injen technology SP3028 Quick Start Manual

Part number SP3028
Volkswagen
2010-12 Golf 2.5L 5 Cyl.
2011-12 Jetta 2.5L 5 Cyl.
(Manual Transmission Only)
1- Short ram intake sytem
1- Heat Shield
1- 3" Dry Air Filter
1- 3.00" straight hose
2- medium clamps (.362) .048
1- M6 vibra mount
2- Fender washer
2- M6 nut
1- M6 allen stainless screw
1- Vinyl trim @ 11-1/2" L
1- Rubber trim @ 17-1/2" L
Note: The installation of this cold air intake does require mechanical skills. Removal of the front bumper requires
loosening and removing several plastic plugs and screws that may be difficult. It is recommended that this
system be installed by a professional mechanic. Be sure to disconnect the negative terminal before proceeding.
Congratulations! You have just purchased the worlds first tuned intake system.
Figure 1
Buy products from authorized and licensed manufacturers using any of our
patented processes, beware of cheap knock-offs, look for our licensing logo.
1- Calibration Method for Air Intake Tracts for Internal Combustion Engines.
2- Calibration Device for Air Intake Tracts for Internal Combustion Engines.
3- Calibration Method and Device for Air Intake Tracts having Air Fusion
4- Tuning Method and Device for intake tracts having built-in
Air Filter Horns
Injen is the first and only intake manufacturer that tunes and controls air/fuel
ratios, short/long term fuel trim levels using the MR step down process, Air
Fusion and built-in air intake horns.
Congratulations! You have just purchased the best engineered,
dyno-proven Power-Flow air intake system available.
(X-11083)
(#1014)
Report any defective or missing parts to the Authorized Injen
(#3044)
Technology dealer you purchased this product from.
(#4004)
Before installing any parts of this system, please read the instructions
(#6020)
thoroughly. If you have any questions regarding installation please
(#6010)
contact the dealer you purchased this product from.
(#6002)
Installation DOES require some mechanical skills. A qualified
(#6083)
mechanic is always recommended.
(#6023)
*Do not attempt to install the intake system while the engine is hot.
The installation may require removal of radiator fluid line that may
(#6058)
be hot.
Injen Technology offers a limited lifetime warranty to the original
purchaser against defects in materials and workmanship. Warranty
claims must be handled through the dealer from which the item was
purchased.
Injen Technology 244 Pioneer Place Pomona, CA 91768 USA
Note: This intake system was Dyno-tested with an Injen filter and
Injen parts the use of any other filter or part will void the
warranty and CARB exemption number.
Parts and accessories are available on line at "Injenonline.com
M.R. Technology, Leading the way
MR Technology Step down process:
Please check the contents of this box immediately.
Please check the contents of this box immediately.
Patent# 7,359,795
Figure 2
Patent# 7,359,795
Published and patent pending
Published and patent pending
patent pending
