Wired seeTouchR QS Wallstation: Advanced Programming Mode
Wired seeTouchR QS Wallstations contain an Advanced Programming Mode (APM) that allows installers to
customize wallstations that are part of QS stand-alone systems. This document serves as a supplement to the
seeTouchR QS Wallstations Installation Guide. Before using APM, it is important to have a good understanding
of the advanced features.
Table Of Contents
Wall Station Overview .................................................................................................................................3
Entering and Exiting Advanced Programming Mode (APM) ...................................................................4
Changing Wallstation Button Columns .....................................................................................................5
• Allows the user to change the number of buttons that are used on a wallstation.
Ex. A wallstation was shipped from the factory as a 7-button wallstation, but a 3-button button kit was
ordered.
• A llows the user to divide a wallstation into more than one column that can each have different column
types and be assigned to different loads, etc.
Ex. A 10 button wallstation can be modified to have two 5 button columns that each act as an
independent wallstation.
• A wallstation can be divided into no more than 4 columns.
• One button (1B) columns are allowed.
• Allows the user to enable or disable a button, its backlight LED or its status LED.
CCI Remapping and Scene Banking .........................................................................................................7
• Allows the user to change the button on the wallstation to which the two CCIs are mapped.
• F or Scene columns, also has the option of changing the recalled scenes of the column when the CCI is
closed versus when the CCI is open. This is known as "Scene Banking".
Ex. A Scene 1-3 column can become a Scene 4-6 column when CCI1 is closed, and back to a Scene
1-3 column when CCI1 is open.
Changing the Column Type ........................................................................................................................9
• A llows the user to change the column type of each column in the wallstation without requiring a
GrAFIk EyeR QS control unit or Energi Savr NodeT unit.
"Raise" and "Lower" Button Remapping ................................................................................................13
• Allows the user to change the column that a "raise" and "lower" button pair is associated with.
®
Application Note #428
Lutron Technical Support Center
1.800.523.9466
Revision A
April 2012
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lutron Electronics seeTouch QS
Summary of Contents for Lutron Electronics seeTouch QS
-
Page 1: Table Of Contents
Application Note #428 ® Revision A April 2012 Wired seeTouchR QS Wallstation: Advanced Programming Mode Wired seeTouchR QS Wallstations contain an Advanced Programming Mode (APM) that allows installers to customize wallstations that are part of QS stand-alone systems. This document serves as a supplement to the seeTouchR QS Wallstations Installation Guide. Before using APM, it is important to have a good understanding of the advanced features. Table Of Contents Wall Station Overview ..........................3 Entering and Exiting Advanced Programming Mode (APM) ..............4 Changing Wallstation Button Columns .....................5 • Allows the user to change the number of buttons that are used on a wallstation. - Page 2 Application Note #428 Table Of Contents (continued) IR Association, and Remote Pass-Through/Button-Mapping Mode Toggle ........14 • Allows the user to associate different types of Ir remotes to different columns on the wallstation. • If in pass-through mode, the Ir remote activates its default actions. Ex. A Scene Ir remote with 5 buttons would activate Scenes 1-4 and OFF. Ex. A Shade Ir remote with 5 buttons would activate Shade Open, Preset1, Preset2, Preset3, and Shade Close. • Button-mapping mode allows the buttons on the Ir remote to map to the buttons on the wallstation. Ex. A ny type of Ir remote with 5 buttons pointed at a Scene 7-10 & OFF wallstation would recall Scenes 7-10 & OFF when the buttons are pushed. Ex. A ny type of Ir remote with 5 buttons pointed at a 5 button Zone Toggle wallstation would perform the same actions that the wallstation buttons perform when the buttons on the Ir remote are pressed. Programming Lockout ..........................15 • P revents accidental reprogramming when wallstations are mounted in public spaces by locking the wallstation out of all programming modes (including Programming Mode, Shade Association Mode, Shade Preset Adjust Mode, Shade Limit Set Mode, APM, Advanced Configuration Mode (ACM), etc.). Also prevents any programming from being changed in Normal Mode when individual buttons are held.
