACC2 rear... -
Page 138: Cooling System
17 COOLING SYSTEM 17.1 Cooling system Water pump in the engine ensures forced circulation of the coolant. The pressure resulting from the warming of the cooling system is regulated by a valve in radiator cap . Heat expansion causes excess coolant to flow into compensating tank . -
Page 139: Correcting The Coolant Level In The Compensating Tank
COOLING SYSTEM 17 – Check the coolant level in the compensating tank. The coolant level must be between MIN and MAX. » If there is no coolant in the compensating tank: – Check the cooling system for leaks. Info Do not start up the motorcycle! –... - Page 140 17 COOLING SYSTEM – Add coolant until the coolant reaches the specified level. Guideline The coolant level must be between MIN and MAX. Coolant ( p. 162) – Mount the cover of the compensating tank. Z03272-10...
-
Page 141: Tuning The Engine 18
TUNING THE ENGINE 18 18.1 Ride Mode Possible states Street – Homologated performance with balanced response; • the motorcycle traction control allows normal slip on the rear wheel. Rain – Reduced homologated performance for better ridabil- • ity; the motorcycle traction control allows less slip on the rear wheel. -
Page 142: Slip Adjustment (Optional)
18 TUNING THE ENGINE 18.3 Slip adjustment (optional) The spin adjuster is a motorcycle traction control function. The slip adjustment allows the motorcycle traction control to be tuned through nine levels to the desired characteristic map. Level 1 allows the maximum slip on the rear wheel, and level 9 the minimum. -
Page 143: Service Work On The Engine 19
SERVICE WORK ON THE ENGINE 19 19.1 Checking the engine oil level Info The engine oil level must be checked at normal engine operating temperature. – Stand motorcycle upright on a horizontal surface. – Check the engine oil level. Info After switching off the engine, wait one minute before checking the level. - Page 144 19 SERVICE WORK ON THE ENGINE – Remove oil drain plugs along with the magnets, the O- rings, and the oil screens. F01974-10 – Remove screws . Take off oil filter cover with the O- ring. – Pull oil filter out of the oil filter housing.
-
Page 145: Adding Engine Oil
Engine oil (SAE 10W/50) ( p. 162) Info In order to achieve optimal engine oil performance, it is not advisable to mix different engine oils. KTM recommends changing the engine oil where neces- H01066-10 sary. – Mount and tighten filler plug with the O-ring. -
Page 146: Checking The Free Travel Of The Clutch Lever
19 SERVICE WORK ON THE ENGINE 19.4 Checking the free travel of the clutch lever Note Clutch damage If there is no free travel by the clutch lever, the clutch will begin to slip. – Check the free travel of the clutch lever each time before using the motorcycle. –... -
Page 147: Cleaning, Care 20
CLEANING, CARE 20 20.1 Cleaning the motorcycle Note Material damage Components become damaged or destroyed if a pressure cleaner is used incorrectly. The high pressure forces water into the electrical components, connectors, throttle cables, and bearings, etc. Pressure which is too high causes malfunctions and destroys components. –... -
Page 148: Checks And Maintenance Steps For Winter Operation
20 CLEANING, CARE – After the motorcycle has cooled down, lubricate all moving parts and pivot points. – Clean the chain. ( p. 90) – Treat bare metal (except for brake discs and the exhaust sys- tem) with a corrosion inhibitor. Preserving materials for paints, metal and rubber p. -
Page 149: Storage 21
STORAGE 21 21.1 Storage Info If you plan to garage the motorcycle for a longer period, perform the following steps or have them per- formed. Before storing the motorcycle, check all parts for function and wear. If service, repairs, or replacements are necessary, you should do this during the storage period (less workshop overload). -
Page 150: Preparing For Use After Storage
21 STORAGE 21.2 Preparing for use after storage – Take the motorcycle off the front lifting gear. ( p. 88) – Remove the rear of the motorcycle from the lifting gear. p. 87) – Install the 12-V battery. p. 127) –... -
Page 151: Troubleshooting 22
KTM diagnostics tool. – N The idling speed indicator Gear position sensor not pro- Read out the trouble code memory lamp does not light up when grammed using the KTM diagnostics tool. the transmission is in neutral... - Page 152 Check the wheel speed sensor for dam- age. – Malfunction in ABS Read out the ABS fault memory using the KTM diagnostics tool. – High oil consumption Engine vent hose bent Route the vent hose without bends or change it if necessary.
