Thank you for purchasing the MODWAY HEADBOARD！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step -by -step
instructions.
2.Owing to the size and weight of the headboard, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Appro ximately assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked a ll the components and
hardware and the furniture is fully assembled. Please ensur e that the packaging is disposed of in a safe and
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all fitting out of reach of children.
Component:
1
Headboard
Customer Service 908-368-1025︱www.modwayfurniture.com
TIWN HEADBOARD
2
x1
Hardware:
A
B
C
1
2
2
Bolt M6x20mm
Arc Washer M6
Allen Wrench M5
Low Post
x2
Page 1 of 6
x4
x4
x1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for modway MOD-5538
Summary of Contents for modway MOD-5538
- Page 1 MOD-5538 TIWN HEADBOARD Thank you for purchasing the MODWAY HEADBOARD！ Before you start, here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step -by -step instructions. 2.Owing to the size and weight of the headboard, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 2 MOD-5538 TIWN HEADBOARD STEP 1: Insert Low Post (2) into Headboard (1) as shown. Attach by using Arc Washer (B) and Bolt (A) from the holes on the back of Low Post (2) and Headboard (1). Use Allen Wrench (C) to tighten Bolts (A) clockwise until secure at this step.
- Page 3 MODWAY CONNECTING HEADBOARD TO BED FRAME ASSEMBLY INSTRUCTIONS OPTION 1 Hardware: OPTION 1 Bolt M6x45mm Bolt M6x65mm Arc Washer M6 Spring Washer M6 Hex Nut M6 Allen Wrench M4 Component: OPTION 1 Bed Frame Headboard Customer Service 908-368-1025︱www.modwayfurniture.com Page 3 of 6...
- Page 4 MODWAY CONNECTING HEADBOARD TO BED FRAME Note: Extra hardware were provided for attaching the headboard to you r Bed Frame (use is optional). STEP 1: Line up the Bed Frame (2) board’s pre-drilled holes to mat ch those of the Headboard (1) .
- Page 5 MODWAY CONNECTING HEADBOARD TO BED FRAME ASSEMBLY INSTRUCTIONS OPTION 2 Note: This is assembly instruction fo r Headboard connect to MODWAY Bed Frame MOD-5347/5348/5349/ 5350/5351/5352/5353/5354/5357/5358/5359/5360/5361/5362/5363/5364. Hardware: OPTION 2 Bolt M6x45mm Bolt M6x65mm Arc Washer M6 Spring Washer M6 Allen Wrench M4...
- Page 6 MODWAY CONNECTING HEADBOARD TO BED FRAME STEP 1: Line up the Bed Fame (2) board’s pre-drilled holes to mat c h those of the Headboard (1). Secure the Headboard (1) to the Bed Frame (2) by using 2 pieces of Bolt (B) with 2 pieces of Spring Washer (D), 2 pieces of Washer (C) for the thicker Bed Frame (2), and 2 pieces of Bolt (A) with 2 pieces of Spring Washer (D), 2 pieces of Washer (C) for the thinner Bed Frame (2).