-
Page 3: A Wall Station Overview
Application Note #428 Wallstation Overview Domestic: International: North American style wallstation European style wallstation Note: S everal advanced features require the use of a “raise” or “lower” button and/or a button that the user may not be able to access on a fully assembled wallstation. In this case, the user should: 1. Snap off the faceplate of the wallstation. 2. remove the screws and the faceplate adapter (if present). 3. Gently pry off the button kit This should allow access to all buttons, status LEDs, and backlight LEDs. North American style wallbox Mounting 1. S nap off Screws (2) faceplate Adapter Screws (2) Wallbox 2. r emove screws and Button Control... -
Page 4: B Entering And Exiting Advanced Programming Mode (Apm)
Application Note #428 Entering and Exiting Advanced Programming Mode (APM) To Enter APM (from Normal Mode): Simultaneously hold the top and bottom button of the column for 30 seconds (if it is a single button [1B] column, hold the single button for 60 seconds). Once the hold time elapses, the status LEDs in that column will all blink rapidly to indicate that the column is in APM and all backlight LEDs of that column will be solid on. You may now release the held buttons. To Exit APM: Simultaneously hold the top and bottom button of the column for 3 seconds (if it is a 1B column, hold the single button for 10 seconds). Once the hold time elapses, all status LEDs and backlight LEDs will return to their appropriate settings in Normal Mode. Note: APM will timeout after 10 minutes and will return to Normal Mode. North American style wallstation Note: For wallstations with two sets of buttons, you will program each set as if they were separate wallstations. European style wallstation Group 1 Open Group 2 Preset... -
Page 5: C Changing Wallstation Button Columns
Application Note #428 Changing Wallstation Button Columns Note: S ome wallstation models ship from Lutron with certain buttons disabled (i.e. European style wallstations with spaces between the buttons). If buttons are disabled on a wallstation, they must first be enabled before they can be added to new columns. Please see section D “Enabling or disabling a button, backlight LED, and/or status LED” on page 6. Functionality: To change the number of buttons in a column: 1. H old down the top and bottom buttons of the new column you wish to create for 30 seconds. (If creating a one button column, hold down the appropriate button for 60 seconds) 2. O nce the hold time elapses, the status LEDs of the newly created column will blink simultaneously. This puts the newly created column into APM. 3. T o exit APM, hold the top and bottom buttons of the new column for 3 seconds (if it is a 1B column, hold the single button for 10 seconds). 4. Once the hold time elapses, the wallstation will return to Normal Mode. To create more than one column on a wallstation: • U p to four separate and independently functioning columns on a wallstation can be created by using the same steps above but with unused buttons. -
Page 6: D Enabling Or Disabling A Button, Backlight Led, And/Or Status Led
Application Note #428 Enabling or Disabling a Button, Backlight LED, and/or Status LED 1. Enter APM. 2. H old any button for 6 seconds. Once the hold time elapses, all backlight LEDs will turn off and all status LEDs will be periodically blipping (pulsing on for a very short duration) together. This is Advanced Configuration Mode (ACM). Functionality: Upon entering ACM, all status LEDs will blip in unison to indicate that the wallstation is in ACM. This initial blip of all status LEDs is the ACM Default Mode where each button is unaffected until pressed. Once a button is pressed, it will acquire the functions shown in the table below and will not return to the unaffected Default Mode until you enter ACM again. Each press of a button will cycle that button through the following possible states: Feedback in Advanced Resulting State in Normal Mode Configuration Mode Backlight LED Status LED Backlight State Button Status LED... -
Page 7: Ecci Remapping And Scene Banking
Application Note #428 Contact Closure Input (CCI) Assignment and Scene Banking 1. Enter APM. 2. S imultaneously press and hold any button of the column in APM along with any “raise” button for 3 seconds. 3. O nce the hold time elapses, all backlight LEDs in that column will go off, the status LED of the button to which the CCI is currently programmed will remain solid ON, and the remaining status LEDs of that column will flash once every 8 seconds. North American style wallstation European style wallstation I f the button to which the CCI is currently programed is a raise or lower button, it will be indicated by the following: Currently Programmed Button LED Indication North American Style European Style Wallstations Wallstations... - Page 8 Application Note #428 CCI Assignment and Scene Banking (continued) Functionality: Once in the CCI programming mode, the following options are available: 1. Make the button to which a CCI action is currently programmed do “nothing”: • H old the currently programmed button for 3 seconds to make the selected CCI action be “nothing”. • The wallstation will automatically move on to programming the next CCI action. 2. Change the button to which the CCI action is currently programmed: • H old a button for 3 seconds to make that button the currently programmed button for the selected CCI action. • The wallstation will automatically move on to programming the next CCI action. 3. Not changing the settings of the selected CCI action: • Tap any button to move on to programming the next CCI action. 4. Assign a scene bank to the selected CCI action: • S imultaneously hold the top and bottom buttons of a scene column for 3 seconds to make that scene column “bank” when this CCI action happens. Ex. A Scene 1-3 column can become a Scene 4-6 column when CCI1 is closed, and back to a Scene 1-3 column when CCI1 is open.
