StarTech.com 132N-TB4USB4DOCK Quick Start Manual page 2

Package Contents
Thunderbolt 4/USB4 Docking Station x 1
•
3ft (1m) Thunderbolt 4 Host Cable x 1
•
Universal Power Adapter x 1
•
Quick-Start Guide x 1
•
Requirements
Computer
•
Thunderbolt 4
•
Thunderbolt 3 (Intel or M1 based Mac's)
•
USB-C Port With DP Alt Mode
•
This Dock can function with Thunderbolt 4, USB4 or USB-C host ports. For
•
maximum performance a Thunderbolt 4 or USB4 port is recommended.
Video support and performance, such as resolution and refresh rate, depend on
•
the host computer and the performance of the video card or USB4 port.
Notes:
DisplayPort Video Output ports do not support the use of passive DisplayPort
•
Adapters.
For the latest drivers, manuals, product information, technical specifications, and declarations of conformance,
please visit: www.StarTech.com/132N-TB4USB4DOCK
www.StarTech.com/132UE-TB4USB4DOCK
Installation
Connect the Power Adapter from an AC outlet, to the
1.
When connecting USB-A peripheral devices, connect a USB-A cable from the USB
2.
peripheral devices to the USB-A Data Ports and/or the USB-A Data/Charge Port on
the Dock.
Regulatory Compliance
FCC - Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modifications not expressly approved by StarTech.com could
void the user's authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
or
DC 20V Port on the dock.
When connecting USB-C peripheral devices, connect a USB-C cable from the USB
3.
peripheral devices to the USB-C Data Port on the Dock.
When connecting a wired network, connect an RJ-45 terminated network cable
4.
(CAT 5e or better) from the local area network (e.g. Router, Switch, Modem, etc.)
to the 2.5 Gigabit Ethernet Port on the Dock (CAT 6 or better recommended for
2.5Gb speeds).
Connect a DisplayPort monitor to the DisplayPort Port (Group A) on the dock
5.
using a DisplayPort cable (sold separately).
Connect an HDMI monitor to the HDMI Port (Group A) on the dock using an
6.
HDMI cable (sold separately).
Connect a DisplayPort monitor to the DisplayPort Port (Group B) on the dock
7.
using a DisplayPort cable (sold separately).
Connect an HDMI monitor to the HDMI Port (Group B) on the dock using an
8.
HDMI cable (sold separately).
Connect the included Thunderbolt 4 Host Cable from a Thunderbolt 4 Port
9.
on the Host Computer, to the Thunderbolt 4 Host Port on the Dock. The Host
Computer will automatically detect and install the Dock.
Insert a memory card into the microSD Card Reader on the Dock. The Dock will
10.
recognize the card and mount it as a drive. To remove the memory card, push the
card in and then pull the memory card out.
Insert a memory card into the SD Card Reader on the Dock. The Host Computer
11.
will recognize the card and mount it as a drive. To remove the memory card, pull
the memory card out.
Note: To protect the memory card and the data stored on it, it's important to
safely unmount (eject) the card within the Host Computer operating system,
before physically removing the card from the Dock.
Warranty Information
This product is backed by a three-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss
of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the
product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the
limitations or exclusions contained in this statement may not apply to you.
StarTech.com Ltd.
StarTech.com StarTech.com LLP
Ltd.
4490 South Hamilton Unit B, Pinnacle 15
Gowerton Rd,
45 Artisans Cres Road
Brackmills
London, Ontario Groveport, Ohio
N5V 5E9 43125 Northampton
NN4 7BW
Canada U.S.A.
United Kingdom
StarTech.com Ltd. FR: startech.com/fr
Siriusdreef 17-27 DE: startech.com/de
2132 WT Hoofddorp ES: startech.com/es
The Netherlands NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
