MOD-5535/5536/5537
Thank you for purchasing the MOD-5535/5536/5537 HEADBOARD！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the headboard, we recommend that it is assembled by two adults, on a carpeted
or padded area, in the room that it is intended for. Approx assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
Component:
1
Headboard
(Style may vary)
Customer Service 908-368-1025︱www.modwayfurniture.com
HEADBOARD
Hardware:
2
x1
A
B
Arc Washer M6
C
1
2
2
Low Post
Bolt M6x20mm
Allen Wrench M5
x2
Page 1 of 6
x4
x4
x1