-
Page 153: Technical Specifications 23
TECHNICAL SPECIFICATIONS 23 23.1 engine Design 2-cylinder 4-stroke in-line engine, water-cooled Displacement 799 cm³ (48.76 cu in) Stroke 65.7 mm (2.587 in) Bore 88 mm (3.46 in) Compression ratio 12.5:1 Control DOHC, 4 valves per cylinder controlled via cam lever, chain drive Valve diameter, intake 36 mm (1.42 in) -
Page 154: Engine Tightening Torques
23 TECHNICAL SPECIFICATIONS 23.2 Engine tightening torques EJOTALtracs Plus 60x14 Screw plug, water pump drain hole ® 8 Nm (5.9 lbf ft) Loctite ® 243™ Screw, bleeder flange EJOTALtracs ® M6x12 8 Nm (5.9 lbf ft) Loctite ® 243™ Hose clamp, intake flange 2.5 Nm (1.84 lbf ft) Engine vent nozzle 2 Nm (1.5 lbf ft) - Page 155 TECHNICAL SPECIFICATIONS 23 Screw, locking lever 10 Nm (7.4 lbf ft) Loctite ® 243™ Screw, main shaft bearing support 10 Nm (7.4 lbf ft) Loctite ® 243™ Screw, oil pan M6x30 10 Nm (7.4 lbf ft) Screw, oil pan M6x35 10 Nm (7.4 lbf ft) Screw, oil pump cover 10 Nm (7.4 lbf ft)
-
Page 156: Capacities
23 TECHNICAL SPECIFICATIONS Screw, oil pump idler gear 15 Nm (11.1 lbf ft) Loctite ® 243™ Screw, tensioning rail 15 Nm (11.1 lbf ft) Loctite ® 243™ Stud, exhaust flange 15 Nm (11.1 lbf ft) Loctite ® 243™ Spark plug 11 Nm (8.1 lbf ft) Oil pressure sensor M10x1... -
Page 157: Fuel
TECHNICAL SPECIFICATIONS 23 23.3.3 Fuel Please observe the labels on EU fuel pumps. A00420-10 Total fuel tank capacity, approx. 20 l (5.3 US gal) Super unleaded (ROZ 95) p. 163) Fuel reserve, approx. 3 l (3 qt.) 23.4 Chassis Frame Lattice frame made of chrome molybdenum steel tub- ing, powder-coated WP APEX 3043... -
Page 158: Electrical System
The tires specified represent one of the possible series production tires. For alternative manufacturers, if any, contact an authorized dealer or qualified tire dealership. If local road approval regulations apply, these and the respective technical specifications must be observed. Additional information is available in the Service section under: KTM.COM 23.7 Fork Fork article number 05.58.6S.29... -
Page 159: Shock Absorber
TECHNICAL SPECIFICATIONS 23 23.8 Shock absorber Shock absorber article number 01.58.4S.29 WP Suspension APEX 3146 Shock absorber Spring preload Standard 3 clicks Full payload 10 clicks Inbuilt length 364 mm (14.33 in) Spring length 200 mm (7.87 in) Spring rate Medium (standard) 115 N/mm (657 lb/in) Gas pressure... - Page 160 23 TECHNICAL SPECIFICATIONS Screw, license plate holder 5 Nm (3.7 lbf ft) Loctite ® 243™ Screw, lower rear panel 3 Nm (2.2 lbf ft) Screw, side stand sensor 2 Nm (1.5 lbf ft) Loctite ® 243™ Screw, trim 3 Nm (2.2 lbf ft) Battery cover attachment screw 5 Nm (3.7 lbf ft) Brake cylinder screw on the rear...
