Summary of Contents for NCR 7370-K402
- Page 1 Kit Instructions PIN Pad Mount (Ingenico ISC250) 7370-K402 Issue A...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Software screen images are representative, and in some cases, may not match a customer’s installed software exactly.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Jul 2022 First Issue... -
Page 4: Kit Contents
7370-K402 PIN Pad Mount (Ingenico ISC250) This publication provides procedures for installing a PIN Pad Mount for an Ingenico ISC250 device on the NCR FastLane SelfServ™ Checkout (7370) unit. Note: The Ingenico ISC250 PIN Pad is supplied by the customer. Kit Contents... -
Page 5: Installation Procedure
4. Route the PIN Pad Cable. For more information, refer to Routing the PIN Pad Cable page 9. Note: The Ingenico ISC250 PIN Pad is not included in the 7370-K402 PIN Pad Kit. For more information, contact an NCR Customer Service Representative. - Page 6 7370-K402 PIN Pad Mount (Ingenico ISC250) Removing the PIN Pad To remove the PIN Pad, follow these steps: 1. Disconnect the PIN Pad Power Cable. 2. Using a security hex key, remove one (1) M4x10 button head hex screw from the...
- Page 7 7370-K402 PIN Pad Mount (Ingenico ISC250) 3. Slide the PIN Pad away from the three (3) hooks on the PIN Pad Mount.
- Page 8 7370-K402 PIN Pad Mount (Ingenico ISC250) Removing the PIN Pad Mount To remove the PIN Pad Mount, follow these steps: 1. Remove the PIN Pad. For more information, refer to Removing the PIN Pad on page 3. 2. Using a security hex key, remove one (1) M4x6 button head hex screw to detach the...
- Page 9 7370-K402 PIN Pad Mount (Ingenico ISC250) 3. Slide the PIN Pad Mount out of the slots on the PIN Pad Arm.
- Page 10 7370-K402 PIN Pad Mount (Ingenico ISC250) Installing the PIN Pad Mount To install the PIN Pad Mount, follow these steps: 1. Slide the PIN Pad Mount into the slots on the PIN Pad Arm, as shown in the image below.
- Page 11 7370-K402 PIN Pad Mount (Ingenico ISC250) Installing the PIN Pad To install the PIN Pad, follow these steps: 1. Install the PIN Pad Mount. For more information, refer to Installing the PIN Pad Mount on the previous page. 2. Slide the PIN Pad onto three (3) hooks on the PIN Pad Mount.
- Page 12 7370-K402 PIN Pad Mount (Ingenico ISC250) Routing the PIN Pad Cable To route the PIN Pad Cable into the SelfServ Checkout unit, follow these steps: 1. Do the following: a. Connect the cable to the PIN Pad. b. Secure the cable to the PIN Pad Arm using cable ties.
- Page 13 7370-K402 PIN Pad Mount (Ingenico ISC250) 2. From the Tower Cabinet cable access hole, do the following: a. Route the cable along the wall of the Tower Cabinet. b. Secure the cable using cable ties. c. Pass the cable through the cable access hole at the rear of the Scanner Bucket, as shown in the example below.
- Page 14 7370-K402 PIN Pad Mount (Ingenico ISC250) 3. From the Tower Cabinet, do the following: a. Route the cable down the Pedestal Cabinet. b. Connect the PIN Pad cable to the R6 I/O Box (USB H). Note: Keep the PIN Pad Cable (and other communications cables) away from and...
