MOD-5243
Thank you for purchasing the MODWAY MIRROR !
Before you start,here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the mirror, we recommed that it is assembled by two adults,on a carpeted or
padded area, in the room that it is intended for.Approx assembly time:30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled.Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten.Depending on use, it may be necessary to tighten
the components from time to time,so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
Component :
Customer Service 908-368-1025 www.modway.com
1- DRESSER
2- MIRROR
3- SUPPORT RAIL
Hardware for Support Rail on
MIRROR
A
Hardware for Support Rail on
Dresser
B
3
M4 x 32MM WOOD SCREW
M4 x 32MM WOOD SCREW
2
1
x6
x4
Page 1/3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for modway Tracy MOD-5243
Summary of Contents for modway Tracy MOD-5243
- Page 1 MOD-5243 Thank you for purchasing the MODWAY MIRROR ! Before you start,here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. 2.Owing to the size and weight of the mirror, we recommed that it is assembled by two adults,on a carpeted or padded area, in the room that it is intended for.Approx assembly time:30 minutes.
- Page 2 STEP 2 : 1. Attach Support Rails(5) and Mirror(4) with Dresser(3) together. Then, insert M5 x 32mm Wood Screw (D) through the Support Rails(5).Tighten with Screw Driver. B x 4 Hardware & Tool required Page 2/3 Customer Service 908-368-1025 www.modway.com...
- Page 3 MOD-5243 STEP 3 : Place Place Assembly is completed. The Dresser(with mirror support) is ready to enjoy now ! Page 3/3 Customer Service 908-368-1025 www.modway.com...