- Page 161 TECHNICAL SPECIFICATIONS 23 Screw, magnetic holder on side 2 Nm (1.5 lbf ft) stand Loctite ® 243™ Screw, manifold clamp 8 Nm (5.9 lbf ft) Copper paste Screw, radiator bracket, bottom 5 Nm (3.7 lbf ft) Screw, rear brake disc 14 Nm (10.3 lbf ft) Loctite ®...
- Page 162 23 TECHNICAL SPECIFICATIONS Screw, steering damper on holder 8 Nm (5.9 lbf ft) Loctite ® 243™ Screw, steering damper on triple 8 Nm (5.9 lbf ft) clamp Loctite ® 243™ Screw, steering stem 20 Nm (14.8 lbf ft) Loctite ® 243™...
-
Page 163: Declarations Of Conformity 24
The full text of the Declaration of Conformity is available at the following Internet address. Certification website: http://www.ktm.com/252m1100 KTM AG hereby declares that the Immo641 wireless system conforms with the relevant guidelines. The full text of the Declaration of Conformity is available at the following Internet address. -
Page 164: Substances
25 SUBSTANCES Brake fluid DOT 4 / DOT 5.1 Standard/classification – Guideline – Use only brake fluid that complies with the specified standard (see specifications on the container) and that exhibits the corresponding properties. Recommended supplier Castrol – REACT PERFORMANCE DOT 4 MOTOREX ®... - Page 165 SUBSTANCES 25 Fork oil (SAE 4) (48601166S1) Standard/classification – SAE ( p. 165) (SAE 4) Guideline – Use only oils that comply with the specified standards (see specifications on the container) and that exhibit the corresponding properties. Shock absorber fluid (SAE 2.5) (50180751S1) Standard/classification –...
-
Page 166: Auxiliary Substances
26 AUXILIARY SUBSTANCES Chain cleaner Recommended supplier MOTOREX ® – Chain Clean Fuel additive Recommended supplier MOTOREX ® – Fuel Stabilizer Long-life grease Recommended supplier MOTOREX ® – Bike Grease 2000 Motorcycle cleaner Recommended supplier MOTOREX ® – Moto Clean Preserving materials for paints, metal and rubber Recommended supplier MOTOREX... -
Page 167: Standards 27
STANDARDS 27 JASO T903 MA2 Different technical development directions required a separate specification for motorcycles – the JASO T903 MA2 standard. Earlier, engine oils from the automobile industry were used for motorcycles because there was no separate motor- cycle specification. Whereas long service intervals are demanded for automobile engines, the focus for motorcycle engines is on high performance at high engine speeds. -
Page 168: Index Of Special Terms
28 INDEX OF SPECIAL TERMS Anti-lock braking system Safety system that prevents locking of the wheels when driving straight ahead without the influence of lateral forces Daytime Running Light Light, which enhances the visibility of the vehicle dur- ing the day but is not focused, and in contrast to low beam does not illuminate the road surface ETTC Engine traction torque control... -
Page 169: List Of Abbreviations 29
LIST OF ABBREVIATIONS 29 Art. no. Article number circa compare e.g. for example etc. et cetera i.a. inter alia number poss. possibly... -
Page 170: List Of Symbols
139) is not enabled or is currently intervening. The TC indicator lamp also lights up if a malfunction is detected. Contact an authorized KTM workshop. The TC indicator lamp flashes, if MTC or MSR (optional) actively engage. The cruise control system indicator lamp (optional) lights up yellow – The cruise control sys- tem function is switched on, but cruise control is not activated. -
Page 171: Index
INDEX Chain INDEX checking ......92 checking for dirt ..... 90 12-V battery cleaning . - Page 172 INDEX passenger seat heating (optional) ..40 Engine Phone Pairing ..... . . 56 running in .
- Page 173 INDEX Oil screens cleaning ......141 Hand brake lever ..... . . 16 Owner's Manual .
- Page 174 INDEX Side cover, left Tire pressure installing ......95 checking ......122 removing .
- Page 175 *3214950en* 3214950en 11.10.2023 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KISKA/KTM KTM.COM...
Need help?
Do you have a question about the 790 ADVENTURE 2024 and is the answer not in the manual?
Questions and answers
