modway MOD-5237 Manual page 2

MOD-5237
STEP 1 :
Place SIDERAILS(3) and FOOTBOARD(2) on a carpeted or padded area as shown. Attach FOOTBOARD(2) with SIDERAILS(3)
Place
together. Then inserting JCBC BOLT M6 x 25mm(D) and FLAT WASHER
Place
C x 1
D x 4
Hardware & Tool required
STEP 2 :
1. Attach BED LEG(8) with SIDE RAIL(3) by inserting JCBC BOLT M6 x 70MM(F).
REMARK: DON'T FULLY TIGHTEN
8
F x 4
C x 1
Hardware & Tool required
Customer Service 908-368-1025 www.modwayfurniture.com
C
3
G x 4
THE SCREWS BEFORE
HEADBOARD IS INSERTED
3
1
'' (G).Tighten with M4 Allen Key(Ball Shape)Long(C).
4
4x
G
D
2
4x
F
C
2
Page 2/5
