injen technology SP2115 Quick Start Manual

Part number SP2115
2009-10 Scion tC 2.4L 4 cyl.
1- Two piece cold air intake
1- 3" Injen/AMSOIL
Ea nano-fiber dry filter
1- 2.50" straight hose
1- 3.00" straight hose
1- 14" vinyl trim
2- 6mm vibra-mounts (#6020)
2- .312
Power-bands
2- .362
Power-bands
2- 6mm flange nuts
2- fender washers
1- 4 page instruction
Note:
Sold separetly:
Hydro-shield used X-1033
Note: The installation of this cold air intake does require mechanical skills. Removal of the front bumper requires
loosening and removing several plastic plugs and screws that may be difficult. In addition to removing the
bumper, you will also have to remove the air resonator box, battery and tray when beginning this installation.
Injen strongly recommends that this system be installed by a professional mechanic.
Figure 1
Buy products from authorized and licensed manufacturers using any of our
patented processes, beware of cheap knock-offs, look for our licensing logo.
1- Calibration Method for Air Intake Tracts for Internal Combustion Engines.
2- Calibration Device for Air Intake Tracts for Internal Combustion Engines.
3- Calibration Method and Device for Air Intake Tracts having Air Fusion
4- Tuning Method and Device for intake tracts having built-in
Air Filter Horns
Congratulations! You have just purchased the best engineered,
dyno-proven cold air intake system available.
(#1017)
Report any defective or missing parts to the Authorized Injen
(#3048)
Technology dealer you purchased this product from.
Before installing any parts of this system, please read the instructions
(#3044)
thoroughly. If you have any questions regarding installation please
(#6023)
contact the dealer you purchased this product from.
Installation DOES require some mechanical skills. A qualified
(#4003)
.040
mechanic is always recommended.
(#4004)
.048 *Do not attempt to install the intake system while the engine is hot.
The installation may require removal of radiator fluid line that may
(#6002)
be hot.
(#6010)
Injen Technology offers a limited lifetime warranty to the original
purchaser against defects in materials and workmanship. Warranty
claims must be handled through the dealer from which the item was
purchased.
Injen Technology 285 Pioneer Place Pomona, CA 91768 USA
Note: This intake system was Dyno-tested with an Injen filter and
Parts and accessories are available on line at "Injenonline.com
"The World's First Tuned Intake System!"
MR Technology Step down process:
Please check the contents of this box immediately.
Injen parts the use of any other filter or part will void the
warranty and CARB exemption number.
Figure 2
,
Patent# 7,359,795
Published and patent pending
Published and patent pending
patent pending
