- Page 1 Labrador 160 Safety is our concern! Part No. 175 3652 GB-2/06.02 LEMKEN GmbH & Co. KG Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220 eMail: lemken@lemken.com, Internet: http://www.lemken.com...
- Page 3 Only use genuine Lemken spare-parts. Spurious parts negatively influence the function of the implement, show a shorter lifetime and increase in nearly all cases additional maintenance. We trust that you will understand that LEMKEN is unable to guarantee poor operation and damage caused by using spurious parts!
-
Page 4: Table Of Contents
Under „defined use“ the manufacturer’s prescribed operation-, maintenance- and repair conditions are to be adhered to! • The LEMKEN Labrador may only be operated, maintained and repaired by such persons who have been made acquainted with it and who have been advised about the dangers! •... - Page 5 6 SHEARBOLT DEVICE ....................11 7 SHARES AND LEG PROTECTION ................11 8 TYRES ........................12 9 TRANSPORT ON PUBLIC ROADS ................12 TECHNICAL DATA....................12 NOTES........................13 NOISE, AIRBORNE SOUND .................. 13 PRODUCT REGISTRATION / GUARANTEE............13...
-
Page 6: Safety Instructions
1 SAFETY INSTRUCTIONS General Safety Instructions • Before using the machine, always check both it and the tractor for roadworthiness and operational safety! • As well as the notes in these instructions the operator is advised to comply with the generally applicable safety at work regulations and those relating to use of the public highway! •... - Page 7 • On all pivoting parts actuated by power assistance (e.g. hydraulics) exists danger of injury by bruising and crushing! • Before leaving the tractor lower the machine to the ground. Apply the parking brake, stop the engine and remove the ignition key! •...
-
Page 8: Warning Stickers
2 WARNING STICKERS 2.1 General Instructions The LEMKEN Labrador is equipped with all features to ensure safe operation. Where potential danger areas of the implement can not be fully safeguarded, warning stickers are fitted which draw attention to these. 2.2 Meaning of the stickers Familiarise with the meaning of the stickers. -
Page 9: Preparation Of Tractor
3 PREPARATION OF TRACTOR 3.1 Tyres Ensure that all tyres- especially the rear ones - are at identical pressures. 3.2 Lift rods Adjust lift rods (1) of the three point linkage to equal length by means of the adjustment device. Where there are alternative positions for the lift rods on the lower links (3), use the rearmost position, in order to unload the tractor hydraulics. -
Page 10: Attaching And Detaching The Plough
4 ATTACHING AND DETACHING THE PLOUGH 4.1 Attaching to the Tractor Set tractor hydraulics to 'Position − Control'. Attach lower links (3) to the drawbar (5) − and secure. Fit top link (6) to headstock and secure − by means of securing clip (2)! Raise implement by means of the −... -
Page 11: Adjustments
5 ADJUSTMENTS 5.1 Adjustment of the top link In order to guide the Labrador safely during work, the top link (in working position) must be nearly parallel to the ground. Therefore headstock provided with several holes. To reach sufficient ground clearance during transport, it can be required to fit the top... -
Page 12: Changing The Leg Distance
5.4 Changing the leg distance For the adaption to each tractor track the legs can be moved laterally on the frame. This will be done as follows: - Lift implement by means of the tractor hydraulics secure against unintentional lowering! - Loosen nuts (10) of the U-bolts (11)! - Displace brackets! It must be ensured that the leg brackets (12) will be... -
Page 13: Shearbolt Device
6 SHEARBOLT DEVICE Each leg is provided with a shearbolt device (13). This shearbolt device protects frame, leg and share against overload. When a shearbolt is broken the following must be done: Lift implement secure against unintentional lowering! Remove residuals of the shearbolts! Swing leg (14) backwards –... -
Page 14: Tyres
The maximum allowed transport speed is 25 miles per hour. On bad roads the speed must be reduced accordingly. 10 TECHNICAL DATA No. of Working Line distance Weight in tines depth in cm changeable from -> to 100 – 225 Labrador 160 50 – 112,5... -
Page 15: Notes
12 NOISE, AIRBORNE SOUND The noise level of the Labrador 160 does not exceed 70 dB (A) during work. 13 PRODUCT REGISTRATION / GUARANTEE We would like to point out that the guarantee period starts, only when the...