-
Page 9: F Changing The Column Type
Application Note #428 Changing the Column Type Columns A “column” in a seeTouchR QS multi-column wallstation is defined as a group of (typically adjacent) buttons that all perform a similar logic feature. Column Type The “type” of a column determines the logic of how that column operates. To change your wallstation’s column types using Column Type Change Mode: 1. Enter APM. 2. S imultaneously press and hold any button of the column in APM along with any “Lower” button for 3 seconds. North American style wallstation European style wallstation 3. O nce the hold time elapses, all backlights of that column will remain solid on and the status LEDs will blip in the following pattern (each column type is listed below and explained in subsequent pages): • 1 blip every 8 seconds = “Scene with OFF” column type (not an option for 1B column) • 2 blips every 8 seconds = “Scene” column type • 3 blips every 8 seconds = “Zone Toggle” column type • 4 blips every 8 seconds = “Partition” column type • 5 blips every 8 seconds = “Shade” column type (not an option for 1B column) • 6 blips every 8 seconds = “Shade Toggle” column type... - Page 10 Application Note #428 Changing the Column Type (continued) North American style wallstation European style wallstation Backlight Backlight Backlight Status LEDs LEDs LEDs Status Buttons LEDs Buttons Buttons Lower Raise Left right Bottom Bottom Lower Raise Lower Raise Left right Raise Lower Column Type The following is a listing of all the possible column types for a seeTouchR QS wallstation:...
- Page 11 Application Note #428 Changing the Column Type (continued) Two-Button (2B) Special Functions 2B Partition Type: Same as normal Partition type except that a top button press opens the partition and a bottom button press closes the partition. 2B Fine Tune Type: The buttons of the wallstation in this mode function as raise and lower buttons for the assigned zones. Tapping the buttons will raise/lower the level of all assigned zones by one percent. Holding the buttons will smoothly raise to high end or smoothly lower to low end. 2B Sequence Type: The sequence column type causes all the assigned scene controllers to continuously cycle through their scenes (either Scenes 1-4 or Scenes 5-16) using the programmed fade times for each scene. This is useful for spaces that desire dynamic lighting such as decorative lighting or displays in retail stores. 2B Panic Type: Panic type causes all the assigned scene controllers to go to Scene 16, and temporarily disables all buttons presses and ignores scene or zone level changes. 2B Timeclock: Timeclock type allows the user to enable or disable the Timeclock on a Grafik EyeR QS control unit. Pressing the top button of the 2B column enables the Timeclock and pressing the bottom button disables the Timeclock. Shade Type: In shade type, the top button of a column becomes the Open button and the bottom button becomes the Close button for the associated LutronR SivoiaR QS shades/draperies or third party AC shades. If the wallstation has more than two buttons, the middle buttons between Open and Close serve as programmable preset buttons for LutronR SivoiaR QS shades/draperies, or “stop” buttons for...
- Page 12 Application Note #428 Changing the Column Type (continued) Functionality: Once in the Column Type Change Mode described on previous page, the user has the following options: 1. Tapping any button will continue scrolling to the next valid column type option. 2. I f the wallstation type is Scene with OFF, Scene, or 2B Special Functions, the user may choose a subtype as follows: • Press and hold any button of that column for 3 seconds. • O nce hold time elapses, all status LEDs will go to OFF indicating that the user entered the sub mode. Then, the status LEDs will blip in the following pattern: Column Type Programming Mode Status LED Indication Sub Mode Options Selection 1 blip every 8 seconds Starts with Scene 1 2 blips every 8 seconds Starts with Scene 2 Scene with OFF 3 blips every 8 seconds Starts with Scene 3 …Continues sequentially…...
