Installation Instructions
Year
2016-2018
2012-2015
2014-2016
2014-2016
2015-2016
2013-2016
2014-2016
2015-2016
Make
BMW
BMW
BMW
BMW
BMW
435i Gran Coupe/xDrive
BMW
BMW
BMW
Model
M2
335i/xDrive
335i GT/xDrive
435i/xDrive
M135i
M235i
M235i/xDrive
Part Number: EVO1107
Engine
L6-3.0L(t) F87
L6-3.0L(t) F30/31
L6-3.0L(t) F34
L6-3.0L(t) F32/F33
L6-3.0L(t) F36
L6-3.0L(t) F20
L6-3.0L(t) F22
L6-3.0L(t) F22/23

Advertisement

loading
Need help?

Need help?

Do you have a question about the EVO1107 and is the answer not in the manual?

Questions and answers

Related Manuals for injen technology EVO1107

Summary of Contents for injen technology EVO1107

  • Page 1 Installation Instructions Part Number: EVO1107 Year Make Model Engine 2016-2018 L6-3.0L(t) F87 2012-2015 335i/xDrive L6-3.0L(t) F30/31 2014-2016 335i GT/xDrive L6-3.0L(t) F34 2014-2016 435i/xDrive L6-3.0L(t) F32/F33 2015-2016 435i Gran Coupe/xDrive L6-3.0L(t) F36 2013-2016 M135i L6-3.0L(t) F20 2014-2016 M235i L6-3.0L(t) F22 2015-2016 M235i/xDrive L6-3.0L(t) F22/23...

  • Page 2: Parts Included

    PARTS INCLUDED ITEM PART NO. DESCRIPTION X-15202 AIR BOX X-15203 TUBE X-15139 SMALL CLEAR WINDOW X-6109 PUSH-ON RETAINING RINGS X-14066 5/8-18 CRANKCASE FITTING X-6047 M4X 0.7 X 10MM BUTTON HEAD SCREW X-1134-BB TWIST LOCK FILTER X-6110 3/4" VINYL CAP RECOMMENDED TOOLS Ratcheting Wrench 8mm Nut Driver Needle Nose Pliers...
  • Page 3 Injen intake systems excluding the filter element. Any and all warranty coverage is limited to the repair or replacement of the defective part only, at Injen Technology’s discretion. The warranty does not cover incidental or consequential damages, nor does it cover the cost of installation or removal of the defective part or its replacement.
  • Page 4 OEM intake. Disconnect the MAF harness. Loosen the clamp holding the OEM tube. IF EQUIPPED: Disconnect the crank case line. 4. IF EQUIPPED: 5. IF EQUIPPED: Remove the strut Remove the OEM intake assembly. Remove the four bolts holding the strut tower brace. tower brace.
  • Page 5 Note: Check clearance and adjust if needed! Failure to check the alignment and adjust the intake can cause damage that will void the warranty. Injen Technology is not responsible for any damages caused by/from improper installation.
