Part number PF5010
Jeep Grand Cherokee WK
2005-2010 3.7L V6
1- MR Tech Power-Flow intake
1- Web Nano/fiber dry filter
1- Elbow hose
1- Rubber grommet
2- Power-band (.048)
1- Vibra mount M6
1- Fender washer M6
1- Nut M6
1- 15mm hose @ 16"L
1- Heat shield
3- Heat shield clamps
3- 1/2 hex bolts
1- 4 page installation instructions.
Note: The C.A.R.B. Exempt sticker must be attached under
the hood in a manner such that it is easily viewed by an emis-
sions inspector.
Note: The installation of this cold air intake does require mechanical skills. Removal of the front bumper requires
loosening and removing several plastic plugs and screws that may be difficult. In addition to removing the
bumper, you will also have to remove the air resonator box, battery and tray when beginning this installation.
Injen strongly recommends that this system be installed by a professional mechanic.
MR
(SR)
Congratulations! You have just purchased the best engineered,
(#1021)
dyno-proven cold air intake system available.
(#3013)
(#8002)
Report any defective or missing parts to the Authorized Injen
(#4004)
Technology dealer you purchased this product from.
(#6020)
Before installing any parts of this system, please read the instructions
(#6010)
thoroughly. If you have any questions regarding installation please
(#6002)
contact the dealer you purchased this product from.
(#3079)
Installation DOES require some mechanical skills. A qualified
(#1970)
mechanic is always recommended.
(#4010)
*Do not attempt to install the intake system while the engine is hot.
(#6019)
The installation may require removal of radiator fluid line that may
be hot.
Injen Technology offers a limited lifetime warranty to the original
purchaser against defects in materials and workmanship. Warranty
claims must be handled through the dealer from which the item was
purchased.
Injen Technology 244 Pioneer Place Pomona, CA 91768 USA
Note: This intake system was Dyno-tested with an Injen filter and
Technology, "The World's First Tuned Intake System!"
Optimum performance, Factory safe air/fuel ratio.
Please check the contents of this box immediately.
Please check the contents of this box immediately.
Injen parts. The use of any other filter or part will void the
warranty and CARB exemption number.
Parts and accessories are available on line at "Injenonline.com"
Advertisement
Table of Contents
Related Manuals for injen technology PF5010
Summary of Contents for injen technology PF5010
- Page 1 The installation may require removal of radiator fluid line that may 1- 4 page installation instructions. be hot. Injen Technology offers a limited lifetime warranty to the original purchaser against defects in materials and workmanship. Warranty claims must be handled through the dealer from which the item was Note: The C.A.R.B.
- Page 2 Figure 12 Figure 11 Lift up the bottom half of the air box and remove from vehicle. A) Carefully pull the crank case line away from the engine. B) Remove crank case from engine. Page 2 of Part # PF5010...
- Page 3 Figure 19 Connect the temperature sensor harness. Position the intake tube to the elbow hose and brack- Install the new provided 15mm hose to the fitting on et to the vibra mount. engine side. Page 3 of Part # PF5010...
- Page 4 5. Check the filter for excessive dirt build up. Clean or replace the filter with an original Injen filter (can be bought on-line at “injenonline.com”). Congratulations! You have just completed the installation of the best intake system sold on the market. Enjoy the added power and performance of your new intake system. Page 5 of Part # PF5010...