-
Page 13: G "Raise" And "Lower" Button Remapping
Application Note #428 Changing the Column Type (continued) Note: I f one column on a dual column wallstation enters Column Type Change Mode, all other columns on that wallstation will also enter Column Type Change Mode to allow the user to more easily change the column type of more than one column without having to exit and re-enter APM. Exit APM by simultaneously pressing and holding the top and bottom buttons of the column for 3 seconds (if it is a 1B column, hold the single button for 10 seconds). Once hold time elapses, all status LEDs and backlight LEDs will return to their appropriate settings in Normal Mode. “Raise” and “Lower” Button Remapping 1. E nter APM. 2. S imultaneously press and hold the “raise” and “lower” buttons that you wish to assign to the column in APM for 3 seconds. 3. O nce hold time elapses, status LEDs of that column will flash slowly for 3 additional seconds, indicating that the “raise” and “lower” buttons have been assigned to that column, then return to APM. North American style wallstation European style wallstation 4. E xit APM by simultaneously pressing and holding the top and bottom buttons of the column for 3 seconds (if it is a 1B column, hold the single button for 10 seconds). Once hold time elapses, all... -
Page 14: Hir Association, And Remote Pass-Through/Button-Mapping Mode Toggle
Application Note #428 Assigning an IR Remote 1. Enter APM 2. Point an Ir remote toward the wallstation in APM 2. Hold the raise button for 3 seconds 4. S tatus LEDs on the wallstation will then flash slowly for 3 seconds to indicate that the Ir remote has been successfully assigned 5. Wallstation will automatically return to APM 6. E xit APM by simultaneously pressing and holding the top and bottom buttons of the column for 3 seconds (if it is a 1B column, hold the single button for 10 seconds). Once hold time elapses, all status LEDs and backlight LEDs will return to their appropriate settings in Normal Mode. IR Remote Pass-through and Button-mapping Modes 1. Enter APM. Functionality: Note: The default mode for any Ir remote is pass-through mode. Once in APM, the user has the following options: A. E nable button-mapping mode: • Press and hold the favorite button of the Ir remote for 3 seconds • O nce hold time elapses, status LEDs of that column will flash slowly for 3 additional seconds, indicating that the column has switched to button-mapping mode, then return to APM. -
Page 15: I Programming Lockout
Application Note #428 Programming lockout Functionality: To enable programming lockout mode: 1. Simultaneously press and hold “raise”, “Lower”, and any active button for 30 seconds. North American style wallstation European style wallstation 2. O nce the hold time elapses, all status LEDs will light in a sequential flash of status LEDs from the bottom to top of the wallstation, indicating that the user has locked out of programming mode. (This sequence of flashes is known as a reverse waterfall). 3. T hen, all status LEDs and backlight LEDs will return to their appropriate settings in Normal Mode. Note: Each time the user attempts to enter a programming mode after locking out of programming mode, all status LEDs will light in a sequential flash of status LEDs from the bottom to top of the wallstation indicating that all programming is locked out. To disable programming lockout mode: 1. S imultaneously press and hold “raise”, “lower”, and any button of the column in APM for the 30 seconds. -
Page 16: (Continued On Next Page
Application Note #428 Information Display Sequence Functionality: 1. T ap the same button in a column 20 times consecutively. This will cause status LEDs to begin flashing. 2. T he first 3 times the status LEDs flash consecutively, they are showing the code revision of the wallstation (with the format x.yz). Note: A number “0” is displayed not by zero flashes, but instead by a quick sequential flash of status LEDs from the bottom to top of the column (for 1 second). • O nce the user has tapped the same button of a column 20 consecutive times, the column will enter information display mode and the status LEDs will immediately begin flashing consecutively “x” amount of times. • Count the “x” number of flashes. • A short pause will occur, then the status LEDs will flash consecutively for the second time (6 seconds after entering information display mode), “y” amount of times. • Count the “y” number of flashes. • A short pause will occur, then the status LEDs will flash consecutively for the third time (12 seconds after entering information display mode) “z” amount of times. • Count the “z” number of flashes. -
Page 17: K Shade Toggle Type Programming
Application Note #428 Information Display Sequence (continued) 4. T he next time the status LEDs flash consecutively, they are showing the column type of column. • A short pause will occur, then the status LEDs will flash consecutively for the fifth time (24 seconds after entering information display mode), for “m” amount of times. • Count the “m” number of flashes. • The “m” amount of consecutive flashes represents the following: “m” Column Type Scene with OFF Scene Zone Toggle Partition Shade Shade Toggle Shade Group 2B Special Functions Fine Tune • O nce the user has reached this step, the wallstation has given the user the number representing the type of the selected column. 5. O nce the column has sequenced through the code revision, hardware type, and column type, all status LEDs and backlight LEDs will return to their appropriate settings in Normal Mode. -
Page 18: Restoring Factory Defaults
