Part number RD1482
04-08 Acura TL 3.2L V6
07-08 Acura TL Type-S 3.5L V6
03-07 Honda Accord 3.0L V6
1- Injen cold air intake
1- 3.50" Injen filter
1- 2.75"X3" molded step hose(#3011)
1- Power-Band (.362)
1- Power-Band (.312)
1- 14" 10mm vacuum hose
1- m6 vibra-mount
1- m6 flange nut
1- Fender washer
1- 1/4" plastic coupler
1- Instruction
This intake system was specifically
Note:
designed and tested with this
size filter element.
F
i
g
u
r
e
1
F
i
g
u
r
e
1
(CA)
(#1015)
(#4004)
(.048)
(#4003)
(.040)
(#3077)
(#6020)
(#6002)
(#6010)
(#8008)
Now available, Hydro Shield by Injen
Part Number X-1034
Hydro Shield Sold Separately
Advertisement
Related Manuals for injen technology RD1482
Summary of Contents for injen technology RD1482
- Page 1 Part number RD1482 04-08 Acura TL 3.2L V6 07-08 Acura TL Type-S 3.5L V6 03-07 Honda Accord 3.0L V6 1- Injen cold air intake (CA) 1- 3.50” Injen filter (#1015) 1- 2.75”X3” molded step hose(#3011) 1- Power-Band (.362) (#4004) (.048) 1- Power-Band (.312)
- Page 2 Remove the PCV pipe Remove the PCV pipe from the vacuum hose from the vacuum hose and coolant line. and coolant line. The smaller line The smaller line >>>>>> >>>>>> connects the connects the coolant lines. coolant lines. 1/4” coupler >>> 1/4”...
- Page 3 Connect one end of the Connect one end of the 14” 10mm hose over 14” 10mm hose over >>>>>> >>>>>> the valve cover port the valve cover port and the other end over and the other end over the 1/2” nipple on the the 1/2”...
- Page 4 Note: Please disconnect the negative battery terminal before starting this installation. 1. Remove the stock intake box and intake duct leading to the throttle body unplug the vacuum hose from the intake duct. This installation will require the removal of the front bumper in order to place the filter in the bumper section.
