Lutron Electronics HOMEWORKS seeTouch SKD-1B Installation Instructions

Installation Instructions
Please Read Before Installing
Overview
The Designer-style seeTouch Button Kits allow the
customization of Designer-style seeTouch Keypads.
Button Kits may be used to change the color and but-
ton configuration, and add engraving to clearly identify
each button's function.
Important Notes
Mounting: Ensure all controls are correctly wired and
mounted before installing button kits or wallplates.
Ensure controls are free from debris (e.g. plaster,
spackling compound) before installing button kits or
wallplates.
Wallplates: Lutron Claro
wallplates are recommended for best color match and
clean aesthetic appearance. Do not paint button kits
or wallplates.
Cleaning: To clean, wipe with a clean damp cloth.
DO NOT use any chemical cleaning solutions.
and Satin Colors
® TM
Designer-style seeTouch
SKD-1B, -2B, -3B, -3BRL, -4B, -4FS, -4S, -4SIR, -5B,
-5FS, -5BRL, -6B, -6BRL, -7B
SKD-1B SKD-2B
SKD-4B SKD-4FS
SKD-5B SKD-5FS
SKD-6BRL SKD-7B
Button Kits
TM
SKD-3B SKD-3BRL
SKD-4S SKD-4SIR
SKD-5BRL
SKD-6B
1
