MOD-5244 / MOD-5238
Thank you for purchasing the MODWAY BED !
Before you start,here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed, we recommed that it is assembled by two adults,on a carpeted or
padded area, in the room that it is intended for.Approx assembly time:30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components
and hardware and the furniture is fully assembled.Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten.Depending on use, it may be necessary to tighten
the components from time to time,so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
Component :
1- HEADBOARD
2- LEGS
Customer Service 908-368-1025 www.modwayfurniture.com
3- MATTRESS PANEL
4- WOODEN SUPPORT
Hardware for Headboard
A
JCBC SCREW M6 X 40MM
B
FLAT WASHER 1/4''
C
SPRING WASHER 1/4''
M4 ALLEN KEY (BALL SHAPE)LONG
D
E
BOLT BASE GLIDE M6 x 23(C83)
Hardware for Bed Frame and Legs
F
JCBC SCREW M6 X 35MM
G
JCBC SCREW M6 X 40MM
H
SPRING WASHER 1/4''
FLAT WASHER 1/4''
I
J
WOOD DOWEL DIA 8 x 30MM
1
4
x12
x12
x12
x1
x2
x2
x12
x14
x14
x2
3
2
Page 1/3
