8. ADJUSTMENT
NOTE: It is recommended
that this
performed, when changing
to a finer grinding, with the
motor running, to prevent
coffee from
between the
blocking the grinder.
NOTE: If
throughput is very low, this
is because the coffee is
being ground very fine. If
the throughput is very high,
this is because the coffee is
being ground very coarse. A
perfect Espresso is produced
when the grinding gives an
infusion of 25 ml of coffee in
25 seconds using about 7 g of
ground coffee.
8.4. PREPARATION OF THE
PORTAFILTER DETECTOR (OPTIONAL)
1. Place the detector on the double portafilter
(Fig. 1).
2. Check that the detector ring tab is properly
closed (Fig. 2).
3. Make sure that the arrow is in the correct
position on the lower side (Fig. 3).
Fig. 1
14

operation

be
building up
burrs and
the coffee
Fig. 2 Fig. 3
K09657H02 | PROC-CAL/002/03 USER MANUAL | V. 11/07/2023
9.
9.1. MAIN SWITCH
The main switch (
positions: AUTOMATIC / OFF / MANUAL
or ON /OFF.
The equipment's
electronic functions
are activated
Equipment off
Equipment in manual
mode.
9.2. USAGE
Through the program menu (section 10.4.3),
it is possible to select three distinct functional
modes: PUSH, DETECTION and TOUCH.
9.3. PUSH MODE
In the PUSH mode, a pre-programmed single,
double or triple dose can be set by simple
pressing the corresponding icon on the TFT
screen ( ).
The preselection of a single, double or triple
dose will remain active until it is changed by
pressing one of the three numbered icons. This
preselection is reflected on the TFT screen
( ) with the icon of the active selection in the
secondary color, and the rest of the icons in the
main color.
Dispensing the preselected dose by pressing
the lower pulse button ( ) one time. When the
grinding cycle begins, a timer countdown will
begin on the TFT screen (
down the timed dose cycle to zero.
OPERATION
) has the following
E6-E8
E5
E10
I ON
O OFF
II
), which will count
